DC1790A-B
Analog Devices Inc.The LTM2886 is a complete galvanic digital ?Module? (micromodule) isolator. No external components are required. A single 3.3V or 5V supply powers both sides of the interface through an integrated, isolated DC/DC converter. A logic supply pin allows easy interfacing with different logic levels from 1.62V to 5.5V, independent of the main supply.Available options are compliant with SPI and I2C (master mode only) specifications.The isolated side includes fixed ?5V and 5V adjustable power supplies, each capable of providing more than 100mA of load current. The 5V adjustable supply may be programmed via an external voltage divider.Coupled inductors and an isolation power transformer provide 2500VRMS of isolation between the input and output logic interface. This device is ideal for systems where the ground loop is broken, allowing for a large common mode voltage range. Communication is uninterrupted for common mode transients greater than 30kV/?s.Applications Isolated SPI or I2C Interfaces Industrial Systems Test and Measurement Equipment Breaking Ground Loops
DC1790A-D
Analog Devices Inc.The LTM2886 is a complete galvanic digital ?Module? (micromodule) isolator. No external components are required. A single 3.3V or 5V supply powers both sides of the interface through an integrated, isolated DC/DC converter. A logic supply pin allows easy interfacing with different logic levels from 1.62V to 5.5V, independent of the main supply.Available options are compliant with SPI and I2C (master mode only) specifications.The isolated side includes fixed ?5V and 5V adjustable power supplies, each capable of providing more than 100mA of load current. The 5V adjustable supply may be programmed via an external voltage divider.Coupled inductors and an isolation power transformer provide 2500VRMS of isolation between the input and output logic interface. This device is ideal for systems where the ground loop is broken, allowing for a large common mode voltage range. Communication is uninterrupted for common mode transients greater than 30kV/?s.Applications Isolated SPI or I2C Interfaces Industrial Systems Test and Measurement Equipment Breaking Ground Loops
LTC3260EMSE Demo Board | Low Noise Dual Supply Inverting Charge Pump Plus ±LDO, 4.5V ≤ VIN ≤ 32V, VOUT = ±3.3V/±5V/±12V/±24V/±Adj @ ±50mA
Analog Devices Inc.Demonstration circuit 1793A is a high voltage inverting charge pump with low noise dual-polarity LDO regulators featuring the LTC3260EMSE. The LTC3260 operates with an input voltage from 4.5V to 32V. The demo board provides selectable LDO± output set magnitudes of 3.3V, 5V, 12V and 24V for each polarity. Additional LDO± set point jumper selections and optional topside ADJ± resistors allow the user to set other desired LDO± output voltages. The demo board also provides the means to select between Burst Mode® operation or constant-frequency mode operation, plus select an operating frequency of 500kHz, 200kHz, and 50kHz.
LTC6360 Driving LTC2367-16 Demo Board | 16-Bit, 0.5Msps SAR ADC (Requires DC590 or DC718)
Analog Devices Inc.DC1796A-C Demo Board for:
LTC6360 Very Low Noise Single-Ended SAR ADC Driver with True Zero Output
LTC2367-16 16-Bit, 500ksps, Pseudo- Differential Unipolar SAR ADC with 94.7dB SNR
LTC6362 with 2Msps 16-bit LTC2380-16 Demo Board | SAR ADC, LTC6655-5. Requires DC718 or DC2026
Analog Devices Inc.DC1805A-A Demo Board for:
LTC2380-16 16-Bit, 2Msps, Low Power SAR ADC with 96dB SNR
LTC6362 Precision, Low Power Rail-to-Rail Input/Output Differential Op Amp/SAR ADC Driver
LTC6655 0.25ppm Noise, Low Drift Precision References
LTC3869EUFD Demo Board | VIN = 4.5V to 14V, VOUT1 = 1.5V @15A, VOUT2 = 1.2V @ 15A, with RSENSE
Analog Devices Inc.Demonstration circuit 1807A is a dual output, dual phase synchronous buck converter featuring the LTC3869EUFD. The input voltage range is 4.5V to 14V, output voltages and currents are 1.5V/15A and 1.2V/15A. Two versions of the board are available. DC1807A-A has an on-board sense resistor for current feedback, while the DC1807A-B is configured with a DCR sense circuit that allows the converter to use the inductors DCR as the sense element instead of the on-board sense resistors to save cost and board space and improves efficiency.
