Power Management IC Development Tools LTC4121EUD-4.2 Demo Board 400mA Synchronous Buck Battery Charger, VIN = 4.4V to 40V, VBAT = fixed 4.2V

Real Time Clock 3V/5V Real-Time Clock

EPROM 1Kb Add-Only Memory

Battery Management Lithium-Ion Lin Bat Chr Cntr

LED Lighting Drivers 36V, 2A Sync Buck LED Drvr

Battery Management Hi Eff USB Pwr Manager + 3x Buck DC/DC

LED Display Drivers 8-Digit MUXd Decoder/Driver

Operational Amplifiers - Op Amps Single/Dual/Triple/Quad Operational Amplifiers

ANALOGUE SWITCH, QUAD, WSOIC-16; No. of Channels: 4Channels; Analogue Switch Type: SPST; On State Resistance Max: 4ohm; Supply Voltage Range: 4.5V to 36V, ± 4.5V to ± 20V; Analogue Switch Case: WSOIC; No. of Pins: 16Pins; Oper

Switching Voltage Regulators 60V, 4A DC/DC Module Reg

EVAL KIT, PROGRAMMABLE GAIN AMPLIFIER; Silicon Manufacturer: Maxim Integrated Products; Silicon Core Number: MAX3522B; Kit Application Type: Amplifier; Application Sub Type: Programmable Gain Amplifier; Kit Contents: Eval Kit MAX3522B; Product Range: -; SVHC: No SVHC (27-Jun-2018)

EVALUATION KIT, IO-LINK TRANSCEIVER; Kit Application Type: Interface; Application Sub Type: IO-Link Transceiver; Silicon Manufacturer: Maxim Integrated Products; Silicon Core Number: MAX22513; Product Range: -; Kit Contents: Evaluation Kit MAX22513, USB-A-to-Micro-B Cable, Software; SVHC: No SVHC (15-Jan-2019); MSL: MSL 1 - Unlimited

Operational Amplifiers - Op Amps

Transimpedance Amplifiers Analog CATV Transimpedance Amp

Precision Amplifiers 23MHz, 50V/ s, 1x S 2x Prec Op Amps

The AD8042 is a low power voltage feedback, high speed amplifier designed to operate on +3 V, +5 V or ± 5 V supplies. It has true single supply capability with an input voltage range extending 200 mV below the negative rail and within 1 V of the positive rail.The output voltage swing extends to within 30 mV of each rail, providing the maximum output dynamic range. Additionally, it features gain flatness of 0.1 dB to 14 MHz while offering differential gain and phase error of 0.04% and 0.06° on a single 5 V supply. This makes the AD8042 useful for professional video electronics such as cameras, video switchers or any high speed portable equipment. The AD8042's low distortion and fast settling make it ideal for buffering single-supply, high speed Analog-to-Digital converters (ADCs).The AD8042 offers low power supply current of 12 mA maximum and can run on a single 3.3 V power supply. These features are ideally suited for portable and battery powered applications where size and power are critical.The wide bandwidth of 160 MHz along with 200 V/µs of slew rate on a single 5 V supply make the AD8042 useful in many general-purpose, high speed applications where single supplies from +3.3 V to +12 V and dual power supplies of up to ±6 V are needed. The AD8042 is available in 8-lead PDIP and SOIC_N packages.ApplicationsVideo switchersDistribution amplifiersAnalog-to-digital driversProfessional camerasCCD Imaging systemsUltrasound equipment (multichannel)

The AD8661 / AD8662 / AD8664 are rail-to-rail output, single-supplyamplifiers that use the Analog Devices, Inc., patentedDigiTrim® trimming technique to achieve low offset voltage.The AD8661 / AD8662 / AD8664 series features extendedoperating ranges, with supply voltages up to 16 V. It alsofeatures low input bias current, wide signal bandwidth,and low input voltage and current noise.The combination of low offset, very low input bias current,and a wide supply range makes these amplifiers useful in a widevariety of applications usually associated with higher priced JFETamplifiers. Systems using high impedance sensors, such asphotodiodes, benefit from the combination of low input biascurrent, low noise, low offset, and wide bandwidth. The wideoperating voltage range meets the demands of high performanceanalog-to-digital converters (ADCs) and digital-to-analogconverters (DACs). Audio applications and medical monitoringequipment can take advantage of the high input impedance, lowvoltage, low current noise, and wide bandwidth.The single AD8661 is available in a narrow 8-lead SOIC packageand a very thin, dual lead, 8-lead LFCSP. The AD8661 SOICpackage is specified over the extended industrial temperaturerange of −40°C to +125°C. The AD8661 LFCSP is specified overthe industrial temperature range of −40°C to +85°C. The AD8662is available in a narrow 8-lead SOIC package and an 8-lead MSOP,both specified over the extended industrial temperature range of−40°C to +125°C. The AD8664 is available in a narrow 14-leadSOIC package and a 14-lead TSSOP, both with an extendedindustrial temperature range of −40°C to +125°C.Applications Sensors Medical equipment Consumer audio Photodiode amplification ADC drivers

