The HMC813LC4B is a Successive Detection Log Video Amplifier (SDLVA) with a limited RF output which operates from 1 to 20 GHz. The HMC813LC4B provides a logging range of 55 dB. This device offers typical fast rise/fall times of 5/10 ns. The HMC813LC4B log video output slope is typically 15 mV/dB. Maximum recovery times are less than 15 ns. Ideal for high speed channelized receiver applications, the HMC813LC4B operates from a single +3.3 V supply, and consumes only 153 mA. The HMC813LC4B is available in a highly compact 4×4 mm SMT ceramic package and is ideal for high speed channelized receiver applications.APPLICATIONS EW, ELINT & IFM Receivers DF Radar Systems ECM Systems Broadband Test & Measurement Power Measurement & Control Circuits Military & Space Applications

The HMC828LP6CE is a fully functioned Fractional-N Phase-Locked-Loop (PLL) Frequency Synthesizer with an Integrated Voltage Controlled Oscillator (VCO). The synthesizer consists of an integrated low noise VCO with divide-by-2 output, an autocalibration subsystem for low voltage VCO tuning, a very low noise digital Phase Detector (PD), a precision controlled charge pump, a low noise reference path divider and a fractional divider.The fractional synthesizer features an advanced delta-sigma modulator design that allows both ultra-fine step sizes and low spurious products. The phase detector (PD) features cycle slip prevention (CSP) technology to allow faster frequency hopping times. Ultra low in-close phase noise and low spurious also allows wider loop bandwidths for faster frequency hopping and low micro-phonics.For theory of operation and register map refer to the 'PLLs w/ Integrated VCO - RF VCOs' Operating Guide.Applications Cellular/4G Infrastructure Repeaters and Femtocells Communications Test Equipment CATV Equipment Phased Array Applications DDS Replacement  Very High Data Rate Radios

The HMC829LP6GE is a low noise, wide band, Fractional-N Phase-Locked-Loop (PLL) that features an integrated Voltage Controlled Oscillator (VCO ) with a fundamental frequency of 2800 MHz - 4200 MHz, and an integrated VCO Output Divider (divide by 1/2/4/6.../60/62), that together allow the HMC829LP6GE to generate frequencies from 45 MHz to 1050 MHz, from 1400 MHz to 2100 MHz, and from 2800 MHz to 4200 MHz. The integrated Phase Detector (PD) and delta-sigma modulator, capable of operating at up to 100 MHz, permit wider loop-bandwidths with excellent spectral performance.For theory of operation and register map refer to the 'PLLs w/ Integrated VCO - Microwave VCOs' Operating Guide.Applications Cellular/4G, WiMax Infrastructure Repeaters and Femtocells Communications Test Equipment CATV Equipment Phased Array Applications DDS Replacement Very High Data Rate Radios

The HMC832LP6GE is a 3.3 V, high performance, wide-band, Fractional-N Phase-Locked-Loop (PLL) that features an integrated Voltage Controlled Oscillator (VCO) with a fundamental frequency of 1500 MHz - 3000 MHz, and an integrated VCO Output Divider (divide by 1/2/4/6.../60/62), that enables the HMC832LP6GE to generate continuous frequencies from 25 MHz to 3000 MHz. The integrated Phase Detector (PD) and delta-sigma modulator, capable of operating at up to 100 MHz, permit wider loop-bandwidths and faster frequency tuning, with excellent spectral performance.Industry leading phase noise and spurious performance, across all frequencies, enable the HMC832LP6GE to minimize blocker effects, improve receiver sensitivity and transmitter spectral purity. Low noise floor (-160 dBc/Hz) eliminates any contribution to modulator/mixer noise floor in transmitter applications.The HMC832LP6GE features all 3.3 V supply and an innovative Programmable Performance technology that enables the HMC832LP6GE to tailor current consumption and corresponding noise floor performance to each individual application by selecting either a low current consumption mode, or a high performance mode for an improved noise floor performance.Additional features of the HMC832LP6GE include 12 dB of RF output gain control in 1 dB steps; Output Mute function to automatically mute the output during frequency changes when the device is not locked; Selectable resistance for better output return loss; Programmable differential or single-ended outputs, with the ability to select either output in single-ended mode; and a delta-sigma modulator Exact Frequency Mode which enables users to generate output frequencies with 0 Hz frequency error.Applications Cellular Infrastructure Microwave Radio WiMax, WiFi Communications Test Equipment CATV Equipment DDS Replacement Military Tunable Reference Source for Spurious- Free Performance

