12 Bit Analog to Digital Converter 1 Input 1 SAR 8-SO

Current Sense Amplifier 1 Circuit 8-SO

General Purpose Amplifier 2 Circuit 8-SO

Elliptic, Low Pass Switched Capacitor Filter IC Elliptic, Low Pass Switched Capacitor 8th Order 14kHz/20kHz 8-SO

Non-Isolated PoL Module DC DC Converter 1 Output 1.2 ~ 36V - - 6A 6V - 58V Input

LTC2256-12 series 12 Bit 25M Samples per Second Analog to Digital Converter (ADC) Evaluation Board

Quad-Channel Digital Isolator (3/1 Channel Directionality) Features: Qualified for automotive applications Low power operation Bidirectional communication 3 V/5 V level translation High temperature operation: 125°C High data rate: dc to 90 Mbps (NRZ) Precise timing characteristics High common-mode transient immunity: >25 kV/μs See data sheet for additional features

2.5kV rms Isolated Error Amplifier Features: Stability in isolated feedback applications 0.5% initial accuracy 1% accuracy over the full temperature range Compatible with Type II or Type III compensation networks Reference voltage: 1.225 V Compatible with DOSA Low power operation: <7 mA total Wide voltage supply range VDD1: 3 V to 20 V VDD2: 3 V to 20 V Bandwidth: 400 kHz Isolation voltage: 2.5 kV rms Safety and regulatory approvals UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 565 V peak Wide temperature range −40°C to +125°C ambient operation 150°C maximum junction temperature Qualified for automotive applications

Triple-Channel, Digital Isolator, Enhanced System-Level ESD Reliability (2/1 channel directionality) Features: Enhanced system-level ESD performance per IEC 61000-4-x Low power operation 5 V operation 2.0 mA per channel maximum at 0 Mbps to 2 Mbps 4.1 mA per channel maximum at 10 Mbps 36 mA per channel maximum at 90 Mbps 3.3 V operation 1.0 mA per channel maximum at 0 Mbps to 2 Mbps 2.8 mA per channel maximum at 10 Mbps 17 mA per channel maximum at 90 Mbps Bidirectional communication 3.3 V/5 V level translation High temperature operation: 105°C High data rate: dc to 90 Mbps (NRZ) Precise timing characteristics 2 ns maximum pulse width distortion 2 ns maximum channel-to-channel matching High common-mode transient immunity: >25 kV/μs Output enable function 16-lead SOIC wide body, RoHS-compliant package Safety and regulatory approvals UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE Certificate of Conformity DIN V VDE V 0884-10 (VDE V 0884-10): 2006-12 VIORM = 560 V peak CQC Certification per GB4943.1-2011

Dual-Channel, 5 kV Isolators with Integrated DC/DC Converter (0/2 channel directionality) Features: isoPower integrated, isolated DC/DC converter Regulated 5 V or 3.3 V output Up to 400 mW output power Dual dc-to-25 Mbps (NRZ) signal isolation channels 16-lead SOIC package with 7.6 mm creepage High temperature operation: 105°C maximum High common-mode transient immunity: >25 kV/μs Safety and regulatory approvals UL recognition (pending) 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice #5A IEC 60601-1: 250 V rms, 8 mm package (RI-16-1) IEC 60950-1: 400 V rms, 8 mm package (RI-16-1) VDE certificate of conformity (RW-16) IEC 60747-5-2 (VDE 0884 Part 2):2003-01 VIORM = 846 V peak VDE certificate of conformity, 8 mm package (RI-16-1) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 846 V peak

Dual-Channel Isolators with Integrated DC-to-DC Converter (1/1 Channel Directionality) Features: isoPower integrated, isolated dc-to-dc converter Regulated 3.135 V to 5.25 V output Up to 150 mW output power Dual dc-to-100 Mbps (NRZ) signal isolation channels Soft start power supply 20-lead SSOP package with 5.3 mm creepage Supports SPI up to 15 MHz High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs Safety and regulatory approvals UL recognition 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak

