Overvoltage Protection, Circuit Breaker PMIC 8-SO

Non-Isolated PoL Module DC DC Converter 4 Output 0.6 ~ 5.5V 0.6 ~ 5.5V 0.6 ~ 5.5V 0.6 ~ 5.5V 4A, 4A, 4A, 4A 4V - 14V Input

16-Bit, Isolated Sigma-Delta Modulator Features: 5 MHz to 20 MHz external clock input rate 16 bits, no missing codes Signal to noise ratio (SNR): 88 dB (typical) Effective number of bits (ENOB): 14.2 bits typical Typical offset drift vs. temperature: 1.6 μV/°C typical On-board digital isolator On-board reference See data sheet for additional featuresAD7403-EP supports defense and aerospace applications (AQEC standard) Download AD7403-EP data sheet Military temperature range: −55°C to +125°C Controlled manufacturing baseline One assembly/test site One fabrication site Enhanced product change notification Qualification data available on request V62/16625 DSCC Drawing Number

Complete 12-Bit, 100 kHz, Sampling ADC (AD7870/AD7870A) Features: Complete Monolithic 12-Bit ADC with: 2 µs Track/Hold Amplifier 8 µs A/D Converter On-Chip Reference Laser-Trimmed Clock Parallel, Byte and Serial Digital Interface 57 ns Data Access Time 72 dB SNR at 10 kHz Input Frequency (AD7870, AD7875) Low Power: –60 mW typ Variety of Input Ranges: ±3 V for AD7870 0 V to +5 V for AD7875 ±10 V for AD7876

Dual Differential 16-Bit, 1 MSPS PulSAR 12.0 mW in QSOP Features: 16-bit resolution with no missing codes Throughput: 1 MSPS Low power dissipation 7.0 mW at 1 MSPS (VDD1 and VDD2 only) 12.0 mW at 1 MSPS (total) 140 µW at 10 kSPS INL: ±0.5 LSB typical, ±2.0 LSB maximum True differential analog input range: ±VREF 0 V to VREF with VREF between 2.4 V to 5.1 V Allows use of any input range Easy to drive with the ADA4941-1 SINAD: 93.5 dB at 1 kHz THD: −112 dB at 1 kHz No pipeline delay Single-supply 2.5 V operation with 1.8 V/2.5 V/3 V/5 V logic interface Serial interface SPI/QSPI/MICROWIRE/DSP compatible 20-lead QSOP package Wide operating temperature range: −40°C to +125°C

MMIC VCO SMT w/ Buffer Amplifier, 3.35 - 3.55 GHz Features: Pout +4.7 dBm Phase Noise: -112 dBc/HZ @ 100 KHz No External Resonator Needed Single Supply: 3V @ 41 mA 50 Ohm Matched & DC Blocked RF I/Os OFN Leadless SMT Package, 16mm2

16-Bit, 200 kSPS, Parallel I/O A/D Converter Features: Fast 16-Bit ADC 200 kSPS Throughput Single 5 V Supply Operation Input Range: ±10 V 100 mW Max Power Dissipation Choice of External or Internal 2.5 V Reference High Speed Parallel Interface On-Chip Clock 28-Lead Skinny DIP, SSOP or SOIC Packages

16-Bit, 200 kSPS, Parallel I/O A/D Converter Features: Fast 16-Bit ADC 200 kSPS Throughput Single 5 V Supply Operation Input Range: ±10 V 100 mW Max Power Dissipation Choice of External or Internal 2.5 V Reference High Speed Parallel Interface On-Chip Clock 28-Lead Skinny DIP, SSOP or SOIC Packages

4T4R Direct RF Receiver and Transmitter Features: Flexible, reconfigurable radio common platform design Transmitter/receiver channel bandwidth up to 1.2 GHz (4T4R) RF DAC/RF ADC RF frequency range up to 7.5 GHz On-chip PLL with multichip synchronization External RF clock input option Versatile digital features Selectable interpolation and decimation filters Configurable DDCs and DUCs 8 fine complex DUCs (FDUC) and 4 coarse complex DUCs (CDUC) 8 fine complex DDCs (FDDC) and 4 coarse complex DDCs (CDDC) FDUCs and FDDCs are fully bypassable 2 independent 48-bit NCOs per DUC or DDC Programmable 192-tap PFIR filter for receive equalization Supports 4 different profile settings loaded via GPIO Receive AGC support Fast detect with low latency for fast AGC control Signal monitor for slow AGC control Dedicated AGC support pins Transmit DPD support Programmable delay and gain per transmit data path Coarse DDC delay adjust for DPD observation path Supports real or complex digital data (8-, 12-, or 16-bit) Auxiliary features ADC clock driver with selectable divide ratios Power amplifier downstream protection circuitry On-chip temperature monitoring unit Programmable GPIO pins support toggling between modes TDD power savings option and sharing ADCs SERDES JESD204B or JESD204C interface, 16 lanes up to 24.75 Gbps 8 lanes JESD204B/C transmitter (JTx) and 8 lanes JESD204B/C receiver (JRx) Supports Subclass 1 Supports multidevice synchronization 15 mm × 15 mm, 324-ball BGA with 0.8 mm pitch

