600mA Universal Multi-Output LED/CAM Driver Features: Low Noise, Multi-Mode Charge Pump (1x, 1.5x, 2x) Provides Up to 91% Efficiency Slew Limited Switching Reduces Conducted and Radiated Noise (EMI) Up to 600mA Total Output Current Twelve 28mA Universal Current Sources with 64-Step Linear Brightness Control 425mA CAM LED Current Source with 16-Step Linear Brightness Control and 2-Second High Current Safety Timer Independent On/Off, Brightness Level, Blinking and Gradation Control for Each Current Source Using 2-Wire I2C Interface Internal Current Reference Two I2C Addresses are Available (LTC3207 00110110, LTC3207-1 00110100) Configurable ENU Pin for Asynchronous LED On/Off Control Automatic or Forced Mode Switching Internal Soft-Start Limits Inrush Current Short-Circuit/Thermal Protection 4mm × 4mm 24-Pin QFN Plastic Package

14-Bit, 125Msps Dual-Channel IF/Baseband Receiver Subsystem Features: Integrated Dual 14-Bit, High-Speed ADC, Passive Filters and Fixed Gain Differential Amplifiers Up to 300MHz IF Range Lowpass and Bandpass Filter Versions Integrated Low Noise, Low Distortion Amplifiers Fixed Gain: 8dB, 14dB, 20dB or 26dB 50Ω, 200Ω or 400Ω Input Impedance Integrated Bypass Capacitance, No External Components Required 66dB SNR Up to 140MHz Input (LTM9002-AA) 76dB SFDR Up to 140MHz Input (LTM9002-AA) Auxiliary 12-Bit DACs for Gain Adjustment Clock Duty Cycle Stabilizer Single 3V to 3.3V Supply Low Power: 1.3W (665mW/ch.) Shutdown and Nap Modes 15mm × 11.25mm LGA Package

Octal 12-/10-/8-Bit SPI VOUT DACs with 10ppm/C Reference Features: Integrated Precision Reference 2.5V Full-Scale 10ppm/°C (LTC2636-L) 4.096V Full-Scale 10ppm/°C (LTC2636-H) Maximum INL Error: 2.5LSB (LTC2636-12) Low Noise: 0.75mVP-P 0.1Hz to 200KHz Guaranteed Monotonic Over –40°C to 125°C Temperature Range Selectable Internal or External Reference 2.7V to 5.5V Supply Range (LTC2636-L) Ultralow Crosstalk Between DACs (<2.4nV•s) Low Power: 0.9mA at 3V (LTC2636-L) Power-On-Reset to Zero-Scale/Mid-Scale Double-Buffered Data Latches Tiny 14-Lead 4mm × 3mm DFN and 16-Lead MSOP Packages

6A DC/DC Module Regulator with Tracking and Frequency Synchronization Features:Complete Standalone Power SupplyWide Input Voltage Range: 4.5V to 26.5V6A DC Typical, 8A Peak Output Current0.8V to 5V OutputOutput Voltage Tracking±1.75% Maximum Total DC ErrorCurrent Mode Control/Fast Transient ResponsePhase-Lockable Fixed Frequency 250kHz to 780kHzOn-Board Frequency SynchronizationSelectable Burst Mode® OperationPower Good Voltage IndicatorOutput Overvoltage ProtectionOutput Current Foldback Limiting9mm × 15mm × 4.32mm LGA and 9mm × 15mm × 4.92mm BGA Packages

8-Channel PMBus Power System Manager Featuring Accurate Output Voltage Measurement Features: Sequence, Trim, Margin and Supervise Eight Power Supplies Manage Faults, Monitor Telemetry and Create Fault Logs PMBus™ Compliant Command Set Supported by LTpowerPlay® GUI Margin or Trim Supplies to Within 0.25% of Target Fast OV/UV Supervisors Per Channel Coordinate Sequencing and Fault Management Across Multiple LTC PSM Devices Automatic Fault Logging to Internal EEPROM Operate Autonomously without Additional Software Internal Temperature and Input Voltage Supervisors Accurate Monitoring of Eight Output Voltages, Input Voltage and Internal Die Temperature I2C/SMBus Serial Interface Can Be Powered from 3.3V, or 4.5V to 15V Programmable Watchdog Timer 100% Pin-Compatible Upgrade to the LTC2978/LTC2978A Available in 64-Pin 9mm × 9mm QFN PackageAEC-Q100 Qualified for Automotive Applications

