The ADP1050 is an advanced digital controller with a PMBus? interface targeting high density, high efficiency dc-to-dc power conversion. This controller implements voltage mode control with high speed, input voltage feedforward operation for enhanced transient and noise performance. The ADP1050 has four programmable pulse-width modulation (PWM) outputs capable of controlling most high efficiency power supply topologies, with the added control of synchronous rectification (SR).The ADP1050 implements several features to enable a robust system of parallel and redundant operation for customers who require high availability. The device provides synchronization, prebias startup, and conditional overvoltage techniques to identify and safely shut down an erroneous power supply in parallel operation mode.The ADP1050 is based on flexible state machine architecture and is programmed using an intuitive graphical user interface (GUI). The easy to use GUI reduces design cycle time and results in a robust, hardware coded system loaded into the built-in EEPROM. The small size (4 mm ? 4 mm) of the LFCSP package makes the ADP1050 ideal for ultracompact, isolated dc-to-dc power module or embedded power designs.Applications High density, isolated dc-to-dc power supplies Intermediate bus converters High availability parallel power systems Server, storage, industrial, networking, and communications infrastructure

The ADP1051 is an advanced digital controller with a PMBus? interface targeting high density, high efficiency dc-to-dc power conversion. This controller implements voltage mode control with high speed, input line feedforward for enhanced transient and improved noise performance. The ADP1051 has six programmable pulse-width modulation (PWM) outputs capable of controlling most high efficiency power supply topologies, with added control of synchronous rectification (SR). The device includes adaptive dead time compensation to improve efficiency over the load range, and programmable light load mode operation, combined with low power consumption, to reduce system standby power losses.The ADP1051 implements several features to enable a robust system of parallel and redundant operation for customers that require high availability or parallel connection. The device provides synchronization, reverse current protection, pre-bias startup, accurate current sharing between power supplies, and conditional overvoltage techniques to identify and safely shut down an erroneous power supply in parallel operation mode.The ADP1051 implements several features to enable a robust system of parallel and redundant operation for customers that require high availability or parallel connection. The device provides synchronization, reverse current protection, pre-bias startup, accurate current sharing between power supplies, and conditional overvoltage techniques to identify and safely shut down an erroneous power supply in parallel operation mode.APPLICATIONS High density, isolated DC/DC power supplies Intermediate bus converters High availability parallel power systems Server, storage, industrial, networking, and communications infrastructure

The ADP1052 is an advanced digital controller with a PMBus? interface targeting high density, high efficiency, dc-to-dc power conversion. This controller implements voltage mode control with high speed, input line feedforward for enhanced transient and improved noise performance. The ADP1052 has six programmable pulse-width modulation (PWM) outputs capable of controlling most high efficiency power supply topologies, with added control of synchronous rectification (SR). The device includes adaptive dead time compensation to improve efficiency over the load range, and programmable light load mode operation, combined with low power consumption, to reduce system standby power losses.The ADP1052 implements several features to enable a robust system of parallel and redundant operation for customers that require high availability or parallel connection. The device provides synchronization, reverse current protection, prebias startup, accurate current sharing between power supplies, and conditional overvoltage techniques to identify and safely shut down an erroneous power supply in parallel operation mode.The ADP1052 is based on flexible state machine architecture and is programmed using an intuitive GUI. The easy to use interface reduces design cycle time and results in a robust, hardware coded system loaded into the built-in EEPROM. The small size (4 mm ? 4 mm) LFCSP package makes the ADP1052 ideal for ultracompact, isolated dc-to-dc power module or embedded power designs.APPLICATIONS High density isolated dc-to-dc power supplies Intermediate bus converters High availability parallel power systems Server, storage, industrial, networking, and communications infrastructure