Limiting Amplifiers Limiting amp w/o DC Offset, 32Gbps

The HMC877LC3 is a phase shifter/time delay with 0 to 500°(1.4 UI) continuously adjustable shift/delay range. The delay control is linearly monotonic with respect to the differential control voltage (VDCP, VDCN) and the control input has a modulation bandwidth of 2.5 GHz. The device provides a differential output voltage with constant amplitude for single-ended or differential input voltages above the input sensitivity level, while the output voltage swing may be adjusted using the VAC control pin. The HMC877LC3 features internal temperature compensation and bias circuitry to minimize delay variations with temperature. The device also features a delay control voltage range adjustment pin, LC. All RF input and outputs of the HMC877LC3 are internally terminated with 50 Ohms to VCC, and may either be AC or DC coupled. Output pins can be connected directly to a 50 Ohm to VCC terminated system, while DC blocking capacitors must be used if the terminated system input is 50 Ohms to a DC voltage other than VCC. The HMC877LC3 is available in ROHS-compliant 3 x 3 mm SMT package.APPLICATIONS Synchronization of Clock & Data Transponder Design Broadband Test & Measurement RF ATE Applications

The HMC881LP5E is a MMIC low pass filter which features a user selectable cutoff frequency. The cutoff frequency can be varied from 2.2 to 4.0 GHz by applying a single analog tuning voltage between 0 and 14V. This low pass filter provides a low 3.8 dB insertion loss, 10 dB return loss and 1.25 x ƒcutoff stopband attenuation of >20 dB. This tunable filter can be used as a much smaller alternative to physically large switched filter banks and cavity tuned filters. The HMC881LP5E has excellent microphonics due to the monolithic design, and provides a dynamically adjustable solution in advanced communications applications. The low pass tunable filter is packaged in a RoHS compliant 5x5mm QFN leadless package.Applications Test & Measurement Equipment Military RADAR & EW/ECM SATCOM & Space R&D Laboratories

The HMC902LP3E is a gallium arsenide (GaAs), pseudomorphic high electron mobility transistor (pHEMT), monolithic microwave integrated circuit (MMIC) low noise amplifier (LNA), which is self biased with optional bias control for IDQ reduction. The HMC902LP3E is housed in a leadless 3 mm × 3 mm plastic surface mount package. The amplifier operates between 5 GHz and 11 GHz, providing 19.5 dB of small signal gain, 1.8 dB noise figure, and 28 dBm of output IP3, while requiring only 80 mA from a 3.5 V supply.The P1dB output power of 16 dBm enables the LNA to function as a local oscillator (LO) driver for balanced, I/Q, or image reject mixers. The HMC902LP3E also features inputs/outputs that are dc blocked and internally matched to 50 Ω, making it ideal for high capacity microwave radios and C band, very small aperture terminal (VSAT) applications.Applications Point to point radios Point to multi point radios Military and space Test instrumentation

The AD7765 is a high performance, 24-bit sigma-delta (Σ-Δ) analog-to-digital converter (ADC). It combines wide input bandwidth, high speed, and performance of 112 dB dynamic range at a 156 kHz output data rate. With excellent dc specifications, the converter is ideal for high speed data acquisition of ac signals where dc data is also required.Using the AD7765 eases front-end antialias filtering requirements, simplifying the design process significantly. The AD7765 offers pin-selectable decimation rates of 128× and 256×. Other features include an integrated buffer to drive the reference, as well as a fully differential amplifier to buffer and level shift the input to the modulator.An overrange alert pin indicates when an input signal exceeds the acceptable range. The addition of internal gain and internal overrange registers makes the AD7765 a compact, highly integrated data acquisition device requiring minimal peripheral components.The AD7765 also offers a low power mode, significantly reducing power dissipation without reducing the output data rate or available input bandwidth.The differential input is sampled at up to 40 MSPS by an analog modulator. The modulator output is processed by a series of low-pass filters. The external clock frequency applied to the AD7765 determines the sample rate, filter corner frequencies, and output word rate.The AD7765 device boasts a full band on-board FIR filter. The full stop-band attenuation of the filter is achieved at the Nyquist frequency. This feature offers increased protection from signals that lie above the Nyquist frequency being aliased back into the input signal bandwidth.The reference voltage supplied to the AD7765 determines the input range. With a 4 V reference, the analog input range is ±3.2768 V differential, biased around a common mode of 2.048 V. This common-mode biasing is achieved using the on-chip differential amplifier, further reducing the external signal conditioning requirements.The AD7765 is available in a 28-lead TSSOP package and is specified over the industrial temperature range of −40°C to +85°C.APPLICATIONS Data acquisition systems Vibration analysis Instrumentation

