Fractional-N Frequency Synthesizer Features: RF bandwidth to 4 GHz 2.7 V to 3.3 V power supply Separate VP allows extended tuning voltage Programmable fractional modulus Programmable charge pump current 3-wire serial interface Analog and digital lock detect Power-down mode Pin-compatible with ADF4106/ADF4110/ADF4111/ADF4112/ ADF4113 and ADF4153 Consistent RF output phase Loop filter design possible with ADIsimPLL

General Purpose Amplifier 2 Circuit Rail-to-Rail 8-SO

Triple-Channel, Digital Isolator, Enhanced System-Level ESD Reliability (2/1 channel directionality) Features: Enhanced system-level ESD performance per IEC 61000-4-x Low power operation 5 V operation 2.0 mA per channel maximum at 0 Mbps to 2 Mbps 4.1 mA per channel maximum at 10 Mbps 36 mA per channel maximum at 90 Mbps 3.3 V operation 1.0 mA per channel maximum at 0 Mbps to 2 Mbps 2.8 mA per channel maximum at 10 Mbps 17 mA per channel maximum at 90 Mbps Bidirectional communication 3.3 V/5 V level translation High temperature operation: 105°C High data rate: dc to 90 Mbps (NRZ) Precise timing characteristics 2 ns maximum pulse width distortion 2 ns maximum channel-to-channel matching High common-mode transient immunity: >25 kV/μs Output enable function 16-lead SOIC wide body, RoHS-compliant package Safety and regulatory approvals UL recognition: 2500 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE Certificate of Conformity DIN V VDE V 0884-10 (VDE V 0884-10): 2006-12 VIORM = 560 V peak CQC Certification per GB4943.1-2011

Quad-Channel Isolators with Integrated DC-to-DC Converter (3:1 directionality) Features: isoPower integrated, isolated dc-to-dc converter 100 mA output supply AEC-Q100 qualified for automotive applications ADuM6421AW (ADuM6423AW pending) Meets CISPR 32/EN55032 Class B emission limits up to 5 Mbps at a full load on a 2-layer PCB Quad dc to 100 Mbps signal isolation channels 28-lead, fine pitch, SOIC with 8.3 mm minimum creepage High temperature operation: 125°C maximum High common-mode transient immunity: 100 kV/μs Safety and regulatory approvals (pending) UL recognition (pending) 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE V 0884-11 certificate of conformity (pending) VIORM = 566 V peak CQC certification per GB4943.1-2011 (pending)

3GHz HDMI 5:1 Transceiver with On-Screen Display Features: 5-input, 1-output HDMI® transceiver HDMI support 3GHz video support (e.g. 4k × 2k) Audio return channel (ARC) 3D TV support Content type bits CEC 1.4-compatible Extended colorimetry Character- and icon-based on-screen display (OSD) 3D OSD overlay on all mandatory 3D formats Support for OSD overlay on 3 GHz video formats High-Bandwidth Digital Content Protection (HDCP 1.4) HDCP repeater support Up to 127 KSVs supported 300 MHz maximum TMDS clock frequency (up to 4k × 2k) 48-, 36-, 30-bit deep colour input modes supported Ultralow jitter digital PLL (100% deskew) See data sheet for additional features

500kHz High Efficiency 3A Switching Regulator Features: Faster Switching with Increased Efficiency Uses Small Inductors: 4.7µH All Surface Mount Components Low Minimum Supply Voltage: 2.7V Quiescent Current: 4mA Typ Current Limited Power Switch: 3A Regulates Positive or Negative Outputs Shutdown Supply Current: 12µA Typ Easy External Synchronization

5.7 kV RMS/1.5 kV RMS, Quad-Channel LVDS 2.5 Gigabit Isolator (0 Reverse Channels) Features: 5.7 kV rms and 1.5 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS signal levels Quad-channel configuration Any data rate up to 2.5 Gbps switching with low jitter 10 Gbps total bandwidth across four channels 2.15 ns typical propagation delay Typical jitter: 0.82 ps rms random, 40 ps total peak Lower power 1.8 V supplies ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: 100 kV/μs typical Safety and regulatory approvals (28-lead SOIC_W_FP package) UL (pending): 5700 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-11 (VDE V 0884-11):2017-01 VIORM = 849 VPEAK (working voltage) Enable or disable refresh (low speed output correctness check) Operating temperature range: −40°C to +125°C 28-lead, wide-body, finer pitch SOIC_W_FP package with 8.3 mm creepage and clearance or 6 mm × 6 mm LFCSP package with 1.27 mm creepage and clearance

5 kV RMS/3.75 kV RMS, Dual LVDS Gigabit Isolator (0 Reverse Channels) Features: 5 kV rms and 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Any data rate up to 1.1 Gbps switching with low jitter 4 ns typical propagation delay 2.6 ps rms typical random jitter, rms 90 ps typical peak-to-peak total jitter at 1.1 Gbps 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection, phase spur level Glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN 55022 Class B radiated emissions limits with 1.1 Gbps PRBS Safety and regulatory approvals (20-lead SOIC_W package) UL (pending): 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 VPEAK Fail-safe output high for open, short, and terminated input conditions (ADN4655/ADN4656) Operating temperature range: −40°C to +125°C 7.8 mm minimum creepage and clearance