Quad-Channel Isolators with Integrated DC-to-DC Converter (3:1 directionality) Features: isoPower integrated, isolated dc-to-dc converter 100 mA output supply AEC-Q100 qualified for automotive applications ADuM6421AW (ADuM6423AW pending) Meets CISPR 32/EN55032 Class B emission limits up to 5 Mbps at a full load on a 2-layer PCB Quad dc to 100 Mbps signal isolation channels 28-lead, fine pitch, SOIC with 8.3 mm minimum creepage High temperature operation: 125°C maximum High common-mode transient immunity: 100 kV/μs Safety and regulatory approvals (pending) UL recognition (pending) 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE V 0884-11 certificate of conformity (pending) VIORM = 566 V peak CQC certification per GB4943.1-2011 (pending)

OVP and EMI Protected, Precision, Low Noise and Bias Current Single Op Amp Features: Low offset voltage: 60 μV maximum at 25°C (8-lead and 14-lead SOIC) Low offset voltage drift: 1 μV/°C maximum (8-lead and 14-lead SOIC) Low input bias current: 1 nA maximum at 25°C Low voltage noise density: 8 nV/√Hz typical at 1 kHz Large signal voltage gain (AVO): 100 dB minimum over full supply voltage and operating temperature Input overvoltage protection to 32 V above and below the supply voltage rail Integrated EMI filter 70 dB typical rejection at 1000 MHz 90 dB typical rejection at 2400 MHz Rail-to-rail output swing Low supply current: 500 μA typical per amplifier Wide bandwidth Gain bandwidth product (AV = 100): 3.5 MHz typical Unity-gain crossover (AV = 1): 3.5 MHz typical −3 dB bandwidth (AV = 1): 6 MHz typical Dual-supply operation Specified at ±5 V to ±15 V, operates over ±2.5 V to ±18 V Unity-gain stable No phase reversal Long-term offset voltage drift (10,000 hours): 2 μV typical Temperature hysteresis: 2 μV typical

Rail-to-Rail, Fast, Low Power 2.5 V to 5.5 V, Single-Supply TTL/CMOS Comparator Features: Fully specified rail-to-rail at VCC = 2.5 V to 5.5 V Input common-mode voltage from −0.2 V to VCC + 0.2 V Low glitch TTL-/CMOS-compatible output stage 40 ns propagation delay Low power 1 mW at 2.5 V Shutdown pin Programmable hysteresis Power supply rejection > 60 dB −40°C to +125°C operation

Rail-to-Rail, Fast, Low Power 2.5 V to 5.5 V, Single-Supply TTL/CMOS Comparator Features: Fully specified rail-to-rail at VCC = 2.5 V to 5.5 V Input common-mode voltage from −0.2 V to VCC + 0.2 V Low glitch TTL-/CMOS-compatible output stage 40 ns propagation delay Low power 1 mW at 2.5 V Shutdown pin Programmable hysteresis Power supply rejection > 60 dB −40°C to +125°C operation

4-Channel, 24 GHz, Receiver Downconverter Features: Integrated baluns for single-ended receiver (Rx) inputs and local oscillator (LO) input Rx channel gain: 22 dB Noise figure (NF): 10 dB P1dB: −10 dBm LO input range: −8 dBm to +5 dBm Rx to IF isolation: 30 dB RF signal bandwidth: 250 MHz Rx output impedance: 900 Ω differential LO input buffer: 24 GHz RF and LO S11 at 50 Ω: −5 dB Temperature sensor with analog output: ±5° Electrostatic discharge (ESD) performance Human body model (HBM): 2000 V Charged device model (CDM): 500 V Qualified for automotive applications

LC2MOS 15 V 4 Channel High Performance Analog Multiplexer Features: 44 V supply maximum ratings VSS to VDD analog signal range Low on resistance (100 Ω maximum) Low power (ISUPPLY < 75 µA) Fast switching Break-before-make switching action Plug-in replacement for DG408

