Quad-Channel Isolators with Integrated DC/DC Converter (1/3 channel directionality) Features: isoPower integrated, isolated DC/DC converter Regulated 3.3 V or 5 V output Up to 400 mW output power Quad dc-to-25 Mbps (NRZ) signal isolation channels Schmitt trigger inputs 16-lead SOIC package with 7.6 mm creepage High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs See data sheet for additional features

Quad-Channel Isolators with Integrated DC/DC Converter (0/4 channel directionality) Features: isoPower integrated, isolated DC/DC converter Regulated 3.3 V or 5 V output Up to 400 mW output power Quad dc-to-25 Mbps (NRZ) signal isolation channels Schmitt trigger inputs 16-lead SOIC package with 7.6 mm creepage High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs See data sheet for additional features

Quad-Channel Isolators with Integrated DC-to-DC Converter (3:1 directionality) Features: isoPower integrated, isolated dc-to-dc converter 100 mA output supply AEC-Q100 qualified for automotive applications ADuM6421AW (ADuM6423AW pending) Meets CISPR 32/EN55032 Class B emission limits up to 5 Mbps at a full load on a 2-layer PCB Quad dc to 100 Mbps signal isolation channels 28-lead, fine pitch, SOIC with 8.3 mm minimum creepage High temperature operation: 125°C maximum High common-mode transient immunity: 100 kV/μs Safety and regulatory approvals (pending) UL recognition (pending) 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE V 0884-11 certificate of conformity (pending) VIORM = 566 V peak CQC certification per GB4943.1-2011 (pending)

Ultralow Noise, LDO XFET 2.5V Voltage Reference w/Current Sink and Source Features: Ultralow noise (0.1 Hz to 10 Hz) ADR440: 1 μV p-p ADR441: 1.2 μV p-p ADR443: 1.4 μV p-p ADR444: 1.8 μV p-p ADR445: 2.25 μV p-p Superb temperature coefficient A Grade: 10 ppm/°C B Grade: 3 ppm/°C Low dropout operation (supply voltage headroom): 500 mV Input range: (VOUT + 500 mV) to 18 V High output source and sink current +10 mA and −5 mA, respectively Wide temperature range: −40°C to +125°CADR441-EP supports defense and aerospace applications (AQEC standard) Download ADR441-EP Data Sheet (pdf) Military temperature range (−55°C to +125°C) Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request V62/18620 DSCC Drawing Number

Integrated Dual RF Receiver Features: Dual receivers Maximum Receiver BW: 200 MHz Fully integrated, fractional-N, RF synthesizers Fully integrated clock synthesizer Multichip phase synchronization for RF LO and baseband clocks JESD204B datapath interface Tuneable range: 75 MHz to 6000 MHz

Integrated Dual RF Tx, Rx, and Observation Rx Features: Dual transmitters Dual receivers Dual input shared observation receiver Maximum receiver bandwidth: 200 MHz Maximum tunable transmitter synthesis bandwidth: 450 MHz Maximum observation receiver bandwidth: 450 MHz Fully integrated fractional-N RF synthesizers Fully integrated clock synthesizer Multichip phase synchronization for RF LO and baseband clocks JESD204B datapath interface Tuning range (center frequency): 75 MHz to 6000 MHz

Integrated, Dual RF Transceiver with Observation Path Features: Dual differential Tx Dual differential Rx Observation receiver with 2 inputs Fully integrated, ultralow power DPD actuator and adaptation engine for PA linearization Sniffer receiver with 3 inputs Tunable range: 300 MHz to 6000 MHz Linearization signal BW to 40 MHz Tx synthesis BW to 250 MHz Rx BW: 8 MHz to 100 MHz Supports FDD and TDD operation Fully integrated independent fractional-N RF synthesizers for Tx, Rx, ORx, and clock generation JESD204B digital interface

Up to 1GHz SHARC+ DSP with 640KB L1, 1024KB Shared L2 SRAM, 120-lead LQFP_EP Features:SHARC+ Core infrastructure 800MHz (max) or 1GHz (max) Core clock frequency 640KB on-chip Level 1 (L1) SRAM memory (with parity) increases low latency performance 32-bit, 40-bit & 64-bit floating point support 32-bit fixed point Byte, short-word, word, long-word addressedMemory 1024KB on-chip Level 2 (L2) SRAM with ECC protection - eliminates need for external memory in many use cases Advanced Hardware Accelerators Enhanced FIR/IIR offload engines running at Core clock frequency for added processing power Security Crypto Engines with OTPPowerful DMA SystemInnovative Digital Audio Interface (DAI) includes: 8x Full SPORT interfaces w/TDM & I2S modes 2x S/PDIF Rx/Tx, 8 ASRC pairs 4x Precision Clock Generators 24 BuffersOther Peripheral Connectivity / Interfaces: 2x Quad SPI, 1x Octal SPI MLB 3-pin 4x I2C, 2x UARTs 6x General Purpose Timer, 1x General Purpose Counter 2x Watchdog Timers 2-ch 12bit Housekeeping ADCs 22 GPIO pins, 24 DAI pins Thermal SensorPackage 14mm x 14mm 120-lead LQFP_EAdditional Features Security and Protection Crypto hardware accelerators Fast secure boot with IP protection Enhanced FIR and IIR accelerators running up to 1 GHz AEC-Q100 qualified for automotive applications

