Nonvolatile Memory, Dual 1024-Position Digital Resistor

ANALOGUE SWITCH DUAL SPDT MSOP-10; Analog Switch Type:SPDT; No. of Channels:2Channels; On State Resistance Max:4ohm; Supply Voltage Range:1.8V to 5.5V; Analog Switch Case:MSOP; No. of Pins:10Pins; Operating Temperature Min:-40 C

Complete Quad, 16-Bit, High Accuracy, Serial Input, Bipolar Voltage Output DAC Features: Complete quad, 16-bit digital-to-analog converters (DAC) Programmable output range: ±10 V, ±10.2564 V, or ±10.5263 V ±1 LSB max INL error, ±1 LSB maximum DNL error Low noise: 60 nV/√Hz Settling time: 10 µs maximum Integrated reference buffers Internal reference: 10 ppm/°C maximum On-chip die temperature sensor Output control during power-up/brownout Programmable short-circuit protection Simultaneous updating via LDAC Asynchronous CLR to zero code Digital offset and gain adjust See Data Sheet for Additional Information

ANALOGUE SWITCH DUAL SPDT LFCSP-12; Analogue Switch Type:SPDT; No. of Channels:2Channels; On State Resistance Max:475ohm; Supply Voltage Range:12V ± 15V; Analogue Switch Case:LFCSP; No. of Pins:12Pins; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:ADG1236 Series; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016)

ANALOG MULTIPLEXER 8X1 LFCSP-16; Multiplexer Configuration:8:1; No. of Circuits:1Circuits; On State Resistance Max:75ohm; Supply Voltage Range:2V to 12V ± 2V to ± 6V; Analogue Multiplexer Case:LFCSP; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:ADG658 Series; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016)

15 MHz Rail-to-Rail Operational Dual Op Amp Features: Wide Bandwidth: 15 MHz Low Offset Voltage: 325 µV max Low Noise: 9.5 nV/√Hz @ 1 kHz Single-Supply Operation: +2.7 V to +12 V Rail-to-Rail Output Swing Low TCVOS: 1 µV/°C typ High Slew Rate: 13 V/µs See data sheet for additional featuresOP262-EP supports defense and aerospace applications (AQEC standard) Download OP262-EP data sheet (pdf) Military temperature range (−55°C to +125°C) Controlled manufacturing baseline One assembly/test site One fabrication site Enhanced product change notification See data sheet for additional features V62/12639 DSCC Drawing number

10 A, RRIO, Zero Input Crossover Distortion Quad Op Amp Features: PSRR: 100 dB minimum CMRR: 105 dB typical Very low supply current: 10 μA per amplifier maximum 1.8 V to 5 V single-supply or ±0.9 V to ±2.5 V dual-supply operation Rail-to-rail input and output 3 mV offset voltage maximum Very low input bias current: 0.5 pA typical

256-/1024-Position, Digital Potentiometers with Maximum 1% R-Tolerance Error and 20-TP Memory

6.5V, 4 A, High Efficiency, Step-Down DC-to-DC Regulator Features: 4 A continuous output current 43 mΩ and 29 mΩ integrated FET ±1.5% output accuracy Input voltage range: 2.7 V to 6.5 V Output voltage: 0.6 V to VIN Switching frequency Fixed frequency: 600 kHz or 1.2 MHz Adjustable frequency: 500 kHz to 1.4 MHz Synchronizable from 500 kHz to 1.4 MHzSelectable synchronize phase shift: 0° or 180° Current mode architecture Precision enable input Power-good output Voltage tracking input Integrated soft start Internal compensation Starts up into a precharged output UVLO, OVP, OCP, and thermal shutdown Available in 16-lead, 4 mm × 4 mm LFCSP package Supported by ADIsimPower™ design tool