The ADP1071-1/ADP1071-2 are pulse-width modulation (PWM) current mode fixed frequency synchronous flyback controllers designed for isolated dc-to-dc power supplies. Analog Devices proprietary iCouplers? are integrated in the ADP1071-1/ADP1071-2 to eliminate the bulky signal trans-formers and optocouplers that transmit signals over the isolation boundary. Integrating the iCouplers reduces system design complexity, cost, and component count and improves overall system reliability. With the integrated isolators and metal-oxide semiconductor field effect transistor (MOSFET) drivers on both the primary and the secondary side, the ADP1071-1/ADP1071-2 offer a compact system level design and yield a higher efficiency than a diode rectified flyback converter at heavy loads.Output regulation is achieved by sensing the output voltage on the secondary side, where the feedback and the PWM signals are transmitted between the primary and secondary sides through the iCouplers.The ADP1071-1/ADP1071-2 are offered in a 16-lead SOIC_W package with an isolation voltage rating of 5 kV rms. The ADP1071-2 is designed for isolated dc-to-dc applications typically with an input voltage less than 36 V, and the ADP1071-1 targets high input voltage applications, in which the dc input voltage can exceed 60 V.The ADP1071-1/ADP1071-2 offer features such as input current protection, output overvoltage protection (OVP), undervoltage lockout (UVLO), precision enable with adjustable hysteresis, overtemperature protection (OTP), and power saving light load mode (LLM).Applications Isolated dc-to-dc or ac-to-dc power conversion Telecom, industrial Small cell PoE powered device Enterprise switches and routers

The ADP121 is a quiescent current, low dropout, linear regulator that operates from 2.3 V to 5.5 V and provides up to 150 mA of output current. The low 135 mV dropout voltage at 150 mA load improves efficiency and allows operation over a wide input voltage range. The low 30 ?A of quiescent current at full load makes the ADP121 ideal for battery-operated portable equipment.The ADP121 is available in output voltages ranging from 1.2 V to 3.3 V. The parts are optimized for stable operation with small 1 ?F ceramic output capacitors. The ADP121 delivers good transient performance with minimal board area.Short-circuit protection and thermal overload protection circuits prevent damage in adverse conditions. The ADP121 is available in a tiny 5-lead TSOT and 4-ball 0.4 mm pitch WLCSP pack-ages and utilizes the smallest footprint solution to meet a variety of portable applications.

The ADP121 is a quiescent current, low dropout, linear regulator that operates from 2.3 V to 5.5 V and provides up to 150 mA of output current. The low 135 mV dropout voltage at 150 mA load improves efficiency and allows operation over a wide input voltage range. The low 30 ?A of quiescent current at full load makes the ADP121 ideal for battery-operated portable equipment.The ADP121 is available in output voltages ranging from 1.2 V to 3.3 V. The parts are optimized for stable operation with small 1 ?F ceramic output capacitors. The ADP121 delivers good transient performance with minimal board area.Short-circuit protection and thermal overload protection circuits prevent damage in adverse conditions. The ADP121 is available in a tiny 5-lead TSOT and 4-ball 0.4 mm pitch WLCSP pack-ages and utilizes the smallest footprint solution to meet a variety of portable applications.

The ADP122 /?ADP123 are low quiescent current, low dropoutlinear regulators. They are designed to operate from an inputvoltage between 2.3 V and 5.5 V and to provide up to 300 mA of output current. The low 85 mV dropout voltage at a 300 mA loadimproves efficiency and allows operation over a wide inputvoltage range.The low 170 ?A of quiescent current at full load makes the ADP122ideal for battery-operated portable equipment.The ADP122 is capable of 31 fixed output voltages from 1.75 Vto 3.3 V. The ADP123 is the adjustable version of the device andallows the output voltage to be set between 0.8 V and 5.0 V by an external voltage divider.The ADP122 / ADP123 are specifically designed for stable operationwith tiny 1 ?F ceramic input and output capacitors to meet therequirements of high performance, space constrained applications.The ADP122 / ADP123 have an internal soft start that gives aconstant start-up time of 350 ?s. Short-circuit protection andthermal overload protection circuits prevent damage in adverse conditions. The ADP122 / ADP123 are available in a tiny, 5-leadTSOT package and 6-lead LFCSP package for the smallestfootprint solution to meet a variety of portable applications.APPLICATIONS Digital camera and audio devices Portable and battery-powered equipment Automatic meter reading (AMR) meters GPS and location management units Medical instrumentation Point-of-sale equipment

