The Arduino Ethernet is a microcontroller board based on the ATmega328. It has 14 digital input/output pins, 6 analog inputs, a 16 MHz crystal oscillator, a RJ45 connection, a power jack, an ICSP header, and a reset button. NB: Pins 10, 11, 12 and 13 are reserved for interfacing with the Ethernet module and should not be used otherwise. This reduces the number of available pins to 9, with 4 available as PWM outputs. An optional Power over Ethernet module can be added to the board as well. The Ethernet differs from other boards in that it does not have an onboard USB-to-serial driver chip, but has a Wiznet Ethernet interface. This is the same interface found on the Ethernet shield. An onboard microSD card reader, which can be used to store files for serving over the network, is accessible through the SD Library. Pin 10 is reserved for the Wiznet interface, SS for the SD card is on Pin 4. The 6-pin serial programming header is compatible with the USB Serial adapter and also with the FTDI USB cables or with Sparkfun and Adafruit FTDI-style basic USB-to-serial breakout boards. It features support for automatic reset, allowing sketches to be uploaded without pressing the reset button on the board. When plugged into a USB to Serial adapter, the Arduino Ethernet is powered from the adapter. The Revision 3 of the board introduces the standardized 1.0 pinout, that consist in: added SDA and SCL pins that are near to the AREF pin and two other new pins placed near to the RESET pin, this will the opportunity to shield that use i2c or TWI components to be compatible with all the Arduino boards; the IOREF that allow the shields to adapt to the voltage provided from the board. Shields that use the IOREF pin will be compatible both with the board that use the AVR, which operate with 5V and with the Arduino Due that operate with 3.3V. Next to the IOREF pin there is a not connected pin, that is reserved for future purposes.

Arduino Yun Mini is a breadboard PCB developed with ATmega 32u4 MCU and QCA MIPS 24K SoC CPU operating up to 400 MHz. Qualcomm Atheros CPU supports a Linux distribution based on OpenWRT named Linino. The board has built- in WiFi ( IEEE 802.11b/g/n operations up to 150Mbps 1x1 2.4 GHz ) supports 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connector, an ICSP header, two reset buttons and one user button. The Arduino Yún Mini is similar to the Leonardo in that the ATmega32u4 has built-in USB communication, eliminating the need for a secondary processor. This allows the Arduino Yún Mini to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port.

With the new Arduino M0 board, the more creative individual will have the potential to create one’s most imaginative and new ideas for IoT devices, wearable technologies, high tech automation, wild robotics and other not yet thinkable adventures in the world of makers. The Arduino M0 represents a simple, yet powerful, 32-bit extension of the Arduino UNO platform. The board is powered by Atmel’s SAMD21 MCU, featuring a 32-bit ARM Cortex M0 core. With the addition of the M0 board, the Arduino family becomes larger with a new member providing increased performance. The power of its Atmel’s core gives this board an upgraded flexibility and boosts the scope of projects one can think of and make; moreover, it makes the M0 the ideal educational tool for learning about 32-bit application development.

The Arduino Robot is the first official Arduino on wheels. The robot has two processors, one on each of its two boards. The Motor Board controls the motors, and the Control Board reads sensors and decides how to operate. Each of the boards is a full Arduino board programmable using the Arduino IDE.

The Arduino Micro is a microcontroller board based on the ATmega32u4, developed in conjunction with Adafruit.

The Arduino Mini is a small microcontroller board originally based on the ATmega168, but now supplied with the 328. The new Mini (revision 05) has a new package for the ATmega328, which enables all components to be on the top of the board. It also has an onboard reset button

The Arduino Fio is a microcontroller board based on the ATmega328P runs at 3.3V and 8 MHz. It has 14 digital input/output pins (of which 6 can be used as PWM outputs), 8 analog inputs, an on-board resonator, a reset button, and holes for mounting pin headers. It has connections for a Lithium Polymer battery and includes a charge circuit over USB.

Enter the world of FPGAs using the simplicity of Arduino and Seeed Studio’s Grove ecosystem. "Amazing and FPGA in the same word let along the same sentence" do we hear you say?! Yes, as Arduino continues its quest to 'democratize IoT development,' we've added the new MKR Vidor 4000 board to the MKR family, making the power and flexibility of FPGA accessible to everyone! Entry level - Simply use the Arduino IDE as usual - including example Vidor software libraries bring in FPGA bitfile too - as if by magic! Intermediate level - Visual tool let you configure a hardware system. Advanced level - Quartus project file enables you to develop your own Verilog, which you can make available to others in the visual tool. Still not convinced that it's AMAZING, well you get all this and the MKR Connector Carrier and Grove Starter Kit Plus for only €125,00. Meaning, there's never been a better time to enter the world of FPGA and the endless project possibilities it offers! Bundle contains: 1 x MKR Vidor 4000 - Microchip ATSAMD21 (ARM Cortex-M0+ processor) and standard MKR pinout. Connect a MIPI camera for machine vision applications, or drive a video display via micro HDMI. Control precision robotics systems with a quadrature encoder, or high resolution PWM. An additional MiniPCI Express connector gives the FPGA even more I/O options, while an onboard BLE and WiFi module means you can easily connect your applications. Features: The first FPGA Arduino board WiFi (ESP32) IMU ECC508 8MB SRAM 2MB Flash MIPI Video Input HDMI MiniPCI Express 1 x MKR Connector Carrier - Allows you to connect several Seeed Studio Grove modules to your Arduino board; enabling you to build real systems quickly and easily for your IoT prototype. Features: Interface with up to 14 Grove Connectors Analog inputs six at 5V Digitial input/output six at 5V Other connectors one 5V I2C, one 5V UART 1 x Grove Starter Kit Plus - Simple, quick and easy, the Grove Starter Kit turns building your IoT devices into an enjoyable process. The perfect add kit for the Arduino MKR Vidor 4000, it contains a compatible Grove Base Shield and a bunch of sensors and actuators with built in Grove interfaces. Simply plug in the modules and you are ready to bring your IoT solution to life.

