The AD5241 / AD52421 provide a single-/dual-channel, 256-position, digitally controlled variable resistor (VR) device. These devices perform the same electronic adjustment function as a potentiometer, trimmer, or variable resistor. Each VR offers a completely programmable value of resistance between the A terminal and the wiper, or the B terminal and the wiper. For the AD5242, the fixed A-to-B terminal resistance of 10 kΩ, 100 kΩ, or 1 MΩ has a 1% channel-to-channel matching tolerance. The nominal temperature coefficient of both parts is 30 ppm/°C.Wiper position programming defaults to midscale at system power on. When powered, the VR wiper position is programmed by an I2C-compatible, 2-wire serial data interface. Both parts have two extra programmable logic outputs available that enable users to drive digital loads, logic gates, LED drivers, and analog switches in their system.The AD5241 / AD5242 are available in surface-mount, 14-lead SOIC and 16-lead SOIC packages and, for ultracompact solutions, 14-lead TSSOP and 16-lead TSSOP packages. All parts are guaranteed to operate over the extended temperature range of −40°C to +105°C.APPLICATIONS Multimedia, video, and audio Communications Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Programmable voltage-to-current conversion Line impedance matching

The AD5241 / AD52421 provide a single-/dual-channel, 256-position, digitally controlled variable resistor (VR) device. These devices perform the same electronic adjustment function as a potentiometer, trimmer, or variable resistor. Each VR offers a completely programmable value of resistance between the A terminal and the wiper, or the B terminal and the wiper. For the AD5242, the fixed A-to-B terminal resistance of 10 kΩ, 100 kΩ, or 1 MΩ has a 1% channel-to-channel matching tolerance. The nominal temperature coefficient of both parts is 30 ppm/°C.Wiper position programming defaults to midscale at system power on. When powered, the VR wiper position is programmed by an I2C-compatible, 2-wire serial data interface. Both parts have two extra programmable logic outputs available that enable users to drive digital loads, logic gates, LED drivers, and analog switches in their system.The AD5241 / AD5242 are available in surface-mount, 14-lead SOIC and 16-lead SOIC packages and, for ultracompact solutions, 14-lead TSSOP and 16-lead TSSOP packages. All parts are guaranteed to operate over the extended temperature range of −40°C to +105°C.APPLICATIONS Multimedia, video, and audio Communications Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Programmable voltage-to-current conversion Line impedance matching

The AD5243 and AD5248 provide a compact 3 mm × 4.9 mmpackaged solution for dual, 256-position adjustment applications.The AD5243 performs the same electronic adjustment functionas a 3-terminal mechanical potentiometer, and the AD5248performs the same adjustment function as a 2-terminal variableresistor. Available in four end-to-end resistance values (2.5 kΩ,10 kΩ, 50 kΩ, and 100 kΩ), these low temperature coefficientdevices are ideal for high accuracy and stability-variableresistance adjustments. The wiper settings are controllablethrough the I2C-compatible digital interface. The AD5248 hasextra package address decode pins, AD0 and AD1, allowingmultiple parts to share the same I2C, 2-wire bus on a PCB. Theresistance between the wiper and either endpoint of the fixedresistor varies linearly with respect to the digital code transferred into the RDAC latch. (The terms digital potentiometer, VR,and RDAC are used interchangeably.)Operating from a 2.7 V to 5.5 V power supply and consumingless than 6 µA allows the AD5243/AD5248 to be used inportable battery-operated applications.For applications that program the AD5243/AD5248 at thefactory, Analog Devices, Inc., offers device programmingsoftware running on Windows® NT/2000/XP operating systems.This software effectively replaces the need for external I2Ccontrollers, which in turn enhances the time to market ofsystems. An AD5243/AD5248 evaluation kit and software areavailable. The kit includes a cable and instruction manual.Applications Systems calibrations Electronics level settings Mechanical trimmers replacement in new designs Permanent factory printed circuit board (PCB) setting Transducer adjustment of pressure, temperature, position, chemical, and optical sensors RF amplifier biasing Gain control and offset adjustment

