The AD5590 is a 16-channel input and 16-channel output analog I/O port with eight uncommitted amplifiers, operating from a single 4.5 V to 5.25 V supply. The AD5590 comprises 16 input channels multiplexed into a 1 MSPS, 12-bit successive approximation ADC with a sequencer to allow a preprogrammed selection of channels to be converted sequentially. The ADC contains a low noise, wide bandwidth track-and-hold amplifier that can handle input frequencies in excess of 1 MHz.The conversion process and data acquisition are controlled using ASYNC and the serial clock signal, allowing the device to easily interface with microprocessors or DSPs. The input signal is sampled on the falling edge of ASYNC and conversion is also initiated at this point. There are no pipeline delays associated with the ADC. By setting the relevant bits in the control register, the analog input range for the ADC can be selected to be a 0 V to VREFA input or a 0 V to 2 ? VREFA with either straight binary or twos complement output coding. The conversion time is determined by the ASCLK frequency because it is also used as the master clock to control the conversion.The DAC section of the AD5590 comprises sixteen 12-bit DACs divided into two groups of eight. Each group has an on-chip reference. The on-board references are off at power-up, allowing the use of external references. The internal references are enabled via a software write.The AD5590 incorporates a power-on reset circuit that ensures that the DAC outputs power up to 0 V and remain powered up at this level until a valid write takes place. The DAC contains a power-down feature that reduces the current consumption of the device and provides software-selectable output loads while in power-down mode for any or all DAC channels. The outputs of all DACs can be updated simultaneously using the LDAC function, with the added functionality of user-selectable DAC channels to simultaneously update. There is also an asynchronous CLR that updates all DACs to a user-programmable code: zero scale, midscale, or full scale.The AD5590 contains eight low noise, single-supply amplifiers. These amplifiers can be used for signal conditioning for the ADCs, DACs, or other independent circuitry, if required.APPLICATIONS Optical Line Cards (Monitoring and Control) Base Stations General Purpose Analog I/O Monitoring and control

The AD5593R has eight input/output (I/O) pins, which can beindependently configured as digital-to-analog converter (DAC)outputs, analog-to-digital converter (ADC) inputs, digital outputs,or digital inputs. When an I/O pin is configured as an analogoutput, it is driven by a 12-bit DAC. The output range of theDAC is 0 V to VREF or 0 V to 2 ? VREF. When an I/O pin isconfigured as an analog input, it is connected to a 12-bit ADCvia an analog multiplexer. The input range of the ADC is 0 V toVREF or 0 V to 2 ? VREF. The I/O pins can also be configured tobe general-purpose, digital input or output (GPIO) pins. Thestate of the GPIO pins can be set or read back by accessing theGPIO write data register and GPIO read configuration registers,respectively, via an I2C write or read operation.The AD5593R has an integrated 2.5 V, 20 ppm/?C reference thatis turned off by default and an integrated temperature indicatorthat gives an indication of the die temperature. The temperaturevalue is read back as part of an ADC read sequence.The AD5593R is available in 16-lead TSSOP and LFCSP, as wellas a 16-ball WLCSP, and operates over a temperature range of?40?C to +105?C.Applications Control and monitoring General-purpose analog and digital I/O

The AD5671R/AD5675R are low power, octal, 12-/16-bit buffered voltage output digital-to-analog converters (DACs). They include a 2.5 V, 2 ppm/?C internal reference (enabled by default) and a gain select pin giving a full-scale output of 2.5 V (gain = 1) or 5 V (gain = 2). The devices operate from a single 2.7 V to 5.5 V supply and are guaranteed monotonic by design. The AD5671R/AD5675R are available in a 20-lead TSSOP and in a 20-lead LFCSP and incorporate a power-on reset circuit and a RSTSEL pin that ensures the DAC outputs power up to zero scale or midscale and remain there until a valid write. The AD5671R/AD5675R contain a power-down mode, reducing the current consumption to 1 ?A typical while in power-down mode.Product Highlights High Relative Accuracy (INL). AD5671R (12-bit): ?1 LSB maximum AD5675R (16-bit): ?3 LSB maximum Low Drift 2.5 V On-Chip ReferenceApplications Optical transceivers Base-station power amplifiers Process control (PLC input/output cards) Industrial automation Data acquisition systems