Octal I2C 16-/12-Bit Rail-to-Rail DACs with 10ppm/C Max Reference Features: Integrated Reference 10ppm/°C Max Maximum INL Error: ±4LSB Guaranteed Monotonic Over Temperature Selectable Internal or External Reference 2.7V to 5.5V Supply Range (LTC2657-L) Integrated Reference Buffers Ultralow Crosstalk between DACs(0.8nV•s) Power-On-Reset to Zero-Scale/Mid-Scale 400kHz I2C Interface Tiny 20-Lead 4mm × 5mm QFN and 20-Lead Thermally enhanced TSSOP Packages

12-Bit, 25Msps Low Power Dual ADCs Features: 2-Channel Simultaneous Sampling ADC 71dB SNR 90dB SFDR Low Power: 167mW/112mW/94mW Total 83mW/56mW/47mW per Channel Single 1.8V Supply Serial LVDS Outputs: 1 or 2 Bits per Channel Selectable Input Ranges: 1VP-P to 2VP-P 800MHz Full Power Bandwidth S/H Shutdown and Nap Modes Serial SPI Port for Configuration Pin Compatible 14-Bit and 12-Bit Versions 40-Pin (6mm × 6mm) QFN Package

Octal 12-/10-/8-Bit I2C VOUT DACs with 10ppm/C Reference Features: Integrated Precision Reference: 2.5V Full-Scale 10ppm/°C (LTC2637-L) 4.096V Full-Scale 10ppm/°C (LTC2637-H) Maximum INL Error: 2.5LSB (LTC2637-12) Low Noise: 0.75mVP-P 0.1Hz to 200KHz Guaranteed Monotonic Over –40°C to 125°C Temperature Range Selectable Internal or External Reference 2.7V to 5.5V Supply Range (LTC2637-L) Ultralow Crosstalk Between DACs (<3nV•s) Low Power: 100μA per DAC at 3V (LTC2637-L) Power-On-Reset to Zero-Scale/Mid-Scale Double-Buffered Data Latches Tiny 14-Lead 4mm × 3mm DFN and 16-Lead MSOP Packages

20A DC/DC Module (Power Module) Step-Down Regulator Features: Complete 20A Switch Mode Power Supply 4.5V to 20V Input Voltage Range 0.6V to 5.5V Output Voltage Range ±1.5% Total DC Output Voltage Error (–40°C to 125°C) Differential Remote Sense Amplifier for Precision Regulation for (VOUT ≤ 3.3V) Current Mode Control/Fast Transient Response Parallel Current Sharing (Up to 80A) Frequency Synchronization Selectable Pulse-Skipping or Burst Mode® Operation Soft-Start/Voltage Tracking Up to 88% Efficiency (12VIN, 1.8VOUT) Overcurrent Foldback Protection Output Overvoltage Protection Internal Temperature Monitor Overtemperature Protection 15mm × 15mm × 4.32mm LGA and 15mm × 15mm × 4.92mm BGA Packages SnPb (BGA) or RoHS Compliant (LGA and BGA) Finish

20V, 5A Synchronous Step-Down Regulator Features: High Efficiency: Up to 96% 5A Output Current 4V to 20V VIN Range Integrated Power N-Channel MOSFETs (70mΩ Top and 35mΩ Bottom) Adjustable Frequency 800kHz to 4MHz PolyPhase® Operation (Up to 12 Phases) Output Tracking 0.6V ±1% Reference Accuracy Current Mode Operation for Excellent Line and Load Transient Response Shutdown Mode Draws Less Than 15μA Supply Current LTC3605: 15V Absolute Maximum VIN LTC3605A: 22V Absolute Maximum VIN The LTC3605A Is Pin Compatible with the LTC3605 Available in 24-Pin (4mm × 4mm) QFN Package

