The ADuM3190S is an isolated error amplifier based on Analog Devices, Inc., iCoupler? technology. The ADuM3190S is ideal for linear feedback power supplies. The primary side controllers of the ADuM3190S enable improvements in transient response, power density, and stability as compared to commonly used optocoupler and shunt regulator solutions.Unlike optocoupler-based solutions, which have an uncertain current transfer ratio over lifetime and at high temperatures, the ADuM3190 transfer function does not change over its lifetime, and it is stable over a wide temperature range of ?55?C to +125?C.Included in the ADuM3190S is a wideband operational amplifier for a variety of commonly used power supply loop compensation techniques. The ADuM3190S is fast enough to allow a feedback loop to react to fast transient conditions and overcurrent conditions. Also included is a high accuracy 1.225 V reference to compare with the supply output setpoint.The ADuM3190S is packaged in a small 16-lead flatpack package for a 500 V rms isolation voltage rating.APPLICATIONS Linear power supplies Inverters Uninterruptible Power Supply (UPS) DOSA-compatible modules Voltage monitors

The ADuM4070 is a regulated DC/DC isolated power supply controller with an internal MOSFET driver. The DC/DC controller has an internal isolated PWM feedback from the secondary side based on the?iCoupler? chip scale transformer technology and complete loop compensation. This eliminates the need to use an optocoupler for feedback and compensates the loop for stability.The ADuM4070 isolator provides a more stable output voltage and higher efficiency compared to unregulated isolated DC/DC jpower supplies. The fully integrated feedback and loop compensation in a wide-body SOIC package provide a smaller form factor and 8.3 mm creepage distance solution. The regulated feedback provides a relatively flat efficiency curve over the full output power range. The ADuM3070 enables a DC/DC converter with a 3.3 V to 24 V isolated output voltage range from either a 5.0 V or a 3.3 V input voltage, with an output power of up to 2.5 W.Applications Power supply startup bias and gate drives Isolated sensor interfaces Process controls

The ADuM4146 is a single-channel gate driver specifically optimized for driving silicon carbide (SiC), metal-oxide semiconductor field effect transistors (MOSFETs). Analog Devices, Inc., iCoupler? technology provides isolation between the input signal and the output gate drive.The ADuM4146 includes a Miller clamp to provide robust SiC turn off with a single-rail supply when the gate voltage drops to less than 2 V. Operation with unipolar or bipolar secondary supplies is possible with or without the Miller clamp operation.The Analog Devices chip scale transformers also provide isolated communication of control information between the high voltage and low voltage domains of the chip. Information on the status of the chip can be read back from dedicated outputs. Control of resetting the device after a fault on the secondary side is performed on the primary side of the device.Integrated onto the ADuM4146 is a desaturation detection circuit that provides protection against high voltage short-circuit SiC operation. The desaturation protection contains noise reducing features, such as a 300 ns masking time after a switching event to mask voltage spikes due to initial turn on (see Figure 17 in the data sheet). An optional internal 500 ?A current source allows low device count, and the internal blanking switch allows the addition of an external current source if more noise immunity is needed.The secondary undervoltage lockout (UVLO) is set to 14.5 V (typical) for Grade A and is set to 11.5 V (typical) for Grade B and Grade C with common SiC and insulated gate bipolar transistor (IGBT) levels taken into consideration. APPLICATIONS SiC/MOSFET/IGBT gate drivers Photovoltaic (PV) inverters Motor drives Power supplies

The ADuM4165/ADuM4166 are USB 2.0 port isolators, utilizing Analog Devices, Inc., iCoupler? technology to dynamically support all USB 2.0 data rates; low (1.5 Mbps), full (12 Mbps), or high (480 Mbps), as required. The devices support host isolation with automatic speed negotiation as well as peripheral isolation.High speed data is retimed for jitter reduction, requiring an external clock signal or crystal input. The ADuM4165 supports the clock or crystal input on the upstream side, and the ADuM4166 supports the clock or crystal input on the downstream side, offering two options to best suit the system design.The low power standby mode for downstream (Side 2) supports applications with limited available power, such as battery-operated peripherals. The upstream (Side 1) standby current meets USB 2.0 requirements for suspended operation.The isolators are specified over an extended industrial temperature range of ?55?C to +125?C and are available in a 20-lead, wide-body, increased creepage SOIC_IC with 8.3 mm creepage and clearance.APPLICATIONS USB peripheral, USB host, and USB hub isolation Electronic test and measurement equipment Medical devices and integrated PCs Industrial PCs and isolated USB ports for debug or upgrade USB isolator modules and USB cable isolatorsProtected by U.S. Patents 7,075,329; 8,432,182; 8,525,547; and 8,564,327. Other patents are pending.