The AD5683R/AD5682R/AD5681R/AD5683, members of thenanoDAC+? family, are low power, single-channel, 16-/14-/12-bitbuffered voltage out digital-to-analog converters (DACs). Thedevices, except the AD5683, include an enabled by default internal2.5 V reference, offering 2 ppm/?C drift. The output span can beprogrammed to be 0 V to VREF or 0 V to 2 ? VREF. All devicesoperate from a single 2.7 V to 5.5 V supply and are guaranteedmonotonic by design. The devices are available in a 2.00 mm ?2.00 mm, 8-lead LFCSP or a 10-lead MSOP.The internal power-on reset circuit ensures that the DAC registeris written to zero scale at power-up while the internal outputbuffer is configured in normal mode. TheAD5683R/AD5682R/AD5681R/AD5683 contain a power-downmode that reduces the current consumption of the device to 2 ?A(maximum) at 5 V and provides software selectable output loadswhile in power-down mode.The AD5683R/AD5682R/AD5681R/AD5683 use a versatile3-wire serial interface that operates at clock rates of up to 50 MHz.Some devices also include asynchronous RESET pin and VLOGICpin options, allowing 1.8 V compatibilityProduct Highlights High Relative Accuracy (INL). AD5683R/AD5683 (16-bit): ?2 LSB maximum. Low Drift, 2.5 V On-Chip Reference. 2 ppm/?C typical temperature coefficient. 5 ppm/?C maximum temperature coefficient. Two Package Options. 2.00 mm ? 2.00 mm, 8-lead LFCSP. 10-lead MSOP.Applications Process controls Data acquisition systems Digital gain and offset adjustment Programmable voltage sources

The AD5790?is a single 20-bit, voltage out DAC that operates from a bipolar supply up to 33V. Reference buffers are also provided on-chip The AD5790 accepts a positive reference input in the range of 5V to VDD ? 2.5V and a negative reference input in the range of VSS + 2.5v to 0V. The AD5790 offers a relative accuracy of +/-2 LSB's max and operation is guaranteed monotonic with a -1 LSB to +3 LSB's DNL specification.The part uses a versatile 3-wire serial interface that operates at clock rates up to 35 MHz and is compatible with standard SPI?, QSPI?, MICROWIRE?, and DSP interface standards. The part incorporates a power-on reset circuit that ensures the DAC output powers up to 0V and in a known output impedance state and remains in this state until a valid write to the device takes place. The part provides a disable feature that places the output in a defined load state.PRODUCT HIGHLIGHTS 20-bit resolution Wide power supply range of up to ?16.5 V. ?40?C to +125?C operating temperature range. Low 8 nV/?Hz noise. Low ?0.018 ppm/?C gain error temperature coefficient.APPLICATIONS Medical instrumentation Test and measurement Industrial control Scientific and aerospace instrumentation Data acquisition systems Digital gain and offset adjustment Power supply control

The AD5821A is a single, 10-bit digital-to-analog converter (DAC) with output current sinking capability of 120 mA. It features an internal reference and operates from a single 2.7 V to 5.5 V supply. The DAC is controlled via a 2-wire, I2C?-compatible serial interface that operates at clock rates up to 400 kHz.The AD5821A incorporates a power-on reset circuit that ensures the DAC output powers up to 0 V and remains there until a valid write takes place. It has a power-down feature that reduces the current consumption of the device to 1 ?A maximum.The AD5821A is designed for autofocus, image stabilization, and optical zoom applications in camera phones, digital still cameras, and camcorders.The AD5821A is also suitable for many industrial applications, such as controlling temperature, light, and movement without derating over temperatures ranging from ?30?C to +85?C.The I2C 7-bit address for the AD5821A is 0xC.

