High Linearity Differential RF/IF Amplifier/ADC Driver Features: 51.0dBm OIP3 at 240MHz into a 100Ω Diff Load NF = 2.9dB at 240MHz 20MHz to 2060MHz –3dB Bandwidth 20.8dB Gain A-Grade 100% OIP3 Tested at 380MHz 0.6nV/√Hz Total Input Noise S11 < –10dB Up to 1.4GHz S22 < –10dB Up to 1.4GHz >2.75VP-P Linear Output Swing P1dB = 24.0dBm Insensitive to VCC Variation 100Ω Differential Gain-Block Operation Input/Output Internally Matched to 100Ω Diff Single 5V Supply DC Power = 850mW 4mm × 4mm, 24-Lead QFN Package

16-/14-/11-Bit 2.7Gsps DACs Features:80dBc SFDR at 50MHz fOUT>68dBc SFDR from DC to 1080MHz fOUT40mA Nominal Full-Scale, ±1V Output Compliant10mA to 60mA Adjustable Full-Scale Current RangeSingle or Dual Port DDR LVDS and DHSTL InterfaceLow Latency (7.5 Cycles for Single Port, 11 Cycles for Dual Port)>78dBc 2-Tone IMD from DC to 1000MHz fOUT–156dBc/Hz Additive Phase Noise at 1MHz Offset for 65MHz fOUT170-Lead (9mm × 15mm) BGA Package

Dual 9A or Single 18A Module Regulator with Digital Power System Management Features: Dual, Fast, Analog Loops with Digital Interface for Control and Monitoring Wide Input Voltage Range: 4.5V to 17V Output Voltage Range: 0.5V to 5.5V ±0.5% Maximum DC Output Error Over Temperature ±2.5% Current Readback Accuracy at 9A Load 400kHz PMBus-Compliant I2C Serial Interface Integrated 16-Bit Σ ADC Supports Telemetry Polling Rates Up to 125Hz Constant Frequency Current Mode Control Parallel and Current Share Multiple Modules All 7-Bit Slave Addresses Supported Drop-In Pin-Compatible to Dual 13A LTM4676A and Dual 18A LTM4677 16mm × 11.9mm × 3.51mm BGA Package Readable Data: Input and Output Voltages, Currents, and Temperatures Running Peak Values, Uptime, Faults and Warnings Onboard EEPROM Fault Log Record with ECC Writable Data and Configurable Parameters: Output Voltage, Voltage Sequencing and Margining Digital Soft-Start/Stop Ramp OV/UV/OT, UVLO, Frequency and Phasing

Dual 13A or Single 26A Module (Power Module) Regulator with Digital Power System Management Features: Dual, Fast, Analog Loops with Digital Interface for Control and Monitoring Wide Input Voltage Range: 4.5V to 26.5V Output Voltage Range: 0.5V to 5.5V ±0.5% Maximum DC Output Error Over Temperature ±2.5% Current Readback Accuracy at 10A Load 400kHz PMBus-Compliant I2C Serial Interface Integrated 16-Bit ΔΣ ADC Supports Telemetry Polling Rates Up to 125Hz Constant Frequency Current Mode Control Parallel and Current Share Multiple Modules All 7-Bit Slave Addresses Supported Pin-Compatible to Dual 18A LTM4677 16mm × 16mm × 5.01mm BGA PackageReadable Data: Input and Output Voltages, Currents, and Temperatures Running Peak Values, Uptime, Faults and Warnings Onboard EEPROM Fault Log Record with ECCWritable Data and Configurable Parameters: Output Voltage, Voltage Sequencing and Margining Digital Soft-Start/Stop Ramp OV/UV/OT, UVLO, Frequency and Phasing