The ADV7172 / ADV7173?is an integrated Digital Video Encoder that converts digital CCIR-601 4:2:2 8-bit component video data into a standard analog baseband television signal compatible with worldwide standards.There are six DACs available on the ADV7172 / ADV7173. In addition to the Composite output signal there is the facility to output S-VHS Y/C Video, RGB Video and YUV Video.The on-board SSAF (Super Sub-Alias Filter), with extended luminance frequency response and sharp stopband attenuation, enables studio quality video playback on modern TVs, giving optimal horizontal line resolution. An additional sharpness control feature allows extra luminance boost on the frequency response.An advanced power management circuit enables optimal control of power consumption in both normal operating modes and power down or sleep modes. A PC?98-Compliant autodetect feature has been added to allow the user to determine whether or not the DACs are correctly terminated. If not, the ADV7172 /? ADV7173 flags that they are not connected through the Status bit and provides the option of automatically powering them down, thereby reducing power consumption.The ADV7172 / ADV7173 also supports both PAL and NTSC square pixel operation. The parts also incorporate WSS and CGMS-A data control generation.APPLICATIONS High Performance DVD Playback Systems Portable Video Equipment including Digital Still Cameras and Laptop PCs Video Games PC Video/Multimedia and Digital Satellite/Cable Systems (Set-Top Boxes/IRD)

The ADV7180 automatically detects and converts standard analog baseband television signals compatible with worldwide NTSC, PAL, and SECAM standards into 4:2:2 component video data compatible with the 8-bit ITU-R BT.656 interface standard.The simple digital output interface connects gluelessly to a wide range of MPEG encoders, codecs, mobile video processors, and Analog Devices, Inc., digital video encoders, such as the ADV7391. External HS, VS, and FIELD signals provide timing references for LCD controllers and other video ASICs, if required. Accurate 10-bit analog-to-digital conversion provides professional quality video performance for consumer applications with true 8-bit data resolution. Three analog video input channels accept standard composite, S-video, or component video signals, supporting a wide range of consumer video sources. AGC and clamp-restore circuitry allow an input video signal peak-to-peak range to 1.0 V. Alternatively, these can be bypassed for manual settings.The line-locked clock output allows the output data rate, timing signals, and output clock signals to be synchronous, asynchronous, or line locked even with ?5% line length variation. Output control signals allow glueless interface connections in many applications. The ADV7180 is programmed via a 2-wire, serial bidirectional port (I2C? compatible) and is fabricated in a 1.8 V CMOS process. Its monolithic CMOS construction ensures greater functionality with lower power dissipation. LFCSP package options makes the decoder ideal for space-constrained portable applications. A 64-lead LQFP package is pin compatible with the ADV7181C.The 48-Lead LQFP, 40-lead LFCSP, and 32-lead LFCSP use one pin to output VS or FIELD.APPLICATIONS Digital camcorders and PDAs Low cost SDTV PIP decoder for digital TVs Multichannel DVRs for video security AV receivers and video transcoding PCI-/USB-based video capture and TV tuner cards Personal media players and recorders Smartphone/multimedia handsets In-car/automotive infotainment units Rearview camera/vehicle safety systems

The ADV7614 is a high quality, single-chip integrated 4:1 multiplexed High-Definition Multimedia Interface (HDMI?) receiver. The ADV7614 incorporates a quad input HDMI receiver that supports all HDTV formats up to 1080p and displays resolutions up to UXGA (1600 ? 1200 at 60 Hz). The reception of encrypted video is possible with the inclusion of HDCP. The HDMI receiver also includes programmable/adaptive equalization that ensures robust operation of the interface with cable lengths up to 30 meters.The ADV7614 provides complete audio support for eight channels of I2S audio, Sony/Philips digital interface format (S/PDIF) digital audio output, and super audio CD (SACD) and compressed SACD support with direct stream digital (DSD) and direct stream transfer (DST) output interfaces, respectively.The HDMI receiver also supports high bit rate (HBR) audio streaming to allow recovery (and downstream processing) of compressed lossless audio formats, including Dolby? TrueHD and DTS?-HD master audio or DTS-HD high resolution audio. In addition, it also provides an advanced audio functionality, such as a mute controller that prevents audible extraneous noise in the audio output.Fabricated in an advanced CMOS process, the ADV7614 is provided in a space-saving, 260-ball, 15 mm ? 15 mm, CSP_BGA surface-mount, RoHS-compliant package, and is specified over the ?40?C to +70?C temperature range. APPLICATIONS Advanced TVs AVR video receivers PDP HDTVs LCD TVs (HDTV ready) OLED HDTVs LCD/DLP front projectors HDMI switcher