The AD5940 and AD5941 are high precision, low power analog front ends (AFEs) designed for portable applications that require high precision, electrochemical-based measurement techniques, such as amperometric, voltammetric, or impedance measurements. The AD5940/AD5941 is designed for skin impedance and body impedance measurements, and works with the AD8233 AFE in a complete bioelectric or biopotential measurement system. The AD5940/AD5941 is designed for electrochemical toxic gas sensing.The AD5940/AD5941 consist of two high precision excitation loops and one common measurement channel, which enables a wide capability of measurements of the sensor under test. The first excitation loop consists of an ultra low power, dual-output string, digital-to-analog converter (DAC), and a low power, low noise potentiostat. One output of the DAC controls the noninverting input of the potentiostat, and the other output controls the noninverting input of the transimpedance amplifier (TIA). This low power excitation loop is capable of generating signals from dc to 200 Hz.The second excitation loop consists of a 12-bit DAC, referred to as the high speed DAC. This DAC is capable of generating high frequency excitation signals up to 200 kHz.The AD5940/AD5941 measurement channel features a 16-bit, 800 kSPS, multichannel successive approximation register (SAR) analog-to-digital converter (ADC) with input buffers, a built in antialias filter, and a programmable gain amplifier (PGA). An input multiplexer (mux) in front of the ADC allows the user to select an input channel for measurement. These input channels include multiple external current inputs, external voltage inputs, and internal channels. The internal channels allow diagnostic measurements of the internal supply voltages, die temperature, and reference voltages.The current inputs include two TIAs with programmable gain and load resistors for measuring different sensor types. The first TIA, referred to as the low power TIA, measures low bandwidth signals. The second TIA, referred to as the high speed TIA, measures high bandwidth signals up to 200 kHz.An ultra low leakage, programmable switch matrix connects the sensor to the internal analog excitation and measurement blocks. This matrix provides an interface for connecting external transimpedance amplifier resistors (RTIAs) and calibration resistors. The matrix can also be used to multiplex multiple electronic measurement devices to the same wearable electrodes.A precision 1.82 V and 2.5 V on-chip reference source is available. The internal ADC and DAC circuits use this on-chip reference source to ensure low drift performance for the 1.82 V and 2.5 V peripherals.The AD5940/AD5941 measurement blocks can be controlled via direct register writes through the serial peripheral interface (SPI) interface, or, alternatively, by using a preprogrammable sequencer, which provides autonomous control of the AFE chip. 6 kB of static random access memory (SRAM) is partitioned for a deep data first in, first out (FIFO) and command FIFO. Measurement commands are stored in the command FIFO and measurement results are stored in the data FIFO. A number of FIFO related interrupts are available to indicate when the FIFO is full.A number of general-purpose inputs/outputs (GPIOs) are available and controlled using the AFE sequencer. The AFE sequencer allows cycle accurate control of multiple external sensor devices.The AD5940/AD5941 operate from a 2.8 V to 3.6 V supply and are specified over a temperature range of ?40?C to +85?C. The AD5940 is packaged in a 56-lead, 3.6 mm ? 4.2 mm WLCSP. The AD5941 is packaged in a 48-lead LFCSP.APPLICATIONS Electrochemical measurements Electrochemical gas sensors Potentiostat/amperometric/voltammetry/cyclic voltammetry Bioimpedance applications Skin impedance Body impedance Continuous glucose monitoring Battery impedance