10 MHz, 14.5 nV/Hz, Rail-to-Rail I/O, Zero Input Crossover Distortion Amplifier Features: Power supply rejection ratio (PSRR): 98 dB minimum  Common-mode rejection ratio (CMRR): 95 dB minimum Offset voltage: 120 μV maximum Single-supply operation: 2.7 V to 5.5 V  Dual-supply operation: ±1.35 V to ±2.75 V  Wide bandwidth: 10 MHz  Rail-to-rail input and output  Low noise 2 μV p-p from 0.1 Hz to 10 Hz  14.5 nV/√Hz at 1 kHz  Very low input bias current: 2 pA maximum

18 V, 725 A, 4 MHz CMOS RRIO Operational Amplifier Features: Low power at high voltage (18 V): 725 μA maximum Low offset voltage: 2.2 mV maximum over entire common-mode range Low input bias current: 15 pA maximum Gain bandwidth product: 4 MHz typical at Av = 100 Unity-gain crossover: 4 MHz typical −3 dB closed-loop bandwidth: 2.1 MHz typical Single-supply operation: 3 V to 18 V Dual-supply operation: ±1.5 V to ±9 V Unity-gain stable

8 GHz to 16 GHz, 4-Channel, X Band and Ku Band Beamformer Features: 8 GHz to 16 GHz frequency range Half-duplex for transmit and receive modes Single-pin transmit and receive control 360° phase adjustment range 2.8° phase resolution ≥31 dB gain adjustment range ≤0.5 dB gain resolution Bias and control for external transmit and receive modules Memory for 121 prestored beam positions Four −20 dBm to +10 dBm power detectors Integrated temperature sensor Integrated 8-bit ADC for power detectors and temperature sensor Programmable bias modes 4-wire SPI interface

8 GHz to 16 GHz, 4-Channel, X Band and Ku Band Beamformer Features: 8 GHz to 16 GHz frequency range Half-duplex for transmit and receive modes Single-pin transmit and receive control 360° phase adjustment range 2.8° phase resolution ≥31 dB gain adjustment range ≤0.5 dB gain resolution Bias and control for external transmit and receive modules Memory for 121 prestored beam positions Four −20 dBm to +10 dBm power detectors Integrated temperature sensor Integrated 8-bit ADC for power detectors and temperature sensor Programmable bias modes 4-wire SPI interface

Low Power, 5-Electrode Electrocardiogram (ECG) Analog Front End with respiration measurement and pace detection) Features: Biopotential signals in; digitized signals out 5 acquisition (ECG) channels and one driven lead Parallel ICs for up to 10+ electrode measurements Master ADAS1000 or ADAS1000-1 used with slave ADAS1000-2 AC and dc lead-off detection Internal pace detection algorithm on 3 leads Support for user’s own pace Thoracic impedance measurement (internal/external path) Selectable reference lead Scalable noise vs. power control, power-down modes Low power operation from 11 mW (1 lead), 15 mW (3 leads), 21 mW (all electrodes) Lead or electrode data available Supports AAMI EC11:1991/(R)2001/(R)2007, AAMI EC38 R2007, EC13:2002/(R)2007, IEC60601-1 ed. 3.0 b:2005, IEC60601-2-25 ed. 2.0 :2011, IEC60601-2-27 ed. 2.0 b:2005, IEC60601-2-51 ed. 1.0 b: 2005 Fast overload recovery Low or high speed data output rates Serial interface SPI-/QSPI™-/DSP-compatible 56-lead LFCSP package (9 mm × 9 mm) 64-lead LQFP package (10 mm × 10 mm body size)

Microwave Wideband Synthesizer with Integrated VCO Features: RF output frequency range: 62.5 MHz to 32,000 MHz Fractional-N synthesizer and Integer N synthesizer High resolution 39-bit fractional modulus Typical spurious PFD: −90 dBc Integrated rms jitter: 38 fs (1 kHz to 100 MHz) Normalized phase noise floor: −234 dBc/Hz PFD operation to 250 MHz Reference frequency operation to 600 MHz Programmable divide by 1, 2, 4, 8, 16, 32, or 64 output 62.5 MHz to 8,000 MHz output at RF8x and RFAUX8x 8,000 MHz to 16,000 MHz output at RF16x 16,000 MHz to 32,000 MHz output at RF32x Lock time approximately 3 ms with automatic calibration Lock time <30 μs with autocalibration bypassed Analog and digital power supplies: 3.3 V VCO power supply: 3.3 V and 5 V RF output mute function 7mm × 7mm, 48-terminal LGA package

