Evaluation Kits

Displaying 9021 - 9040 of 11973

Evaluation Kits

DC1497A

The LT3597 is a 60V triple step-down LED driver capable of achieving 10,000:1 digital PWM dimming at 100Hz with fast NPN current sources driving up to 10 LEDs in each channel. LED dimming can also be achieved via analog control of the CTRL1-3 pin.The step-down switching frequency is programmed between 200kHz and 1MHz. The frequency is also synchronizable to an external clock. The LT3597 provides maximum LED brightness while adhering to manufacturers? specifications for thermal derating. The derate temperature is programmed by placing a negative temperature coefficient (NTC) resistor on the master control pin.The LT3597 adaptively controls VOUT in order to achieve optimal efficiency. Other features include: 2% LED current matching between channels, open LED reporting, shorted LED protection, programmable LED current, and programmable temperature protection.Applications LED Billboards and Signboards Mono, Multi, Full-Color LED Displays Large Screen Display LED Backlighting Automotive, Industrial, and Medical Displays

STEVAL-IFP017V3

STMicroelectronics

EVAL BOARD

Evaluation Kit

STEVAL-MKI192V1

STMicroelectronics

ST eval board for pressure sensor LPS22HH.

Evaluation Kit

INA233 Current Shunt Monitor Evaluation Module

Texas Instruments

INA233 Current Shunt Monitor Evaluation Module

Evaluation Kit Parts

AXC-SMALLPKG1EVM for Small Package Direction-Controlled Translation Devices

Texas Instruments

This EVM is designed to support SN74AXC8T245 in the RJW package and SN74AXC1T45 in DEA and the DTQ packages. There is also option of populating the SN74AVC4T245 in the RSV package. It is also designed to support the bus hold and Q1 devices for the respective channel counts. The AXC devices belong to the low voltage direction controlled translation family with operating voltage from 0.65V to 3.6V with 12mA of drive strength. The AVC are low voltage translation devices operating from 1.2V -3.6V with lower drive strength of 12mA. Features: High speed SMB connector available Ground port for each header pin supports high speed measurement DIR and OE pin have the option of 10K ohm resistor pullup or pulldown Layout optimized for high speed connectivity Highlights the Small Package technology of TI

Evaluation Kit Parts