The AD7124-8 is a low power, low noise, completely integratedanalog front end for high precision measurement applications.The device contains a low noise, 24-bit ?-? analog-to-digitalconverter (ADC), and can be configured to have 8 differentialinputs or 15 single-ended or pseudo differential inputs. The onchiplow gain stage ensures that signals of small amplitude canbe interfaced directly to the ADC.One of the major advantages of the AD7124-8 is that it gives theuser the flexibility to employ one of three integrated powermodes. The current consumption, range of output data rates,and rms noise can be tailored with the power mode selected.The device also offers a multitude of filter options, ensuring thatthe user has the highest degree of flexibility.The AD7124-8 can achieve simultaneous 50 Hz and 60 Hzrejection when operating at an output data rate of 25 SPS (singlecycle settling), with rejection in excess of 80 dB achieved at loweroutput data rates.The AD7124-8 establishes the highest degree of signal chainintegration. The device contains a precision, low noise, lowdrift internal band gap reference and accepts an externaldifferential reference, which can be internally buffered. Otherkey integrated features include programmable low drift excitationcurrent sources, burnout currents, and a bias voltage generator,which sets the common-mode voltage of a channel to AVDD/2.The low-side power switch enables the user to power downbridge sensors between conversions, ensuring the absoluteminimal power consumption of the system. The device alsoallows the user the option of operating with either an internalclock or an external clock.The integrated channel sequencer allows several channels to beenabled simultaneously, and the AD7124-8 sequentially convertson each enabled channel, simplifying communication with thedevice. As many as 16 channels can be enabled at any time, achannel being defined as an analog input or a diagnostic suchas a power supply check or a reference check. This uniquefeature allows diagnostics to be interleaved with conversions.The AD7124-8 also supports per channel configuration. Thedevice allows eight configurations or setups. Each configurationconsists of gain, filter type, output data rate, buffering, andreference source. The user can assign any of these setups on achannel by channel basis.The AD7124-8 also has extensive diagnostic functionalityintegrated as part of its comprehensive feature set. Thesediagnostics include a cyclic redundancy check (CRC), signalchain checks, and serial interface checks, which lead to a morerobust solution. These diagnostics reduce the need for externalcomponents to implement diagnostics, resulting in reducedboard space needs, reduced design cycle times, and cost savings.The failure modes effects and diagnostic analysis (FMEDA) of atypical application has shown a safe failure fraction (SFF) greaterthan 90% according to IEC 61508.The device operates with a single analog power supply from 2.7 Vto 3.6 V or a dual 1.8 V power supply. The digital supply has arange of 1.65 V to 3.6 V. It is specified for a temperature rangeof ?40?C to +125?C. The AD7124-8 is housed in a 32-leadLFCSP package.Note that, throughout this data sheet, multifunction pins, suchas DOUT/RDY, are referred to either by the entire pin name orby a single function of the pin, for example, RDY, when onlythat function is relevant.Applications Temperature measurement Pressure measurement Industrial process control Instrumentation Smart transmitters

The AD7147 CapTouch? controller is designed for use with capacitance sensors implementing functions such as buttons, scroll bars, and wheels. The sensors need only one PCB layer, enabling ultrathin applications.The AD7147 is an integrated CDC with on-chip environmental calibration. The CDC has 13 inputs channeled through a switch matrix to a 16-bit, 250 kHz sigma-delta (?-?) converter. The CDC is capable of sensing changes in the capacitance of the external sensors and uses this information to register a sensor activation. By programming the registers, the user has full control over the CDC setup.High resolution sensors require minor software to run on the host processor.The AD7147 is designed for single electrode capacitance sensors (grounded sensors). There is an active shield output to minimize noise pickup in the sensor.The AD7147 has on-chip calibration logic to compensate for changes in the ambient environment. The calibration sequence is performed automatically and at continuous intervals as long as the sensors are not touched. This ensures that there are no false or non-registering touches on the external sensors due to a changing environment.The AD7147 has an SPI-compatible serial interface, and the AD7147-1 has an I2C?-compatible serial interface. Both parts have an interrupt output, as well as a GPIO. There is a VDRIVE pin to set the voltage level for the serial interface independent of VCC.The AD7147 is available in a 24-lead, 4 mm ? 4 mm LFCSP and operates from a 2.6 V to 3.6 V supply. The operating current consumption in low power mode is typically 26 ?A for 13 sensors.APPLICATIONS Cell phones Personal music and multimedia players Smart handheld devices Television, A/V, and remote controls Gaming consoles Digital still cameras?

