RF ATTENUATORS - DIGITAL ROHS COMPLIANT: YES

DAC, 18BIT, 12.5KSPS, SOT-23-8; Resolution (Bits):18bit; Sampling Rate:12.5kSPS; Input Channel Type:Serial; Supply Voltage Range:4.5V to 5.5V; ADC / DAC Case Style:SOT-23; No. of Pins:8Pins; Data Interface:SPI; MSL:MSL 1 - Unlimited RoHS Compliant: Yes

Operational Amplifier, Single, 8 MHz, 1, 2.8 V/ s, 4V to 18V, SOIC, 8 RoHS Compliant: Yes

RF Detector Log Detector, 8-30 GHz

Sub-GHz Modules I/Q mix / IRM Module, 11 - 16 GHz

RF Mixer DBL-BAL mix SMT, 6 - 20 GHz

RF Mixer 27-31.5 GHz Triple Balanced mix

RF Amplifier Medium pow amp Chip, 17.5 - 25.5 GHz

Gyroscopes High Precision Calibrated Gyro

The ADP7156 is a linear regulator that operates from 2.3 V to 5.5 V and provides up to 1.2 A of output current. Using an advanced proprietary architecture, it provides high power supply rejection and ultralow noise, achieving excellent line and loadtransient response with only a 10 μF ceramic output capacitor.There are 16 standard output voltages for the ADP7156. The following voltages are available from stock: 1.2 V, 1.8 V, 2.0 V, 2.5 V, 2.8 V, 3.0 V and 3.3 V. Additional voltages available by special order are 1.3 V, 1.5 V, 1.6 V, 2.2 V, 2.6 V, 2.7 V, 2.9 V, 3.1 V, and 3.2 V.The ADP7156 regulator typical output noise is 0.9 μV rms from 100 Hz to 100 kHz and 1.7 nV/√Hz for noise spectral density from 10 kHz to 1 MHz. The ADP7156 is available in a 10-lead, 3 mm × 3 mm LFCSP and 8-lead SOIC packages, making it not only a very compact solution, but also providing excellent thermal performance for applications requiring up to 1.2 A of output current in a small, low profile footprint.APPLICATIONS Regulation to noise sensitive applications: phase-locked loops (PLLs), voltage controlled oscillators (VCOs), and PLLs with integrated VCOs Communications and infrastructure Backhaul and microwave links

The ADP7157 is an adjustable linear regulator that operates from 2.3 V to 5.5 V and provides up to 1.2 A of output current. Output voltages from 1.2 V to 3.3 V are possible depending on the model. Using an advanced proprietary architecture, the device provides high power supply rejection and ultralow noise, achieving excellent line and load transient response with only a 10 μF ceramicoutput capacitor.The ADP7157 is available in four models that optimize powerdissipation and PSRR performance as a function of the inputand output voltage.The typical output noise the ADP7157 regulator is 0.9 μV rms from 100 Hz to 100 kHz and 1.7 nV/√Hz for noise spectral density from 10 kHz to 1 MHz. The ADP7157 is available in 10-lead, 3 mm ×3 mm LFCSP and 8-lead SOIC packages, making it not only avery compact solution, but also providing excellent thermalperformance for applications requiring up to 1.2 A of outputcurrent in a small, low profile footprint.Applications Regulation to noise sensitive applications: phase-locked loops (PLLs), voltage controlled oscillators (VCOs), and PLLs with integrated VCOs Communications and infrastructure Backhaul and microwave links

The ADRF5130 is a high power, reflective, 0.7 GHz to 3.8 GHz, silicon, single-pole, double-throw (SPDT) switch in a leadless, surface-mount package. The switch is ideal for high power and cellular infrastructure applications, like long-term evolution (LTE) base stations.The ADRF5130 has high power handling of 43 dBm (maximum) and 0.1 dB compression (P0.1dB) of 46 dBm, with a low insertion loss of 0.6 dB at 2 GHz and 0.7 dB at 3.5 GHz. On-chip circuitry operates at a single, positive supply voltage of 5 V and typical supply current of 1.06 mA, making the ADRF5130 an ideal alternative to pin diode-based switches.The device comes in a RoHS compliant, compact, 24-lead, 4 mm × 4 mm LFCSP package.Applications Cellular/4G infrastructure Wireless infrastructure Military and high reliability applications Test equipment Pin diode replacement