AMP INST DUAL SMD LFCSP-16 8222; No. of Amplifiers:2 Amplifier; Input Offset Voltage:120µV; Slew Rate:2V/µs; Bandwidth:150kHz; Supply Voltage Range:± 2.3V to ± 18V; Amplifier Case Style:LFCSP; No. of Pins:16Pins; Amplifier Output:Single Ended / Differential; CMRR:130dB; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:AD8222 Series; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016); Amplifer Supply Voltage:± 2.3V to ± 18V; Base Number:8222; Gain Bandwidth:1200kHz; No. of Amplifiers:2Amplifiers; Operating Temperature Range:-40°C to +125°C; Output Type:Single Ended; Programmable Gain Max:10000; Supply Current:900µA; Supply Voltage Max:18V; Supply Voltage Min:2.3V; Termination Type:Surface Mount Device

4.0 Gbps Dual Driver

OP AMP 15V 1.3MHZ 0.7V/US 8MSOP; No. of Amplifiers:2 Amplifier; Bandwidth:1.3MHz; Slew Rate:0.7V/µs; Supply Voltage Range:± 2.5V to ± 15V; Amplifier Case Style:MSOP; No. of Pins:8Pins; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:OP2177 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); Amplifer Supply Voltage:± 2.5V to ± 15V; No. of Amplifiers:2Amplifiers; Op Amp Type:Precision

24-Bit, 312 kSPS, 109 dB Sigma-Delta ADC with On-Chip Buffers and Serial Interface Features: High performance 24-bit Σ-Δ ADC 115 dB dynamic range at 78.125 kHz output data rate 109 dB dynamic range at 312.5 kHz output data rate 312.5 kHz maximum fully filtered output word rate Pin-selectable oversampling rates of 64×, 128×, and 256× Low power mode Flexible serial peripheral interface (SPI) Fully differential modulator input On-chip differential amplifier for signal buffering On-chip reference buffer Full band, low-pass, finite impulse response (FIR) filter Overrange alert pin Digital gain correction registers Power-down mode Synchronization of multiple devices via the SYNC pin Daisy chaining

RF/IF AMPLIFIER 16 dB 1 GHz 5.5 V 3-SOT-89 FULL REEL; Frequency Min:20MHz; Frequency Max:1GHz; Gain:16.7dB; Noise Figure Typ:3dB; RF IC Case Style:SOT-89; No. of Pins:3Pins; Supply Voltage Min:4.5V; Supply Voltage Max:5.5V

TEMPERATURE TRANSDUCER 0.5C FLATPACK-2; IC Output Type:Current; Sensing Accuracy Range: 0.5 C; Sensing Temperature Min:-55 C; Sensing Temperature Max:+150 C; Sensor Case Style:Flatpack; No. of Pins:2; Supply Voltage Min:4V; MSL:- ;RoHS Compliant: Yes

Fast Response, High Voltage, Current Shunt Comparator Features: Input-to-output response: <100 ns High input common-mode voltage range Operating: 5 V to 65 V Survival: 0 V to 68 V Current output Hysteresis: 10 mV Integrated 2.4 V regulator Wide operating temperature range: -40°C to +125°C 8-lead MSOP package Qualified for automotive applications

DIGITAL TO ANALOG CONVERTER DAC 10 BIT 175MSPS LFCSP-32; Resolution (Bits):10bit; Sampling Rate:175MSPS; Input Channel Type:Parallel; Supply Voltage Range:1.7V to 3.6V; ADC / DAC Case Style:CSP; No. of Pins:32Pins; Packaging:Each ;RoHS Compliant: Yes

OP AMP RRIO 2.5MHZ 1V/US 5SOT23; No. of Amplifiers:1 Amplifier; Bandwidth:2.5MHz; Slew Rate:1V/µs; Supply Voltage Range:2.7V to 5V; Amplifier Case Style:SOT-23; No. of Pins:5Pins; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:AD8628 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); Amplifer Supply Voltage:2.7V to 5V; No. of Amplifiers:1Amplifiers; Op Amp Type:Zero Drift

Open-Drain Microprocessor Supervisory Circuit in 4-Lead SOT-143

Micropower Single-Supply Rail-to-Rail Input/Output Op Amps