The ADV7625 is a high performance, five-input, dual-output, High-Definition Multimedia Interface (HDMI?) transceiver with crosspoint and splitter capabilities. The ADV7625 supports 3 GHz video and features two independent HDMI receivers, two independent HDMI transmitters, two audio output ports, two audio input ports, and a pixel port input. The ADV7625 supports all HDCP repeater functions through fully tested Analog Devices, Inc., repeater software libraries and drivers.The HDMI receivers and transmitters in the ADV7625 support the reception and transmission of 3 GHz video formats up to 4k ? 2k at 24 Hz/25 Hz/30 Hz, in addition to all mandatory HDMI 3D TV formats. The receivers and transmitters also provide support for THX? Media Director?.Each HDMI receiver features an integrated equalizer that ensures robust operation of the interface with cable lengths up to 30 meters. The HDMI receivers share a 768-byte volatile extended display identification data (EDID) memory, which can facilitate one or two EDIDs, one for each receiver. Each HDMI port features dedicated 5 V detect and Hot Plug? assert pins.Each HDMI transmitter supports audio return channel (ARC) and features an integrated HDMI CEC controller that supports capability discovery and control (CDC).The ADV7625 offers two audio output ports and two audio input ports. Each audio port supports the extraction and insertion of up to eight channels of audio data out of or into the HDMI streams. HDMI audio formats, including I2S, S/PDIF, direct stream digital (DSD), and high bit rate (HBR) audio are supported.The ADV7625 features a TTL pixel port input that facilitates the reception of digital video data from an analog front-end decoder (for example, the ADV7180, ADV7181D, or ADV7842).The ADV7625 has an integrated on-screen display (OSD) generator that enables the creation and control of high quality character- and icon-based system status and control displays. The OSD can be overlaid on 3 GHz video formats and 3D video. Customers who are interested in using OSD are provided with Blimp, the Analog Devices OSD development tool.The ADV7625 is provided in a space-saving, 260-ball, 15 mm ? 15 mm CSP_BGA surface-mount, RoHS-compliant package and is specified over the 0?C to 70?C temperature range. APPLICATIONS AVRs Soundbar with HDMI repeater support Matrix switch Other repeater applications

The ADV7840 is a high quality, single chip, multiformat video decoder graphics digitizer with an integrated 4:1 multiplexed HDMI? receiver.This multiformat 3D comb filter decoder supports the conversion of PAL, NTSC, and SECAM standards in the form of a compositeor an S-Video input signal into a digital ITU-R BT.656 format.SCART and overlay functionality are enabled by the ability of theADV7840 to process CVBS and standard definition RGB signals simultaneously.The ADV7840 contains one main component processor (CP),which processes YPrPb and RGB component formats, including RGB graphics. The CP also processes the video signals from theHDMI receiver. The ADV7840 can operate in quad HDMI andanalog input mode, thus allowing for fast switching between theADCs and HDMI.The ADV7840 supports the decoding of a component RGB/YPrPb video signal into a digital YCrCb or RGB pixel output stream. The support for component video includes 525i, 625i,525p, 625p, 720p, 1080i, 1080p, and 1250i standards, as well asmany other HD and SMPTE standards.Graphics digitization is also supported by the ADV7840. TheADV7840 is capable of digitizing RGB graphics signals from VGA to UXGA rates and converting them into a digital RGB or YCrCb pixel output stream.The ADV7840 incorporates a quad input HDMI 1.3-compatible receiver that supports all HDTV formats up to 1080p and display resolutions up to UXGA (1600 ? 1200 at 60 Hz). The reception of encrypted video is possible with the inclusion of HDCP. The HDMI receiver also includes programmable equalization that ensures robust operation of the interface with cablelengths up to 30 meters. The HDMI receiver has advanced audio functionality, such as a mute controller, that prevents audible extraneous noise in the audio output.Fabricated in an advanced CMOS process, the ADV7840 is provided in a 19 mm ? 19 mm, 416-ball, CSP_BGA, surface-mount, RoHS-compliant package and is specified over the 0?C to +70?C temperature range.ApplicationsAdvanced TVsPDP HDTVsLCD TVs (HDTV ready)LCD/DLP? rear projection HDTVsCRT HDTVsLCoS? HDTVsAVR video receiversLCD/DLP front projectorsHDTV STBs with PVRCRT HDTVProjectorsDVD recorders with progressive scan input support