The AD7766/AD7766-1/AD7766-2 are high performance,24-bit, oversampled SAR analog-to-digital converters (ADCs).The AD7766/AD7766-1/AD7766-2 combine the benefits of alarge dynamic range and input bandwidth, consuming 15 mW,10.5 mW, and 8.5 mW power, respectively, and are contained ina 16-lead TSSOP package.Ideal for ultralow power data acquisition (such as PCI- and USBbasedsystems), the AD7766/AD7766-1/AD7766-2 provide 24-bitresolution. The combination of exceptional SNR, wide dynamicrange, and outstanding dc accuracy make the AD7766/AD7766-1/AD7766-2 ideally suited for measuring small signal changes over awide dynamic range. This is particularly suitable for applicationswhere small changes on the input are measured on larger ac ordc signals. In such an application, the AD7766/AD7766-1/AD7766-2 accurately gather both ac and dc information.The AD7766/AD7766-1/AD7766-2 include an on-board digitalfilter (complete with linear phase response) that acts to eliminateout-of-band noise by filtering the oversampled input voltage.The oversampled architecture also reduces front-end antialiasrequirements. Other features of the AD7766/AD7766-1/AD7766-2include a SYNC/PD (synchronization/power-down) pin, allowingthe synchronization of multiple AD7766/AD7766-1/AD7766-2devices. The addition of an SDI pin provides the option of daisychaining multiple AD7766/AD7766-1/AD7766-2 devices.The AD7766/AD7766-1/AD7766-2 operate from a 2.5 V supplyusing a 5 V reference. The devices operate from −40°C to +105°C. Applications Low power PCI/USB data acquisition systems Low power wireless acquisition systems Vibration analysis Instrumentation High precision medical acquisition

The AD7792/AD7793 are low power, low noise, complete analog front ends for high precision measurement applications. The AD7792/AD7793 contain a low noise 16-/24-bit Σ-Δ ADC with three differential analog inputs. The on-chip, low noise instrumentation amplifier means that signals of small amplitude can be interfaced directly to the ADC. With a gain setting of 64, the rms noise is 40 nV when the update rate equals 4.17 Hz.The devices contain a precision low noise, low drift internal band gap reference and can accept an external differential reference. Other on-chip features include programmable excitation current sources, burnout currents, and a bias voltage generator. The bias voltage generator sets the common-mode voltage of a channel to AVDD/2.The devices can be operated with either the internal clock or an external clock. The output data rate from the parts is software-programmable and can be varied from 4.17 Hz to 470 Hz.The parts operate with a power supply from 2.7 V to 5.25 V. They consume a current of 400 μA typical and are housed in a 16-lead TSSOP package.Applications Thermocouple measurements RTD measurements Thermistor measurements Gas analysis Industrial process control Instrumentation Portable instrumentation Blood analysis Smart transmitters Liquid/gas chromatography 6-digit DVM

The AD7804/AD7808 are quad/octal 10-bit digital-to-analog converters, with serial load capabilities, while the AD7805/AD7809 are quad/octal 10-bit digital-to-analog converters with parallel load capabilities. These parts operate from a +3.3 V to +5 V (10%) power supply and incorporates an on-chip reference. These DACs provide output signals in the form of VBIAS VSWING. VSWING is derived internally from VBIAS. On-chip control registers include a system control register and channel control registers. The system control register has control over all DACs in the package. The channel control registers allow individual control of DACs. The complete transfer function of each individual DAC can be shifted around the VBIAS point using an on-chip Sub DAC. All DACs contain double buffered data inputs, which allow all analog outputs to be simultaneously updated using the asynchronous LDAC input. ApplicationsOptical Disk Drives Instrumentation and Communication Systems Process Control and Voltage Setpoint Control Trim Potentiometer Replacement Automatic Calibration Data Sheet, Rev. A, 12/98