LTC3869EUFD Demo Board | VIN = 4.5V to 14V, VOUT1 = 1.5V @15A, VOUT2 = 1.2V @ 15A, with DCR Sense
Analog Devices Inc.Demonstration circuit 1807A is a dual output, dual phase synchronous buck converter featuring the LTC3869EUFD. The input voltage range is 4.5V to 14V, output voltages and currents are 1.5V/15A and 1.2V/15A. Two versions of the board are available. DC1807A-A has an on-board sense resistor for current feedback, while the DC1807A-B is configured with a DCR sense circuit that allows the converter to use the inductors DCR as the sense element instead of the on-board sense resistors to save cost and board space and improves efficiency.
LTC2943-1 Demo Board | 20VIN, 1A Battery Gas Gauge w/ Internal RSENSE (requires DC2026)
Analog Devices Inc.Demonstration circuit 1812A-C features the LTC2943-1. The LTC2943-1 has an operating range of 3.6V to 20V making it perfectly suited for multicell battery applications. A precision analog coulomb counter integrates current measured through the internal sense resistor. The LTC2943-1 measures voltage, current and temperature with an internal 14-bit No Latency ΔΣ™ ADC. The measurements are stored in internal registers accessible via the onboard SMBus/I2C interface.
LTC4415EMSE Demo Board I Dual 4A Ideal Diodes with Adjustable Current Limit
Analog Devices Inc.DC1819A: Demo Board for the LTC4415 Dual 4A Ideal Diodes with Adjustable Current Limit,
LTC2389-16 with LTC6655/LT6201, 16-Bit, 2.5Msps, Serial/Parallel SAR ADC with 96dB SNR. Requires DC718
Analog Devices Inc.DC1826A-E Demo Board for:
LTC2389-16 16-Bit, 2.5Msps SAR ADC with Pin-Configurable Analog Input Range and 96dB SNR
LTC6655 0.25ppm Noise, Low Drift Precision References
LT6201 Dual 165MHz, Rail-to-Rail Input and Output, 0.95nV/√Hz Low Noise, Op Amp Family
LTC4000EUFD-1 Demo Board I 20V ≤ VIN ≤ 60V, Battery Charger Controller and PowerPath Manager, MPPC, VOUT = 14.6V @ 5A
Analog Devices Inc.Demonstration circuit 1830B is a battery charger controller and PowerPath™ manager with maximum power point control (MPPC) featuring the LTC4000-1. MPPC extracts near maximum power from high impedance sources such as solar panels, wind turbines or fuel cells. MPPC is achieved by means of an input voltage regulation control loop. This board should be connected to a front-end DC/DC power supply for a complete charger solution.
LTC2955IDDB-2 | Pushbutton On/Off Controller with Automatic Turn On (EN Output)
Analog Devices Inc.DC1836A-B: Demo Board for the LTC2955 Pushbutton On/Off Controller with Automatic Turn-On.
LTC1598CG | 12-Bit, Low Power, 8-Channel, Serial ADC
Analog Devices Inc.DC183A: Demo Board for the LTC1598 8-Channel, Micropower Sampling 12-Bit Serial I/O A/D Converter.
DC1846A-A
Analog Devices Inc.The LTC6947 is a high performance, low noise, 6GHz phase-locked loop (PLL), including a reference divider, phase-frequency detector (PFD), ultralow noise charge pump, fractional feedback divider, and VCO output divider.The fractional divider uses an advanced, 4th order ?? modulator which provides exceptionally low spurious levels. This allows wide loop bandwidths, producing extremely low integrated phase noise values.The programmable VCO output divider, with a range of 1 through 6, extends the output frequency range. The differential, low-noise output buffer has user-programmable output power ranging from ?4.3dBm to +4.5dBm, and may be muted through either a digital input pin or software.The ultralow noise charge pump contains selectable high and low voltage clamps useful for VCO monitoring, and also may be set to provide a V+/2 bias.All device settings are controlled through a SPI-compatible serial port.Applications Wireless Basestations (LTE, WiMAX, W-CDMA, PCS) Broadband Wireless Access Microwave Data Links Military and Secure Radio Test and Measurement
LTC2872 RS232/RS485 Dual Multiprotocol Transceiver with Integrated Termination
Analog Devices Inc.DC1851A: Demo Board for the LTC2872 RS232/RS485 Dual Multiprotocol Transceiver with Integrated Termination.