The ADXL1004 delivers ultralow noise density over an extended frequency range and is optimized for bearing fault detection and diagnostics. The ADXL1004 has typical noise density of 125 ?g/?Hz across the linear frequency range. Microelectronicmechanical systems (MEMS) accelerometers have stable and repeatable sensitivity, and are immune to external shocks up to 10,000 g.The integrated signal conditioning electronics enable such features as full electrostatic self test (ST) and an overrange (OR) indicator, useful for embedded applications. With low power and single-supply operation of 3.3 V to 5.25 V, the ADXL1004 also enables wireless sensing product design. The ADXL1004 is available in a 5 mm ? 5 mm ? 1.80 mm LFCSP package, and operates over the ?40?C to +125?C temperature range.Applications Condition monitoring Predictive maintenance Asset health Test and measurement Health usage monitoring system (HUMSs) Acoustic emissions

The ADXL195?/ ADXL295 are dual spectrum accelerometers that measure baseband acceleration in up to two axes (XL-X and XL-Y), as well as high frequency (HF) acceleration energy. Identical, independent X and Y sense structures are implemented to achieve the best possible fail-safe performance.The XL-X and XL-Y channels output baseband acceleration information with a nominal full-scale range of ?120 g and a bandwidth of 408 Hz. The acceleration data is provided as a 12-bit, twos complement word with a resolution of 62.5 mg/LSB.HF acceleration within the frequency band of 15.5 kHz to 23 kHz is rectified and filtered to generate an average g (gAVG) energy measurement. The HF channel has a nominal full-scale range of 40 gAVG and a bandwidth of 393 Hz. When combined with the XL-X and XL-Y information, HF acceleration information allows for enhanced vehicle impact detection and discrimination.The ADXL195 / ADXL295 are available in a 16-lead, narrow-body SOIC package with an exposed pad. The ADXL195 / ADXL295 can operate at 3.3 V and 5 V and are specified for operation from ?40?C to +105?C.APPLICATIONS Enhanced crash sensing Shock detection

The ADXL312 is a small, thin, low power, 3-axis accelerometer with high resolution (13-bit) measurement up to ?12 g. Digital output data is formatted as 16-bit twos complement and is accessible through either a serial port interface (SPI) (3- or 4-wire) or I2C digital interface.The ADXL312 is well suited for car alarm or black box applications. It measures the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion or shock. Its high resolution (2.9 mg/LSB) enables resolution of inclination changes of as little as 0.25?. A built-in FIFO facilitates using oversampling techniques to improve resolution to as little as 0.05? of inclination.Several special sensing functions are provided. Activity and inactivity sensing detects the presence or absence of motion and whether the acceleration on any axis exceeds a user-set level. These functions can be mapped to interrupt output pins. An integrated 32 level FIFO can be used to store data to minimize host processor intervention.Low power modes enable intelligent motion-based power management with threshold sensing and active acceleration measurement at extremely low power dissipation.The ADXL312 is supplied in a small, thin 5 mm ? 5 mm ? 1.45 mm, 32-lead, LFCSP package.Applications Car alarm Hill start aid (HSA) Electronic parking brake Data recorder (black box)

The ADXL314 is a ?200 g range, 13-bit resolution, 3-axis digital accelerometer. The digital output data is formatted as 16-bit, twos complement data and is accessible through a serial peripheral interface (SPI), 3-wire or 4-wire, or an I2C digital interface.An integrated memory management system with a 32 level, first in, first out (FIFO) buffer can store data to minimize host processor activity and lower overall system power consumption.Low power modes enable intelligent motion-based power management with threshold sensing and active acceleration measurement at low power dissipation, typically 65 ?A for VS = 2.5 V at a 100 Hz output data rate (ODR).The ADXL314 is supplied in a small, thin 5 mm ? 5 mm ? 1.45 mm, 32-lead LFCSP.APPLICATIONS Tire and battery pack monitoring High force event detection