The AD7147 CapTouch? controller is designed for use with capacitance sensors implementing functions such as buttons, scroll bars, and wheels. The sensors need only one PCB layer, enabling ultrathin applications.The AD7147 is an integrated CDC with on-chip environmental calibration. The CDC has 13 inputs channeled through a switch matrix to a 16-bit, 250 kHz sigma-delta (?-?) converter. The CDC is capable of sensing changes in the capacitance of the external sensors and uses this information to register a sensor activation. By programming the registers, the user has full control over the CDC setup.High resolution sensors require minor software to run on the host processor.The AD7147 is designed for single electrode capacitance sensors (grounded sensors). There is an active shield output to minimize noise pickup in the sensor.The AD7147 has on-chip calibration logic to compensate for changes in the ambient environment. The calibration sequence is performed automatically and at continuous intervals as long as the sensors are not touched. This ensures that there are no false or non-registering touches on the external sensors due to a changing environment.The AD7147 has an SPI-compatible serial interface, and the AD7147-1 has an I2C?-compatible serial interface. Both parts have an interrupt output, as well as a GPIO. There is a VDRIVE pin to set the voltage level for the serial interface independent of VCC.The AD7147 is available in a 24-lead, 4 mm ? 4 mm LFCSP and operates from a 2.6 V to 3.6 V supply. The operating current consumption in low power mode is typically 26 ?A for 13 sensors.APPLICATIONS Cell phones Personal music and multimedia players Smart handheld devices Television, A/V, and remote controls Gaming consoles Digital still cameras?

The AD7293 is a PA drain current controller containing functionality for general-purpose monitoring and control of current, voltage, and temperature, integrated into a single chip solution with an SPI-compatible interface.The device features a 4-channel, 12-bit successive approximation register (SAR) ADC, eight 12-bit DACs (four bipolar and four unipolar with output ranges that can be configured to shut down under external pin control), a ?1.25?C accurate internal temperature sensor, and eight general-purpose input/output (GPIO) pins.The device also includes limit registers for alert functions and four high-side current sense amplifiers to measure current across external shunt resistors. These amplifiers can be optionally set to operate as part of four independent closed-loop drain current controllers.A high accuracy 2.5 V internal reference is provided to drive theDACs and the ADC. The 12-bit ADC monitors and digitizes theinternal temperature sensor, and two inputs are included for theexternal diode temperature sensors.Product Highlights Four independent closed-loop drain current controllers. Built-in monitoring, sequencing, and alert features. Compatible with both depletion mode and enhancement mode power amplifiers.Applications GaN and GaAs power amplifier monitoring and controls Base station power amplifiers General-purpose system monitoring and controls

The AD7329 is an 8-Channel, 12-Bit Plus Sign Successive Approximation ADC. The ADC has a high-speed serial interface that can operate at throughput rates up to 1 MSPS. The ADC has a high-speed serial interface that can operate at throughput rates up to 250 kSPS.The AD7329 can accept True Bipolar Analog input signals. The Ad7329 has four software selectable ranges, ?10 V, ?5 V, ?2.5 V and 0 to 10 V. Each analog input channel can be independently programmed to one of the input ranges by setting the appropriate bits in the Range Registers.The Analog Input Channels can be configured as single ended, fully differential or pseudo differential. Dedicated Control Register bits are used to configure the Analog inputs.The ADC contains a 2.5 V Internal reference. The AD7329 also allows for external Reference operation. If a 3 V external reference is applied to the REFIN/OUT pin, the ADC can handle a True Bipolar ? 12 V Analog input range. VDD and VSS supplies of ? 12 V are required for this ? 12 V input range.The AD7329 has multiplexer output pins and ADC input pins. These allow the user to insert buffers, differential amplifiers or antialiasing filters, if required, between the Multiplexer and the ADC. This means that for eight analog inputs only a single driver is required for the AD7329.The AD7329 has a number of power down mode to reduce power consumption at lower throughput rates.PRODUCT HIGHLIGHTS The AD7329 can accept True Bipolar Analog Input signals, ?10V, ?5V, ?2.5V and 0 to 10V unipolar signals. The Eight Analog Inputs can be configured as 8 Single-Ended inputs, 4 True Differential, 4 Pseudo Differential or 7 Pseudo Differential Inputs. SPI/QSPI/DSP/MICROWIRE compatible Interface. Low Power, TBD mW at maximum throughput rate. Channel Sequencer

