The AD8436 is a new generation, translinear precision, lowpower, true rms-to-dc converter loaded with options. It computes a precise dc equivalent of the rms value of ac waveforms, includingcomplex patterns such as those generated by switch mode power supplies and triacs. Its accuracy spans a wide range of input levels and temperatures. The ensured accuracy of ≤±0.5% and ≤10 μV output offset result from the latest Analog Devices, Inc., technology. The crest factor error is 3 V extends the dynamic range with no external scaling,accommodating demanding low level signal conditions andallowing ample overrange without clipping.The AD8436 operates from single or dual supplies of ±2.4 V(4.8 V) to ±18 V (36 V). A and J grades are available in a compact 4 mm × 4 mm, 20-lead chip-scale package; A and B grades areavailable in a 20-lead QSOP package. The operating temperatureranges are −40°C to 125°C for A and B grades and 0°C to 70°Cfor J grade.

The AD8634 is a precision, 9.7 MHz bandwidth, dual amplifier that features rail-to-rail outputs. The AD8634 is guaranteed to operate from 3 V to 30 V (or from ±1.5 V to ±15 V) and at very high temperatures.The AD8634 is well suited for applications that require both ac and dc precision performance. The combination of wide bandwidth, low noise, and precision makes the AD8634 useful in a wide variety of applications, including filters and interfacing with a variety of sensors.This dual-channel op amp is offered in an 8-lead SOIC package with an operating temperature range of −40°C to +175°C. It is also available in an 8-lead ceramic flat package (FLATPACK) with an operating temperature range of −40°C to +210°C. Both packages are designed for robustness at extreme temperatures and are qualified for up to 1000 hours of operation at the maximum temperature rating.The AD8634 is a member of a growing series of high temperature qualified products offered by Analog Devices, Inc. For a complete selection table of available high temperature products, see the high temperature product list and qualification data available at www.analog.com/hightemp. APPLICATIONSDown-hole drilling and instrumentationAvionicsHeavy industrialHigh temperature environments

The AD8634 is a precision, 9.7 MHz bandwidth, dual amplifier that features rail-to-rail outputs. The AD8634 is guaranteed to operate from 3 V to 30 V (or from ±1.5 V to ±15 V) and at very high temperatures.The AD8634 is well suited for applications that require both ac and dc precision performance. The combination of wide bandwidth, low noise, and precision makes the AD8634 useful in a wide variety of applications, including filters and interfacing with a variety of sensors.This dual-channel op amp is offered in an 8-lead SOIC package with an operating temperature range of −40°C to +175°C. It is also available in an 8-lead ceramic flat package (FLATPACK) with an operating temperature range of −40°C to +210°C. Both packages are designed for robustness at extreme temperatures and are qualified for up to 1000 hours of operation at the maximum temperature rating.The AD8634 is a member of a growing series of high temperature qualified products offered by Analog Devices, Inc. For a complete selection table of available high temperature products, see the high temperature product list and qualification data available at www.analog.com/hightemp. APPLICATIONSDown-hole drilling and instrumentationAvionicsHeavy industrialHigh temperature environments

The single ADA4077-1, dual ADA4077-2, and quad ADA4077-4amplifiers feature extremely low offset voltage and drift, and lowinput bias current, noise, and power consumption. Outputs are stable with capacitive loads of more than 1000 pF with no external compensation.Applications for this amplifier include sensor signal conditioning (such as thermocouples, resistance temperature detectors (RTDs),strain gages), process control front-end amplifiers, and precisiondiode power measurement in optical and wireless transmission systems. The ADA4077-1/ADA4077-2/ADA4077-4 are useful in line powered and portable instrumentation, precision filters,and voltage or current measurement and level setting.Unlike other amplifiers, the ADA4077-1/ADA4077-2/ADA4077-4 have an MSL1 rating that is compliant with the most stringent of assembly processes, and they are specified over theextended industrial temperature range from −40°C to +125°C for the most demanding operating environments.APPLICATIONS Process control front-end amplifiers  Optical network control circuits Instrumentation Precision sensors and controls Precision filters