The AD7818 and AD7817 are 10-bit, single- and 4-channel A/D converters with on-chip temperature sensor that can operate from a single 2.7 V to 5.5 V power supply. Each part contains a 9 μs successive-approximation converter based around a capacitor DAC, an on-chip temperature sensor with an accuracy of ±2°C, an on-chip clock oscillator, inherent track-and-hold functionality and an on-chip reference (2.5 V). The AD7816 is a temperature monitoring only device in a SOIC/MSOP package.The on-chip temperature sensor of the AD7817 and AD7818 can be accessed via Channel 0. When Channel 0 is selected and a conversion is initiated, the resulting ADC code at the end of the conversion gives a measurement of the ambient temperature with a resolution of ±0.25°C. See Temperature Measurement section of this data sheet.The AD7816, AD7817, and AD7818 have a flexible serial interface that allows easy interfacing to most microcontrollers. The interface is compatible with the Intel 8051, Motorola SPI® and QSPI™ protocols and National Semiconductors MICROWIRE™ protocol. For more information refer to the Serial Interface section of this data sheet.The AD7817 is available in a narrow body 0.15' 16-lead small outline IC (SOIC), in a 16-lead, thin shrink small outline package (TSSOP), while the AD7816 / AD7818 come in an 8-lead small outline IC (SOIC) and an 8-lead microsmall outline IC (MSOP).PRODUCT HIGHLIGHTS The devices have an on-chip temperature sensor that allows an accurate measurement of the ambient temperature to be made. The measurable temperature range is −55°C to +125°C. An overtemperature indicator is implemented by carrying out a digital comparison of the ADC code for Channel 0 (temperature sensor) with the contents of the on-chip overtemperature register. The overtemperature indicator pin goes logic low when a predetermined temperature is exceeded. The automatic power-down feature enables the AD7817 and AD7818 to achieve superior power performance at slower throughput rates, that is, 40 μW at 1 kSPS throughput rate.APPLICATIONS Data acquisition systems with ambient temperature monitoring Industrial process control Automotive Battery charging applications

The AD8138 is a major advancement over op amps fordifferential signal processing. The AD8138 can be used as asingle-ended-to-differential amplifier or as a differential-to-differentialamplifier. The AD8138 is as easy to use as an opamp and greatly simplifies differential signal amplification anddriving. Manufactured on the proprietary ADI XFCB bipolarprocess, the AD8138 has a −3 dB bandwidth of 320 MHz anddelivers a differential signal with the lowest harmonic distortionavailable in a differential amplifier. The AD8138 has a uniqueinternal feedback feature that provides balanced output gainand phase matching, suppressing even order harmonics. Theinternal feedback circuit also minimizes any gain error thatwould be associated with the mismatches in the external gainsetting resistors.The differential output of the AD8138 helps balance the inputto differential ADCs, maximizing the performance of the ADC. The AD8138 eliminates the need for a transformer with highperformance ADCs, preserving the low frequency and dc information.The common-mode level of the differential output isadjustable by a voltage on the VOCM pin, easily level-shifting theinput signals for driving single-supply ADCs. Fast overloadrecovery preserves sampling accuracy. The AD8138 distortion performance makes it an ideal ADCdriver for communication systems, with distortion performancegood enough to drive state-of-the-art 10-bit to 16-bit convertersat high frequencies. The high bandwidth and IP3 of theAD8138 also make it appropriate for use as a gain block in IFand baseband signal chains. The AD8138 offset and dynamicperformance makes it well suited for a wide variety of signalprocessing and data acquisition applications. The AD8138 is available in both SOIC and MSOP packages foroperation over −40°C to +85°C temperatures.The AD8138-EP supports defense and aerospace applications (AQEC).