60V Low IQ, Dual, 2-Phase Synchronous Step-Down DC/DC Controller Features: Wide VIN Range: 4.5V to 60V (65V Abs Max) Wide Output Voltage Range: 0.8V ≤ VOUT ≤ 99% • VIN Adjustable Gate Drive Level 5V to 10V (OPTI-DRIVE) No External Bootstrap Diodes Required Low Operating IQ: 29μA (One Channel On) Selectable Gate Drive UVLO Thresholds Out-of-Phase Operation Reduces Required Input Capacitance and Power Supply Induced Noise Phase-Lockable Frequency: 75kHz to 850kHz Selectable Continuous, Pulse Skipping or Low Ripple Burst Mode® Operation at Light Loads Selectable Current Limit (LTC3892/LTC3892-2) Very Low Dropout Operation: 99% Duty Cycle Power Good Output Voltage Monitors (LTC3892/LTC3892-2) Low Shutdown IQ: 3.6μA Small 32-Lead 5mm × 5mm QFN Package (LTC3892/LTC3892-2) or TSSOP Package (LTC3892-1)

20VIN, Dual 4A or Single 8A DC/DC Module Regulator Features: Small Form Factor Dual 4A Power Supply Wide Input Voltage Range: 4.5V to 20V (2.375V Min with CPWR Bias) Dual 180° Out-of-Phase Outputs with 4A DC Dual Outputs with 0.6V to 5.5V Range Output Voltage Tracking ±1.5% Maximum Total DC Output Voltage Error Up to 95% Maximum Efficiency Phase-Lockable Fixed Frequency 600kHz to 1.4MHz Constant On-Time, Valley Current Mode Architecture Selectable Burst Mode® Operation Output Overvoltage and Overcurrent Protection 9mm × 11.25mm × 4.92mm BGA Package

Wake-Up Timer with Pushbutton Control Features: 1.5V to 36V Supply Input Range Adjustable Wake-Up Period: 250ms to 39 Days Adjustable Maximum Awake Time 0.8μA Quiescent Current 0.3μA Shutdown Current Pushbutton Input with Debouncing Low Leakage EN Output Allows DC/DC Converter Control (LTC2956-1) High Voltage EN Output Drives External P-Channel MOSFET (LTC2956-2) ±25kV ESD HBM on PB Input 12-Lead 3mm × 3mm QFN and MSOP Packages

Multi-Sensor High Accuracy Digital Temperature Measurement System Features: Directly Digitize RTDs, Thermocouples, Thermistors, and Diodes Single 2.85V to 5.25V Supply Results Reported in °C or °F 20 Flexible Inputs Allow Interchanging Sensors Automatic Thermocouple Cold Junction Compensation Built-In Standard and User-Programmable Coefficients for Thermocouples, RTDs and Thermistors Configurable 2-, 3- or 4-Wire RTD Configurations Measures Negative Thermocouple Voltages Automatic Burn Out, Short-Circuit and Fault Detection Buffered Inputs Allow External Protection Simultaneous 50Hz/60Hz Rejection Includes 10ppm/°C (max) Reference (I-Grade)

SPI, 1.5 RON, 15 V/5 V/+12 V, High Density Octal SPST Switch Features: SPI with error detection Includes CRC, invalid read and write address, and SCLK count error detection Supports burst mode and daisy-chain mode Industry-standard SPI Mode 0 and Mode 3 interface compatible Integrated passive components Route through of digital signals and supplies Guaranteed break-before-make switching allowing external wiring of switches to deliver multiplexer configurations 1.5 typical on resistance at 25°C (±15 V dual supply) 0.3 typical on resistance flatness at 25°C (±15 V dual supply) 0.1 typical on resistance match between channels at 25°C (±15 V dual supply) VSS to VDD analog signal range Fully specified at ±15 V, ±5 V, and +12 V 1.8 V logic compatibility with 2.7 V ≤ VL ≤ 3.3 V (excludes SPI readback to a 1.8 V device) 4 mm × 5 mm, 30-terminal LGA