The ADP122?/ ADP123 are low quiescent current, low dropoutlinear regulators. They are designed to operate from an inputvoltage between 2.3 V and 5.5 V and to provide up to 300 mA of output current. The low 85 mV dropout voltage at a 300 mA loadimproves efficiency and allows operation over a wide inputvoltage range.The low 170 ?A of quiescent current at full load makes the ADP122ideal for battery-operated portable equipment.The ADP122 is capable of 31 fixed output voltages from 1.75 Vto 3.3 V. The ADP123 is the adjustable version of the device andallows the output voltage to be set between 0.8 V and 5.0 V by an external voltage divider.The ADP122 / ADP123 are specifically designed for stable operationwith tiny 1 ?F ceramic input and output capacitors to meet therequirements of high performance, space constrained applications.The ADP122 / ADP123 have an internal soft start that gives aconstant start-up time of 350 ?s. Short-circuit protection andthermal overload protection circuits prevent damage in adverse conditions. The ADP122 / ADP123 are available in a tiny, 5-leadTSOT package and 6-lead LFCSP package for the smallestfootprint solution to meet a variety of portable applications.APPLICATIONS Digital camera and audio devices Portable and battery-powered equipment Automatic meter reading (AMR) meters GPS and location management units Medical instrumentation Point-of-sale equipment

The ADP124 /?ADP125 are low quiescent current, low dropout linear regulators. They are designed to operate from an input voltage between 2.3 V and 5.5 V and to provide up to 500 mA of output current. The low 130 mV dropout voltage at a 500 mA load improves efficiency and allows operation over a wide input voltage range.The low 210 ?A of quiescent current with a 500 mA load makes the ADP124 / ADP125 ideal for battery-operated portable equipment.The ADP124 is capable of 31 fixed-output voltages from 1.75 V to 3.3 V. The ADP125 is the adjustable version of the device and allows the output voltage to be set between 0.8 V and 5.0 V by an external voltage divider.The ADP124/ADP125 are specifically designed for stable operation with tiny 1 ?F ceramic input and output capacitors to meet the requirements of high performance, space constrained applications.The ADP124 / ADP125 have an internal soft start that gives a constant start-up time of 350 ?s. Short-circuit protection and thermal overload protection circuits prevent damage in adverse conditions. The ADP124 / ADP125 are available in an 8-lead exposed paddle MSOP package. When compared with the standard MSOP package, the exposed paddle MSOP package has lower thermal resistance (?JA). The lower thermal resistance package allows the ADP124 / ADP125 to meet the needs of a variety of portable applications while minimizing the rise in junction temperature.APPLICATIONS Digital camera and audio devices Portable and battery-powered equipment Automatic meter reading (AMR) meters GPS and location management units Medical instrumentation Point of load power

The ADP151 is an ultralow noise, low dropout (LDO) linear regulator that operates from 2.2 V to 5.5 V and provides up to 200 mA of output current. The low 135 mV dropout voltage at 200 mA load improves efficiency and allows operation over a wide input voltage range.Using an innovative circuit topology, the ADP151 achieves ultralow noise performance without the necessity of a bypass capacitor, making the device ideal for noise-sensitive analog and RF applications. The ADP151 also achieves ultralow noise performance without compromising the power supply rejection ratio (PSRR) or transient line and load performance. The low 265 ?A of operating supply current at 200 mA load makes the ADP151 suitable for battery-operated portable equipment.The ADP151 also includes an internal pull-down resistor on the EN input.The ADP151 is specifically designed for stable operation with tiny 1 ?F, ?30% ceramic input and output capacitors to meet the requirements of high performance, space constrained applications.The ADP151 is capable of 16 fixed output voltage options, ranging from 1.1 V to 3.3 V.Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP151 is available in tiny 5-lead TSOT, 6-lead LFCSP, and 4-ball, 0.4 mm pitch, halide-free WLCSP packages for the smallest footprint solution to meet a variety of portable power application requirements.APPLICATIONS RF, voltage controlled oscillator (VCO), and phase locked loop (PLL) power supplies Mobile phones Digital camera and audio devices Portable and battery-powered equipment Post dc-to-dc regulation Portable medical devices Automotive

