10 GHz, High Speed Window Comparator Features: Propagation delay: 88 ps Propagation delay at 50 mV overdrive: 20 ps Minimum detectable pulse width: 60 ps Differential latch control Power dissipation: 240 mW 16-terminal 2.9 mm × 2.9 mm LCC package

Active Bias Controller Features: Automatic Gate voltage adjustment (No Calibration required) Supply Voltage: 4V to 12V Digital Voltage: 3.3V to 5V Controls both Enhancement and Depletion type devices Adjustable Drain Current up to 200mA Sink/Source Gate Current Capability Optional Internal negative voltage generation that can be disabled to use external negative rail Fast Enable/Disable Trigger-out Output for Daisy Chain Power-Up and Power-Down Sequencing

0 Hz/DC to 34 GHz, SPDT MEMS Switches Features: ADGM1001: DC to 34 GHz Insertion loss 0.8 dB (typical) at 18 GHz 1.5 dB (typical) at 34 GHz IIP3: 76 dBm (typical) Maximum RF power: 33 dBm On resistance: 3.4 Ω (typical) Maximum dc current: 200 mA Actuation lifetime: 100 million cycles (minimum) On switching time (tON): 200 μs (typical) Integrated 3.3 V driver for simple control with parallel and SPI Independently controllable switches Space-saving integrated passive components Small, 5.00 mm × 4.00 mm × 0.90 mm, 24-lead LGA package Temperature range: –40°C to +85°C

Integrated Optical Module for Smoke Detection Features: Supports UL-217 edition 8/ UL-568 ed. 7; EN-54; GB..; ISO Lowers Nuisance Alarms using a Dual Wavelength detection with higher SNR and dynamic range. 3X Lower power dissipation enables smaller/ cheaper batteries Integrated Optical Module (3.8mm x 5mm x 0.9mm with 1 blue LED, 1 IR LED and 2 Photo diodes) simplifies EMC design, allows for greater diversity of industrial design options and results in 75% fewer discrete components. Loop calibration at final test reduces calibration challenges with smoke detector products. Supported by ADI designed smoke chamber manufactured by Accumold, 28800X. (Please see EVAL-CHAMBER Mechanical Dimensions (PDF), also under Resources below)

Nanopower, 3-Axis, 2 g/4 g/8 g Digital Output MEMS Accelerometer Features: Supply voltage range Single-cell battery operation: 1.1 V to 3.6 V Internal power supply regulation for high PSRR Ultralow power 0.89 μA at 100 Hz ODR, 2.0 V supply 180 nA motion activated wake-up mode 40 nA standby current High resolution: 0.25 mg/LSB Built-in features for system level power savings Single-tap and double-tap detection with only 35 nA of added current Adjustable threshold sleep and wake-up modes for motion activation Autonomous interrupt processing, without need for microcontroller intervention, to allow the rest of the system to be turned off completely Deep 512 sample embedded FIFO minimizes host processor load Awake state output enables implementation of motion activated switch Low noise to 170 μg/√Hz Acceleration sample synchronization via external trigger On-chip temperature sensor Internal two-pole antialias filter SPI (4-wire) and I2C digital interfaces Small and thin 2.2 mm × 2.3 mm × 0.87 mm package

High Performance, SPI Digital Output, Angular Rate Sensor Features: Excellent null offset stability over temperature High vibration rejection over a wide frequency range 2000 g powered shock survivability SPI digital output with 16-bit data-word Low noise Continuous self-test Fail-safe functions Temperature sensor 3.3 V and 5 V operation −40°C to +105°C operation Small, low-profile industry standard SOIC package provides yaw rate (Z-axis) response Innovative ceramic vertical mount package (VMP) provides pitch and roll rate response Qualified for automotive applications

Quad 16-Bit Rail-to-Rail DACs in 16-Lead SSOP Features: Smallest Pin Compatible Quad 16-Bit DAC: LTC2604: 16-Bits LTC2614: 14-Bits LTC2624: 12-Bits Guaranteed 16-Bit Monotonic Over Temperature Separate Reference Inputs for each DAC Wide 2.5V to 5.5V Supply Range Low Power Operation: 250µA per DAC at 3V Individual DAC Power-Down to 1µA, Max Ultralow Crosstalk Between DACs (<5µV) High Rail-to-Rail Output Drive (±15mA) Double Buffered Digital Inputs LTC2604-1/LTC2614-1/LTC2624-1: Power-On Reset to Midscale 16-Lead Narrow SSOP Package