The AD5243 and AD5248 provide a compact 3 mm × 4.9 mmpackaged solution for dual, 256-position adjustment applications.The AD5243 performs the same electronic adjustment functionas a 3-terminal mechanical potentiometer, and the AD5248performs the same adjustment function as a 2-terminal variableresistor. Available in four end-to-end resistance values (2.5 kΩ,10 kΩ, 50 kΩ, and 100 kΩ), these low temperature coefficientdevices are ideal for high accuracy and stability-variableresistance adjustments. The wiper settings are controllablethrough the I2C-compatible digital interface. The AD5248 hasextra package address decode pins, AD0 and AD1, allowingmultiple parts to share the same I2C, 2-wire bus on a PCB. Theresistance between the wiper and either endpoint of the fixedresistor varies linearly with respect to the digital code transferred into the RDAC latch. (The terms digital potentiometer, VR,and RDAC are used interchangeably.)Operating from a 2.7 V to 5.5 V power supply and consumingless than 6 µA allows the AD5243/AD5248 to be used inportable battery-operated applications.For applications that program the AD5243/AD5248 at thefactory, Analog Devices, Inc., offers device programmingsoftware running on Windows® NT/2000/XP operating systems.This software effectively replaces the need for external I2Ccontrollers, which in turn enhances the time to market ofsystems. An AD5243/AD5248 evaluation kit and software areavailable. The kit includes a cable and instruction manual.Applications Systems calibrations Electronics level settings Mechanical trimmers replacement in new designs Permanent factory printed circuit board (PCB) setting Transducer adjustment of pressure, temperature, position, chemical, and optical sensors RF amplifier biasing Gain control and offset adjustment

The AD5243 and AD5248 provide a compact 3 mm × 4.9 mmpackaged solution for dual, 256-position adjustment applications.The AD5243 performs the same electronic adjustment functionas a 3-terminal mechanical potentiometer, and the AD5248performs the same adjustment function as a 2-terminal variableresistor. Available in four end-to-end resistance values (2.5 kΩ,10 kΩ, 50 kΩ, and 100 kΩ), these low temperature coefficientdevices are ideal for high accuracy and stability-variableresistance adjustments. The wiper settings are controllablethrough the I2C-compatible digital interface. The AD5248 hasextra package address decode pins, AD0 and AD1, allowingmultiple parts to share the same I2C, 2-wire bus on a PCB. Theresistance between the wiper and either endpoint of the fixedresistor varies linearly with respect to the digital code transferred into the RDAC latch. (The terms digital potentiometer, VR,and RDAC are used interchangeably.)Operating from a 2.7 V to 5.5 V power supply and consumingless than 6 µA allows the AD5243/AD5248 to be used inportable battery-operated applications.For applications that program the AD5243/AD5248 at thefactory, Analog Devices, Inc., offers device programmingsoftware running on Windows® NT/2000/XP operating systems.This software effectively replaces the need for external I2Ccontrollers, which in turn enhances the time to market ofsystems. An AD5243/AD5248 evaluation kit and software areavailable. The kit includes a cable and instruction manual.Applications Systems calibrations Electronics level settings Mechanical trimmers replacement in new designs Permanent factory printed circuit board (PCB) setting Transducer adjustment of pressure, temperature, position, chemical, and optical sensors RF amplifier biasing Gain control and offset adjustment