The ADP1612/ADP1613 are step-up dc-to-dc switching con-verters with an integrated power switch capable of providing an output voltage as high as 20 V. With a package height of less than 1.1 mm, the ADP1612/ADP1613 are optimal for space-constrained applications such as portable devices or thin film transistor (TFT) liquid crystal displays (LCDs).The ADP1612/ADP1613 operate in current mode pulse-width modulation (PWM) with up to 94% efficiency. Adjustable soft start prevents inrush currents when the part is enabled. The pin-selectable switching frequency and PWM current-mode architecture allow for excellent transient response, easy noise filtering, and the use of small, cost-saving external inductors and capacitors. Other key features include undervoltage lockout (UVLO), thermal shutdown (TSD), and logic controlled enable.The ADP1612/ADP1613 are available in the lead-free 8-lead MSOP.Applications TFT LCD bias suppliesPortable applicationsIndustrial/instrumentation equipment

The ADP1621 is a fixed-frequency, pulse-width modulation (PWM), current-mode, step-up converter controller. It drives an external n-channel MOSFET to convert the input voltage to a higher output voltage. The ADP1621 can also be used to drive flyback, SEPIC, and forward converter topologies, either isolated or nonisolated.The ADP1621 eliminates the use of a current-sense power resistor by measuring the voltage drop across the on resistance of the n-channel MOSFET. This technique, allowed up to a maximum voltage of 30 V at the switch node, maximizes efficiency and reduces cost. For switch-node voltages higher than 30 V or for more accurate current limiting, the CS pin can be connected to a current-sense resistor in the source of the MOSFET. The slope compensation is implemented by an external resistor, allowing a wide range of external components (inductors and MOSFETs), and can be chosen for various switching frequencies and input and output voltages.The ADP1621 supply input voltage range is 2.9 V to 5.5 V, although higher input voltages are possible with the use of a small-signal NPN pass transistor or a single resistor. The voltage of the power input can be as low as 1 V for fuel cell applications. The switching frequency is set by an external resistor over a range of 100 kHz to 1.5 MHz and can be synchronized to an external clock by using the SDSN pin. The shutdown quiescent current is less than 10 ?A. The ADP1621 has a thermal shutdown feature that shuts down the gate driver when the junction temperature reaches approximately 150?C. The internal soft start circuit limits inrush current at startup. The ADP1621 is available in the 10-lead MSOP lead-free package and is specified over the ?40?C to +125?C junction temperature range.Applications APD bias Portable electronic equipment Isolated dc-to-dc converter Step-up/step-down dc-to-dc converter LED driver for laptop computer and navigation system LCD backlighting

TheADP160/ADP161/ADP162/ADP163are ultralow quiescentcurrent, low dropout, linear regulators that operate from 2.2 Vto 5.5 V and provide up to 150 mA of output current. The low195 mV dropout voltage at 150 mA load improves efficiency andallows operation over a wide input voltage range.The ADP16x are specifically designed for stable operation withtiny 1 ?F ? 30% ceramic input and output capacitors to meetthe requirements of high performance, space-constrainedapplications.The ADP160 is available in 15 fixed output voltage options,ranging from 1.2 V to 4.2 V. The ADP160/ADP161 also includea switched resistor to discharge the output automatically when the LDO is disabled. The ADP162 is identical to the ADP160but does not include the output discharge function.The ADP161and ADP163 are available as a adjustable outputvoltage regulators. They are only available in a 5-lead TSOTpackage. The ADP163 is identical to the ADP161 but does notinclude the output discharge function.Short-circuit and thermal overload protection circuits preventdamage in adverse conditions. The ADP160 and ADP162 areavailable in a tiny 5-lead TSOT and a 4-ball, 0.5 mm pitchWLCSP package for the smallest footprint solution to meet avariety of portable power applications.Applications Mobile phones Digital cameras and audio devices Portable and battery-powered equipment Post dc-to-dc regulation Portable medical devices