LTC3536EMSE (MSOP) Demo Board | 1.8V ≤ VIN ≤ 5.5V, VOUT = 3.3V @ 1A
Analog Devices Inc.Demonstration circuit 1852A is a combined step-up and step-down DC/DC converter, using the LTC3536 monolithic synchronous buck-boost regulator in the MSOP package. The DC1852A has wide input voltage range of 1.8V to 5.5V and is capable of delivering up to 1A of output current. The output voltage of the DC1852A can be set as low as 1.8V and can go as high as 5.5V. DC1852A supports two operation modes: fixed-frequency pulse-width modulation (PWM) and Burst Mode® operation.
DC1856B-B
Analog Devices Inc.The LTM4649 is a complete 10A high efficiency switching mode step-down DC/DC ?Module? regulator in a 9mm ? 15mm ? 4.92 BGA package. Included in the package are the switching controller, power FETs, inductor, and all support components. Operating over an input voltage range of 4.5V to 16V, the LTM4649 supports an output voltage range of 0.6V to 3.3V, set by a single external resistor. This high efficiency design delivers 10A continuous current. Only bulk input and output capacitors are needed.High switching frequency and a current mode architecture enable a very fast transient response to line and load changes without sacrificing stability. The device supports frequency synchronization, programmable multiphase operation, and output voltage tracking for supply rail sequencing.Fault protection features include output overvoltage and overcurrent protection. The LTM4649 is offered in a small 9mm ? 15mm ? 4.92mm BGA package available with SnPb or RoHS compliant terminal finish.Applications Telecom, Networking and Industrial Equipment Point of Load Regulation
DC1864A
Analog Devices Inc.The LTC3621/LTC3621-2 is a high efficiency 17V, 1A synchronous monolithic step-down regulator. The switching frequency is fixed to 1MHz or 2.25MHz with a ?40% synchronizing range. The regulator features ultralow quiescent current and high efficiencies over a wide VOUT range.The step-down regulator operates from an input voltage range of 2.7V to 17V and provides an adjustable output range from 0.6V to VIN while delivering up to 1A of output current. A user-selectable mode input is provided to allow the user to trade off ripple noise for light load efficiency; Burst Mode operation provides the highest efficiency at light loads, while pulse-skipping mode provides the lowest voltage ripple. The MODE pin can also be used to allow the user to sync the switching frequency to an external clock. LTC3621 Options Part Name Frequency VOUT LTC3621 1.00MHz Adjustable LTC3621-3.3 1.00MHz 3.3V LTC3621-5 1.00MHz 5V LTC3621-2 2.25MHz Adjustable LTC3621-23.3 2.25MHz 3.3 LTC3621-25 2.25MHz 5V APPLICATIONS Portable-Handheld Scanners Industrial and Embedded Computing Automotive Applications Emergency Radio
LT1374CR | 4.5A SWITCH, 500kHz STEP-DOWN REGULATOR, 5.5V to 25VIN, 3.3V or 5.0V @ 4A OUTPUT, DD PACKAGE
Analog Devices Inc.DC187A-A: Demo Board for the LT1374 4.5A, 500kHz Step-Down Switching Regulator.
DC1884A-C
Analog Devices Inc.The LTM9011-14/LTM9010-14/LTM9009-14 are 8-channel, simultaneous sampling 14-bit A/D converters designed for digitizing high frequency, wide dynamic range signals. AC performance includes 73.1dB SNR and 88dB spurious free dynamic range (SFDR). Low power consumption per channel reduces heat in high channel count applications. Integrated bypass capacitance and flow-through pinout reduces overall board space requirements.DC specs include ?1LSB INL (typ), ?0.3LSB DNL (typ) and no missing codes over temperature. The transition noise is a low 1.2LSBRMS.The digital outputs are serial LVDS to minimize the number of data lines. Each channel outputs two bits at a time (2-lane mode). At lower sampling rates there is a one bit per channel option (1-lane mode).The ENC+ and ENC? inputs may be driven differentially or single-ended with a sine wave, PECL, LVDS, TTL, or CMOS inputs. An internal clock duty cycle stabilizer allows high performance at full speed for a wide range of clock duty cycles.Applications Communications Cellular Base Stations Software Defined Radios Portable Medical Imaging Multichannel Data Acquisition Nondestructive Testing
