TPS61046 28V Boost Converter in WCSP Package Evaluation Module
Texas InstrumentsTPS61046 28V Boost Converter in WCSP Package Evaluation Module
The LM48511 Integrates a Boost Converter with a High Efficiency
Texas InstrumentsThe LM48511 Integrates a Boost Converter with a High Efficiency
Evaluation Module for TPS54527 Synchronous Step-Down Converter with D-CAP2 Mode
Texas InstrumentsEvaluation Module for TPS54527 Synchronous Step-Down Converter with D-CAP2 Mode
TLV62566EVM-232 1.5A High Efficiency Step Down (Buck) Converter Evaluation Module
Texas InstrumentsTLV62566EVM-232 1.5A High Efficiency Step Down (Buck) Converter Evaluation Module
TPS61040 Boost Converter Evaluation Module for LCD Supply; 18V/20mA
Texas InstrumentsTPS61040 Boost Converter Evaluation Module for LCD Supply; 18V/20mA
LMH2121EVAL Power Detector RF Envelope Detector Evaluation Board/Module
Texas InstrumentsLMH2121EVAL Power Detector RF Envelope Detector Evaluation Board/Module
Ultra Low Noise; 150mA Linear Regulator for RF Analog Circuits Requires No Bypass Capacitor
Texas InstrumentsUltra Low Noise; 150mA Linear Regulator for RF Analog Circuits Requires No Bypass Capacitor
DC2002A
Analog Devices Inc.The LTC3774 is a dual PolyPhase? current mode synchronous step-down switching regulator controller that drives power blocks, DRMOS or external gate drivers and power MOSFETs. It offers an LTC-proprietary technique that enhances the signal-to-noise ratio of the current sense signal, allowing the use of inductors with very low DC winding resistances as the current sense element for maximum efficiency and reduced jitter.The maximum current sense voltage is programmable from 10mV to 30mV. High speed, low offset remote sense differential amplifiers and a precise 0.6V reference provide accurate output voltages between 0.6V and 3.5V from a wide 4.5V to 38V input supply range. Soft recovery from output shorts or overcurrent minimizes output overshoot. Burst Mode? operation, continuous and pulse-skipping modes are supported. The constant operating frequency can be synchronized to an external clock or linearly programmed from 200kHz to 1.2MHz. Up to six LTC3774 controllers can be paralleled for 1-, 2-, 3-, 4-, 6-, 8- or 12-phase operation.The LTC3774 is available in a 36-lead (5mm ? 6mm) QFN package.Applications Computer Systems Telecom and Datacom Systems Industrial Equipment DC Power Distribution Systems
DC2815A
Analog Devices Inc.The LT3120 is a high efficiency 26V monolithic buck-boost converter. Extensive feature integration and very low resistance internal power switches minimize the total solution footprint for even the most demanding applications. A proprietary 4-switch PWM architecture provides seamless low noise operation from input voltages above, equal to, or below the output voltage.External frequency programming as well as synchronization using an internal PLL enable operation over a wide switching frequency range of 400kHz to 2MHz. The wide 2.5V to 26V input range is well suited for operation from unregulated power sources including battery stacks and backup capacitors. After start-up, operation is possible with input voltages as low as 500mV.Other features include, output short-circuit protection, thermal overload protection, less than 3?A shutdown current, power good indicator, Burst Mode operation, and maximum power point control.The LT3120 is offered in thermally enhanced 28-lead 4mm ? 5mm LQFN package.APPLICATIONS RF Power Supply USB Power Delivery System Backup Power Supply 1-Cell to 5-Cell Lithium Battery Powered Products Wide Input Range Power Supply Lead Acid to 12V Regulator
DC2895A
Analog Devices Inc.The LT7101 is a high efficiency, monolithic synchronous step-down DC/DC converter utilizing a constant frequency, average current mode control architecture. It operates from an input voltage range of 4.4V to 105V and provides an adjustable regulated output voltage from 1V to VIN while delivering up to 1A of output current.?The LT7101 features high frequency operation and a low minimum on-time that reduce inductor size and enable constant-frequency operation even at very high stepdown ratios. In addition, the LT7101 achieves the lowest possible dropout voltage with 100% maximum duty cycle operation. During light load operation, converter efficiency and output ripple can be optimized by selecting Burst Mode, pulse-skipping or forced continuous operation.The LT7101 includes accurate, high speed average current programming and monitoring without the need for an external sense resistor. Additional features include a bypass LDO to maximize efficiency, fixed or adjustable output voltage and loop compensation, and a wide array of protection features to enhance reliability.?Applications Battery Chargers and CC/CV Supplies Automotive and Military Systems Industrial, Avionics and Heavy Equipment Medical Instruments and Telecommunication Systems
KSZ9031MNX-EVAL
Microchip Technology Inc.Ethernet Development Tools 1-Port Gigabit Ethernet PHY - Evaluation Board
KSZ8765CLX-EVAL
Microchip Technology Inc.Ethernet Development Tools 5-Port 10/100 with RGMII/GMII + Fiber - Evaluation Board
KSZ8795CLXD-EVAL
Microchip Technology Inc.Ethernet Development Tools 5-Port 10/100 with RGMII/GMII - Evaluation Board
KSZ8852HLE-EVAL
Microchip Technology Inc.Ethernet Development Tools Eval-2-Port Ethernet Controller