The AD8139 is an ultralow noise, high performance differentialamplifier with rail-to-rail output. With its low noise, highSFDR, and wide bandwidth, it is an ideal choice for drivinganalog-to-digital converters (ADCs) with resolutions to 18 bits.The AD8139 is easy to apply, and its internal common-modefeedback architecture allows its output common-mode voltageto be controlled by the voltage applied to one pin. The internalfeedback loop also provides outstanding output balance as wellas suppression of even-order harmonic distortion products. Fullydifferential and single-ended-to-differential gain configurationsare easily realized by the AD8139. Simple external feedbacknetworks consisting of four resistors determine the closed-loopgain of the amplifier. The AD8139 is manufactured on the proprietary Analog Devices,Inc., second-generation XFCB process, enabling it to achieve lowlevels of distortion with input voltage noise of only 2.25 nV/√Hz.The AD8139 is available in an 8-lead SOIC package with anexposed paddle (EP) on the underside of its body and a 3 mm ×3 mm LFCSP. It is rated to operate over the temperature rangeof −40°C to +125°C.Applications ADC drivers to 18 bits Single-ended-to-differential converters Differential filters Level shifters Differential PCB drivers Differential cable drivers

The AD820 is a precision, low power FET input op amp that can operate from a single supply of 5 V to 36 V, or dual supplies of ±2.5 V to ±18 V. It has true single-supply capability, with an input voltage range extending below the negative rail, allowing the AD820 to accommodate input signals below ground in the single-supply mode. Output voltage swing extends to within 10 mV of each rail, providing the maximum output dynamic range. Offset voltage of 800 μV maximum, offset voltage drift of 2 μV/°C, typical input bias currents below 25 pA, and low input voltage noise provide dc precision with source impedances up to 1 GΩ. 1.8 MHz unity gain bandwidth, −93 dB THD at 10 kHz, and 3 V/μs slew rate are provided for a low supply current of 800 μA. The AD820 drives up to 350 pF of direct capacitive load and provides a minimum output current of 15 mA. This allows the amplifier to handle a wide range of load conditions. This combination of ac and dc performance, plus the outstanding load drive capability, results in an exceptionally versatile amplifier for the single-supply user.The AD820 is available in two performance grades. The A and B grades are rated over the industrial temperature range of −40°C to +85°C. The AD820 is offered in three 8-lead package options: plastic DIP (PDIP), surface mount (SOIC) and (MSOP).ApplicationsBattery-powered precision instrumentationPhotodiode preamps Active filters12-bit to 14-bit data acquisition systemsMedical instrumentation Low power references and regulatorsData Sheet, Rev. F, 11/08

The AD820 is a precision, low power FET input op amp that can operate from a single supply of 5 V to 36 V, or dual supplies of ±2.5 V to ±18 V. It has true single-supply capability, with an input voltage range extending below the negative rail, allowing the AD820 to accommodate input signals below ground in the single-supply mode. Output voltage swing extends to within 10 mV of each rail, providing the maximum output dynamic range. Offset voltage of 800 μV maximum, offset voltage drift of 2 μV/°C, typical input bias currents below 25 pA, and low input voltage noise provide dc precision with source impedances up to 1 GΩ. 1.8 MHz unity gain bandwidth, −93 dB THD at 10 kHz, and 3 V/μs slew rate are provided for a low supply current of 800 μA. The AD820 drives up to 350 pF of direct capacitive load and provides a minimum output current of 15 mA. This allows the amplifier to handle a wide range of load conditions. This combination of ac and dc performance, plus the outstanding load drive capability, results in an exceptionally versatile amplifier for the single-supply user.The AD820 is available in two performance grades. The A and B grades are rated over the industrial temperature range of −40°C to +85°C. The AD820 is offered in three 8-lead package options: plastic DIP (PDIP), surface mount (SOIC) and (MSOP).ApplicationsBattery-powered precision instrumentationPhotodiode preamps Active filters12-bit to 14-bit data acquisition systemsMedical instrumentation Low power references and regulatorsData Sheet, Rev. F, 11/08