The MAX4991–MAX4994 low on-resistance analog switches operate from a single +1.8V to +5.5V supply. The MAX4991/MAX4993 feature a slow turn-on time to reduce clicks and pops due to coupling capacitors and audio amplifiers with a DC output bias. This feature provides click-and-pop reduction without adding additional parts for existing architectures.The MAX4991/MAX4992 are dual single-pole/double-throw (SPDT) switches, while the MAX4993/MAX4994 are double-pole/double-throw (DPDT) switches. The MAX4993/MAX4994 feature an active-low enable input (active-low EN) that sets all the channels to high impedance and reduces supply current when driven high. These devices have 0.3Ω on-resistance and 0.004% THD+N to route high fidelity audio signals.The MAX4991–MAX4994 are available in space-saving 10-pin UTQFN (1.4mm x 1.8mm) package, and are specified for operation over the -40°C to +85°C extended temperature range.ApplicationsAudio Signal RoutingCellular PhonesPortable MP3 PlayersSpeaker Headset Source Switching

The MAX5134–MAX5137 is a family of pin-compatible and software-compatible 16-bit and 12-bit DACs. The MAX5134/MAX5135 are low-power, quad 16-/12-bit, buffered voltage-output, high-linearity DACs. The MAX5136/MAX5137 are low-power, dual 16-/12-bit, buffered voltage-output, high-linearity DACs. They use a precision internal reference or a precision external reference for rail-to-rail operation. The MAX5134–MAX5137 accept a wide +2.7V to +5.25V supply-voltage range to accommodate most low-power and low-voltage applications. These devices accept a 3-wire SPI-/QSPI™-/MICROWIRE®-/DSP-compatible serial interface to save board space and reduce the complexity of optically isolated and transformer-isolated applications. The digital interface’s double-buffered hardware and software active-low LDAC provide simultaneous output updates. The serial interface features an active-low READY output for easy daisy-chaining of several MAX5134–MAX5137 devices and/or other compatible devices. The MAX5134–MAX5137 include a hardware input to reset the DAC outputs to zero or midscale upon power-up or reset, providing additional safety for applications that drive valves or other transducers that need to be off during power-up. The high linearity of the DACs makes these devices ideal for precision control and instrumentation applications. The MAX5134–MAX5137 are available in an ultra-small (4mm x 4mm), 24-pin TQFN package or a 16-pin TSSOP package. Both packages are specified over the -40°C to +105°C extended industrial temperature range.ApplicationsAutomatic Test EquipmentAutomatic TuningCommunication SystemsData AcquisitionGain and Offset AdjustmentPortable InstrumentationPower-Amplifier ControlProcess Control and Servo LoopsProgrammable Voltage and Current Sources

The MAX9650/MAX9651 are single- and dual-channel VCOM amplifiers with rail-to-rail inputs and outputs. The MAX9650/MAX9651 can drive up to 1300mA of peak current per channel and operate up to 20V.The MAX9650/MAX9651 are designed to source and sink a high current quickly to hold the VCOM voltage stable in large TFT-LCD panels.The MAX9650/MAX9651 feature 40V/µs slew rate and 35MHz bandwidth to quickly settle outputs for 120Hz frame rate and full HD television.The MAX9650/MAX9651 feature output short-circuit protection and thermal shutdown. These devices are available in exposed pad packages for excellent heat dissipation.ApplicationsDisplays: LCDFlat-Panel and Plasma TVsInstrument Control Voltage SourcesTFT-LCD Display Panels