LC2MOS Quad SPST Switch Features: 44 V Supply Maximum Ratings VSS to VDD Analog Signal Range Low On-Resistance (< 70 Ω) Low ΔRON ( 9 Ω max) Low ΔRON Match ( 3 Ω max) Low Power Dissipation Fast Switching Times ton < 110 ns toff < 60 ns Low Leakage Current (3 nA max) Low Charge Injection (6 pC max) Break-Before-Make Switching Action

Fault Protection and Detection, 10 RON, Quad SPST Switches, 2 x NO, 2 x NC Features: Overvoltage protection up to −55 V and +55 V Power-off protection up to −55 V and +55 V Overvoltage detection on source pins Low on resistance: 10 On-resistance flatness of 0.5 5.5 kV human body model (HBM) ESD rating Latch-up immune under any circumstance Known state without digitals present VSS to VDD analog signal range ±5 V to ±22 V dual supply operation 8 V to 44 V single-supply operation Fully specified at ±15 V, ±20 V, +12 V, and +36 V

SPI, 1.5 RON, 15 V/5 V/+12 V, High Density Octal SPST Switch Features: SPI with error detection Includes CRC, invalid read and write address, and SCLK count error detection Supports burst mode and daisy-chain mode Industry-standard SPI Mode 0 and Mode 3 interface compatible Integrated passive components Route through of digital signals and supplies Guaranteed break-before-make switching allowing external wiring of switches to deliver multiplexer configurations 1.5 typical on resistance at 25°C (±15 V dual supply) 0.3 typical on resistance flatness at 25°C (±15 V dual supply) 0.1 typical on resistance match between channels at 25°C (±15 V dual supply) VSS to VDD analog signal range Fully specified at ±15 V, ±5 V, and +12 V 1.8 V logic compatibility with 2.7 V ≤ VL ≤ 3.3 V (excludes SPI readback to a 1.8 V device) 4 mm × 5 mm, 30-terminal LGA

4-Channel, Low Noise, Low Power, 24-Bit, Sigma-Delta ADC with PGA and Reference Features: Three power modes RMS noise Low power: 24 nV rms at 1.17 SPS, gain = 128 (255 μA typical) Mid power: 20 nV rms at 2.34 SPS, gain = 128 (355 μA typical) Full power: 23 nV rms at 9.4 SPS, gain = 128 (930 μA typical) Up to 22 noise free bits in all power modes (gain = 1) Output data rate Full power: 9.38 SPS to 19,200 SPS Mid power: 2.34 SPS to 4800 SPS Low power: 1.17 SPS to 2400 SPS Rail-to-rail analog inputs for gains > 1 Simultaneous 50 Hz/60 Hz rejection at 25 SPS (single cycle settling) Diagnostic functions (which aid safe integrity level (SIL) certification Crosspoint multiplexed analog inputs 4 differential/7 pseudo differential inputs Programmable gain (1 to 128) Band gap reference with 10 ppm/°C drift maximum (70 μA) Matched programmable excitation currents Internal clock oscillator On-chip bias voltage generator Low-side power switch General-purpose outputs Multiple filter options Internal temperature sensor Self and system calibration Sensor burnout detection Automatic channel sequencer Per channel configuration Power supply: 2.7 V to 3.6 V and ±1.8 V Independent interface power supply Power-down current: 5 μA maximum Temperature range: −40°C to +125°C 32-lead LFCSP/24-lead TSSOP 3-wire or 4-wire serial interface SPI, QSPI, MICROWIRE, and DSP compatible Schmitt trigger on SCLK ESD: 4 kVAD7124-4-EP Supports defense and aerospace applications (AQEC standard) Download AD7124-4-EP Data Sheet (PDF) Full military temperature range: −55°C to +125°C Controlled manufacturing baseline 1 assembly/test site 1 fabrication site Product change notification Qualification data available on request V62/19614

Precision Analog Front End and Controller for Battery Test/Formation Systems Features: Integrated constant current and voltage modes with automatic switchover Charge and Discharge modes Precision voltage and current measurement Integrated precision control feedback blocks Precision interface to PWM or linear power converters Programmable gain settings Current sense gains: 26, 66, 133, 200 Voltage sense gains: 0.2, 0.27, 0.4, 0.8 Programmable OVP, OCP fault detection Current sharing & balancing Excellent ac & dc performance See datasheet for additional features