The ADXL343 is a versatile 3-axis, digital-output, low?g MEMS accelerometer. Selectable measurement range and bandwidth, and configurable, built-in motion detection make it suitable for sensing acceleration in a wide variety of applications. Robustness to 10,000 g?of shock and a wide temperature range (?40?C to +85?C) enable use of the accelerometer even in harsh environments.The ADXL343 measures acceleration with high resolution (13-bit) measurement at up to ?16g. Digital output data is formatted as 16-bit twos complement and is accessible through either an SPI (3- or 4-wire) or I2C digital interface. The ADXL343 can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion or shock. Its high resolution (3.9 mg/LSB) enables measurement of inclination changes less than 1.0?.Several special sensing functions are provided. Activity and inactivity sensing detect the presence or lack of motion. Tap sensing detects single and double taps in any direction. Free-fall sensing detects if the device is falling. These functions can be mapped individually to either of two interrupt output pins.An integrated memory management system with a 32-level first in, first out (FIFO) buffer can be used to store data to minimize host processor activity and lower overall system power consumption.The ADXL343 is supplied in a small, thin, 3 mm ? 5 mm ? 1 mm, 14-terminal, plastic package.APPLICATIONS Handsets Gaming and pointing devices Hard disk drive (HDD) protection

The high performance ADXL350 is a small, thin, low power,3-axis accelerometer with high resolution (13-bit) and selectablemeasurement ranges up to ?8?g. The ADXL350 offers industry-leading temperature performance with guaranteed min/max specification for offset over temperature. Digital output data isformatted as 16-bit twos complement and is accessible througheither a SPI (3- or 4-wire) or I2C digital interface.The ADXL350 is well suited for high performance portableapplications. It measures the static acceleration of gravity in tilt sensingapplications, as well as dynamic acceleration resultingfrom motion or shock. Its high resolution (2 mg/LSB) enablesmeasurement of inclination changes of less than 1.0?.Several special sensing functions are provided. Activity andinactivity sensing detect the presence or lack of motion and ifthe acceleration on any axis exceeds a user-set level. Tap sensingdetects single and double taps. Free-fall sensing detects if thedevice is falling. These functions can be mapped to one of twointerrupt output pins.Low power modes enable intelligent motion-based powermanagement with threshold sensing and active accelerationmeasurement at extremely low power dissipation.The ADXL350 is supplied in a small, thin, 3 mm ? 4 mm ?1.2 mm, 16-lead cavity laminate package.APPLICATIONS Portable Consumer Devices High performance medical and industrial applications

The analog output ADXL354 and the digital output ADXL355 are low noise density, low 0 g offset drift, low power, 3-axisaccelerometers with selectable measurement ranges. TheADXL354B supports the ?2 g and ?4 g ranges, the ADXL354Csupports the ?2 g and ?8 g ranges, and the ADXL355 supports the ?2 g, ?4 g, and ?8 g ranges. The ADXL354/ADXL355 offerindustry leading noise, minimal offset drift over temperature,and long-term stability enabling precision applications with minimal calibration.Highly integrated in a compact form factor, the low powerADXL355 is ideal in an Internet of Things (IoT) sensor nodeand other wireless product designs.The ADXL355 multifunction pin names may be referenced by their relevant function only for either the serial peripheralinterface (SPI) or I2C interface.Applications Inertial measurement units (IMUs)/altitude and heading reference systems (AHRS) Platform stabilization systems Structural health monitoring Seismic imaging Tilt sensing Robotics Condition Monitoring

The ADXL363 is an ultralow power, three-sensor combination consisting of a 3-axis MEMS accelerometer, a temperature sensor, and an on-board analog-to-digital converter (ADC) input for synchronous conversion of an external signal. The entire system consumes less than 2 ?A at a 100 Hz output data rate and 270 nA when in motion triggered wake-up mode.The ADXL363 communicates via a serial port interface (SPI) and always provides 12-bit output resolution for all three sensors.The ADXL363 temperature sensor operates with a scale factor of 0.065?C/LSB (typical). Acceleration and temperature data can be stored in a 512-sample multimode first in, first out (FIFO) buffer, allowing up to 13 sec of data to be stored.In addition to the accelerometer and temperature sensor, the ADXL363 also provides access to an internal ADC for synchronous conversion of an additional analog input.The ADXL363 operates on a wide 1.6 V to 3.5 V supply range, and can interface, if necessary, to a host operating on a separate, lower supply voltage. The ADXL363 is available in a 3 mm ? 3.25 mm ? 1.06 mm package.APPLICATIONS Home healthcare devices Wireless sensors Motion enabled metering devices