The AD5243 and AD5248 provide a compact 3 mm × 4.9 mmpackaged solution for dual, 256-position adjustment applications.The AD5243 performs the same electronic adjustment functionas a 3-terminal mechanical potentiometer, and the AD5248performs the same adjustment function as a 2-terminal variableresistor. Available in four end-to-end resistance values (2.5 kΩ,10 kΩ, 50 kΩ, and 100 kΩ), these low temperature coefficientdevices are ideal for high accuracy and stability-variableresistance adjustments. The wiper settings are controllablethrough the I2C-compatible digital interface. The AD5248 hasextra package address decode pins, AD0 and AD1, allowingmultiple parts to share the same I2C, 2-wire bus on a PCB. Theresistance between the wiper and either endpoint of the fixedresistor varies linearly with respect to the digital code transferred into the RDAC latch. (The terms digital potentiometer, VR,and RDAC are used interchangeably.)Operating from a 2.7 V to 5.5 V power supply and consumingless than 6 µA allows the AD5243/AD5248 to be used inportable battery-operated applications.For applications that program the AD5243/AD5248 at thefactory, Analog Devices, Inc., offers device programmingsoftware running on Windows® NT/2000/XP operating systems.This software effectively replaces the need for external I2Ccontrollers, which in turn enhances the time to market ofsystems. An AD5243/AD5248 evaluation kit and software areavailable. The kit includes a cable and instruction manual.Applications Systems calibrations Electronics level settings Mechanical trimmers replacement in new designs Permanent factory printed circuit board (PCB) setting Transducer adjustment of pressure, temperature, position, chemical, and optical sensors RF amplifier biasing Gain control and offset adjustment

The AD5243 and AD5248 provide a compact 3 mm × 4.9 mmpackaged solution for dual, 256-position adjustment applications.The AD5243 performs the same electronic adjustment functionas a 3-terminal mechanical potentiometer, and the AD5248performs the same adjustment function as a 2-terminal variableresistor. Available in four end-to-end resistance values (2.5 kΩ,10 kΩ, 50 kΩ, and 100 kΩ), these low temperature coefficientdevices are ideal for high accuracy and stability-variableresistance adjustments. The wiper settings are controllablethrough the I2C-compatible digital interface. The AD5248 hasextra package address decode pins, AD0 and AD1, allowingmultiple parts to share the same I2C, 2-wire bus on a PCB. Theresistance between the wiper and either endpoint of the fixedresistor varies linearly with respect to the digital code transferred into the RDAC latch. (The terms digital potentiometer, VR,and RDAC are used interchangeably.)Operating from a 2.7 V to 5.5 V power supply and consumingless than 6 µA allows the AD5243/AD5248 to be used inportable battery-operated applications.For applications that program the AD5243/AD5248 at thefactory, Analog Devices, Inc., offers device programmingsoftware running on Windows® NT/2000/XP operating systems.This software effectively replaces the need for external I2Ccontrollers, which in turn enhances the time to market ofsystems. An AD5243/AD5248 evaluation kit and software areavailable. The kit includes a cable and instruction manual.Applications Systems calibrations Electronics level settings Mechanical trimmers replacement in new designs Permanent factory printed circuit board (PCB) setting Transducer adjustment of pressure, temperature, position, chemical, and optical sensors RF amplifier biasing Gain control and offset adjustment

The AD524 is a precision monolithic instrumentation amplifier designed for data acquisition applications requiring high accuracy under worst-case operating conditions. An outstanding combination of high linearity, high common mode rejection, low offset voltage drift, and low noise makes the AD524 suitable for use in many data acquisition systems.The AD524 has an output offset voltage drift of less than 25 µV/ °C, input offset voltage drift of less than 0.5 µV/°C, CMR above 90 dB at unity gain (120 dB at G = 1000) and maximum nonlinearity of 0.003% at G = 1. In addition to the outstanding dc specifications the AD524 also has a 25MHz gain bandwidth product (G = 1000). To make it suitable for high speed data ac-quisition systems the AD524 has an output slew rate of 5 V/µs and settles in 15µs to 0.01% for gains of 1 to 100.As a complete amplifier the AD524 does not require any external components for fixed gains of 1, 10, 100 and 1,000. For other gain settings between 1 and 1000 only a single resistor is required. The AD524 input is fully protected for both power on and power off fault conditions.The AD524 IC instrumentation amplifier is available in four different versions of accuracy and operating temperature range. The economical 'A' grade, the low drift 'B' grade and lower drift, higher linearity 'C' grade are specified from -25°C to +85°C. The 'S' grade guarantees performance to specification over the extended temperature range -55°C to +125°C. Devices are available in 16-pin ceramic DIP and SOIC packages and a 20-terminal leadless chip carrier.Product HighlightsThe AD524 has guaranteed low offset voltage, offset voltage drift, and low noise for precision high gain applications. The AD524 is functionally complete with pin program- mable gains of 1, 10, 100, and 1000, and single resistor programmable for any gain. Input and output offset nulling terminals are provided for very high precision applications and to minimize offset voltage changes in gain ranging applications. The AD524 is input protected for both power-on and power-off fault conditions. The AD524 offers superior dynamic performance with a gain bandwidth product of 25 MHz, full power response of 75 kHz and a settling time of 15 μs to 0.01% of a 20 V step (G = 100). Data Sheet, Rev. F, 11/07

