EVQ5073-G-00A
Monolithic Power Systems (MPS)5.5V, 2A, Configurable Current, Low RDS(ON) Load Switch Evaluation Board, AEC-Q100 Qualified
106137-HMC445LP4
Analog Devices Inc.The HMC445LP4(E) is an active miniature x16 frequency multiplier utilizing InGaP GaAs HBT technology in 4x4 mm leadless surface mount package. Power output is +7 dBm typical from a 5V supply voltage and varies little vs. input power, temperature and supply voltage. Suppression of undesired fundamental and sub-harmonics is >25 dBc typical with respect to output signal level. The low additive SSB phase noise of -130 dBc/Hz at 100 kHz offset helps the user maintain good system noise performance. The HMC445LP4(E) is ideal for use in LO multiplier chains allowing reduced parts count vs. traditional approaches.APPLICATIONS Fiber Optic Point-to-Point Radios Military Radar
106789-HMC311LP3
Analog Devices Inc.The HMC311LP3(E) is a GaAs InGaP Heterojunction Bipolar Transistor (HBT) Gain Block MMIC SMT DC to 6 GHz amplifiers. This 3 ? 3mm QFN packaged amplifier can be used as either a cascadable 50 ? gain stage or to drive the LO of HMC mixers with up to +17 dBm output power. The HMC311LP3(E) offers 14.5 dB of gain and an output IP3 of +32 dBm while requiring only 56 mA from a +5V supply. The Darlington feedback pair used results in reduced sensitivity to normal process variations and yields excellent gain stability over temperature while requiring a minimal number of external bias components.Applications Cellular / PCS / 3G Fixed Wireless & WLAN CATV & Cable Modem Microwave Radio