3-Channel Sigma-Delta ADC with SPI Features: One (ADE7903) 24-bit, Σ-Δ ADC (simultaneously sampling with three ADE7912/ADE7913 ADCs) On-chip temperature sensor 4-wire SPI serial interface Standalone 24-bit, Σ-Δ ADC Up to four ADE7903 and ADE7912/ADE7913 devices clocked from a single crystal or an external clock Synchronization of multiple ADE7903 and ADE7912/ADE7913 devices ±31.25 mV peak input range for current channel ±500 mV peak input range for voltage channels Single 3.3 V supply 20-lead, wide body SOIC package Operating temperature: −40°C to +85°C

Phase Detector / PLL Frequency Synthesizer Features: 400 MHz bandwidth 2.7 to 3.3 V power supply Separate charge pump supply (VP) allows extended tuning voltage in 3 V systems Programmable charge pump currents 3-wire serial interface Analog and digital lock detect Hardware and software power-down mode 104  MHz phase detectorADF4002-EP supports defense and aerospace applications (AQEC standard) Download ADF4002-EP data sheet (pdf) Military temperature range: −55°C to +125°C Controlled manufacturing baseline One assembly/test site One fabrication site Enhanced product change notification Qualification data available on request V62/11607 DSCC Drawing Number

Microwave Wideband Synthesizer with Integrated VCO Features: Output frequency range: 800 MHz to 12.8 GHz Jitter = 18 fsRMS (Integration BW: 100 Hz to 100 MHz) Jitter = 27 fsRMS (ADC SNR Method) Wideband Noise Floor: -160 dBc/Hz @12 GHz PLL Specifications: -239 dBc/Hz: Normalized In-Band Phase Noise Floor -147 dBc/Hz: Normalized In-Band 1/f Noise Phase Detector Frequency up to 500 MHzReference Input Frequency up to 1 GHz Typical -100 dBc PFD spursReference to Output Delay Specifications: Part-to-Part Standard Deviation: 3 ps Temperature Drift: 0.03 ps/ Adjustment Step Size: <+/-0.1 ps Multi-chip Output Phase Alignment 3.3 V and 5 V Power supplies 7 mm x 7 mm 48 Lead LGA

5 kV RMS/3.75 kV RMS, Dual LVDS Gigabit Isolator (0 Reverse Channels) Features: 5 kV rms and 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Any data rate up to 1.1 Gbps switching with low jitter 4 ns typical propagation delay 2.6 ps rms typical random jitter, rms 90 ps typical peak-to-peak total jitter at 1.1 Gbps 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection, phase spur level Glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN 55022 Class B radiated emissions limits with 1.1 Gbps PRBS Safety and regulatory approvals (20-lead SOIC_W package) UL (pending): 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 VPEAK Fail-safe output high for open, short, and terminated input conditions (ADN4655/ADN4656) Operating temperature range: −40°C to +125°C 7.8 mm minimum creepage and clearance

5 kV RMS/3.75 kV RMS, Dual LVDS Gigabit Isolator (Second Channel Reversed) Features: 5 kV rms and 3.75 kV rms LVDS isolators Complies with TIA/EIA-644-A LVDS standard Multiple dual-channel configurations Any data rate up to 1.1 Gbps switching with low jitter 4 ns typical propagation delay 2.6 ps rms typical random jitter, rms 90 ps typical peak-to-peak total jitter at 1.1 Gbps 2.5 V or 3.3 V supplies −75 dBc power supply ripple rejection, phase spur level Glitch immunity ±8 kV IEC 61000-4-2 ESD protection across isolation barrier High common-mode transient immunity: >25 kV/μs Passes EN 55022 Class B radiated emissions limits with 1.1 Gbps PRBS Safety and regulatory approvals (20-lead SOIC_W package) UL (pending): 5000 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A (pending) VDE certificate of conformity (pending) DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 424 VPEAK Fail-safe output high for open, short, and terminated input conditions (ADN4655/ADN4656) Operating temperature range: −40°C to +125°C 7.8 mm minimum creepage and clearance

250 Mbps, Half Duplex, Quad M-LVDS Transceivers Features: Four M-LVDS transceivers (driver and receiver pairs) Switching rate: 250 Mbps (125 MHz) Independent pin select for each receiver, two modes: Type 1: input hysteresis of 15 mV typical Type 2: differential input threshold voltage offset by 100 mV to support open-circuit, short-circuit, and bus idle fail-safe Compatible with the TIA/EIA-899 standard for M-LVDS Glitch free power-up/power-down on the M-LVDS bus Controlled transition times on the driver output Common-mode range: −1 V to +3.4 V, allowing communication with ±2 V of ground noise Driver outputs high-Z when disabled or powered off Independent enable pins for each driver and receiver Enhanced ESD protection on bus pins ≥±15 kV HBM, air discharge ≥±8 kV HBM, contact discharge ≥±10 kV IEC 61000-4-2, air discharge ≥±8 kV IEC 61000-4-2, contact discharge Enhanced ±8 kV HBM ESD protection for all pins, contact discharge Operating temperature range: −40°C to +105°C Available in 48-lead, 7 mm x 7 mm LFCSP

