BQ24316EVM-251 Evaluation Module
Texas InstrumentsThe bq2431x evaluation module is a complete charger module for evaluating a charger front-end protection and charger solution using the bq2431x and bq24080 devices. It is designed to deliver up to 700 mA of charge current to Li-ion or Li-polymer applications. The charger front-end protection current is designed to 1000 mA. The bq2431x protects the charging system against three types of failures: input overvoltage when the AC adapter fails to regulate its voltage; load overcurrent when failures such as a short circuit occur in the charging system; and battery overcharge.
Features:
Evaluation module for bq2431x DSJ
Evaluation module for bq24080 charger IC
Evaluation module for bq2431x and bq24080 chipset solution
Input operating range for bq2431x 4.5 V - 26 V
Input operating range for bq24080 4.5 V - 6.5 V
Input overvoltage protection
Input overcurrent protection
Battery overvoltage protection
LED indication for status signals
Test points for key signals available for testing purpose. Easy probe hook-up
Jumpers available. Easy to change connections