The ADA4084-1 (single), ADA4084-2 (dual), and ADA4084-4 (quad) are single-supply, 10 MHz bandwidth amplifiers featuring rail-to-rail inputs and outputs. They are guaranteed to operate from +3 V to +30 V (or ±1.5 V to ±15 V).These amplifiers are well suited for single-supply applications requiring both ac and precision dc performance. The combination of wide bandwidth, low noise, and precision makes the ADA4084-1/ADA4084-2/ADA4084-4 useful in a wide variety of applications, including filters and instrumentation.Other applications for these amplifiers include portable telecommunications equipment, power supply control and protection, and use as amplifiers or buffers for transducers with wide output ranges. Sensors requiring a rail-to-rail input amplifier include Hall effect, piezoelectric, and resistive transducers.The ability to swing rail to rail at both the input and output enables designers to build multistage filters in single-supply systems and to maintain high signal-to-noise ratios.The ADA4084-1/ADA4084-2/ADA4084-4 are specified over the industrial temperature range of −40°C to +125°C.The single ADA4084-1 is available in the 5-lead SOT-23 and 8-lead SOIC; the dual ADA4084-2 is available in the 8-lead SOIC, 8-lead MSOP, and 8-lead LFCSP surface-mount packages; and the ADA4084-4 is offered in the 14-lead TSSOP and 16-lead LFCSP.The ADA4084-1/ADA4084-2/ADA4084-4 are members of a growing series of high voltage, low noise op amps offered by Analog Devices, Inc.Applications Battery-powered instrumentation High-side and low-side sensing Power supply control and protection Telecommunications Digital-to-analog converter (DAC) output amplifiers Analog-to-digital converter (ADC) input buffers

The ADA4084-1 (single), ADA4084-2 (dual), and ADA4084-4 (quad) are single-supply, 10 MHz bandwidth amplifiers featuring rail-to-rail inputs and outputs. They are guaranteed to operate from +3 V to +30 V (or ±1.5 V to ±15 V).These amplifiers are well suited for single-supply applications requiring both ac and precision dc performance. The combination of wide bandwidth, low noise, and precision makes the ADA4084-1/ADA4084-2/ADA4084-4 useful in a wide variety of applications, including filters and instrumentation.Other applications for these amplifiers include portable telecommunications equipment, power supply control and protection, and use as amplifiers or buffers for transducers with wide output ranges. Sensors requiring a rail-to-rail input amplifier include Hall effect, piezoelectric, and resistive transducers.The ability to swing rail to rail at both the input and output enables designers to build multistage filters in single-supply systems and to maintain high signal-to-noise ratios.The ADA4084-1/ADA4084-2/ADA4084-4 are specified over the industrial temperature range of −40°C to +125°C.The single ADA4084-1 is available in the 5-lead SOT-23 and 8-lead SOIC; the dual ADA4084-2 is available in the 8-lead SOIC, 8-lead MSOP, and 8-lead LFCSP surface-mount packages; and the ADA4084-4 is offered in the 14-lead TSSOP and 16-lead LFCSP.The ADA4084-1/ADA4084-2/ADA4084-4 are members of a growing series of high voltage, low noise op amps offered by Analog Devices, Inc.Applications Battery-powered instrumentation High-side and low-side sensing Power supply control and protection Telecommunications Digital-to-analog converter (DAC) output amplifiers Analog-to-digital converter (ADC) input buffers

The ADA4896-2/ADA4897-1 are unity gain stable, low noise, rail-to-rail output, high speed voltage feedback amplifiers that have a quiescent current of 3 mA. With the 1/f noise of 2.4 nV/√Hz at 10 Hz and a spurious-free dynamic range of −80 dBc at 2 MHz, the ADA4896-2/ADA4897-1 are an ideal solution in a variety of applications, including ultrasound, low noise preamplifiers, and drivers of high performance ADCs. The Analog Devices, Inc., proprietary next generation SiGe bipolar process and innovative architecture enable such high performance amplifiers.TheADA4896-2/ADA4897-1 have 230 MHz bandwidth, 120 V/μs slew rate, and settle to 0.1% in 45 ns. With a wide supply voltage range (3 V to 10 V), the ADA4896-2/ADA4897-1 are ideal candidates for systems that require high dynamic range, precision, and high speed.The ADA4896-2 is available in 8-lead LFCSP and 8-lead MSOP packages. The ADA4897-1 is available in 8-lead SOIC and 6-lead SOT-23 packages. Both the ADA4896-2 and ADA4897-1 work over the extended industrial temperature range of −40°C to +125°C.Applications Low noise preamplifier Ultrasound amplifiers PLL loop filters High performance ADC drivers DAC buffers

