Integrated Circuit True RMS-to-DC Converter

4.0 Gbps Dual Driver

Ethernet Clock Generator, 10 Clock Outputs Features: Fully integrated VCO/PLL core 0.17 ps rms jitter from 1.875 MHz to 20 MHz at 156.25 MHz 0.41 ps rms jitter from 12 kHz to 20 MHz at 125 MHz Input crystal or clock frequency of 25 MHz Preset divide ratios for 156.25 MHz, 33.33 MHz,100 MHz, and 125 MHz Choice of LVPECL or LVDS output format See datasheet for additional features

Dual/Quad Rail-to-Rail Operational Amplifiers

IC MUX 8CH SP JFET DIP16; Multiplexer Configuration:8:1; No. of Circuits:1Circuits; On State Resistance Max:300ohm; Supply Voltage Range:± 15V; Analogue Multiplexer Case:DIP; No. of Pins:16Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Each; Product Range:MUX08 Series; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (20-Jun-2016); Analogue Multiplexer Type:8 Channel Single Pole; Analogue Switch Case Style:DIP; Base Number:8; IC Generic Number:08; Logic Function Number:8; No. of Channels:8Channels; On Resistance Rds(on):400ohm; Operating Temperature Range:-40°C to +85°C; Supply Current:15mA; Supply Voltage Source:Dual; Termination Type:Through Hole

Tiny 16-Bit SPI nanoDAC+, with 2 (16-Bit) LSB INL and 2 ppm/C Reference Features: Ultrasmall package: 2 mm × 2 mm, 8-lead LFCSP High relative accuracy (INL): ±2 LSB maximum at 16 bits AD5683R/AD5682R/AD5681R Low drift, 2.5 V reference: 2 ppm/°C typical Selectable span output: 2.5 V or 5 V Total unadjusted error (TUE): 0.06% of FSR maximum Offset error: ±1.5 mV maximum Gain error: ±0.05% of FSR maximum Low glitch: 0.1 nV-sec High drive capability: 20 mA Low power: 1.2 mW at 3.3 V Independent logic supply: 1.62 V logic compatible Wide operating temperature range: −40°C to +105°C Robust 4 kV HBM ESD protection

Microprocessor Supervisory Circuit with Watchdog Feature, 4.65V Threshold Voltage, Low Supply Current and Active Low Reset Output. Upgrade for ADM699 Features: Superior Upgrade for ADM698/ADM699, MAX698/MAX699 Guaranteed RESET Assertion with VCC = 1 V Low 70 µA Supply Current Precision 4.65 V Voltage Monitor Power OK/Reset Time Delay Power OK/Reset Time Delay Watchdog Timer Minimum Component Count Performance Specified over Temperature ADM8698 is obsolete

Voltage References Low Cost 2.5V Shunt Voltage Reference

Isolated Module DC DC Converter 2 Output 2.5 ~ 13V 1.2 ~ 12V 440mA, 300mA 3.1V - 32V Input

SUPERVISOR CIRCUIT MPU #1 SOT-23-5; Threshold Voltage:4.5V; No. of Supervisors / Monitors:1Monitors; Supply Voltage Min:1V; Supply Voltage Max:5.5V; Reset Type:Manual Active-Low; Digital IC Case:SOT-23; No. of Pins:5Pins; Delay Time:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:ADM6320 Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

DAC WIRELESS COMMUNICATIONS; Resolution (Bits):16bit; Sampling Rate:2.8GSPS; Input Channel Type:Serial; Supply Voltage Range:3.13V to 3.47V; ADC / DAC Case Style:LFCSP; No. of Pins:88Pins; Data Interface:SPI; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:AD9144 Series; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016)

IC CURRENT SENSE AMP 250KHZ MSOP-8; No. of Amplifiers:1 Amplifier; Input Bias Current:130µA; Amplifier Case Style:MSOP; No. of Pins:8Pins; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Bandwidth:250kHz; Supply Voltage Min:2.7V; Supply Voltage Max:5.5V; Input Offset Voltage:200µV; CMRR:100dB; Packaging:Each; Product Range:AD8418 Series; Automotive Qualification Standard:AEC-Q100; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016); No. of Amplifiers:1Amplifiers; Supply Current:2.6mA

Digital to Analog Converters - DAC 10-BIT QUAD I2C DAC I.C. The AD5306 / AD5316 / AD5326 are quadruple 8-, 10-, and 12-bit buffered voltage output DACs, enclosed in a 16-lead TSSOP package. These DACs function within a single 2.5 V to 5.5 V supply range and consume 500 µA at 3 V. Equipped with on-chip output amplifiers, they facilitate rail-to-rail output swing with a slew rate of 0.7 V/µs. The devices utilize a 2-wire serial interface capable of operating at clock rates up to 400 kHz. This interface is SMBus-compatible at VDD <3.6 V, allowing multiple devices to be accommodated on the same bus. Features and Benefits: Four 10-Bit DACS in 16-Lead TSSOP Low Power; 500 µA @ 5 V, 400 µA @ 3 V Power-Down to 300 nA @ 5 V, 90nA @ 3 V Guaranteed Monotonic by Design Power-On-Reset to Zero Volts Double-Buffered Input Logic Output Range: 0 V to VREF or 0 V to 2 VREF 2-Wire (I2C™ Compatible) Serial Interface Data Readback Facility; Software Clear Facility Simultaneous Update via LDAC pin (active low) Buffered/Unbuffered Reference Input Options for each DAC Temperature Range: −40°C to 105°C Applications: Portable battery-powered instruments Digital gain and offset adjustment Programmable voltage and current sources Programmable attenuators Industrial process control Alternative Parts: AD5316R AD5316RBCPZ-RL7 AD5316RBRUZ AD5316RBRUZ-RL7