The ADXL367 is an ultralow power, 3-axis microelectromechanical systems (MEMS) accelerometer that consumes only 0.89 ?A at a 100 Hz output data rate and 180 nA when in motion-triggered wake-up mode. Unlike accelerometers that use power duty cycling to achieve low power consumption, the ADXL367 does not alias input signals by undersampling, but samples the full bandwidth of the sensor at all data rates.The ADXL367 always provides 14-bit output resolution. 8-bit formatted data is offered for more efficient single-byte transfers when a lower resolution is sufficient. 12-bit formatted data is also provided for ADXL362 design compatibility. Measurement ranges of ?2 g, ?4 g, and ?8 g are available, with a resolution of 0.25 mg/LSB on the ?2 g range.In addition to its ultralow power consumption, the ADXL367 has many features to enable true system level power reduction. It includes a deep multimode output first in, first out (FIFO), a built-in micropower temperature sensor, an internal analog-to-digital converter (ADC) for synchronous conversion of an additional analog input with interrupt capability, single-tap and double-tap detection that can operate at any output data rate with only an added 35 nA of current, and a state machine to prevent a false triggering. In addition, the ADXL367 has provisions for external control of the sampling time and/or an external clock.The ADXL367 operates on a wide 1.1 V to 3.6 V supply range, and can interface, if necessary, to a host operating on a separate supply voltage. The ADXL367 is available in a 2.2 mm ? 2.3 mm ? 0.87 mm package.APPLICATIONS 24/7 Always on sensing Industrial Digital Healthcare Prosumer Hearing aids Vital signs monitoring devices Motion-enabled power save switches Motion-enabled metering devices Smart watch with single-cell operation Smart homes

The ADXL372 is an ultralow power, 3-axis, ?200 g MEMS accelerometer that consumes 22 ?A at a 3200 Hz output data rate (ODR). The ADXL372 does not power cycle its front end to achieve its low power operation and therefore does not run the risk of aliasing the output of the sensor.In addition to its ultralow power consumption, the ADXL372 has many features to enable impact detection while providing system level power reduction. The device includes a deep multimode output first in, first out (FIFO), several activity detection modes, and a method for capturing only the peak acceleration of over threshold events.Two additional lower power modes with interrupt driven, wake-up features are available for monitoring motion during periods of inactivity. In wake-up mode, acceleration data can be averaged to obtain a low enough output noise to trigger on low g thresholds. In instant on mode, the ADXL372 consumes 1.4 ?A while continuously monitoring the environment for impacts. When an impact event that exceeds the internally set threshold is detected, the device switches to normal operating mode fast enough to record the event.High g applications tend to experience acceleration content over a wide range of frequencies. The ADXL372 includes a 4-pole low-pass antialiasing filter to attenuate out of band signals that are common in high g applications. The ADXL372 also incorporates a high-pass filter to eliminate initial and slow changing errors, such as ambient temperature drift.The ADXL372 provides 12-bit output data at 100 mg/LSB scale factor. The user can access configuration and data registers via the serial peripheral interface (SPI) or limited I2C protocol. The ADXL372 operates over a wide supply voltage range and is available in a 3 mm ? 3.25 mm ? 1.06 mm package.Multifunction pin names may be referenced by their relevant function only.APPLICATIONS Impact and shock detection Asset health assessment Portable Internet of Things (IoT) edge nodes Concussion and head trauma detection

The ADXL375 is a small, thin, 3-axis MEMS accelerometer that provides low power consumption and high resolution measurement up to ?200?g. The digital output data is formatted as 16-bit, twos complement data and is accessible through a SPI (3- or 4-wire) or I2C digital interface.An integrated memory management system with a 32-level first in, first out (FIFO) buffer can be used to store data to minimize host processor activity and lower overall system power consumption.Low power modes enable intelligent motion-based power management with threshold sensing and active acceleration measurement at extremely low power dissipation.The ADXL375 is supplied in a small, thin, 3 mm ? 5 mm ? 1 mm, 14-lead LGA.APPLICATIONS Concussion and head trauma detection High force event detection