The ADA4896-2/ADA4897-1 are unity gain stable, low noise, rail-to-rail output, high speed voltage feedback amplifiers that have a quiescent current of 3 mA. With the 1/f noise of 2.4 nV/√Hz at 10 Hz and a spurious-free dynamic range of −80 dBc at 2 MHz, the ADA4896-2/ADA4897-1 are an ideal solution in a variety of applications, including ultrasound, low noise preamplifiers, and drivers of high performance ADCs. The Analog Devices, Inc., proprietary next generation SiGe bipolar process and innovative architecture enable such high performance amplifiers.TheADA4896-2/ADA4897-1 have 230 MHz bandwidth, 120 V/μs slew rate, and settle to 0.1% in 45 ns. With a wide supply voltage range (3 V to 10 V), the ADA4896-2/ADA4897-1 are ideal candidates for systems that require high dynamic range, precision, and high speed.The ADA4896-2 is available in 8-lead LFCSP and 8-lead MSOP packages. The ADA4897-1 is available in 8-lead SOIC and 6-lead SOT-23 packages. Both the ADA4896-2 and ADA4897-1 work over the extended industrial temperature range of −40°C to +125°C.Applications Low noise preamplifier Ultrasound amplifiers PLL loop filters High performance ADC drivers DAC buffers

The ADAU1962A is a high performance, single-chip digital-to-analog converter (DAC) that provides 12 DACs with differential or single-ended outputs using the Analog Devices, Inc., patented multibit Σ-Δ architecture. A serial peripheral interface (SPI)/I2C port is included, allowing a microcontroller to adjust volume and many other parameters. The ADAU1962A operates from 2.5 V digital and 3.3 V analog supplies. A linear regulator is included to generate the digital supply voltage from the analog supply voltage. The ADAU1962A is available in an 80-lead LQFP.The ADAU1962A is designed for low EMI. This consideration is apparent in both the system and circuit design architectures. By using the on-board PLL to derive the internal master clock from an external left-right frame clock (LRCLK), the ADAU1962A can eliminate the need for a separate high frequency master clock andcan be used with or without a bit clock. The DACs are designed using the latest Analog Devices continuous time architectures to further minimize EMI. By using 2.5 V digital supplies, power consumption is minimized, and the digital waveforms are asmaller amplitude, further reducing emissions.Note that throughout this data sheet, multifunction pins, such as SCLK/SCL, are referred to by the entire pin name or by a single function of the pin, for example, SCLK, when only that function is relevant.APPLICATIONS Automotive audio systems Home theater systems Digital audio effects processors

The ADAU1966A is a high performance, single-chip digital-to-analog converter (DAC) that provides 16 DACs with differential or single-ended outputs using the Analog Devices, Inc., patented multibit sigma-delta (Σ-Δ) architecture. A serial peripheral interface (SPI)/I2C port is included, allowing a microcontroller to adjust volume and many other parameters. The ADAU1966A operates from 2.5 V digital and 3.3 V analog supplies. A linear regulator is included to generate the digital supply voltage from the analog supply voltage. The ADAU1966A is available in an 80-lead LQFP.The ADAU1966A is designed for low EMI. This consideration is apparent in both the system and circuit design architectures. By using the on-board PLL to derive the internal master clock from an external left-right frame clock (LRCLK), the ADAU1966A can eliminate the need for a separate high frequency master clock and can be used with or without a bit clock. The DACs are designed using the latest Analog Devices continuous time architectures to further minimize EMI. By using 2.5 V digital supplies, power consumption is minimized, and the digital waveforms are a smaller amplitude, further reducing emissions.Note that throughout this data sheet, multifunction pins, such as SCLK/SCL, are referred to by the entire pin name or by a single function of the pin, for example, SCLK, when only that function is relevant.APPLICATIONS Automotive audio systems Home theater systems Digital audio effects processors