Let your WiFi ideas fly! Rapidly prototype IoT devices using a MKR 1010 and Grove modules via the MKR Connector Carrier. Utilizing Arduino's unique 'Panini Concept' — where designers pick up a MKR board, then mix-and-match it with the desired shields and carrier boards to create custom hardware configurations for IoT projects as if they were crafting a sandwich! The IoTerrific bundle includes the Arduino MKR WiFi 1010, plus the MKR MEM Shield and MKR Connector Carrier, making it one of Arduino's most popular 'combos' and providing you with a terrific starting point for designing your next IoT solution. Availble for a limited time period with a special 'combo' price of €49,99. 1 x Arduino MKR WiFi 1010 - Featuring the flexibility of the ESP32 module from u-blox and its low power consumption, the MKR WiFi 1010 enables you to accelerate and simplify the prototyping of WiFi-based IoT applications. The MKR WiFi 1010 features the smae standardized, modular form factor as the rest of the MKR family, and is consists of three main blocks: Microchip ATSAMD21 MCU based on an Arm Cortex-M0+ processor u-blox NINA-W10 series low power 2.4GHz IEEE® 802.11 b/g/n Wi-Fi ECC508 CryptoAuthentication The design includes a Li-Po charging circuit that allows the MKR WiFi 1010 to run on battery power or external 5V, charging the Li-Po battery while operating on external power - switching from one source to the other is done automatically. 1 x MKR MEM Shield - Short on memory? the MKR MEM Shield can help. It adds an additional 2MB flash memory and MicroSD storage to go with your MKR board. 1 x MKR Connector Carrier - Allows you to connect several Seeed Studio Grove modules to your Arduino board; enabling you to build real systems quickly and easily for your IoT prototype. Features: Interface with up to 14 Grove Connectors Analog inputs six at 5V Digitial input/output six at 5V Other connectors one 5V I2C, one 5V UART

Arduino Materia 101 is the first official Arduino 3D printer. It uses an Arduino Mega2560 with a shield specifically made for controlling 3D printers. It's a small machine, with a sheet metal design housing the moving parts. The design is straightforward and easy to understand, which makes it a good machine for beginners, or up-and-coming hardware hackers who want to improve and experiment

The LilyPad Arduino SimpleSnap is a microcontroller board designed for wearables and e-textiles. It is similar to the LilyPad Arduino Simple, except that it has a built in lithium polymer battery, and instead of through-holes, it has conductive snaps. By using matching snaps in your project, you can affix the LilyPad securely but remove it to wash your project or move it to another project. The LilyPad SimpleSnap has 9 pins for input/output. Additionally, it has a built in charging circuit for the battery. The board is based on the ATmega328.

The Zero is a simple and powerful 32-bit extension of the platform established by the UNO. The Zero board expands the family by providing increased performance, enabling a variety of project opportunities for devices, and acts as a great educational tool for learning about 32-bit application development. The Zero applications span from smart IoT devices, wearable technology, high-tech automation, to crazy robotics. The board is powered by Atmel’s SAMD21 MCU, which features a 32-bit ARM Cortex® M0+ core. One of its most important features is Atmel’s Embedded Debugger (EDBG), which provides a full debug interface without the need for additional hardware, significantly increasing the ease-of-use for software debugging. EDBG also supports a virtual COM port that can be used for device and bootloader programming. Warning: Unlike most Arduino & Genuino boards, the Zero runs at 3.3V. The maximum voltage that the I/O pins can tolerate is 3.3V. Applying voltages higher than 3.3V to any I/O pin could damage the board. The board contains everything needed to support the microcontroller; simply connect it to a computer with a micro-USB cable or power it with a AC-to-DC adapter or battery to get started. The Zero is compatible with all the shields that work at 3.3V and are compliant with the 1.0 Arduino pinout.

The Leonardo ETH is a microcontroller board based on the ATmega32U4 (datasheet) and the new W5500 TCP/IP Embedded Ethernet Controller (datasheet). It has 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a RJ45 connection, a micro USB connector, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Leonardo ETH differs from the preceding Ethernet board in that the ATmega32u4 has built-in USB communication, eliminating the need for an external USB-to-serial converter. This allows the Leonardo ETH to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port. It also has other implications for the behaviour of the board. Plus, it has the new W5500 TCP/IP Embedded Ethernet Controller onboard. An optional Power over Ethernet module can be added to the board as well. The Leonardo ETH has the same Wiznet Ethernet interface as the Ethernet Shield 2. An onboard microSD card reader, which can be used to store files for serving over the network, is accessible through the SD Library. Pin 10 is reserved for the Wiznet interface, SS for the SD card is on Pin 4. added SDA and SCL pins: beside the AREF pin, two TWI pins have been added. This will allow to connect the Leonardo ETH to Shields that use the I2C or TWI bus communication for their functioning. the IOREF: it allows the shields to adapt to the IO voltage level provided by the Board. The Shield that uses the IOREF pin will be compatible with both 3V3 and 5V (e.g Due and Uno) IO levels Arduino Boards. Next to the IOREF pin you can find another (currently not in use) pin, that is reserved for future usage.