Digital Isolators Dual-Channel Isolators with Integrated DC-to-DC Converter (1/1 Channel Directionality) The ADuM6210 / ADuM6211 / ADuM6212 represent dual-channel digital isolators featuring isoPower, an integrated, isolated dc-to-dc converter. Leveraging Analog Devices, Inc.'s iCoupler technology, the dc-to-dc converter delivers regulated, isolated power with an adjustable range between 3.135 V and 5.25 V. These isolators accommodate input supply voltages ranging from slightly below the required output to significantly higher values, as detailed in Table 2 for popular voltage combinations and their corresponding power levels. In low-power, isolated designs, the ADuM6210 / ADuM6211 / ADuM6212 negate the necessity for a separate, isolated dc-to-dc converter. The iCoupler chip-scale transformer technology is utilized for both isolated logic signals and the magnetic components of the dc-to-dc converter. The outcome is a compact, all-encompassing isolation solution. isoPower employs high-frequency switching elements to transfer power through its transformer. Careful attention must be given to printed circuit board (PCB) layout to meet emissions standards. Refer to the AN-0971 Application Note for recommended board layout practices. Features and Benefits: isoPower integrated, isolated dc-to-dc converter Regulated 3.135 V to 5.25 V output Up to 150 mW output power Dual dc-to-100 Mbps (NRZ) signal isolation channels Soft start power supply 20-lead SSOP package with 5.3 mm creepage Supports SPI up to 15 MHz High temperature operation: 105°C High common-mode transient immunity: >25 kV/μs Safety and regulatory approvals UL recognition 3750 V rms for 1 minute per UL 1577 CSA Component Acceptance Notice 5A VDE certificate of conformity DIN V VDE V 0884-10 (VDE V 0884-10):2006-12 VIORM = 849 V peak Applications: RS-232 transceivers Power supply start-up bias and gate drives Isolated sensor interfaces Industrial PLCs

16-Lead Plastic Dual In-Line Package [PDIP] The ADG442 is an integrated CMOS component consisting of four individual switches that can be independently selected. It is crafted using an improved LC2MOS process, offering low power dissipation while maintaining high switching speed and low on-resistance. To activate the ADG442 switches, a logic high signal on the corresponding control input is required. When in the ON state, each switch conducts equally well in both directions, and their input signal range extends to the power supplies. All switches feature break-before-make switching action, making them suitable for multiplexer applications. The design inherently incorporates low charge injection, minimizing transients when switching digital inputs. Features and Benefits: 44 V Supply Maximum Ratings VSS to VDD Analog Signal Range Low On-Resistance (< 70 Ω) Low ΔRON ( 9 Ω max) Low ΔRON Match ( 3 Ω max) Low Power Dissipation Fast Switching Timeston < 110 nstoff < 60 ns Low Leakage Current (3 nA max) Low Charge Injection (6 pC max) Break-Before-Make Switching Action Applications: Audio and video switching Automatic test equipment Precision data acquisition Battery-powered systems Sample-and-hold systems Communication systems

POWER AMP 22DB 24-27GHZ 5V LCC-24; Frequency Min:24GHz; Frequency Max:27GHz; Gain:22dB; Noise Figure Typ:-; RF IC Case Style:LCC; No. of Pins:24Pins; Supply Voltage Min:-; Supply Voltage Max:5V; Operating Temperature Min:-40 C

DIGITAL PHASE SHIFTER 6BIT 6.2GHZ QFN; IC Function:Phase Shifter; Supply Voltage Min:-; Supply Voltage Max:-; IC Package Type:QFN; No. of Pins:32Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016)

ADC 12BIT 80MSPS LFCSP-32; Resolution (Bits):12bit; Sampling Rate:80MSPS; Supply Voltage Type:Single; Supply Voltage Min:2.7V; Supply Voltage Max:3.6V; ADC / DAC Case Style:LFCSP; No. of Pins:32Pins; Input Channel Type:Differential Single Ended; Data Interface:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Packaging:Cut Tape; Product Range:Single 12-Bit Pipelined ADCs; Automotive Qualification Standard:-; MSL:MSL 3 - 168 hours; SVHC:No SVHC (20-Jun-2016)

DAC 16BIT TSSOP-16; Resolution (Bits):16bit; Sampling Rate:-; Input Channel Type:Serial; Supply Voltage Range:4.75V to 30V; ADC / DAC Case Style:TSSOP; No. of Pins:16Pins; Data Interface:SPI; Operating Temperature Min:-40°C; Operating Temperature Max:125°C; Packaging:Each; Product Range:AD5761R Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (20-Jun-2016)

ADC 24BIT 31.25KSPS SPI LFCSP-32; Resolution (Bits):24bit; Sampling Rate:31.25kSPS; Supply Voltage Type:Single; Supply Voltage Min:2V; Supply Voltage Max:5.5V; ADC / DAC Case Style:LFCSP; No. of Pins:32; Data Interface:SPI ;RoHS Compliant: Yes