Precision Dual-Channel, Difference Amplifier Features: With no external resistors Difference amplifier: gains of 0.5, 1, or 2 Single ended amplifiers: over 40 different gains Set reference voltage at midsupply Excellent ac specifications 15 MHz bandwidth 30 V/μs slew rate High accuracy dc performance 0.08% maximum gain error 10 ppm/°C maximum gain drift 80 dB minimum CMRR (G = 2) Two channels in small 4 mm × 4 mm LFCSP Supply current: 2.5 mA per channel Supply range: ±2.5 V to ±18 V

High-Performance, Low Distortion 500 MHz Mixer Features: Doubly Balanced Mixer Low Distortion +24 dBm Third Order Intercept (IP3) +10 dBm 1 dB Compression Point Bandwidth 500 MHz RF and LO Input Bandwidths 250 MHz Differential Current IF Output DC to >200 MHz Single-Ended Voltage IF Output Low LO Drive Required: –10 dBm Single- or Dual-Supply Operation DC Coupled Using Dual Supplies All Ports May Be DC Coupled No Lower Frequency Limit—Operation to DC User-Programmable Power Consumption

Dual VGA with Ultralow Noise Preamplifier and Programmable RIN Features: Ultralow noise preamplifier (preamp) Voltage noise = 0.74 nV/√Hz Current noise = 2.5 pA/√Hz 3 dB bandwidth: 100 MHz Low power: 145 mW/channel Wide gain range with programmable postamp −4.5 dB to +43.5 dB in LO gain mode 7.5 dB to 55.5 dB in HI gain mode Low output-referred noise: 48 nV/√Hz typical Active input impedance matching Optimized for 10-bit/12-bit ADCs Selectable output clamping level Single 5 V supply operation AD8332 and AD8334 available in lead frame chip scale package

DC to 50 MHz, Quad I/Q Demodulator and Phase Shifter Features: Quad integrated I/Q demodulator 16 phase select on each output (22.5° per step) Bandwidth: 4LO: LF to 200 MHz RF: LF to 50 MHz Baseband: determined by external filtering Power consumption: 73 mW/channel (290 mW total) Quadrature demodulation accuracy: Phase accuracy: ±1° Amplitude balance: ±0.25 dB Output dynamic range: 160 dB/Hz LO drive: >0 dBm (50 Ω), single-ended sine wave Supply: ±5 V Power-down via SPI (each channel and complete chip)

Very High Common-Mode Voltage Precision Difference Amplifier Features: ±600 V common-mode voltage range Rail-to-rail output Fixed gain of 1 Wide power supply range of ±2.5 V to ±18 V 550 μA typical power supply current Excellent ac specifications 90 dB minimum CMRR 310 kHz bandwidth High accuracy dc performance ±5 ppm maximum gain nonlinearity ±10 µV/°C maximum offset voltage drift ±5 ppm/°C maximum gain drift Download AD8479-EP data sheet (pdf) Military temperature range (−55°C to +125°C) Controlled manufacturing baseline One assembly/test site One fabrication site Product change notification Qualification data available on request A62/19619 VID DSCC Drawing Number

Complete 14-Bit, 3 MSPS Monolithic A/D Converter Features: Low Power Dissipation: 110 mW Single +5 V Supply Integral Nonlinearity Error: 2.5 LSB Differential Nonlinearity Error: 0.6 LSB Input Referred Noise: 0.36 LSB On-Chip Sample-and-Hold Amplifier and Voltage Reference Signal-to-Noise and Distortion Ratio: 79.0 dB Spurious-Free Dynamic Range: 91.0 dB Out-of-Range Indicator Straight Binary Output Data 44-Lead MQFP