50 MHz TO 4.0 GHz RF/IF Gain Block Features: Fixed gain of 15 dB Operation from 50 MHz to 4.0 GHz Highest dynamic range gain block Input/output internally matched to 50 Ω Integrated bias control circuit OIP3 of 43.0 dBm at 900 MHz P1dB of 19.0 dBm at 900 MHz Noise figure of 3.7 dB at 900 MHz Single 5 V power supply Low quiescent current of 83 mA Thermally efficient SOT-89 package ESD rating of ±1.5 kV (Class 1C)

Hot Swap Controller and Digital Power and Energy Monitor with PMBus Interface Features: ±0.3% accurate, 12-bit ADC for IOUT, VIN, VOUT, and temperature 320 ns response time to short circuit Shutdown on detection of FET health fault Constant power foldback for tighter FET SOA protection Remote temperature sensing with programmable warning and shutdown thresholds Resistor-programmable 5 mV to 25 mV VSENSE current limit Programmable start-up current limit 1% accurate UV, OV, and PWRGD thresholds Split hot swap and power monitor inputs to allow additional external ADC filtering Reports power and energy consumption over time Peak detect registers for current, voltage, and power PROCHOT power throttling capability PMBus fast mode compliant interface 5 mm × 5 mm, 32-lead LFCSP

Low Power, +5V CMOS RS-232 100kBPS Transceiver with 4 Drivers, 5 Receivers, Shutdown and Enable Pins Features: Single 5 V Power Supply  Meets All EIA-232-E and V.28 Specifications  120 kB/s Data Rate  On-Board DC-DC Converters  ±9 V Output Swing with 5 V Supply  Small 1 µF Capacitors  Low Power Shutdown ≤ µA  Receivers Active in Shutdown (ADM223)  ±30 V Receiver Input Levels  Latch-Up FREE  Plug-In Upgrade for MAX223/230-241  Plug-In Upgrade for AD230–AD241

18-Bit, 250ksps, Pseudo-Differential Unipolar SAR ADC with 97dB SNR Features: 250ksps Throughput Rate ±2.5LSB INL (Max) Guaranteed 18-Bit No Missing Codes Low Power: 3.4mW at 250ksps, 3.4μW at 250sps 97dB SNR (Typ) at fIN = 2kHz –120dB THD (Typ) at fIN = 2kHz Guaranteed Operation to 125°C 2.5V Supply Pseudo-Differential Unipolar Input Range: 0V to VREF VREF Input Range from 2.5V to 5.1V No Pipeline Delay, No Cycle Latency 1.8V to 5V I/O Voltages SPI-Compatible Serial I/O with Daisy-Chain Mode Internal Conversion Clock 16-Lead MSOP and 4mm × 3mm DFN Packages

17V, 1A Synchronous Step-Down Regulator with 3.5A Quiescent Current Features: Wide VIN Range: 2.7V to 17V Wide VOUT Range: 0.6V to VIN 95% Max Efficiency Low IQ < 3.5μA, Zero-Current Shutdown Constant Frequency (1MHz/2.25MHz) Full Dropout Operation with Low IQ 1A Rated Output Current ±1% Output Voltage Accuracy Current Mode Operation for Excellent Line and Load Transient Response Synchronizable to External Clock Pulse-Skipping, Forced Continuous, Burst Mode® Operation Internal Compensation and Soft-Start Overtemperature Protection Compact 6-Lead DFN (2mm × 3mm) Package or Thermally-Enhanced MS8E Package with Power Good Output and Independent SGND Pin AEC-Q100 Qualified for Automotive Applications

Triple 10A Step-Down DC/DC Module (Power Module) Regulator Features: Three Independent 10A DC Output Current Regulator Channels Input Voltage Range: 4.7V to 16V 2.375V to 16V with External 5V Bias VOUT1,2 Voltage Range: 0.8V to 1.8V VOUT3 Voltage Range: 0.8V to 5.5V ±1.5% Maximum Total DC Output Error Current Mode Control/Fast Transient Response Frequency Synchronization Output Overvoltage and Overcurrent Protection Multiphase Operation with Current Sharing on VOUT1 and VOUT2 General Purpose Temperature Monitors Soft-Start/Voltage Tracking Power Good Monitors 15mm × 15mm × 5.01mm BGA Package

Dual 9A or Single 18A Module Regulator with Digital Power System Management Features: Dual, Fast, Analog Loops with Digital Interface for Control and Monitoring Wide Input Voltage Range: 4.5V to 17V Output Voltage Range: 0.5V to 5.5V ±0.5% Maximum DC Output Error Over Temperature ±2.5% Current Readback Accuracy at 9A Load 400kHz PMBus-Compliant I2C Serial Interface Integrated 16-Bit Σ ADC Supports Telemetry Polling Rates Up to 125Hz Constant Frequency Current Mode Control Parallel and Current Share Multiple Modules All 7-Bit Slave Addresses Supported Drop-In Pin-Compatible to Dual 13A LTM4676A and Dual 18A LTM4677 16mm × 11.9mm × 3.51mm BGA Package Readable Data: Input and Output Voltages, Currents, and Temperatures Running Peak Values, Uptime, Faults and Warnings Onboard EEPROM Fault Log Record with ECC Writable Data and Configurable Parameters: Output Voltage, Voltage Sequencing and Margining Digital Soft-Start/Stop Ramp OV/UV/OT, UVLO, Frequency and Phasing