8-Channel PMBus Power System Manager Featuring Accurate Output Voltage Measurement Features: Sequence, Trim, Margin and Supervise Eight Power Supplies Manage Faults, Monitor Telemetry and Create Fault Logs PMBus™ Compliant Command Set Supported by LTpowerPlay® GUI Margin or Trim Supplies to Within 0.25% of Target Fast OV/UV Supervisors Per Channel Coordinate Sequencing and Fault Management Across Multiple LTC PSM Devices Automatic Fault Logging to Internal EEPROM Operate Autonomously without Additional Software Internal Temperature and Input Voltage Supervisors Accurate Monitoring of Eight Output Voltages, Input Voltage and Internal Die Temperature I2C/SMBus Serial Interface Can Be Powered from 3.3V, or 4.5V to 15V Programmable Watchdog Timer 100% Pin-Compatible Upgrade to the LTC2978/LTC2978A Available in 64-Pin 9mm × 9mm QFN PackageAEC-Q100 Qualified for Automotive Applications

Dual, 12-Bit + Sign, 2Msps Differential Input ADC with Wide Input Common Mode Range Features: 2Msps Throughput Rate ±0.5LSB INL (Typ) Guaranteed 12-Bit, No Missing Codes 8VP-P Differential Inputs with Wide Input Common Mode Range 73dB SNR (Typ) at fIN = 500kHz –85dB THD (Typ) at fIN = 500kHz Guaranteed Operation to 125°C Single 3.3V or 5V Supply Low Drift (20ppm/°C Max) 2.048V or 4.096V Internal Reference 1.8V to 2.5V I/O Voltages CMOS or LVDS SPI-Compatible Serial I/O Power Dissipation 30mW/Ch (Typ) Small 28-Lead (4mm × 5mm) QFN Package

60V Low IQ, Dual, 2-Phase Synchronous Step-Down DC/DC Controller Features: Wide VIN Range: 4.5V to 60V (65V Abs Max) Wide Output Voltage Range: 0.8V ≤ VOUT ≤ 99% • VIN Adjustable Gate Drive Level 5V to 10V (OPTI-DRIVE) No External Bootstrap Diodes Required Low Operating IQ: 29μA (One Channel On) Selectable Gate Drive UVLO Thresholds Out-of-Phase Operation Reduces Required Input Capacitance and Power Supply Induced Noise Phase-Lockable Frequency: 75kHz to 850kHz Selectable Continuous, Pulse Skipping or Low Ripple Burst Mode® Operation at Light Loads Selectable Current Limit (LTC3892/LTC3892-2) Very Low Dropout Operation: 99% Duty Cycle Power Good Output Voltage Monitors (LTC3892/LTC3892-2) Low Shutdown IQ: 3.6μA Small 32-Lead 5mm × 5mm QFN Package (LTC3892/LTC3892-2) or TSSOP Package (LTC3892-1)

Dual Output PolyPhase Step-Down DC/DC Controller with Digital Power System Management Features: PMBus/I2C Compliant Serial Interface Telemetry Read Back includes VIN, IIN, VOUT, IOUT, Temperature and Faults Programmable Voltage, Current Limit, Digital Soft-Start/Stop, Sequencing, Margining, OV/UV and Frequency Synchronization (250kHz to 1MHz) ±0.5% Output Voltage Accuracy Over Temperature Integrated 16-Bit ADC Internal EEPROM with ECC and Fault Logging Integrated Powerful N-Channel MOSFET Gate Drivers Power Conversion Wide VIN Range: 4.5V to 24V VOUT Range: 0.5V to 5.4V (4V on VOUT0) Analog Current Mode Control Loop Accurate PolyPhase® Current Sharing for Up to 6 Phases Available in a 40-Pin (6mm × 6mm) QFN Package AEC-Q100 Qualified for Automotive Applications

60V Low IQ Synchronous Boost Controller with PassThru Features: Synchronous Operation for Highest Efficiency and Reduced Heat Dissipation Wide VIN Range: 4.5V to 60V (65V Abs Max); Operates Down to 2.3V After Start-Up Output Voltage Up to 60V ±1% 1.200V Reference Voltage RSENSE or Inductor DCR Current Sensing 100% Duty Cycle Capability for Synchronous MOSFET Low Quiescent Current: 28μA Phase-Lockable Frequency (75kHz to 850kHz) Programmable Fixed Frequency (50kHz to 900kHz) Power Good Output Voltage Monitor Low Shutdown Current: 4μA Internal LDO Powers Gate Drive from VBIAS or EXTVCC Thermally Enhanced Low Profile 24-Pin 4mm × 4mm QFN Package and 20-Lead TSSOP Package