The AD7405 is a high performance, second-order, ?-? modulatorthat converts an analog input signal into a high speed, single-bitLVDS data stream, with on-chip digital isolation based onAnalog Devices, Inc., iCoupler? technology. The AD7405operates from a 5 V (VDD1) power supply and accepts adifferential input signal of ?250 mV (?320 mV full-scale). Thedifferential input is ideally suited to shunt voltage monitoring inhigh voltage applications where galvanic isolation is required.The analog input is continuously sampled by a high performanceanalog modulator, and converted to a ones density digital outputstream with a data rate of up to 20 MHz. The originalinformation can be reconstructed with an appropriate digitalfilter to achieve 88 dB signal to noise ratio (SNR) at 78.1 kSPS.The LVDS input/output can use a 5 V or a 3.3 V supply (VDD2).The LVDS interface is digitally isolated. The LVDS interfacetechnology, combined with monolithic transformer technology,means the on-chip isolation provides outstanding performancecharacteristics, superior to alternatives such as optocouplerdevices. The AD7405 device is offered in a 16-lead, wide-bodySOIC package and has an operating temperature range of ?40?Cto +125?C.Applications Shunt current monitoring AC motor controls Power and solar inverters Wind turbine inverters Data acquisition systems Analog-to-digital and opto-isolator replacements

The AD7606C-18 is an 18-bit, simultaneous sampling, analog-to-digital data acquisition system (DAS) with eight channels. Each channel contains analog input clamp protection, a programmable gain amplifier (PGA), a low-pass filter (LPF), and an 18-bit successive approximation register (SAR) analog-to-digital converter (ADC). The AD7606C-18 also contains a flexible digital filter, a low drift, 2.5 V precision reference, a reference buffer to drive the ADC, and flexible parallel and serial interfaces.The AD7606C-18 operates from a single 5 V supply and accommodates the following input ranges when sampling at throughput rates of 1 MSPS for all channels: Bipolar single-ended: ?12.5 V, ?10 V, ?6.25 V, ?5 V, and ?2.5 V Unipolar single-ended: 0 V to 12.5 V, 0 V to 10 V, and 0 V to 5 V Bipolar differential: ?20 V, ?12.5 V, ?10 V, and ?5 VThe input clamp protection tolerates voltages up to ?21 V. The single supply operation, on-chip filtering, and high input impedance eliminate the need for external driver op amps, which require bipolar supplies. For applications with lower throughput rates, the AD7606C-18 flexible digital filter can be used to improve noise performance.In hardware mode, the AD7606C-18 is fully compatible with the AD7608 and AD7609. In software mode, the following advanced features are available: Analog input range selectable per channel with added ranges available High bandwidth mode (220 kHz) selectable per channel Additional oversampling options with an oversampling ratio up to 256 System gain, system offset, and system phase calibration, per channel Analog input open circuit detector Diagnostic multiplexer Monitoring functions (serial peripheral interface (SPI) invalid read and write, cyclic redundancy check (CRC), busy stuck monitor, and reset detection)Note that throughout the data sheet, multifunction pins, such as the RD/SCLK pin, are referred to either by the entire pin name or by a single function of the pin, for example, the SCLK pin, when only that function is relevant.APPLICATIONSPower line monitoringProtective relaysMultiphase motor controlInstrumentation and control systemsData acquisition systems

The AD7686 is a 16-bit, charge redistribution, successive approximation, analog-to-digital converter (ADC) that operates from a single 5 V power supply, VDD. It contains a low power, high speed, 16-bit sampling ADC with no missing codes, an internal conversion clock, and a versatile serial interface port. The part also contains a low noise, wide bandwidth, short aperture delay track-and-hold circuit. On the CNV rising edge, the AD7686 samples an analog input IN+ between 0 V to REF with respect to a ground sense IN?. The reference voltage, REF, is applied externally and can be set up to the supply voltage.Power dissipation scales linearly with throughput.The SPI-compatible serial interface also features the ability, using the SDI input, to daisy-chain several ADCs on a single, 3-wire bus or provides an optional busy indicator. This device is compatible with 1.8 V, 2.5 V, 3 V, or 5 V logic, using the separate supply VIO.The AD7686 is housed in a 10-lead MSOP or a 10-lead QFN (LFCSP) with operation specified from ?40?C to +85?C.APPLICATIONS Battery-powered equipment Data acquisitions Instrumentation Medical instruments Process controls

