LT6411 650MHz Different ADC Driver
Analog Devices Inc.DC1108A - Demo Board for:LT6411 - 650MHz Differential ADC Driver/Dual Selectable Gain Amplifier
LTC2755: 16-bit, Quad, SoftSpan, 1LSB INL IOUT DAC, requires DC590
Analog Devices Inc.DC1112A: Demo Board for LTC2755-16 Quad Current Output 16-Bit SoftSpan DACs with Parallel I/O
LTC6102 Current Sense Demo Board
Analog Devices Inc.DC1113A: Demo Board for the LTC6102 Precision Zero Drift Current Sense Amplifier
LTC3850EUF Demo Board | 6.5V ≤ VIN ≤ 14V, VOUT = 3.3V @ 5A & 2.5V @ 5A
Analog Devices Inc.Demonstration circuit 1126 is a high density dual output (3.3V/5A and 2.5V/5A) step down converter featuring the LTC3850EUF. The input voltage range is 6.5V to 14V. For applications that have a 5V +/- 0.5V input, the board has an optional resistor to tie the INTVCC pin to the VIN pin.
An optional DCR sense circuit allows the converter to use the inductors DCR as the sense element instead of the on-board sense resistors to save cost and board space and to improve efficiency.
LTC3419EDD Demo Board | 2.25MHz, 2.5V ≤ VIN ≤ 5.5V, VOUT1 = 1.2V/1.5V/1.8V @ 600mA, VOUT2 = 2.5V/3.3V @ 600mA
Analog Devices Inc.Demonstration circuit 1128A is a dual channel synchronous, 2.25MHz Step-Down DC/DC Regulator featuring the LTC3419. The DC1128A has an input voltage range of 2.5V to 5.5V. Both jumper selectable 3.3V/2.5V and 1.2V/1.5V/1.8V outputs are capable of delivering up to 600mA of output current. The device also features independent internal soft-start for each channel.
LTC2242CUP-12 | CMOS OUT, VCC = 2.5V, 250Msps, 12-Bit, 10MHz < AIN < 250MHz, Need DC890
Analog Devices Inc.DC1133A-A: Demo Board for the LTC2242-12 12-Bit, 250Msps ADC.
LTC6403-1 Demo Circuit
Analog Devices Inc.DC1147A-E: Demo Board for the LTC6403-1 200MHz, Low Noise, Low Power Fully Differential Input/Output Amplifier/Driver
LTC3565EDD Demo Board | 1.25A, 4MHz, Synchronous Step-Down DC/DC Converter
Analog Devices Inc.DC1159A: Demo Board for LTC3565 1.25A, 4MHz, Synchronous Step-Down DC/DC Converter
LTC3725EMSE/LTC3726EGN 1/8 Brick | 9V < VIN < 36V, VOUT: 15V/3A
Analog Devices Inc.DC1174A-C: Demo Board for the LTC3725 Single-Switch Forward Controller and Gate Driver and LTC3726 Secondary-Side Synchronous Forward Controller
LTC3522EUD Demo Board | Buck-Boost Plus Buck, 2.4V ≤ VIN ≤ 4.3V, VOUT1 = 3.3V @ 300mA, VOUT2 = 1.8V @ 200mA
Analog Devices Inc.Demonstration circuit DC1177 is a micropower dual Buck-Boost/Buck synchronous converter based on the LTC3522 monolithic regulator. The DC1177 has an input voltage range of 2.4V to 4.2V and outputs 3.3V @ 300mA and 1.8V @ 200mA.
LTC2361 Demo Board | 12-Bit, 250ksps SAR ADC (Requires DC590B for DC Apps, DC890B for AC Apps)
Analog Devices Inc.DC1190A-D: Demo Board for the LTC2361 250ksps, 12-Bit Serial ADCs in TSOT-23
LTC3529EDCB Demoboard | 1.5A, 2.35MHz Step-Up DC/DC Converter in 2mm × 3mm DFN
Analog Devices Inc.DC1226A: Demo Board for the LTC3529 1.5A, 1.5MHz Step-Up DC/DC Converter in 2mm × 3mm DFN
LTC3850EGN Demo Board | 6.5V < VIN < 24V, VOUT1 = 3.3V/5A, VOUT2 = 2.5V/5A, with DCR Current Sense
Analog Devices Inc.Demonstration circuit 1231A is a Dual Output, Dual Phase 5A Synchronous Buck Converter featuring the LTC3850EGN. The entire circuit, including the bulk output capacitors, fit within a 1.04 × 0.94 area on all layers. The package style for the LTC3850EGN is a 28-lead narrow plastic SSOP. The main features of the board include rail tracking, an internal 5V linear regulator for bias, RUN pins for each output and a PGOOD signal and a Mode selector that allow the converter to run in CCM, pulse skip or Burst Mode operation. Synchronization to an external clock is also possible through some minor component changes. Two versions of the board are available. DC-1231A-A has an on-board sense resistor for current feedback, while the DC1231A-B is configured with a DCR sense circuit that allows the converter to use the inductors DCR as the sense element instead of the on-board sense resistors to save cost and board space and improves efficiency.