Digital Controller for Power Supply Applications with PMBus Interface Features: −40°C to +125°C operation with EEPROM data retention of 15 years at 125°C PMBus Revision 1.2 compliant 32-bit password protection with command masking 64 address selections (16 base addresses, expandable to 64) 6 PWM control signals, 625 ps resolution Duty cycle double update rate Digital control loop (PID + additional pole or zero configurability) Programmable loop filters (CCM, DCM, low/normal temperature) Frequency synchronization Soft start and soft stop functionality Average and peak constant current mode External PN junction temperature sensing 4 GPIOs (2 GPIOs configurable as active clamp snubber PWMs) Fast line voltage feedforward Adaptive dead time compensation for improved efficiency Extended black box data recorder for fault recording See datasheet for additional features

Digital Controller for Power Supply Applications with PMBus Interface Features: −40°C to +125°C operation with EEPROM data retention of 15 years at 125°C PMBus Revision 1.2 compliant 32-bit password protection with command masking 64 address selections (16 base addresses, expandable to 64) 6 PWM control signals, 625 ps resolution Duty cycle double update rate Digital control loop (PID + additional pole or zero configurability) Programmable loop filters (CCM, DCM, low/normal temperature) Frequency synchronization Soft start and soft stop functionality Average and peak constant current mode External PN junction temperature sensing 4 GPIOs (2 GPIOs configurable as active clamp snubber PWMs) Fast line voltage feedforward Adaptive dead time compensation for improved efficiency Extended black box data recorder for fault recording See datasheet for additional features

Isolated, Synchronous Forward Controller with Active Clamp and iCoupler Features: Current mode controller for active clamp forward topology Integrated 5 kV (wide body SOIC package) or 3.0 kV (LGA package) rated dielectric isolation voltage with Analog Devices, Inc., patented iCoupler technology Wide voltage supply range Primary VIN: up to 60 V Secondary VDD2: up to 36 V Integrated 1 A primary side MOSFET driver for power switch and active clamp reset switch Integrated 1 A secondary side MOSFET drivers for synchronous rectification Integrated error amplifier and <1% accurate reference voltage Programmable slope compensation Programmable frequency range: 50 kHz to 600 kHz typical Frequency synchronization Programmable maximum duty cycle limit Programmable soft start Smooth soft start from precharged load Programmable dead time Power saving light load mode using MODE pin Protection features such as short circuit, output overvoltage, and overtemperature protection Cycle-by-cycle input overcurrent protection Precision enable UVLO with hysteresis PGOOD pin for system flagging Tracking function from secondary side Remote (secondary side) shutdown/reset function Safety and regulatory approvals (pending) UL recognition 5000 V rms for 1 minute per UL 1577 (for wide body SOIC package) 3000 V rms for 1 minute per UL 1577 (for LGA package) CSA component acceptance notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak (for wide body SOIC package) VIORM = 560 V peak (for LGA package) CQC certification per GB4943.1-2011 Available in 24-lead SOIC_W package and 24-terminal LGA package AEC-Q100 Qualified for Automotive Applications

25V, 3.5A, 2.4MHz Step-Down Switching Regulator Features: Wide Input Range: 3.6V to 25V 3.5A Maximum Output Current Adjustable Switching Frequency: 200kHz to 2.4MHz Low Shutdown Current: IQ < 1μA Integrated Boost Diode Synchronizable Between 250kHz to 2MHz Power Good Flag Saturating Switch Design: 95mΩ On-Resistance 0.790V Feedback Reference Voltage Output Voltage: 0.79V to 25V Thermal Protection Soft-Start Capability Small 10-Pin (3mm × 3mm) DFN Packages

25V, 3.5A, 2.4MHz Step-Down Switching Regulator Features: Wide Input Range: 3.6V to 25V 3.5A Maximum Output Current Adjustable Switching Frequency: 200kHz to 2.4MHz Low Shutdown Current: IQ < 1μA Integrated Boost Diode Synchronizable Between 250kHz to 2MHz Power Good Flag Saturating Switch Design: 95mΩ On-Resistance 0.790V Feedback Reference Voltage Output Voltage: 0.79V to 25V Thermal Protection Soft-Start Capability Small 10-Pin (3mm × 3mm) DFN Packages

25V, 3.5A, 2.4MHz Step-Down Switching Regulator Features: Wide Input Range: 3.6V to 25V 3.5A Maximum Output Current Adjustable Switching Frequency: 200kHz to 2.4MHz Low Shutdown Current: IQ < 1μA Integrated Boost Diode Synchronizable Between 250kHz to 2MHz Power Good Flag Saturating Switch Design: 95mΩ On-Resistance 0.790V Feedback Reference Voltage Output Voltage: 0.79V to 25V Thermal Protection Soft-Start Capability Small 10-Pin (3mm × 3mm) DFN Packages