The AD524 is a precision monolithic instrumentation amplifier designed for data acquisition applications requiring high accuracy under worst-case operating conditions. An outstanding combination of high linearity, high common mode rejection, low offset voltage drift, and low noise makes the AD524 suitable for use in many data acquisition systems.The AD524 has an output offset voltage drift of less than 25 µV/ °C, input offset voltage drift of less than 0.5 µV/°C, CMR above 90 dB at unity gain (120 dB at G = 1000) and maximum nonlinearity of 0.003% at G = 1. In addition to the outstanding dc specifications the AD524 also has a 25MHz gain bandwidth product (G = 1000). To make it suitable for high speed data ac-quisition systems the AD524 has an output slew rate of 5 V/µs and settles in 15µs to 0.01% for gains of 1 to 100.As a complete amplifier the AD524 does not require any external components for fixed gains of 1, 10, 100 and 1,000. For other gain settings between 1 and 1000 only a single resistor is required. The AD524 input is fully protected for both power on and power off fault conditions.The AD524 IC instrumentation amplifier is available in four different versions of accuracy and operating temperature range. The economical 'A' grade, the low drift 'B' grade and lower drift, higher linearity 'C' grade are specified from -25°C to +85°C. The 'S' grade guarantees performance to specification over the extended temperature range -55°C to +125°C. Devices are available in 16-pin ceramic DIP and SOIC packages and a 20-terminal leadless chip carrier.Product HighlightsThe AD524 has guaranteed low offset voltage, offset voltage drift, and low noise for precision high gain applications. The AD524 is functionally complete with pin program- mable gains of 1, 10, 100, and 1000, and single resistor programmable for any gain. Input and output offset nulling terminals are provided for very high precision applications and to minimize offset voltage changes in gain ranging applications. The AD524 is input protected for both power-on and power-off fault conditions. The AD524 offers superior dynamic performance with a gain bandwidth product of 25 MHz, full power response of 75 kHz and a settling time of 15 μs to 0.01% of a 20 V step (G = 100). Data Sheet, Rev. F, 11/07

The AD5259 provides a compact, nonvolatile LFCSP-10 (3 mm x 3 mm) or MSOP-10 (3 mm x 4.9 mm) packaged solution for 256-position adjustment applications. These devices perform the same electronic adjustment function as mechanical potentiometers or variable resistors, but with enhanced resolution and solid-state reliability. The terms digital potentiometer, VR (variable resistor), and RDAC are used interchangeably.The wiper settings are controllable through an I2C-compatible digital interface that is also used to read back the wiper register and EEPROM content. Resistor tolerance is also stored within EEPROM, providing an end-to-end tolerance accuracy of 0.1%.A separate VLOGIC pin delivers increased interface flexibility. For users who need multiple parts on one bus, Address Bit AD0 and Address Bit AD1 allow up to four devices on the same busAPPLICATIONS LCD panel VCOM adjustment LCD panel brightness and contrast control Mechanical potentiometer replacement in new designs Programmable power supplies RF amplifier biasing Automotive electronics adjustment Gain control and offset adjustment Fiber to the home systems Electronics level settings

The AD5260 and AD5262 are 1- and 2-channel, 256 position, SPI interface digitally controlled, variable resistor (VR) devices. These parts operate from either a single +5 V to +15 V supply or a dual ±5 V supply, extending terminal voltage adjustment to these supply voltages. (Most industry digital potentiometers are limited to a 5 V operating range). These devices perform the same electronic adjustment function as a potentiometer or variable resistor while offering solid-state reliability and electronic packaging compactness. These devices are offered in the thin 1.1 mm height TSSOP 14- and 16-lead surface mount packages.