1 MSPS, 14-Bit, Simultaneous Sampling SAR ADC with PGA and Four Comparators Features: Dual, simultaneous sampling, 14-bit, 2-channel ADC True differential analog inputs Programmable gain stage: ×1, ×2, ×3, ×4, ×6, ×8, ×12, ×16, ×24, ×32, ×48, ×64, ×96, ×128 Throughput rate per ADC 1 MSPS for AD7264 Analog input impedance: >1 GΩ Wide input bandwidth −3 dB bandwidth: 1.7 MHz at gain = 2 4 on-chip comparators SNR: 78 dB typical at gain = 2, 71 dB typical at gain = 32 Device offset calibration System gain calibration On-chip reference: 2.5 V −40°C to +105°C operation High speed serial interface Compatible with SPI, QSPI™, MICROWIRE™, and DSP 48-lead LFCSP and LQFP packages

24-Bit, 156 kSPS, 112 dB Sigma-Delta ADC with On-Chip Buffers and Serial Interface Features: High performance 24-bit Σ-Δ ADC 115 dB dynamic range at 78.125 kHz output data rate 112 dB dynamic range at 156 kHz output data rate 156 kHz maximum fully filtered output word rate Pin-selectable oversampling rates of 128× and 256× Low power mode Flexible serial peripheral interface (SPI) Fully differential modulator input On-chip differential amplifier for signal buffering On-chip reference buffer Full band low-pass finite impulse response (FIR) filter Overrange alert pin Digital gain correction registers Power-down mode Synchronization of multiple devices via the SYNC pin Daisy chaining

0 Hz/DC to 34 GHz, SPDT MEMS Switches Features: ADGM1001: DC to 34 GHz Insertion loss 0.8 dB (typical) at 18 GHz 1.5 dB (typical) at 34 GHz IIP3: 76 dBm (typical) Maximum RF power: 33 dBm On resistance: 3.4 Ω (typical) Maximum dc current: 200 mA Actuation lifetime: 100 million cycles (minimum) On switching time (tON): 200 μs (typical) Integrated 3.3 V driver for simple control with parallel and SPI Independently controllable switches Space-saving integrated passive components Small, 5.00 mm × 4.00 mm × 0.90 mm, 24-lead LGA package Temperature range: –40°C to +85°C

Integrated Optical Module for Smoke Detection Features: Supports UL-217 edition 8/ UL-568 ed. 7; EN-54; GB..; ISO Lowers Nuisance Alarms using a Dual Wavelength detection with higher SNR and dynamic range. 3X Lower power dissipation enables smaller/ cheaper batteries Integrated Optical Module (3.8mm x 5mm x 0.9mm with 1 blue LED, 1 IR LED and 2 Photo diodes) simplifies EMC design, allows for greater diversity of industrial design options and results in 75% fewer discrete components. Loop calibration at final test reduces calibration challenges with smoke detector products. Supported by ADI designed smoke chamber manufactured by Accumold, 28800X. (Please see EVAL-CHAMBER Mechanical Dimensions (PDF), also under Resources below)

High Voltage I2C Current and Voltage Monitor Features: Wide Operating Voltage Range: 7V to 80V 12-Bit Resolution for Both Current and Voltages I2C Interface Additional ADC Input Monitors an External Voltage Continuous Scan and Snapshot Modes Shutdown Mode (LTC4151) Reduces Quiescent Current to 120μA Split SDA for Opto-Isolation (LTC4151-1/LTC4151-2) Available in 10-Lead MSOP, 10-Lead 3mm × 3mm DFN and 16-Lead SO Packages

6 Channel, 14-Bit, 1.5Msps Simultaneous Sampling ADC with Shutdown Features: 1.5Msps ADC with Six Simultaneously Sampled Differential Inputs 250ksps Throughput per Channel 75dB SINAD Low Power Dissipation: 16.5mW 3V Single Supply Operation 2.5V Internal Bandgap Reference, Can be Overdriven with External Reference 3-Wire SPI-Compatible Serial Interface Internal Conversion Triggered by CONV Sleep (12µW) Shutdown Mode NAP (4.5mW) Shutdown Mode 0V to 2.5V Unipolar, or ±1.25V Bipolar Differential Input Range 83dB Common Mode Rejection Tiny 32-Pin (5mm × 5mm) QFN Package