The ADF7023-J is a very low power, high performance, highly integrated 2FSK/GFSK/MSK/GMSK transceiver designed for operation in the 902 MHz to 958 MHz frequency band, which covers the ARIB Standard T96 band at 950 MHz. Data rates from 1 kbps to 300 kbps are supported.The transmit RF synthesizer contains a VCO and a low noise fractional-N phase locked loop (PLL) with an output channel frequency resolution of 400 Hz. The VCO operates at twice the fundamental frequency to reduce spurious emissions. The receive and transmit synthesizer bandwidths are automatically, and independently, configured to achieve optimum phase noise, modulation quality, and settling time. The transmitter output power is programmable from −20 dBm to +13.5 dBm, with automatic PA ramping to meet transient spurious specifications. The part possesses both single-ended and differential PAs, which allow for Tx antenna diversity.The receiver is exceptionally linear, achieving an IP3 specification of −12.2 dBm and −11.5 dBm at maximum gain and minimum gain, respectively, and an IP2 specification of 18.5 dBm and 27 dBm at maximum gain and minimum gain, respectively. The receiver achieves an interference blocking specification of 66 dB at a ±2 MHz offset and 74 dB at a ±10 MHz offset. Thus, the part is extremely resilient to the presence of interferers in spectrally noisy environments. The receiver features a novel, high speed, AFC loop, allowing the PLL to find and correct any RF frequency errors in the recovered packet. A patent pending image rejection calibration scheme is available by downloading the image rejection calibration firmware module to program RAM. The algorithm does not require the use of an external RF source nor does it require any user intervention once initiated. The results of the calibration can be stored in nonvolatile memory for use on subsequent power-ups of the transceiver.See data sheet for additional information.Applications Smart metering IEEE 802.15.4g Home automation Process and building control Home Energy Management Systems (HEMS) Wireless sensor networks (WSNs) Wireless healthcare

The ADG5208/ADG5209 are monolithic CMOS analog multiplexers comprising eight single channels and four differential channels, respectively. The ADG5208 switches one of eight inputs to a common output, as determined by the 3-bit binary address lines, A0, A1, and A2. The ADG5209 switches one of four differential inputs to a common differential output, as determined by the 2-bit binary address lines, A0 and A1.An EN input on both devices enables or disables the device. When EN is disabled, all channels switch off. The ultralow capacitance and charge injection of these switches make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch and fast settling are required. Fast switching speed coupled with high signal bandwidth make these devices suitable for video signal switching.Each switch conducts equally well in both directions when on, and each switch has an input signal range that extends to the power supplies. In the off condition, signal levels up to the supplies are blocked.The ADG5208/ADG5209 do not have VL pins; instead, the logic power supply is generated internally by an on-chip voltage generator.Product Highlights Trench Isolation Guards Against Latch-Up. A dielectric trench separates the P and N channel transistors to prevent latch-up even under severe overvoltage conditions. 0.4 pC Charge Injection. Dual-Supply Operation. For applications where the analog signal is bipolar, the  ADG5208/ADG5209 can be operated from dual supplies of up to ±22 V. Single-Supply Operation. For applications where the analog signal is unipolar, the ADG5208/ADG5209 can be operated from a single rail power supply of up to 40 V. 3 V Logic-Compatible Digital Inputs. VINH = 2.0 V, VINL = 0.8 V. No VL Logic Power Supply Required.Applications Automatic test equipment Data acquisition Instrumentation Avionics Audio and video switching Communication systems

The ADIS16136 iSensor® MEMS Gyroscope is a high performance, digital gyroscope sensing system that operates autonomously and requires no user configuration to produce accurate rate sensing data. It provides performance advantages with low noise density, wide bandwidth, and excellent in-run bias stability, which are enablingfor applications such as platform control, navigation, robotics,and medical instrumentation.This sensor system combines industry leading iMEMS® technology with signal conditioning that optimizes dynamic performance.The factory calibration characterizes the entire sensor signal chainfor sensitivity and bias over a temperature range of −40°C to +85°C.As a result, each ADIS16136 has its own unique correction formulasto produce accurate measurements upon installation. Forsome systems, the factory calibration eliminates the need forsystem level calibration and greatly simplifies it for others.The ADIS16136 provides data at rates of up to 2048 SPS andoffers an averaging/decimation filter structure for optimizingnoise/bandwidth trade-offs. The serial peripheral interface (SPI)and user register structure provide easy access to configurationcontrols and calibrated sensor data for embedded processorplatforms.The 36 mm × 44 mm × 14 mm package provides four holes forsimple mechanical attachment, using M2 (or 2-56 standard size)machine screws along with a standard 24-pin, dual row, 1 mmpitch connector that supports electrical attachment to a printedcircuit board (PCB) or cable system. The ADIS16136 providesan operating temperature range of −40°C to +85°C.APPLICATIONS Precision instrumentation Platform stabilization and control Industrial vehicle navigation Downhole instrumentation Robotics