The ADP165/ADP166 are very low quiescent current, low dropout, linear regulator that operate from 2.2 V to 5.5 V and provides up to 150 mA of output current. The low 120 mV dropout voltage at 150 mA load improves efficiency and allows operation over a wide input voltage range.The ADP165/ADP166 are specifically designed for stable operation with a tiny 1 ?F ? 30% ceramic input and output capacitors to meet the requirements of high performance, space-constrained applications.The ADP165/ADP166 are available in seven fixed output voltage options, ranging from 1.2 V to 3.3 V, and an adjustable output option. The ADP165 also include a switched resistor to discharge the output automatically when the LDO is disabled. The ADP166 is identical to the ADP165, but does not include the output discharge function.Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP165/ADP166 are available in a tiny 5-lead TSOT, a 6-lead LFCSP and a 4-ball, 0.5 mm pitch WLCSP package for the smallest footprint solution to meet a variety of portable power applications.Applications Portable and battery-powered equipment Post dc-to-dc regulation Portable medical devices Wireless sensor network (WSN) devices

The ADP165/ADP166 are very low quiescent current, low dropout, linear regulator that operate from 2.2 V to 5.5 V and provides up to 150 mA of output current. The low 120 mV dropout voltage at 150 mA load improves efficiency and allows operation over a wide input voltage range.The ADP165/ADP166 are specifically designed for stable operation with a tiny 1 ?F ? 30% ceramic input and output capacitors to meet the requirements of high performance, space-constrained applications.The ADP165/ADP166 are available in seven fixed output voltage options, ranging from 1.2 V to 3.3 V, and an adjustable output option. The ADP165 also include a switched resistor to discharge the output automatically when the LDO is disabled. The ADP166 is identical to the ADP165, but does not include the output discharge function.Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP165/ADP166 are available in a tiny 5-lead TSOT, a 6-lead LFCSP and a 4-ball, 0.5 mm pitch WLCSP package for the smallest footprint solution to meet a variety of portable power applications.Applications Portable and battery-powered equipment Post dc-to-dc regulation Portable medical devices Wireless sensor network (WSN) devices

The ADP1660 is a very compact, highly efficient, dual white LEDflash driver for high-resolution camera phones that improvespicture and video quality in low light environments. The deviceintegrates a programmable 1.5 MHz or 3.0 MHz synchronousinductive boost converter, an I2C-compatible interface, and two 750 mA current sources. The high switching frequency enablesthe use of a tiny, 1 mm high, low cost, 1 ?H power inductor,and the parallel current sources permit LED cathode groundingfor thermally enhanced, low EMI, and compact layouts.The LED driver maximizes efficiency over the entire battery voltage range to maximize the input-power-to-LED-power conversion and minimize battery current draw during flash events.The LED driver maximizes efficiency over the entire batteryvoltage range to maximize the input-power-to-LED-powerconversion and minimize battery current draw during flashevents. A programmable DC battery current limit safely maximizesLED current for all LED VF and battery voltage conditions.A TxMASK input permits the flash LED currents and batterycurrent to reduce quickly during a power amplifier current burst.The I2C-compatible interface enables the programmability oftimers, currents, and status bit readback for operationmonitoring and safety control.ADP1660 comes in a compact 12-ball, 0.5 mm pitch packageand operates within specification over the full ?40?C to +125?Cjunction temperature range.APPLICATIONS Camera-enabled cellular phones and smart phones Digital still cameras, camcorders, and PDAs

The ADP1660 is a very compact, highly efficient, dual white LEDflash driver for high-resolution camera phones that improvespicture and video quality in low light environments. The deviceintegrates a programmable 1.5 MHz or 3.0 MHz synchronousinductive boost converter, an I2C-compatible interface, and two 750 mA current sources. The high switching frequency enablesthe use of a tiny, 1 mm high, low cost, 1 ?H power inductor,and the parallel current sources permit LED cathode groundingfor thermally enhanced, low EMI, and compact layouts.The LED driver maximizes efficiency over the entire battery voltage range to maximize the input-power-to-LED-power conversion and minimize battery current draw during flash events.The LED driver maximizes efficiency over the entire batteryvoltage range to maximize the input-power-to-LED-powerconversion and minimize battery current draw during flashevents. A programmable DC battery current limit safely maximizesLED current for all LED VF and battery voltage conditions.A TxMASK input permits the flash LED currents and batterycurrent to reduce quickly during a power amplifier current burst.The I2C-compatible interface enables the programmability oftimers, currents, and status bit readback for operationmonitoring and safety control.ADP1660 comes in a compact 12-ball, 0.5 mm pitch packageand operates within specification over the full ?40?C to +125?Cjunction temperature range.APPLICATIONS Camera-enabled cellular phones and smart phones Digital still cameras, camcorders, and PDAs