14-Bit, 170 MSPS/250 MSPS, JESD204B, Dual Analog-to-Digital Converter Features: JESD204B Subclass 0 or Subclass 1 coded serial digital outputs Signal-to-noise ratio (SNR) = 70.6 dBFS at 185 MHz AIN and 250 MSPS Spurious-free dynamic range (SFDR) = 88 dBc at 185 MHz AIN and 250 MSPS Total power consumption: 711 mW at 250 MSPS 1.8 V supply voltages Integer 1-to-8 input clock divider Sample rates of up to 250 MSPS IF sampling frequencies of up to 400 MHz Internal analog-to-digital converter (ADC) voltage reference Flexible analog input range 1.4 V p-p to 2.0 V p-p (1.75 V p-p nominal) ADC clock duty cycle stabilizer (DCS) 95 dB channel isolation/crosstalk Serial port control Energy saving power-down modes

JESD204B Clock Generator with 14 LVDS/HSTL Outputs Features: 14 outputs configurable for HSTL or LVDS Maximum output frequency 6 outputs up to 1.25 GHz 8 outputs up to 1 GHz Dependent on the voltage controlled crystal oscillator (VCXO) frequency accuracy (start-up frequency accuracy: <±100 ppm) Dedicated 8-bit dividers on each output Coarse delay: 63 steps at 1/2 the period of the RF VCO divider output frequency with no jitter impact Fine delay: 15 steps of 31 ps resolution Typical output to output skew: 20 ps Duty cycle correction for odd divider settings Output 12 and Output 13, VCXO output at power-up Absolute output jitter: <160 fs at 122.88 MHz, 12 kHz to 20 MHz integration range Digital frequency lock detect SPI- and I2C-compatible serial control port Dual PLL architecture PLL1 Provides reference input clock cleanup with external VCXO Phase detector rate up to 110 MHz Redundant reference inputs Automatic and manual reference switchover modes Revertive and nonrevertive switching Loss of reference detection with holdover mode Low noise LVDS/HSTL outputs from VCXO used for radio frequency/intermediate frequency (RF/IF) synthesizers PLL2 Phase detector rate of up to 275 MHz Integrated low noise VCO

Precision Analog Microcontroller, 12-Bit Analog I/O, ARM7TDMI MCU Features: Analog I/O Multichannel, 12-bit, 1 MSPS ADC Up to 16 ADC channels Fully differential and single-ended modes 0 V to VREF analog input range12-bit voltage output DACs Up to 4 DAC outputs available On-chip voltage reference On-chip temperature sensor (±3°C) Voltage comparator Microcontroller ARM7TDMI core, 16-bit/32-bit RISC architecture JTAG port supports code download and debug Clocking options Trimmed on-chip oscillator (±3%) External watch crystal External clock source up to 44 MHz 41.78 MHz PLL with programmable divider See datasheet for additional features

Precision Analog Microcontroller, Tunable Optical Control Microcontroller Features: Analog input/output 22-channel, 14-bit, 800 kSPS analog-to-digital converter (ADC) 10 external channels 1 on-chip die temperature monitor 6 current output digital-to-analog converter (IDAC) monitor channels 3 power monitor channels 2 buffered reference output channels Fully differential and single-ended modes 0 V to 2.5 V analog input range 6 low noise, 12-/14-bit IDAC outputs 1× 250 mA, 1× 200 mA, 2× 100 mA, and 2× 20 mA Semiconductor optical amplifier (SOA) IDAC pull-down to −3.0 V for fast current sink Eight 12-bit voltage output DACs (VDACs) Channel 0 and Channel 1: 0 V to 3 V, 75 Ω load Channel 2 and Channel 3: −5 V to 0 V, 500 Ω load Channel 4 and Channel 5: 0 V to 3 V, 300 Ω load Channel 6: 0 V to 5 V, 500 Ω load Channel 7: 0 V to 5 V, 100 Ω load 2.5 V, on-chip voltage reference 2 buffered 2.5 V outputs Microcontroller ARM Cortex-M3 processor, 32-bit RISC architecture Serial wire port supports code download and debugging Clocking options Trimmed on-chip oscillator (±3%) 80 MHz phase-locked loop (PLL) External 16 MHz crystal option External clock source Memory 2× 128 kB Flash/EE memories, 32 kB SRAM In-circuit download, SW-DP-based debugging Software triggered in-circuit reprogrammability On-chip peripherals UART, 2× I2C and 2× SPI serial input/output 28-pin general-purpose input/output (GPIO) port 3 general-purpose timers Wake-up (W/U) timer Watchdog timer (WDT) 32-element programmable logic array (PLA) Vectored interrupt controller Interrupt on edge or level external pin inputs 9× external interrupts Power Multiple supplies 5 V for VDAC6 and VDAC7 3.3 V for digital and analog inputs/outputs 1.8 V to 2.7 V for IDACs −5 V supply for IDAC3 and VDAC2/VDAC3 Package and temperature range 6 mm × 6 mm, 112-ball CSP_BGA package Fully specified for −40°C to +85°C ambient operation Tools QuickStart™ development system Full third party support