The ADIS16485 iSensor® device is a complete inertial system thatincludes a triaxial gyroscope and a triaxial accelerometer. Eachinertial sensor in the ADIS16485 combines industry-leadingiMEMS® technology with signal conditioning that optimizesdynamic performance. The factory calibration characterizeseach sensor for sensitivity, bias, alignment, and linear acceleration(gyroscope bias). As a result, each sensor has its own dynamiccompensation formulas that provide accurate sensor measurements.The ADIS16485 provides a simple, cost-effective method forintegrating accurate, multiaxis inertial sensing into industrialsystems, especially when compared with the complexity andinvestment associated with discrete designs. All necessary motiontesting and calibration are part of the production process at thefactory, greatly reducing system integration time. Tight orthogonalalignment simplifies inertial frame alignment in navigation systems.The SPI and register structure provide a simple interface fordata collection and configuration control.The ADIS16485 uses the same footprint and connector systemas the ADIS16375 and the ADIS16488A, which greatlysimplifies the upgrade process. It comes in a module that isapproximately 47 mm × 44 mm × 14 mm and has a standardconnector interface.Applications Platform stabilization and control Navigation Personnel tracking Instruments Robotics

The ADIS16488A iSensor® device is a complete inertial systemthat includes a triaxis gyroscope, a triaxis accelerometer, triaxismagnetometer, and pressure sensor. Each inertial sensor in theADIS16488A combines industry-leading iMEMS® technologywith signal conditioning that optimizes dynamic performance.The factory calibration characterizes each sensor for sensitivity,bias, alignment, and linear acceleration (gyroscope bias). As aresult, each sensor has its own dynamic compensation formulas thatprovide accurate sensor measurements.The ADIS16488A provides a simple, cost-effective method forintegrating accurate, multiaxis inertial sensing into industrialsystems, especially when compared with the complexity andinvestment associated with discrete designs. All necessary motiontesting and calibration are part of the production process at thefactory, greatly reducing system integration time. Tight orthogonalalignment simplifies inertial frame alignment in navigation systems.The SPI and register structure provide a simple interface fordata collection and configuration control.The ADIS16488A uses the same footprint and connector system asthe ADIS16375, ADIS16480, and ADIS16485, which greatlysimplifies the upgrade process. The ADIS16488A is packaged ina module that is approximately 47 mm × 44 mm × 14 mm andincludes a standard connector interface.Applications Platform stabilization and control Navigation Personnel tracking Instrumentation Robotics

Based on the iCoupler® and isoPower® chip scale transformertechnology, the ADM3260 is a hot swappable digital and powerisolator with two nonlatching, bidirectional communicationchannels, supporting a complete isolated I2C interface, and anintegrated isolated dc-to-dc converter, supporting up to150 mW of isolated power conversion.iCoupler is a chip scale transformer technology with functional,performance, size, and power consumption advantages ascompared to optocouplers. The bidirectional I2C channels eliminate the need for splitting I2C signals into separate transmitand receive signals for use with standalone optocouplers.Based on the Analog Devices, Inc., isoPower technology, theon-chip isolated dc-to-dc converter provides a regulated, isolatedvoltage of 3.15 V to 5.25 V with up to 150 mW of output power.With the ADM3260, the iCoupler and isoPower channels, alongwith the I2C transceivers, can be integrated with semiconductorcircuitry, which enables a complete isolated I2C interface andallows the power converter to be implemented in a small formfactor. The ADM3260 is available in 20-lead SSOP package andhas an operating temperature range of −40°C to+105°C.isoPower uses high frequency switching elements to transfer powerthrough its transformer. Special care must be taken during printedcircuit board (PCB) layout to meet emissions standards. See theAN-0971 Application Note for board layout recommendationsApplications Isolated I2C, SMBus, and PMBus interfaces Multilevel I2C interfaces Central office switching Telecommunication and data communication equipment −48 V distributed power systems −48 V power supply modules Networking