The AD5260 and AD5262 are 1- and 2-channel, 256 position, SPI interface digitally controlled, variable resistor (VR) devices. These parts operate from either a single +5 V to +15 V supply or a dual ±5 V supply, extending terminal voltage adjustment to these supply voltages. (Most industry digital potentiometers are limited to a 5 V operating range). These devices perform the same electronic adjustment function as a potentiometer or variable resistor while offering solid-state reliability and electronic packaging compactness. These devices are offered in the thin 1.1 mm height TSSOP 14- and 16-lead surface mount packages.

The AD5260 / AD5262 provide a single- or dual-channel, 256- position, digitally controlled variable resistor (VR) device.1 These devices perform the same electronic adjustment function as a potentiometer or variable resistor. Each channel of the AD5260/AD5262 contains a fixed resistor with a wiper contact that taps the fixed resistor value at a point determined by a digital code loaded into the SPI-compatible serial-input register. The resistance between the wiper and either end point of the fixed resistor varies linearly with respect to the digital code transferred into the VR latch. The variable resistor offers a completely programmable value of resistance, between the A terminal and the wiper or the B terminal and the wiper. The fixed A-to-B terminal resistance of 20 Ω, 50 Ω, or 200 Ω has a nominal temperature coefficient of 35 ppm/°C. Unlike the majority of the digital potentiometers in the market, these devices can operate up to 15 V or ±5 V provided proper supply voltages are furnished.Each VR has its own VR latch that holds its programmed resistance value. These VR latches are updated from an internal serial-to-parallel shift register, which is loaded from a standard 3-wire serial-input digital interface. The AD5260 contains an 8-bit serial register whereas the AD5262 contains a 9-bit serial register. Each bit is clocked into the register on the positive edge of the CLK pin. The AD5262 address bit determines the corresponding VR latch to be loaded with the last eight bits of the data word during the positive edging of CS strobe. A serial data output pin at the opposite end of the serial register enables simple daisy-chaining in multiple VR applications without additional external decoding logic. An optional reset pin (PR) forces the wiper to the midscale position by loading 0x80 into the VR latch.The AD5260 / AD5262 are available in thin surface-mount 14-lead TSSOP and 16-lead TSSOP packages. All parts are guaranteed to operate over the extended industrial temperature range of −40°C to +85°C.APPLICATIONS Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Stereo channel audio level control Programmable voltage-to-current conversion Programmable filters, delays, time constants Line impedance matching Low resolution DAC replacement

The AD5260 / AD5262 provide a single- or dual-channel, 256- position, digitally controlled variable resistor (VR) device.1 These devices perform the same electronic adjustment function as a potentiometer or variable resistor. Each channel of the AD5260/AD5262 contains a fixed resistor with a wiper contact that taps the fixed resistor value at a point determined by a digital code loaded into the SPI-compatible serial-input register. The resistance between the wiper and either end point of the fixed resistor varies linearly with respect to the digital code transferred into the VR latch. The variable resistor offers a completely programmable value of resistance, between the A terminal and the wiper or the B terminal and the wiper. The fixed A-to-B terminal resistance of 20 Ω, 50 Ω, or 200 Ω has a nominal temperature coefficient of 35 ppm/°C. Unlike the majority of the digital potentiometers in the market, these devices can operate up to 15 V or ±5 V provided proper supply voltages are furnished.Each VR has its own VR latch that holds its programmed resistance value. These VR latches are updated from an internal serial-to-parallel shift register, which is loaded from a standard 3-wire serial-input digital interface. The AD5260 contains an 8-bit serial register whereas the AD5262 contains a 9-bit serial register. Each bit is clocked into the register on the positive edge of the CLK pin. The AD5262 address bit determines the corresponding VR latch to be loaded with the last eight bits of the data word during the positive edging of CS strobe. A serial data output pin at the opposite end of the serial register enables simple daisy-chaining in multiple VR applications without additional external decoding logic. An optional reset pin (PR) forces the wiper to the midscale position by loading 0x80 into the VR latch.The AD5260 / AD5262 are available in thin surface-mount 14-lead TSSOP and 16-lead TSSOP packages. All parts are guaranteed to operate over the extended industrial temperature range of −40°C to +85°C.APPLICATIONS Mechanical potentiometer replacement Instrumentation: gain, offset adjustment Stereo channel audio level control Programmable voltage-to-current conversion Programmable filters, delays, time constants Line impedance matching Low resolution DAC replacement