Adjustable 1.1A Single Resistor Low Dropout Regulator Features: Outputs May Be Paralleled for Higher Current and Heat Spreading Output Current: 1.1A Single Resistor Programs Output Voltage 1% Initial Accuracy of SET Pin Current Output Adjustable to 0V Low Output Noise: 40VRMS (10Hz to 100kHz) Wide Input Voltage Range: 1.2V to 36V Low Dropout Voltage: 350mV (Except SOT-223 Package) <1mV Load Regulation <0.001%/V Line Regulation Minimum Load Current: 0.5mA Stable with 2.2F Minimum Ceramic Output Capacitor Current Limit with Foldback and Overtemperature Protected Available in 8-Lead MSOP, 3mm 3mm DFN 5-Lead DD-Pak, TO-220 and 3-Lead SOT-223 AEC-Q100 Qualified for Automotive Applications

3A, 4MHz Monolithic Synchronous Step-Down DC/DC Converter Features: 3A Output Current 2.25V to 5.5V Input Voltage Range Low Output Ripple Burst Mode® Operation: IQ = 70μA ±1% Output Voltage Accuracy Output Voltage Down to 0.6V High Efficiency: Up to 95% Low Dropout Operation: 100% Duty Cycle Shutdown Current: ≤1μA Adjustable Switching Frequency: Up to 4MHz Programmable Soft-Start Optional Active Voltage Positioning (AVP) with Internal Compensation Selectable Pulse-Skipping/Forced Continuous/Burst Mode Operation with Adjustable Burst Clamp Inputs for Start-Up Tracking or External Reference DDR Memory Mode, IOUT = ±1.5A Available in Thermally Enhanced 20-Pin (3mm × 4mm) QFN and TSSOP Packages AEC-Q100 Qualified for Automotive Applications

14-Bit, 40Msps Ultralow Power 1.8V ADCs Features: 74dB SNR 88dB SFDR Low Power: 81mW/49mW/35mW Single 1.8V Supply CMOS, DDR CMOS or DDR LVDS Outputs Selectable Input Ranges: 1VP-P to 2VP-P 800MHz Full-Power Bandwidth S/H Optional Data Output Randomizer Optional Clock Duty Cycle Stabilizer Shutdown and Nap Modes Serial SPI Port for Configuration Pin Compatible 14-Bit and 12-Bit Versions 40-Pin (6mm × 6mm) QFN Package

Octal 12-/10-/8-Bit SPI VOUT DACs with 10ppm/C Reference Features: Integrated Precision Reference 2.5V Full-Scale 10ppm/°C (LTC2636-L) 4.096V Full-Scale 10ppm/°C (LTC2636-H) Maximum INL Error: 2.5LSB (LTC2636-12) Low Noise: 0.75mVP-P 0.1Hz to 200KHz Guaranteed Monotonic Over –40°C to 125°C Temperature Range Selectable Internal or External Reference 2.7V to 5.5V Supply Range (LTC2636-L) Ultralow Crosstalk Between DACs (<2.4nV•s) Low Power: 0.9mA at 3V (LTC2636-L) Power-On-Reset to Zero-Scale/Mid-Scale Double-Buffered Data Latches Tiny 14-Lead 4mm × 3mm DFN and 16-Lead MSOP Packages

16-Bit, 1Msps, Low Power SAR ADC with Serial Interface Features: 1Msps Throughput Rate ±2LSB INL (Max) Guaranteed 16-Bit No Missing Codes Low Power: 13mW at 1Msps, 13μW at 1ksps 92dB SNR (typ) at fIN = 20kHz Guaranteed Operation to 125°C 2.5V Supply Fully Differential Input Range ±2.5V External 2.5V Reference Input No Pipeline Delay, No Cycle Latency 1.8V to 5V I/O Voltages SPI-Compatible Serial I/O with Daisy-Chain Mode Internal Conversion Clock 16-pin MSOP and 4mm × 3mm DFN Packages