The ADN2915 provides the receiver functions of quantization, signal level detect, and clock and data recovery for continuous data rates from 6.5 Mbps to 11.3 Gbps. The ADN2915 automatically locks to all data rates without the need for an external reference clock or programming. ADN2915 jitter performance exceeds all jitter specifications required by SONET/SDH, including jitter transfer, jitter generation, and jitter tolerance.The ADN2915 provides manual or automatic slice adjust and manual sample phase adjusts. Additionally, the user can select a limiting amplifier, equalizer, or bypass at the input. The equalizer is either adaptive or can be manually set.The receiver front-end loss of signal (LOS) detector circuit indicates when the input signal level has fallen below a user-programmable threshold. The LOS detect circuit has hysteresis to prevent chatter at the LOS output. In addition, the input signal strength can be read through the I2C registers.The ADN2915 also supports pseudorandom binary sequence (PRBS) generation, bit error detection, and input data rate readback features.The ADN2915 is available in a compact 4 mm × 4 mm, 24-lead chip scale package (LFCSP). All ADN2915 specifications are defined over the ambient temperature range of −40°C to +85°C, unless otherwise noted.Applications SONET/SDH OC-1/OC-3/OC-12/OC-48/OC-192 and all associated FEC rates 1GFC, 2GFC, 4GFC, 8GFC, 10GFC, 1GE, and 10GE WDM transponders Any rate regenerators/repeaters

The ADR4520/ADR4525/ADR4530/ADR4533/ADR4540/ADR4550 devices are high precision, low power, low noise voltage references featuring ±0.02% B, C, and D grade maximum initial error, excellent temperature stability, and low output noise.This family of voltage references uses an innovative core topology to achieve high accuracy while offering industry-leading temperature stability and noise performance. The low, thermally induced output voltage hysteresis and low long-term output voltage drift of the devices also improve system accuracy overtime and temperature variations.A maximum operating current of 950 μA and a maximum low dropout voltage of 300 mV allow the devices to function very well in portable equipment.The ADR4520/ADR4525/ADR4530/ADR4533/ADR4540/ADR4550 series of references are each provided in an 8-lead SOIC and are available in a wide range of output voltages, all of which are specified over the extended industrial temperature range of −40°C to +125°C.APPLICATIONSPrecision data acquisition systemsHigh resolution data convertersHigh precision measurement devicesIndustrial instrumentationMedical devicesAutomotive battery monitoring

The ADSP-BF609 Blackfin processor is optimized for embedded vision and video analytics applications using a dual-core fixed-point DSP processor with a unique pipelined vision processor (PVP). The PVP is a set of functional blocks next to the Blackfin cores designed to accelerate image processing algorithms and reduce overall bandwidth requirements.Other features include a high performance enhanced infrastructure, large on-chip memory and a feature rich peripheral set with expanded connectivity options.In addition to these the ADSP-BF609 processor contains features for safety-critical applications, including a CRC for memory protection, Parity and ECC protection in the internal memory blocks and a Fault Management Unit.The ADSP-BF609 processor is ideal for many embedded vision applications such as automotive advanced driver assistance systems (ADAS), machine vision and robotics for industrial manufacturing systems, security and surveillance system analytics and bar code scanners.

The OP777, OP727 and OP747 are precision single, dual and quad rail-to-rail output single supply amplifiers featuring micropower operationand rail to rail output ranges. These amplifiers provide improved performance over the industry standard OP07 with ±15V supplies and offer the further advantages of true single supply operationdown to +3.0V and smaller package options than any other high voltage precision bipolar amplifier. Outputs are stable with capacitive loads of over1000pF. Supply current is less than 300 µA per amplifier at 5V. 500 series resistors protect the inputs, allowing input signal levels several voltsabove the positive supply without phase reversal.