High Voltage, Latch-Up Proof, 8-Channel Differential Multiplexer Features: Latch-up proof 3.5 pF off source capacitance 33 pF off drain capacitance 0.35 pC typical charge injection ±0.02 nA on channel leakage Low on resistance: 155 typical ±9 V to ±22 V dual-supply operation 9 V to 40 V single-supply operation VSS to VDD analog signal range Human body model (HBM) ESD rating - 8 kV I/O port to supplies

Ultra Low Power ARM Cortex-M4F MCU with Integrated Power Management Features: EEMBC ULPMark™-CP score (3 V): 189 Ultra low power active and hibernate modes Active mode dynamic current: 41 μA/MHz (typical) Flexi mode: 400 μA (typical) Hibernate mode: 0.65 μA (typical) Shutdown mode: 50 nA (typical) Shutdown mode (fast wake-up): 0.20 μA (typical) ARM Cortex-M4F processor at 52 MHz with FPU, MPU, ITM with SWD interface Power management Single-supply operation (connected to VBAT pins): 1.74 V to 3.6 V Optional buck converter for improved efficiency Memory options 512 kB of embedded flash memory with ECC 4 kB of cache memory to reduce active power 128 kB of configurable system SRAM with parity Safety Watchdog with dedicated on-chip oscillator Hardware CRC with programmable polynomial Multiparity bit protected SRAM ECC protected embedded flash Security Hardware cryptographic accelerator supporting AES-128, AES-256, and SHA-256 Protected key storage in flash, SHA-256-based keyed HMAC and key wrap and unwrap User code protection TRNG Digital peripherals 3 SPI interfaces to enable glueless interface to sensors, radios, and converters 1 I2C and 2 UART peripheral interfaces SPORT for natively interfacing with converters and radios Programmable GPIOs (44 in LFCSP and 51 in WLCSP) 3 general-purpose timers with PWM support RGB timer for driving RGB LED RTC0 for time keeping RTC1 with SensorStrobe and time stamping Programmable beeper 27-channel DMA controller Clocking features 26 MHz clock: on-chip oscillator, external crystal oscillator, SYS_CLKIN for external clock, and integrated PLL 32 kHz clock: on-chip oscillator and low power crystal oscillator Clock fail detection for external crystals Analog peripherals 12-bit SAR ADC, 1.8 MSPS, 8 channels, and digital comparator

Precision Analog Microcontroller, 16-Bit Analog Input/Output with MDIO Interface, Arm Cortex-M33 Features: Analog input/output Multichannel, 16-bit, 2 MSPS ADC Up to 16 external channels On-chip die temperature monitor 4 power monitor channels 4 PGA/TIA channels supporting voltage and current measurements Fully differential and single-ended modes 0 V to VREF analog input range 12-bit voltage output DACs 8× 0 V to 2.5 V, 1 kΩ load 4× 0 V to 2.5 V, 2.5 kΩ load On-chip low drift voltage reference, 1.25 V or 2.5 V Buffered 1.25 V or 2.5 V output 4 voltage comparators Microcontroller 32-bit Arm Cortex-M33 core, 32-bit RISC architecture, FPU Serial wire port supports code download and debug Clocking options 16 MHz on-chip oscillator 160 MHz PLL output with programmable divider External clock source Memory 2× 512 kB independent Flash/EE memories 10,000-cycle Flash/EE endurance 20-year Flash/EE retention 128 kB SRAM with ECC Software triggered, in circuit reprogrammability via MDIO or I2C On-chip peripherals 2× UART, 3× SPI, 3× I2C serial input/output Multilevel voltage (3.3 V, 1.8 V, 1.2 V) GPIOs MDIO slave up to 10 MHz 5 general-purpose timers Wake-up timer (WUTs) Watchdog timers (WDTs) 32-element PLA 16-bit PWM 10 external Interrupts Power Multiple supplies: 3.3 V for voltage DACs and ADCs, and 3.3 V, 1.8 V, or 1.2 V for digital inputs/outputs Flexible operating modes for low power applications Packages and temperature range 5 mm × 5 mm 81-ball CSP_BGA and 3.46 mm × 3.46 mm 64-ball WLCSP BGA package uses ULA molding compounds Fully specified for −40°C to +105°C operation Tools Low cost quick start development system Full third-party support