The AD7688 is a 16-bit, 500 kSPS, charge redistribution successive-approximation Analog-to-Digital Converter which operates from a single 5V power supply, VDD. It contains a very low power high-speed 16-bit sampling ADC with no missing codes, an internal conversion clock and a versatile serial interface port. The part also contains a low noise, wide bandwidth, very short aperture delay track/hold circuit. On the CNV rising edge, it samples the voltage difference between IN+ and IN- pins. The voltages on these pins usually swing in opposite phase between 0 V to REF. The reference voltage REF is applied externally and can be set up to the supply voltage.Its power scales linearly with throughput.The SPI compatible serial interface also features the ability, using the SDI input, to ?Daisy chain? several ADCs on a single 3 wire bus and provides an optional Busy indicator. It is compatible with 1.8 V, 2.5 V, 3 V or 5 V logic using the separate supply VIO.The AD7688 is housed in a 10-lead ?SOIC or 10-lead QFN (Chip Scale package) with operationAPPLICATIONS Battery Powered Equipment Medical instruments Mobile communications Personal digital assistants Data Acquisition Instrumentation Medical Instruments Process Control

The AD7770 is an 8-channel, simultaneous sampling ADC. Eightfull sigma-delta (?-?) ADCs are on chip. The AD7770 providesa low input current to allow direct sensor connection. Each inputchannel has a programmable gain stage allowing gains of 1, 2, 4,and 8 to map lower amplitude sensor outputs into the full-scaleADC input range, maximizing the dynamic range of the signalchain. The AD7770 accepts a VREF voltage from 1 V up to 3.6 V.The analog inputs accept unipolar (0 V to VREF) or true bipolar(?VREF/2) analog input signals with 3.3 V or ?1.65 V analogsupply voltages, respectively for PGAGAIN = 1. The analog inputscan be configured to accept true differential, pseudo differential,or single-ended signals to match different sensor outputconfigurations.Each channel contains a PGA, an ADC modulator and asinc3, low latency digital filter. An SRC is provided to allow fineresolution control over the AD7770 ODR. This control can beused in applications where the ODR resolution is required tomaintain coherency with 0.01 Hz changes in the line frequency.The SRC is programmable through the serial port interface (SPI).The AD7770 implements two different interfaces: a data outputinterface and SPI control interface. The ADC data output interfaceis dedicated to transmitting the ADC conversion results fromthe AD7770 to the processor. The SPI writes to and reads fromthe AD7770 configuration registers and for the control andreading of data from the SAR ADC. The SPI can also beconfigured to output the ?-? conversion data.The AD7770 includes a 12-bit SAR ADC. This ADC can beused for AD7770 diagnostics without having to decommissionone of the ?-? ADC channels dedicated to system measurementfunctions. With the use of an external multiplexer, which can becontrolled through the three general-purpose input/output pins(GPIOs), and signal conditioning, the SAR ADC can validatethe ?-? ADC measurements in applications where functionalsafety is required. In addition, the AD7770 SAR ADC includesan internal multiplexer to sense internal nodes.The AD7770 contains a 2.5 V reference and reference buffer. Thereference has a typical temperature coefficient of 10 ppm/?C.The AD7770 offers two modes of operation: high resolution modeand low power mode. High resolution mode provides a higherdynamic range while consuming 10.75 mW per channel; lowpower mode consumes just 3.37 mW per channel at a reduceddynamic range specification.The specified operating temperature range is ?40?C to +105?C,although the device is operational up to +125?C.Applications Protection relays General-purpose data acquisition Industrial process control