The AD8260 includes a high current driver, usable as atransmitter, and a low noise digitally programmable variablegain amplifier (DGA), useable as a receiver.The receiver section consists of a single-ended input preamplifier,and linear-in-dB, differential-output DGA. The receiver hasa small signal –3 dB bandwidth of 230 MHz; the driver smallsignal bandwidth is 195 MHz. The driver delivers ±300 mA,well suited for driving low impedance loads, even whenconnected to a 3.3 V supply.The AD8260 DGA is ideal for trim applications and has a gainspan of 30 dB, in 3 dB steps. Excellent bandwidth uniformity ismaintained across the entire frequency range. The low output-referrednoise of the DGA is advantageous in driving highspeed ADCs. The differential output facilitates the interface tomodern low voltage high speed ADCs.Single-supply and dual-supply operation makes the part versatileand enables gain control of negative-going pulses, such as thosegenerated by photodiodes or photo-multiplier tubes, as well asprocessing band-pass signals on a single supply. For maximumdynamic range, it is essential that the part be ac-coupled whenoperating on a single supply.The AD8260 preamplifier (PrA) is configured with externalresistors for gains greater than 6 dB and can be inverting ornoninverting. The DGA is characterized with a noninvertingpreamplifier gain of 2×. The attenuator has a range of 30 dB andthe output amplifier has a gain of 8× (18.06 dB). The lowestnoninverting gain range is −6 dB to +24 dB and shifts up withincreased preamplifier gain. The gain is controlled via a parallelport (Pin GNS0 to Pin GNS3) with 10 gain steps of 3 dB percode. The preamplifier and DGA are disabled for any code thatis not assigned a gain step.The AD8260 can operate with single or dual supplies from 3.3 Vto ±5 V. An internal buffer normally provides a split supplyreference for single-supply operation; an external reference canalso be used when the VMID buffer is shut down.The operating temperature range is −40°C to +105°C. TheAD8260 is available in a 5 mm × 5 mm, 32-lead LFCSP.Applications Digital AGC systems Tx/Rx signal processing Power line transceivers

The AD8538/AD8539 are very high precision amplifiers featuring extremely low offset voltage, low input bias current, and low power consumption. The supply current is less than 215 μA maximum per amplifier at 5.0 V. Operation is fully specified from 2.7 V to 5.0 V single supply (±1.35 V to ±2.5 V dual supply).The AD8538/AD8539 operate at very low power making these amplifiers ideal for battery-powered devices and portable equipment.The AD8538/AD8539 are specified over the extended industrial temperature range (−40°C to +125°C). The AD8538 amplifier is available in 5-lead TSOT-23, and 8-lead, narrow body SOIC packages, and the AD8539 amplifier is available in 8-lead, narrow body SOIC and 8-lead MSOP.Applications Mobile communications Portable instrumentation Battery-powered devices Sensor interfaces Temperature measurement Electronic scales

The AD8541/AD8542/AD8544 are single, dual, and quad rail-to-rail input and output single-supply amplifiers featuring very low supply current and 1 MHz bandwidth. All are guaranteed to operate from a 2.7 V single supply as well as a 5 V supply. These parts provide 1 MHz bandwidth at a low current consumption of 45 μA per amplifier.Very low input bias currents enable the AD8541/AD8542/AD8544 to be used for integrators, photodiode amplifiers, piezoelectric sensors, and other applications with high source impedance. The supply current is only 45 μA per amplifier, ideal for battery operation.Rail-to-rail inputs and outputs are useful to designers buffering ASICs in single-supply systems. The AD8541/AD8542/AD8544 are optimized to maintain high gains at lower supply voltages, making them useful for active filters and gain stages.The AD8541/AD8542/AD8544 are specified over the extended industrial temperature range (–40°C to +125°C). The AD8541 is available in 8-lead SOIC, 5-lead SC70, and 5-lead SOT-23 packages. The AD8542 is available in 8-lead SOIC, 8-lead MSOP, and 8-lead TSSOP surface-mount packages. The AD8544 is available in 14-lead narrow SOIC and 14-lead TSSOP surface-mount packages. All MSOP, SC70, and SOT versions are available in tape and reel only.Applications ASIC input or output amplifiers Sensor interfaces Piezoelectric transducer amplifiers Medical instrumentations Mobile communications Audio outputs Portable systems