Low Quiescent Current Surge Stopper Features: Low Quiescent Current: 8µA Operating Withstands Surge Voltage Up to the MOSFET Limit Wide Operating Voltage Range: 4V to 72V Overcurrent Protection Selectable Internal 31.5V/50V or Adjustable Gate Clamp Voltage Reverse Input Protection to –60V Adjustable Turn-On Threshold Adjustable Fault Timer with MOSFET Stress Acceleration Controls N-Channel MOSFET Latchoff and Retry Options Low Retry Duty Cycle During Faults 10-Pin DFN (3mm × 3mm) and MSOP Packages AEC-Q100 Qualified for Automotive Applications

60V Low IQ, Dual, 2-Phase Synchronous Step-Down DC/DC Controller Features: Wide VIN Range: 4V to 60V (65V Abs Max) Low Operating IQ: 50µA (One Channel On) Wide Output Voltage Range: 0.8V ≤ VOUT ≤ 24V RSENSE or DCR Current Sensing Out-of-Phase Controllers Reduce Required Input Capacitance and Power Supply Induced Noise Phase-Lockable Frequency (75kHz to 850kHz) Programmable Fixed Frequency (50kHz to 900kHz) Selectable Continuous, Pulse-Skipping or Low Ripple Burst Mode® Operation at Light Loads Selectable Current Limit Very Low Dropout Operation: 99% Duty Cycle Adjustable Output Voltage Soft-Start or Tracking Power Good Output Voltage Monitors Output Overvoltage Protection Low Shutdown IQ : < 14µA Internal LDO Powers Gate Drive from VIN or EXTVCC No Current Foldback During Start-Up Small Low Profile (0.75mm) 5mm × 5mm QFN Package AEC-Q100 Qualified for Automotive Applications

Dual 13A or Single 26A DC/DC Module (Power Module) Regulator Features: Dual 13A or Single 26A Output Wide Input Voltage Range: 4.5V to 16V Output Voltage Range: 0.6V to 5.3V ±1.5% Maximum Total DC Output Error Multiphase Current Sharing with Multiple LTM4620As Up to 100A Higher Efficiency and Wider VOUT Range Than LTM4620 Differential Remote Sense Amplifier Current Mode Control/Fast Transient Response Adjustable Switching Frequency Overcurrent Foldback Protection Frequency Synchronization Internal Temperature Monitor Output Overvoltage Protection Pin Compatible with the LTM4628 (Dual 8A) and LTM4620 (Dual 13A) Thermally Enhanced (15mm × 15mm × 4.41mm) LGA Package and (15mm × 15mm × 5.01mm) BGA Package

USB Compatible Lithium-Ion Battery Charger with Thermal Regulation Features: Charges Single-Cell Li-Ion Batteries Directly from USB Port Thermal Regulation Maximizes Charging Rate without Risk of Overheating* Programmable Charge Current with ±7% Accuracy Low Dropout Operation No External MOSFET, Sense Resistor or Blocking Diode Required Programmable Charge Termination Timer Preset Charge Voltage with ±1% Accuracy C/10 Charge Current Detection Output AC Present Logic Output 25µA Supply Current in Shutdown Mode Automatic Recharge Tiny Thermally Enhanced 10-Pin MSOP Package Charge Current Monitor Useful for Gas Gauging* Thermistor Input for Temperature Qualified Charging

Photoflash Capacitor Chargers in ThinSOT Features: Highly Integrated IC Reduces Solution Size Uses Small Transformers: 5.8mm × 5.8mm × 3mm Fast Photoflash Charge Times: 4.6s for LT3468 (0V to 320V, 100µF, VIN = 3.6V) 5.7s for LT3468-2 (0V to 320V, 100µF, VIN = 3.6V) 5.5s for LT3468-1 (0V to 320V, 50µF, VIN = 3.6V) Controlled Input Current: 500mA (LT3468) 375mA (LT3468-2) 225mA (LT3468-1) Supports Operation from Single Li-Ion Cell, or Any Supply from 2.5V up to 16V Adjustable Output Voltage No Output Voltage Divider Needed Charges Any Size Photoflash Capacitor Low Profile (<1mm) SOT-23 Package