DC1233A-C
Analog Devices Inc.The LT5579 mixer is a high performance upconverting mixer optimized for frequencies in the 1.5GHz to 3.8GHz range. The single-ended LO input and RF output ports simplify board layout and reduce system cost. The mixer needs only ?1dBm of LO power and the balanced design results in low LO signal leakage to the RF output. At 2.6GHz operation, the LT5579 provides high conversion gain of 1.3dB, high OIP3 of +26dBm and a low noise floor of ?157.5dBm/Hz at a ?5dBm RF output signal level. The LT5579 offers a high performance alternative to passive mixers. Unlike passive mixers, which have conversion loss and require high LO drive levels, the LT5579 delivers conversion gain at significantly lower LO input levels and is less sensitive to LO power level variations. The lower LO drive level requirements, combined with the excellent LO leakage performance, translate into lower LO signal contamination of the output signal.Applications GSM/EDGE, W-CDMA, UMTS, LTE and TD-SCDMA Basestations 2.6GHz and 3.5GHz WiMAX Basestations 2.4GHz ISM Band Transmitters High Performance Transmitters
LTC6601-1 | Low Noise Configurable Broadband Filter Demo Board
Analog Devices Inc.DC1251A-A: Demo Board for LTC6601-1 - Low Noise, 0.5% Tolerance, 5MHz to 28MHz, Pin Configurable Filter/ADC Driver
LT3853EUJ Demo Board | Triple, PolyPhase, 6.5V ≤ VIN ≤ 24V, VOUT1 = 2.5V/5A, VOUT2 = 1.8V/5A, VOUT3 = 3.3V/5A
Analog Devices Inc.Demonstration circuit 1254A is a polyphase 3-output step-down supply with tracking featuring the LTC3853EUJ. The input voltage range is 6.5V to 24V. For applications with narrow, 5V ±0.5V input range, the board has an optional resistor to tie the INTVCC pin to the VIN pin. The demo board provides three 5A outputs, with output voltages of 2.5V, 1.8V and 3.3V.
The main features of the board include rail tracking, an internal 5V linear regulator for bias, RUN pins for each output, two PGOOD signals and a Mode selector that allow the converter to run in CCM, pulse skip or Burst Mode operation. Synchronization to an external clock is also possible through some minor component changes.
LTC6416 + LTC2208 Combo board (Requires DC890 & LVDS_XFMR)
Analog Devices Inc.DC1257B: Demo Board for the LTC6416 2GHz Low Noise Differential 16-Bit ADC Buffer
LTC4110EUHF Demo Board | Multi-Chemistry Flyback Battery Backup System Charger/Manager
Analog Devices Inc.Demonstration circuit DC1259A is a single-battery battery- backup controller featuring the LTC4110. The LTC4110 controller provides all the features and functions to offer a complete standalone battery-backup system. The LTC4110 is a multi-chemistry flyback battery charger and discharger that is scalable with other LTC4110s to allow a larger battery array for increased capacity and/or redundancy.
The demo board requires a 12V input voltage and is initially configured to charge a 3 Li-Ion Smart Battery at 1A; the charge voltage is 12.6V. However, the Demo board can be easily configured for a standard battery as well. A SMBus interface is offered to allow host communications in control and status and/or support Smart Batteries. However, no host is required to use the LTC4110.
LTM8022 Demo Board | 4.5V ≤ VIN ≤ 36V, 3.3VOUT @ 1A DC/DC µModule Regulator
Analog Devices Inc.Demonstration circuit 1261A features the LTM8022 step-down μModule® regulator delivering a 3.3V/1A output from a 4.5V to 36V input supply. As a step-down converter, the LTM8022 requires a minimum amount of headroom to keep the output in regulation. Current sharing with another LTM8022 is enabled by tying the VIN, VOUT and SHARE pins together to support higher output loads.
LTM8040EV Demo Board | µModule Buck LED Driver, 4V ≤ VIN ≤ 36V, VLED up to 13V @ 1A