The AD5332 / AD5333 / AD5342 / AD5343 are dual 8-,10-,and 12-bit DACs. They operate from a 2.5 V to 5.5 V supply consuming just 230 µA at 3 V, and feature a power-down pin, PD that further reduces the current to 80 nA. These devices incorporate an on-chip output buffer that can drive the output to both supply rails, while the AD5333 and AD5342 allow a choice of buffered or unbuffered reference input.PRODUCT HIGHLIGHTS Available in a 28-lead TSSOP package Low power, single supply operation from 2.5 V to 5.5 V supply Consumes 0.69 mW at 3 V and 1.5 mW at 5 V On-chip output buffer can drive output to both supply rails Allows a choice of buffered/unbuffered reference input Programmable output range 0-VREF or 0-2VREF (via GAIN pin)

The AD5380 is a complete, single-supply, 40-channel, 14-bit DAC available in a 100-lead LQFP package. All 40 channels have an on-chip output amplifier with rail-to-rail operation. The AD5380 includes a programmable internal 1.25 V/2.5 V, 10 ppm/°C reference, an on-chip channel monitor function that multiplexes the analog outputs to a common MON_OUT pin for external monitoring, and an output amplifier boost mode that allows optimization of the amplifier slew rate. The AD5380 contains a double-buffered parallel interface that features a 20 ns WR pulse width, an SPI-, QSPI-, -MICROWIRE, -DSP compatible serial interface with interface speeds in excess of 30 MHz, and an I2C-compatible interface that supports a 400 kHz data transfer rate.An input register followed by a DAC register provides double buffering, allowing the DAC outputs to be updated independently or simultaneously using the LDAC input.Each channel has a programmable gain and offset adjust register that allows the user to fully calibrate any DAC channel. Power consumption is typically 0.25 mA/channel with boost off.APPLICATIONS Variable optical attenuators (VOA) Level setting (ATE) Optical micro-electro-mechanical systems (MEMS) Control systems Instrumentation

The AD5380 is a complete, single-supply, 40-channel, 14-bit DAC available in a 100-lead LQFP package. All 40 channels have an on-chip output amplifier with rail-to-rail operation. The AD5380 includes a programmable internal 1.25 V/2.5 V, 10 ppm/°C reference, an on-chip channel monitor function that multiplexes the analog outputs to a common MON_OUT pin for external monitoring, and an output amplifier boost mode that allows optimization of the amplifier slew rate. The AD5380 contains a double-buffered parallel interface that features a 20 ns WR pulse width, an SPI-, QSPI-, -MICROWIRE, -DSP compatible serial interface with interface speeds in excess of 30 MHz, and an I2C-compatible interface that supports a 400 kHz data transfer rate.An input register followed by a DAC register provides double buffering, allowing the DAC outputs to be updated independently or simultaneously using the LDAC input.Each channel has a programmable gain and offset adjust register that allows the user to fully calibrate any DAC channel. Power consumption is typically 0.25 mA/channel with boost off.APPLICATIONS Variable optical attenuators (VOA) Level setting (ATE) Optical micro-electro-mechanical systems (MEMS) Control systems Instrumentation

