DC846A
Analog Devices Inc.The LTC2446/LTC2447 4-terminal switching enables multiplexed ratiometric measurements. Four sets of selectable differential inputs coupled with four sets of differential reference inputs allow multiple RTDs, bridges and other sensors to be digitized by a single converter. A fifth differential reference input can be selected for any input channel not requiring ratiometric measurements (thermocouples, voltages, current sense, etc.). The flexible input multiplexer allows single-ended or differential inputs coupled with a slaved reference input or a universal reference input.A proprietary delta-sigma architecture results in absolute accuracy (offset, full-scale, linearity) of 15ppm, noise as low as 200nVRMS and speeds as high as 8kHz. Through a simple 4-wire interface, ten speed/resolution combinations can be selected. The first conversion following a speed, resolution, channel change or reference change is valid since there is no settling time between conversions, enabling scan rates of up to 4kHz. Additionally, a 2x mode can be selected for any speed-enabling output rates up to 8kHz with one cycle of latency.Protected by U.S. Patents, including 6140950, 6169506, 6208279, 6411242, 6639526Applications Flow Weight Scales Pressure Direct Temperature Measurement Gas Chromatography
LTC3783 Demo Board | Boost LED Driver Controller, 3V ≤ VIN ≤ 14.4V, VLED up to 25V @ 360mA
Analog Devices Inc.Demonstration circuit 850A is a Boost LED Driver featuring the LTC3783 a boost/SEPIC/flyback LED driver controller. The demo board requires a 3V to 14.4V input and provides 360mA LED current at up to 25V. It incorporates an output overvoltage protection feature to limit output voltage to less than 27V if the LED string is inadvertently disconnected. The LT3783 features 1000:1 PWM dimming for brightness control and analog dimming control.
DC851A-C
Analog Devices Inc.The LTC2298/LTC2297/LTC2296 are 14-bit 65Msps/40Msps/25Msps, low power dual 3V A/D converters designed for digitizing high frequency, wide dynamic range signals. The LTC2298/LTC2297/LTC2296 are perfect for demanding imaging and communications applications with AC performance that includes 74.3dB SNR and 90dB SFDR for signals at the Nyquist frequency.DC specs include ?1.2LSB INL (typ), ?0.5LSB DNL (typ) and no missing codes over temperature. The transition noise is a low 1LSBRMS.A single 3V supply allows low power operation. A separate output supply allows the outputs to drive 0.5V to 3.6V logic. An optional multiplexer allows both channels to share a digital output bus.A single-ended CLK input controls converter operation. An optional clock duty cycle stabilizer allows high performance at full speed for a wide range of clock duty cycles.Applications Wireless and Wired Broadband Communication Imaging Systems Spectral Analysis Portable Instrumentation
DA728X-EVAL-KIT
Renesas Electronics CorporationEvaluation Kit, DA7280x, Haptic Driver, Power Management - Motor Control
EVALST-ISOSD61L
STMicroelectronicsEvaluation Board, ISOSD61L, 16bit, Isolated Sigma-Delta Converter
PTN38003A-EVM
NXP Semiconductors N.V.Evaluation Board, PTN38003A, USB Type-C PD Controller, Interface
RDGD31603PHSEVM
NXP Semiconductors N.V.Reference Design Board, GD3160, 3-Phase EV Motor Control, IGBT/SiC Gate Driver
STEVAL-CCA044V1
STMicroelectronics160 W + 160 W dual BTL class-D audio amplifier demo board based on the TDA7498E
EVALCO25VSENSOR2GOTOBO1
Infineon Technologies AG3.3 V ?3% PAS CO2 - Carbon Dioxide (CO2) Sensor Evaluation Board