High Linearity Differential RF/IF Amplifier/ADC Driver Features: 51.0dBm OIP3 at 240MHz into a 100Ω Diff Load NF = 2.9dB at 240MHz 20MHz to 2060MHz –3dB Bandwidth 20.8dB Gain A-Grade 100% OIP3 Tested at 380MHz 0.6nV/√Hz Total Input Noise S11 < –10dB Up to 1.4GHz S22 < –10dB Up to 1.4GHz >2.75VP-P Linear Output Swing P1dB = 24.0dBm Insensitive to VCC Variation 100Ω Differential Gain-Block Operation Input/Output Internally Matched to 100Ω Diff Single 5V Supply DC Power = 850mW 4mm × 4mm, 24-Lead QFN Package

16-/14-/11-Bit 2.7Gsps DACs Features:80dBc SFDR at 50MHz fOUT>68dBc SFDR from DC to 1080MHz fOUT40mA Nominal Full-Scale, ±1V Output Compliant10mA to 60mA Adjustable Full-Scale Current RangeSingle or Dual Port DDR LVDS and DHSTL InterfaceLow Latency (7.5 Cycles for Single Port, 11 Cycles for Dual Port)>78dBc 2-Tone IMD from DC to 1000MHz fOUT–156dBc/Hz Additive Phase Noise at 1MHz Offset for 65MHz fOUT170-Lead (9mm × 15mm) BGA Package

Dual 9A or Single 18A Module Regulator with Digital Power System Management Features: Dual, Fast, Analog Loops with Digital Interface for Control and Monitoring Wide Input Voltage Range: 4.5V to 17V Output Voltage Range: 0.5V to 5.5V ±0.5% Maximum DC Output Error Over Temperature ±2.5% Current Readback Accuracy at 9A Load 400kHz PMBus-Compliant I2C Serial Interface Integrated 16-Bit Σ ADC Supports Telemetry Polling Rates Up to 125Hz Constant Frequency Current Mode Control Parallel and Current Share Multiple Modules All 7-Bit Slave Addresses Supported Drop-In Pin-Compatible to Dual 13A LTM4676A and Dual 18A LTM4677 16mm × 11.9mm × 3.51mm BGA Package Readable Data: Input and Output Voltages, Currents, and Temperatures Running Peak Values, Uptime, Faults and Warnings Onboard EEPROM Fault Log Record with ECC Writable Data and Configurable Parameters: Output Voltage, Voltage Sequencing and Margining Digital Soft-Start/Stop Ramp OV/UV/OT, UVLO, Frequency and Phasing

Dual 13A or Single 26A Module (Power Module) Regulator with Digital Power System Management Features: Dual, Fast, Analog Loops with Digital Interface for Control and Monitoring Wide Input Voltage Range: 4.5V to 26.5V Output Voltage Range: 0.5V to 5.5V ±0.5% Maximum DC Output Error Over Temperature ±2.5% Current Readback Accuracy at 10A Load 400kHz PMBus-Compliant I2C Serial Interface Integrated 16-Bit ΔΣ ADC Supports Telemetry Polling Rates Up to 125Hz Constant Frequency Current Mode Control Parallel and Current Share Multiple Modules All 7-Bit Slave Addresses Supported Pin-Compatible to Dual 18A LTM4677 16mm × 16mm × 5.01mm BGA PackageReadable Data: Input and Output Voltages, Currents, and Temperatures Running Peak Values, Uptime, Faults and Warnings Onboard EEPROM Fault Log Record with ECCWritable Data and Configurable Parameters: Output Voltage, Voltage Sequencing and Margining Digital Soft-Start/Stop Ramp OV/UV/OT, UVLO, Frequency and Phasing

Dual 5V, 2A Synchronous Step-Down DC/DCs in Tiny LQFN and WLCSP Features: Dual Outputs Each with 2A Output Current High Efficiency: 19mΩ NMOS and 75mΩ PMOS Wide Bandwidth, Fast Transient Response Switching Frequency Synchronizable Up to 3MHz VIN Range: 2.25V to 5.5V VOUT Range: 0.5V to VIN VOUT Accuracy: ±1% Low Ripple Burst Mode® Operation Peak Current Mode Control Minimum On-Time: 25ns Safely Tolerates Inductor Saturation in Overload Shutdown Current: 1.2µA Precision 400mV Enable Thresholds Internal Soft-Start and Compensation Power Good Output Low Profile, Thermally Enhanced 12-Lead 2mm × 2mm × 0.74mm LQFN and 16-Ball 1.64mm × 1.64mm × 0.5mm WLCSP Packages AEC-Q100 Qualified for Automotive Applications
