ARDUINO CERTIFICATION FUNDAMENTALS BULK 500 CODES

Arduino, Nano RP2040 Connect, Product Name: Arduino Nano RP2040 Connect, Kit Classification: Development Board, Processor Part Number: Arm Cortex-M0+, Revision: 1, MPN: ABX00052

NINA-W102, RP2040 Arduino Nano RP2040 Connect - ARM® Cortex®-M0+ MCU 32-Bit Embedded Evaluation Board

MAX CARRIER BOARD, ARM CORTEX-M4

Arduino Opta Rs485 Board, Cortex M4/M7 Rohs Compliant: Yes |Arduino AFX00001

Microcontroller board based on the ATmega328

Microcontroller board based on the ATmega32u4

Arduino Yún is a microcontroller board based on the ATmega32u4 and the Atheros AR9331. The Atheros processor supports a Linux distribution based on OpenWRT named Linino. The board has built-in Ethernet and WiFi support, a USB-A port, micro-SD card slot, 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a micro USB connection, an ICSP header, and a 3 reset buttons. The Yún distinguishes itself from other Arduino boards by its ability to communicate with the Linux distribution onboard, offering a powerful networked computer with the ease of an Arduino. In addition to Linux commands like the cURL, you can write your own shell and python scripts for robust interactions. The Yún is similar to the Leonardo with the ATmega32u4, except that it has Linux on board. (has built-in USB communication, eliminating the need for a secondary processor).

Arduino Materia 101 is the first official Arduino 3D printer. It uses an Arduino Mega2560 with a shield specifically made for controlling 3D printers. It's a small machine, with a sheet metal design housing the moving parts. The design is straightforward and easy to understand, which makes it a good machine for beginners, or up-and-coming hardware hackers who want to improve and experiment

The LilyPad Arduino SimpleSnap is a microcontroller board designed for wearables and e-textiles. It is similar to the LilyPad Arduino Simple, except that it has a built in lithium polymer battery, and instead of through-holes, it has conductive snaps. By using matching snaps in your project, you can affix the LilyPad securely but remove it to wash your project or move it to another project. The LilyPad SimpleSnap has 9 pins for input/output. Additionally, it has a built in charging circuit for the battery. The board is based on the ATmega328.

The Zero is a simple and powerful 32-bit extension of the platform established by the UNO. The Zero board expands the family by providing increased performance, enabling a variety of project opportunities for devices, and acts as a great educational tool for learning about 32-bit application development. The Zero applications span from smart IoT devices, wearable technology, high-tech automation, to crazy robotics. The board is powered by Atmel’s SAMD21 MCU, which features a 32-bit ARM Cortex® M0+ core. One of its most important features is Atmel’s Embedded Debugger (EDBG), which provides a full debug interface without the need for additional hardware, significantly increasing the ease-of-use for software debugging. EDBG also supports a virtual COM port that can be used for device and bootloader programming. Warning: Unlike most Arduino & Genuino boards, the Zero runs at 3.3V. The maximum voltage that the I/O pins can tolerate is 3.3V. Applying voltages higher than 3.3V to any I/O pin could damage the board. The board contains everything needed to support the microcontroller; simply connect it to a computer with a micro-USB cable or power it with a AC-to-DC adapter or battery to get started. The Zero is compatible with all the shields that work at 3.3V and are compliant with the 1.0 Arduino pinout.

The Leonardo ETH is a microcontroller board based on the ATmega32U4 (datasheet) and the new W5500 TCP/IP Embedded Ethernet Controller (datasheet). It has 20 digital input/output pins (of which 7 can be used as PWM outputs and 12 as analog inputs), a 16 MHz crystal oscillator, a RJ45 connection, a micro USB connector, a power jack, an ICSP header, and a reset button. It contains everything needed to support the microcontroller; simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started. The Leonardo ETH differs from the preceding Ethernet board in that the ATmega32u4 has built-in USB communication, eliminating the need for an external USB-to-serial converter. This allows the Leonardo ETH to appear to a connected computer as a mouse and keyboard, in addition to a virtual (CDC) serial / COM port. It also has other implications for the behaviour of the board. Plus, it has the new W5500 TCP/IP Embedded Ethernet Controller onboard. An optional Power over Ethernet module can be added to the board as well. The Leonardo ETH has the same Wiznet Ethernet interface as the Ethernet Shield 2. An onboard microSD card reader, which can be used to store files for serving over the network, is accessible through the SD Library. Pin 10 is reserved for the Wiznet interface, SS for the SD card is on Pin 4. added SDA and SCL pins: beside the AREF pin, two TWI pins have been added. This will allow to connect the Leonardo ETH to Shields that use the I2C or TWI bus communication for their functioning. the IOREF: it allows the shields to adapt to the IO voltage level provided by the Board. The Shield that uses the IOREF pin will be compatible with both 3V3 and 5V (e.g Due and Uno) IO levels Arduino Boards. Next to the IOREF pin you can find another (currently not in use) pin, that is reserved for future usage.