The ADP165?/ ADP166 are very low quiescent current, low dropout, linear regulator that operate from 2.2 V to 5.5 V and provides up to 150 mA of output current. The low 120 mV dropout voltage at 150 mA load improves efficiency and allows operation over a wide input voltage range.The ADP165 / ADP166 are specifically designed for stable operation with a tiny 1 ?F ? 30% ceramic input and output capacitors to meet the requirements of high performance, space-constrained applications.The ADP165 / ADP166 are available in seven fixed output voltage options, ranging from 1.2 V to 3.3 V, and an adjustable output option. The ADP165 also include a switched resistor to discharge the output automatically when the LDO is disabled. The ADP166 is identical to the ADP165, but does not include the output discharge function.Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP165 / ADP166 are available in a tiny 5-lead TSOT, a 6-lead LFCSP and a 4-ball, 0.5 mm pitch WLCSP package for the smallest footprint solution to meet a variety of portable power applications.APPLICATIONS Portable and battery-powered equipment Post dc-to-dc regulation Portable medical devices Wireless sensor network (WSN) devices

The ADP1706?/ ADP1707 / ADP1708?are CMOS, low dropout linear regulators that operate from 2.5 V to 5.5 V and provide up to 1 A of output current. Using an advanced proprietary architecture, they provide high power supply rejection and achieve excellent line and load transient response with a small 4.7 ?F ceramic output capacitor.The ADP1706 / ADP1707 are available in 16 fixed output volt-age options. The ADP1708 is available in an adjustable version, which allows output voltages that range from 0.8 V to 5.0 V via an external divider. The ADP1706 allows an external soft start capacitor to be connected to program the start-up time; the ADP1707 and ADP1708 contain internal soft start capacitors that give a typical start-up time of 100 ?s. The ADP1707 includes a tracking feature that allows the output to follow an external voltage rail or reference.The ADP1706 / ADP1707 / ADP1708 are available in an 8-lead, exposed paddle SOIC package and an 8-lead, 3 mm ? 3 mm exposed paddle LFCSP, making them not only very compact solutions but also providing excellent thermal performance for applications requiring up to 1 A of output current in a small, low profile footprint.APPLICATIONS Notebook computers Memory components Telecommunications equipment Network equipment DSP/FPGA/microprocessor supplies Instrumentation equipment/data acquisition systems

The ADP1715 / ADP1716?are low dropout, CMOS linear regulators that operate from 2.5 V to 5.5 V and provide up to 500 mA of output current. Using an advanced proprietary architecture, they provide high power supply rejection and achieve excellent line and load transient response with just a small 2.2 ?F ceramic output capacitor.Three versions of this part are available, one with fixed output voltage options and variable soft start (ADP1715), one with adjustable output voltage and fixed soft start (ADP1715 Adjustable), and one with voltage tracking in fixed output voltage options (ADP1716). The fixed output voltage options are internally set to one of sixteen values between 0.75 V and 3.3 V; the adjustable output voltage can be set to any value between 0.8 V and 5.0 V by an external voltage divider connected from OUT to ADJ. The variable soft start uses an external capacitor at SS to control the output voltage ramp. Tracking limits the output voltage to the at-or-below voltage at the TRK pin.The ADP1715 / ADP1716 are available in 8-lead thermally enhanced MSOP packages, making them not only a very compact solution but also providing excellent thermal performance for applications requiring up to 500 mA of output current in a small, low profile footprint.APPLICATIONS Notebook computers Memory components Telecommunications equipment Network Equipment DSP/FPGA/?P supplies Instrumentation equipment/data acquisition systems