The ADRF6658 is a high performance, low power, wideband, dual-channel radio frequency (RF) downconverter with integrated intermediate frequency (IF) digitally controlled amplifiers (DGAs) for wideband, low distortion base station radio receivers.The dual Rx mixers are doubly balanced Gilbert cell mixers with high linearity and excellent image rejection. Both mixers convert 50 Ω RF inputs to open-collector broadband IF outputs. Internal tunable baluns on the RF inputs enable suppression of RF signal harmonics and attenuation of out-of-band signals before the mixer inputs, reducing input reflections and out-of-band interference signals. A flexible local oscillator (LO) architecture allows the use of differential or single-ended LO signals.The dual-channel IF DGAs are based on the ADL5201 and ADL5202 and have a fixed, differential output impedance of 100 Ω. The gain is adjustable over a 31.5 dB range with a 0.5 dB step size via the on-chip SPI, or through independent, 6-bit parallel ports that support latch functionality. Each channel, from the mixer inputs to the IF amplifier outputs, together with an LC interstage band-pass filter, achieves a maximum voltage conversion gain of 26.5 dB.Fabricated with the Analog Devices, Inc., high speed SiGe process, the ADRF6658 is available in a compact, 7 mm × 7 mm, 48-lead LFCSP package, and operates over the −40°C to +105°C temperature range.APPLICATIONS Cellular base stations and wireless infrastructure receivers (W-CDMA, TD-SCDMA, WiMAX, GSM, LTE, PCS, DCS, DECT) Active antenna systems PTP radio link down converters Wireless LANs and CATV equipment

The ADuM141D1 is a quad-channel digital isolator based on Analog Devices, Inc., iCoupler® technology. Combining high speed, complementary metal-oxide semiconductor (CMOS) and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices and other integrated couplers. The maximum propagation delay is 13 ns with a pulse width distortion of less than 3 ns at 5 V operation. Channel matching is tight at 3.0 ns maximum.The ADuM141D data channels are independent and are available in a variety of configurations with a withstand voltage rating of 3.0 kV rms or 3.75 kV rms (see the Ordering Guide). The devices operate with the supply voltage on either side ranging from 1.8 V to 5 V, providing compatibility with lower voltage systems as well as enabling voltage translation functionality across the isolation barrier.Unlike other optocoupler alternatives, dc correctness is ensured in the absence of input logic transitions. Two different fail-safeoptions are available, by which the outputs transition to a predetermined state when the input power supply is not applied or the inputs are disabled. The ADuM140E1/ADuM141E1/ADuM142E1 is pin-compatible with the ADuM1400/ADuM1401/ADuM1402.Applications General-purpose multichannel isolation Serial peripheral interface (SPI)/data converter isolation Industrial field bus isolation1 Protected by U.S. Patents 5,952,849; 6,873,065; 6,903,578; and 7,075,329.Other patents are pending.

The ADuM230D/ADuM230E/ADuM231D/ADuM231E are triple-channel digital isolators based on Analog Devices, Inc., iCoupler® technology. Combining high speed, complementary metal-oxide semiconductor (CMOS) and monolithic air core transformer technology, these isolation components provide outstanding performance characteristics superior to alternatives such as optocoupler devices and other integrated couplers. The maximum propagation delay is 13 ns with a pulse width distortion of less than 3 ns at 5 V operation. Channel matching is tight at 3.0 ns maximum.The ADuM230D/ADuM230E/ADuM231D/ADuM231E data channels are independent and are available in a variety of configurations with a withstand voltage rating of 5.0 kV rms. The devices operate with the supply voltage on either side ranging from 1.8 V to 5 V, providing compatibility with lower voltage systems as well as enabling voltage translation functionality across the isolation barrier.Unlike other optocoupler alternatives, dc correctness is ensured in the absence of input logic transitions. Two different fail-safe options are available, by which the outputs transition to a predetermined state when the input power supply is not applied or the inputs are disabled.Applications General-purpose multichannel isolation Serial peripheral interface (SPI)/data converter isolation Industrial field bus isolation