The AD7961 is a 16-bit, 5 MSPS charge redistribution successive approximation (SAR), analog-to-digital converter (ADC). The SAR architecture allows unmatched performance both in noiseand in linearity. The AD7961 contains a low power, high speed, 16-bit sampling ADC, an internal conversion clock and an internal reference buffer. On the CNV edge, the AD7961samples the voltage difference between the IN+ and IN? pins. The voltages on these pins swing in opposite phase between 0 V and 4.096 V/5 V. The reference voltage is applied to the partexternally. All conversion results are available on a single LVDS self-clocked or echo-clocked serial interface.The AD7961 is available in a 32-lead LFCSP (QFN) with operation specified from ?40?C to +85?C.APPLICATIONS Digital imaging systems ?Digital X-rays ?Computed tomography ?IR cameras MRI gradient control High speed data acquisition Spectroscopy Test equipment

The AD7992 is a 12-bit, low power, successive approximation ADC with an I2 C-compatible interface. The part operates from a single 2.7 V to 5.5 V power supply and features a 2 ?s conversion time. The part contains a 2-channel multiplexer and track-and-hold amplifier that can handle input frequencies up to 11 MHz. The AD7992 provides a 2-wire serial interface compatible with I2C interfaces. The part comes in two versions, the AD7992-0 and the AD7992-1, and each version allows for at least two different I2C addresses. The AD7992-0 supports standard and fast I2C interface modes, and the AD7992-1 supports standard, fast, and high speed I2C interface modes. The AD7992 normally remains in a shutdown state while not converting, and powers up only for conversions. The conversion process can be controlled using the CONVST pin, by a command mode where conversions occur across I2C write operations, or an automatic conversion interval mode selected through software control. The AD7992 requires an external reference in the range of 1.2 V to VDD. This allows the widest dynamic input range to the ADC. On-chip limit registers can be programmed with high and low limits for the conversion result, and an open-drain, out-of-range indicator output (ALERT) becomes active when the conversion result violates the programmed high or low limits. This output can be used as an interrupt.PRODUCT HIGHLIGHTS 2 ?s conversion time and low power consumption. I2C-compatible serial interface with pin-selectable addresses. Two AD7992 versions allow five AD7992 devices to be connected to the same serial bus. The part features automatic shutdown while not converting to maximize power efficiency. Current consumption is 1 ?A max when in shutdown mode at 3 V. Reference can be driven up to the power supply. Out-of-range indicator that can be software disabled or enabled. One-shot and automatic conversion rates. Registers store minimum and maximum conversion results.

The ADA4522-1 / ADA4522-2 / ADA4522-4 are single/dual/quadchannel, zero drift op amps with low noise and power, groundsensing inputs, and rail-to-rail output, optimized for totalaccuracy over time, temperature, and voltage conditions. Thewide operating voltage and temperature ranges, as well as thehigh open-loop gain and very low dc and ac errors make thedevices well suited for amplifying very small input signals andfor accurately reproducing larger signals in a wide variety ofapplications.The ADA4522-1 / ADA4522-2 / ADA4522-4 performance isspecified at 5.0 V, 30 V, and 55 V power supply voltages. Thesedevices operate over the range of 4.5 V to 55 V, and are excellentfor applications using single-ended supplies of 5 V, 10 V, 12 V,and 30 V, or for applications using higher single supplies anddual supplies of ?2.5 V, ?5 V, and ?15 V. The ADA4522-1 / ?ADA4522-2 / ADA4522-4 use on-chip filtering to achieve highimmunity to electromagnetic interference (EMI).The ADA4522-1 / ADA4522-2 / ADA4522-4 are fully specifiedover the extended industrial temperature range of ?40?C to+125?C and are available in 8-lead MSOP, 8-lead SOIC, 14-leadSOIC, and 14-lead TSSOP packages.APPLICATIONS Inductance, capacitance, and resistance (LCR) meter/megohmmeter front-end amplifiers Load cell and bridge transducers Magnetic force balance scales High precision shunt current sensing Thermocouple/resistance temperature detector (RTD) sensors Programmable logic controller (PLC) input and output amplifiers