1 A/0.6 A, DC-to-DC Switching Regulator with Independent Positive and Negative Outputs Features: Wide input supply voltage range: 2.85 V to 15 V Generates well regulated, independently resistor programmable VPOS and VNEG outputs Boost regulator to generate VPOS output Adjustable positive output to 39 V Integrated 1.0 A main switch Optional single-ended primary-inductor converter (SEPIC) configuration for automatic step-up/step-down Inverting regulator to generate VNEG output Adjustable negative output to VIN − 39 V Integrated 0.6 A main switch True shutdown for both positive and negative outputs 1.2 MHz/2.4 MHz switching frequency with optional external frequency synchronization from 1.0 MHz to 2.6 MHz Resistor programmable soft start timer Slew rate control for lower system noise Individual precision enable and flexible start-up sequence control for symmetric start, VPOS first, or VNEG first Out-of-phase operation UVLO, OCP, OVP, and TSD protection 4 mm × 4 mm, 20-lead LFCSP and 20-lead TSSOP −40°C to +125°C junction temperature range Supported by the ADIsimPower tool set

40 V, 200 mA, Low Noise, CMOS LDO Linear Regulator Features: Low noise: 11 μV rms independent of fixed output voltage PSRR of 88 dB at 10 kHz, 68 dB at 100 kHz, 50 dB at 1 MHz, VOUT ≤ 5 V, VIN = 7 V Input voltage range: 2.7 V to 40 V Maximum output current: 200 mA Initial accuracy: ±0.8% Accuracy over line, load, and temperature −1.2% to +1.5%, TJ = −40°C to +85°C ±1.8%, TJ = −40°C to +125°C Low dropout voltage: 200 mV (typical) at a 200 mA load, VOUT = 5 V User programmable soft start (LFCSP and SOIC only) Low quiescent current, IGND = 50 μA (typical) with no load Low shutdown current: 1.8 μA at VIN = 6 V, 3.0 μA at VIN = 40 V Stable with a small 2.2 μF ceramic output capacitor Fixed output voltage options: 1.8 V, 2.5 V, 3.3 V, 3.8 V, and 5.0 V 15 standard voltages between 1.2 V and 5.0 V are available Adjustable output from 1.2 V to VIN – VDO, output can be adjusted above initial set point Precision enable 2 mm × 2 mm, 6-lead LFCSP, 8-Lead SOIC, 5-Lead TSOT AEC-Q100 qualified for automotive applications

Integrated Optical Module for Smoke Detection Features: Supports UL-217 edition 8/ UL-568 ed. 7; EN-54; GB..; ISO Lowers Nuisance Alarms using a Dual Wavelength detection with higher SNR and dynamic range. 3X Lower power dissipation enables smaller/ cheaper batteries Integrated Optical Module (3.8mm x 5mm x 0.9mm with 1 blue LED, 1 IR LED and 2 Photo diodes) simplifies EMC design, allows for greater diversity of industrial design options and results in 75% fewer discrete components. Loop calibration at final test reduces calibration challenges with smoke detector products. Supported by ADI designed smoke chamber manufactured by Accumold, 28800X. (Please see EVAL-CHAMBER Mechanical Dimensions (PDF), also under Resources below)