Creative Technologies in the Classroom 101, or CTC 101, is Arduino’s one-of-a-kind STEAM (Science, Technology, Engineering, Arts, and Mathematics) program for upper secondary education. Students are introduced to the foundations of programming, electronics, and mechanics through a series of playful, well-documented projects and easy-to-assemble experiments. Tailored for high school students ages 13 to 17, CTC is the ideal professional development program for upper secondary school teachers and educators. Inclusive Learning Activities CTC’s learning activities were developed for the classroom, ensuring that no one is left behind. Both teachers and students alike can benefit from five themed modules, and more than 25 hands-on experiments with different degrees of complexity to accommodate various skill levels. Teachers will: Learn how to get started with Programming and Physical Computing, Adapt their lesson plans with more engaging and creative techniques, Take a hands-on approach to achieving defined learning objectives. Students groups will: Get started with programming, Build fully-functional, interactive projects, Explore robotics, Learn about connectivity and wireless communication via Bluetooth, Enhance their problem-solving and teamwork skills in a collaborative environment. What You Will Find in a CTC 101 Kit? CTC 101 is a kit for the classroom, and it can accommodate up to 24 students. It includes more than 700 components and parts: Six Arduino 101 Boards - a microcontroller with programmable inputs and outputs that allow users to create interactive electronics, Six Education Shields - a unit that is placed on top of an Arduino board to make connecting electronic components easier, A set of Sensors and actuators - includes light sensors, button inputs, knock sensors, potentiometers, touch/capacitive sensors, tilt sensors, infrared array, a joystick, LEDs, buzzers, a speaker, servo motors, and more. Component Modules - quick-connect modules that include necessary components onboard, Connectors and various components - other items needed to complete electronics assembly. An Online Environment for Your e-Learning Needs We all agree that it’s never too late to learn a new set of skills. CTC 101 addresses teachers and instructors looking to take advantage of the latest technologies, and integrate them into their curriculum or company portfolio. We have worked hard to give you access to a tailored e-learning platform that contains everything you need to know about programming, electronics, mechanics, and connected devices. This includes well-documented learning resources, videos, and simple to follow instructions.