The ADuM260N/ADuM261N/ADuM262N/ADuM263N1 are6-channel digital isolators based on Analog Devices, Inc., iCoupler®technology. Combining high speed, complementary metal-oxidesemiconductor (CMOS) and monolithic air core transformertechnology, these isolation components provide outstandingperformance characteristics superior to alternatives such asoptocoupler devices and other integrated couplers. The maximumpropagation delay is 13 ns with a pulse width distortion ofless than 4.5 ns at 5 V operation. Channel to channel matchingof propagation delay is tight at 4.0 ns maximum.The ADuM260N/ADuM261N/ADuM262N/ADuM263N datachannels are independent and are available in a variety ofconfigurations with a withstand voltage rating of 5.0 kV rms(see the Ordering Guide in the data sheet). The devices operate with the supplyvoltage on either side ranging from 1.7 V to 5.5 V, providingcompatibility with lower voltage systems as well as enablingvoltage translation functionality across the isolation barrier.Unlike other optocoupler alternatives, dc correctness is ensuredin the absence of input logic transitions. Two different fail-safeoptions are available by which the outputs transition to a predeterminedstate when the input power supply is not applied. APPLICATIONS General-purpose multichannel isolation Serial peripheral interface (SPI)/data converter isolation Industrial field bus isolation 1 Protected by U.S. Patents 5,952,849; 6,873,065; 6,903,578; and 7,075,329. Other patents are pending.

The ADA4571 is an anisotropic magnetoresistive (AMR) sensorwith integrated signal conditioning amplifiers and ADC drivers.The ADA4571 produces two analog outputs that indicate theangular position of the surrounding magnetic field.The ADA4571 consists of two die within one package, an AMRsensor, and a fixed gain (G = 40 nominally) instrumentationamplifier. The ADA4571 delivers clean and amplified cosineand sine output signals related to the angle of a rotatingmagnetic field. The output voltage range is ratiometric to thesupply voltage.The sensor contains two Wheatstone bridges, at a relative angleof 45° to one another. A rotating magnetic field in the x-ysensor plane delivers two sinusoidal output signals with thedouble frequency of the angle (α) between sensor and magneticfield direction. Within a homogeneous field in the x-y plane,the output signals are independent of the physical placement inthe z direction (air gap).The ADA4571 is available in an 8-lead SOIC package.Product Highlights Contactless angular measurement. Measures magnetic field direction rather than field intensity. Minimum sensitivity to air gap variations. Large working distance. Excellent accuracy, even for weak saturation fields. Minimal thermal and lifetime drift. Negligible hysteresis. Single chip solution.Applications Absolute position measurement (linear and angle) Brushless dc motor control and positioning Actuator control and positioning Contactless angular measurement and detection Magnetic angular position sensing

The ADA4610-1/ADA4610-2/ADA4610-4 are precision junction field effect transistor (JFET) amplifiers that feature low input noise voltage, current noise, offset voltage, input bias current, and rail-to-rail output. The ADA4610-1 is a single amplifier, the ADA4610-2 is a dual amplifier, and the ADA4610-4 is a quad amplifier.The combination of low offset, noise, and very low input bias current makes these amplifiers especially suitable for high impedance sensor amplification and precise current measurements using shunts. With excellent dc precision, low noise, and fast settling time, the ADA4610-1/ADA4610-2/ADA4610-4 provide superior accuracy in medical instruments, electronic measurement, and automated test equipment. Unlike many competitive amplifiers, the ADA4610-1/ADA4610-2/ADA4610-4 maintain fast settling performance with substantial capacitive loads. Unlike many older JFET amplifiers, the ADA4610-1/ADA4610-2/ADA4610-4 do not suffer from output phase reversal when input voltages exceed the maximum common-mode voltage range. The fast slew rate and great stability with capacitive loads make the ADA4610-1/ADA4610-2/ADA4610-4 ideal for high performance filters. Low input bias currents, low offset, and low noise result in a wide dynamic range for photodiode amplifier circuits. Low noise and distortion, high output current, and excellent speed make the ADA4610-1/ADA4610-2/ ADA4610-4 great choices for audio applications.The ADA4610-1/ADA4610-2/ADA4610-4 are specified over the −40°C to +125°C extended industrial temperature range.The ADA4610-1 is available in an 8-lead SOIC package and in a 5-lead SOT-23 package. The ADA4610-2 is available in 8-lead SOIC, 8-lead MSOP, and 8-lead LFCSP packages. The ADA4610-4 is available in a 14-lead SOIC package and in a 16-lead LFCSP.Applications Instrumentation Medical instruments Multipole filters Precision current measurement Photodiode amplifiers Sensors Audio