The AD5415 is a CMOS, 12-bit, dual channel, current output digital-to-analog converter. This device operates from a 2.5 V to 5.5 V power supply, making it suited to battery-powered applications and other applications.As a result of being manufactured on a CMOS submicron process, this part offers excellent 4-quadrant multiplication characteristics, with large-signal multiplying bandwidths of 10 MHz.The applied external reference input voltage (VREF) determines the full scale output current. An integrated feedback resistor (RFB) provides temperature tracking and full scale voltage output when combined with an external current to voltage precision amplifier. In addition, this device contains the 4-quadrant resistors necessary for bipolar operation and other configuration modes.This DAC uses a double buffered, 3-wire serial interface that is compatible with SPI®, QSPI™, MICROWIRE™, and most DSP interface standards. In addition, a serial data out pin (SDO) allows daisy-chaining when multiple packages are used. Data readback allows the user to read the contents of the DAC register via the SDO pin. On power-up, the internal shift register and latches are filled with 0s, and the DAC outputs are at zero scale.The AD5415 DAC is available in a 24-lead TSSOP package. The EVAL-AD5415/AD5449SDZ evaluation board is available for evaluating DAC performance. For more information, see the UG-296 evaluation board user guide.APPLICATIONS Portable battery-powered applications Waveform generators Analog processing Instrumentation applications Programmable amplifiers and attenuators Digitally controlled calibration Programmable filters and oscillators Composite video Ultrasound Gain, offset, and voltage trimming

The AD5428 / AD5440 / AD5447 are Dual CMOS 8-, 10- and 12-bit, dual-channel, current output digital-to-analog converters (DACs), respectively. These devices operate from a 2.5 V to 5.5 V power supply, making them suited to battery-powered and other applications.As a result of being manufacture on a CMOS submicron process, they offer excellent 4-quadrant multiplication characteristics, with large signal multiplying bandwidths of up to 10 MHz.These DACs utilize data readback, allowing the user to read the contents of the DAC register via the DB pins. On power-up, the internal register and latches are filled with zeros and the DAC outputs are at zero scale.The applied external reference input voltage (VREF) determines the full scale output current. An integrated feedback resistor (RFB) provides temperature tracking and full scale voltage output when combined with an external I-to-V Precision Amplifier.The AD5428 is available in small 20 lead TSSOP package, while the AD5440/AD5447 DACs are available in small 24-lead TSSOP packages.APPLICATIONS Portable battery-powered applications Waveform generators Analog processing Instrumentation applications Programmable amplifiers and attenuators Digitally controlled calibration Programmable filters and oscillators Composite video Ultrasound Gain, offset, and voltage trimming

The AD5424 / AD5433 / AD5445 are CMOS 8-, 10-, and 12-bitcurrent output digital-to-analog converters (DACs), respectively.These devices operate from a 2.5 V to 5.5 V power supply,making them suitable for battery-powered applications andmany other applications. These DACs utilize data readback,allowing the user to read the contents of the DAC register viathe DB pins. On power-up, the internal register and latches arefilled with 0s and the DAC outputs are at zero scale.As a result of manufacturing with a CMOS submicron process,they offer excellent 4-quadrant multiplication characteristics,with large signal multiplying bandwidths of up to 10 MHz.The applied external reference input voltage (VREF) determines thefull-scale output current. An integrated feedback resistor (RFB)provides temperature tracking and full-scale voltage outputwhen combined with an external I-to-V precision amplifier.While these devices are upgrades of the AD5424 / AD5433 /AD5445 in multiplying bandwidth performance, they have alatched interface and cannot be used in transparent mode.The AD5424 is available in a small, 20-lead LFCSP and a small,16-lead TSSOP, while the AD5433 and AD5445 DACs are availablein a small, 20-lead LFCSP and a small, 20-lead TSSOP.The EVAL-AD5445SDZ evaluation board is available forevaluating DAC performance. For more information, see theUG-333 evaluation board user guide.APPLICATIONS Portable battery-powered applications Waveform generators Analog processing Instrumentation applications Programmable amplifiers and attenuators Digitally controlled calibration Programmable filters and oscillators Composite video Ultrasound Gain, offset, and voltage trimming