This kit includes all the components you need to build simple projects and learn how to turn an idea into reality using Arduino. Arduino Basic Kit has been developed in collaboration with Autodesk. When you purchase the kit you will receive online access to 15 step-by-step tutorials to make simple projects using components that let you control the physical world through different kinds of sensors and actuators. Once you have mastered this knowledge, you will have a palette of code and circuits to create something beautiful and useful. So build, hack and share! Projects you can make: 01 GET TO KNOW YOUR TOOLS an introduction to the basics 02 SPACESHIP INTERFACE design the control panel for your starship 03 LOVE-O-METER measure how hot-blooded you are 04 COLOR MIXING LAMP produce any color with a lamp that uses light as an input 05 MOOD CUE clue people in to how you're doing 06 LIGHT THEREMIN create a musical instrument you play by waving your hands 07 KEYBOARD INSTRUMENT play music and make some noise with this keyboard 08 DIGITAL HOURGLASS a light-up hourglass that can stop you from working too much 09 MOTORIZED PINWHEEL a colored wheel that will make your head spin 10 ZOETROPE create a mechanical animation you can play forward or reverse 11 CRYSTAL BALL a mystical tour to answer all your tough questions 12 KNOCK LOCK tap out the secret code to open the door 13 TOUCHY-FEEL LAMP a lamp that responds to your touch 14 TWEAK THE ARDUINO LOGO control your personal computer from your Arduino 15 HACKING BUTTONS create a master control for all your devices! Getting Started When you purchase an Arduino Basic Kit you will receive an email with all the infos you need to access the tutorials online on Autodesk Project Ignite. You will be able to get started with Arduino, learn the basics of coding and electronics, jump right into the step-by-step tutorials and make the 15 simple projects. You can find the Arduino code for all these projects within the Arduino IDE, click on File / Examples / 10.StarterKit. Arduino Basic Kit includes: 1 Arduino UNO, 1 USB cable, 1 Breadboard 400 points, 70 Solid core jumper wires, 1 Easy-to-assemble wooden base, 1 9v battery snap, 1 Stranded jumper wires (black), 1 Stranded jumper wires (red), 6 Photoresistor [VT90N2 LDR], 3 Potentiometer 10kilohm, 10 Pushbuttons, 1 Temperature sensor [TMP36], 1 Tilt sensor, 1 alphanumeric LCD (16x2 characters), 1 LED (bright white), 1 LED (RGB), 8 LEDs (red), 8 LEDs (green), 8 LEDs (yellow), 3 LEDs (blue), 1 Small DC motor 6/9V, 1 Small servo motor, 1 Piezo capsule [PKM17EPP-4001-B0], 1 H-bridge motor driver [L293D], 1 Optocouplers [4N35], 2 Mosfet transistors [IRF520], 5 Capacitors 100uF, 5 Diodes [1N4007], 3 Transparent gels (red, green, blue), 1 Male pins strip (40x1), 20 Resistors 220 ohm, 5 Resistors 560 ohm, 5 Resistors 1 kilohm, 5 Resistors 4.7 kilohm, 20 Resistors 10 kilohm, 5 Resistors 1 megohm, 5 Resistors 10 megohm. What is the difference between the Starter Kit and the Basic Kit? The Starter Kit includes a 150 pages book with the walk-through of all the projects. Instead if you purchase the Basic Kit you will get access to the projects guides online on Autodesk Project Ignite.

With the new Arduino M0 pro board, the more creative individual will have the potential to create one’s most imaginative and new ideas for IoT devices, wearable technologies, high tech automation, wild robotics and other not yet thinkable adventures in the world of makers. The Arduino M0 pro represents a simple, yet powerful, 32-bit extension of the Arduino UNO platform. The board is powered by Atmel’s SAMD21 MCU, featuring a 32-bit ARM Cortex M0 core. With the addition of the M0 board, the Arduino family becomes larger with a new member providing increased performance. The power of its Atmel’s core gives this board an upgraded flexibility and boosts the scope of projects one can think of and make; moreover, it makes the M0 Pro the ideal educational tool for learning about 32-bit application development. Atmel’s Embedded Debugger (EDBG), integrated in the board, provides a full debug interface with no need for additional hardware, making debugging much easier. EDBG additionally supports a virtual COM port for device programming and traditional Arduino boot loader functionality uses.

The MKRZero brings you the power of a Zero in the smaller format established by the MKR form factor. The MKRZero board acts as a great educational tool for learning about 32-bit application development. It has an on-board SD connector with dedicated SPI interfaces (SPI1) that allows you to play with files with no extra hardware! The board is powered by Atmel’s SAMD21 MCU, which features a 32-bit ARM Cortex M0+ core. Warning: Unlike most Arduino & Genuino boards, the MKRZero runs at 3.3V. The maximum voltage that the I/O pins can tolerate is 3.3V. Applying voltages higher than 3.3V to any I/O pin could damage the board. The board contains everything needed to support the microcontroller; simply connect it to a computer with a micro-USB cable or power it by a LiPo battery. The battery voltage can also be monitored since a connection between the battery and the analog converter of the board exists.

ARDUINO MINI EVALUATION BOARD; Silicon Manufacturer:Atmel; Silicon Family Name:ATmega; Core Architecture:AVR; Core Sub-Architecture:megaAVR; Silicon Core Number:ATmega328; Kit Contents:Eval Board ATmega328; Product Range:-; Features:Atmega328 MCU Headers included for easy Prototyping; No. of Bits:8bit

AC 8C 816 PIN PLUG

ATmega32U4 Arduino Leonardo ETH with POE AVR® ATmega AVR MCU 8-Bit Embedded Evaluation Board

ATSAMD21 Arduino MKR Zero with Headers SAM D ARM® Cortex®-M0+ MCU 32-Bit Embedded Evaluation Board