The ADA4622-1/ADA4622-2/ADA4622-4 are the next generation of the AD820/AD822/AD824 single-supply, rail-to-rail output (RRO), precision junction field effect transistors (JFET) input op amps. The ADA4622-1/ADA4622-2/ADA4622-4 include many improvements that make them desirable as upgrades without compromising the flexibility and ease of use that makes the AD820/AD822/AD824 useful for a wide variety of applications.The input voltage range includes the negative supply and the output swings rail-to-rail. Input EMI filters increase the signal robustness in the face of closely located switching noise sources.The speed, in terms of bandwidth and slew rate, increases along with a strong output drive to improve settling time performance and enables the devices to drive the inputs of modern single-ended, successive approximation register (SAR) analog-to-digital converters (ADCs).Voltage noise is reduced; although the supply current remains the same as the AD820/AD822/AD824, broadband noise is reduced by 25%, and 1/f is reduced by half. DC precision in the ADA4622-1/ADA4622-2/ADA4622-4 improved from the AD820/AD822/AD824 with half the offset and a maximum thermal drift specification added to the ADA4622-1/ADA4622-2/ADA4622-4. The common-mode rejection ratio (CMRR) is improved from the AD820/AD822/AD824 to make the ADA4622-1/ADA4622-2/ADA4622-4 more suitable when used in noninverting gain and difference amplifier configurations.The ADA4622-1/ADA4622-2/ADA4622-4 are specified for operation over the extended industrial temperature range of −40°C to +125°C, and operate from 5 V to 30 V, with specifications at +5 V, ±5 V, and ±15 V. The ADA4622-1 is available in a 5-lead SOT-23 package and an 8-lead LFCSP package. The ADA4622-2 is available in an 8-lead SOIC_N package, an 8-lead MSOP package, and an 8-lead LFCSP package. The ADA4622-4 is available in a 14-lead SOIC_N and a 16-lead, 4 × 4 mm LFCSP.APPLICATIONS High output impedance sensor interfaces Photodiode sensor interfaces Transimpedance amplifiers ADC drivers Precision filters and signal conditioning

The ADA4805-1 is a high speed voltage feedback rail-to-rail output amplifier with an exceptionally low quiescent current of 495 μA, making it ideal for low power, high resolution data conversion systems. Despite being low power, this amplifier provides excellent overall performance. It offers a high bandwidth of 105 MHz at a gain of 1, high slew rate of 160 V/μs, and a low input offset voltage of 125 μV maximum.A shutdown pin allows further reduction of the quiescent supply current to 3 μA. For power sensitive applications, the shutdown mode offers very fast turn-on time of 3 μs from shutdown to fully on (output settled to 16 bits). This allows the user to dynamically manage the power of the amplifier by turning the amplifier off between ADC samples.The Analog Devices, Inc., proprietary extra fast complementary bipolar (XFCB) process allows for both low voltage and low current noise (5.9 nV/√Hz, 0.6 pA/√Hz). The ADA4805-1 operates over a wide range of supply voltages from ±1.5 V to ±5 V, as well as from single 3 V and 5 V supplies, making it ideal for high speed, low power instruments.The ADA4805-1 amplifier is available in both a 6-lead SOT-23 and a 6-lead SC70 package. These amplifiers are rated to work over the industrial temperature range of −40°C to +125°C.Applications High resolution, high precision ADC drivers Battery-powered instrumentation Micropower active filters Portable point of sales terminals Active RFID readers Photo multipliers ADC reference buffers
