ARDUINO STUDENT KIT

ARDUINO SENSOR KIT

With the MKR Vidor 4000 you can configure it the way you want; you can essentially create your own controller board. It comes loaded with hardware and potential: an 8 MB SRAM; a 2 MB QSPI Flash chip — 1 MB allocated for user applications; a Micro HDMI connector; an MIPI camera connector; and Wifi & BLE powered by U-BLOX NINA W10 Series. It also includes the classic MKR interface on which all pins are driven both by SAMD21 and FPGA. Plus, it has a Mini PCI Express connector with up to 25 user programmable pins. The FPGA contains 16K Logic Elements, 504 KB of embedded RAM, and 56 18x18 bit HW multipliers for high-speed DSP. Each pin can toggle at over 150 MHz and can be configured for functions such as UARTs, (Q)SPI, high resolution/high frequency PWM, quadrature encoder, I2C, I2S, Sigma Delta DAC, etc. The on-board FPGA can be also used for high-speed DSP operations for audio and video processing. This board also features a Microchip SAMD21. Communication between FPGA and the SAMD21 is seamless.

NANO 33 BLE DEV BRD, ARM CORTEX-M4F MCU; Silicon Manufacturer:Nordic Semiconductor; No. of Bits:32bit; Silicon Family Name:-; Core Architecture:ARM; Core Sub-Architecture:Cortex-M4F; Silicon Core Number:nRF52840; Product Range:- RoHS Compliant: Yes

NANO 33 BLE W/HEADER DEVELOPMENT BOARD; Silicon Manufacturer:Nordic Semiconductor; No. of Bits:32bit; Silicon Family Name:-; Core Architecture:ARM; Core Sub-Architecture:Cortex-M4F; Silicon Core Number:nRF52840; Product Range:- RoHS Compliant: Yes

CD4081BNSR, CD40106BNSR, CD40109BNSRG4, LT3652HV, MP2322, MP1542, MC14067BDWG, TPS54620, TS13102, TCA6424A, W25Q16JVZPIQ Arduino Edge Control - ARM® Cortex®-M4F MCU 32-Bit Embedded Evaluation Board

Arduino, MKR Environmental Shield Rev2, Product Name: Arduino MKR Environmental Shield Rev2, Processor Part Number: ASX00029

ARDUINO MKR THERM SHIELD;

ARDUINO MKR RGB;

ARDUINO MKR MOTOR CARRIER;

Arduino Ethernet shield 2 without POE. Technology: Development Board. Processor Type: MCU. MPN: A000024

STARTER KIT, 8-BIT AVR ATMEGA MCU ROHS COMPLIANT: YES

ATmega328P Arduino Uno R3 AVR® ATmega AVR MCU 8-Bit Embedded Evaluation Board

NANO MOTOR CARRIER DEV BOARD;

ATmega32U4 Arduino Micro series AVR MCU 8-Bit Embedded Evaluation Board

TINKERKIT BRACCIO ROBOTIC ARM;

Arduino Nano 33 BLE Sense Rev2 with headers An AI (Artificial Intelligence) enabled board in the shape of the classic Nano board, with all the sensors to start building your next project right away. The Arduino Nano 33 BLE Sense Rev2 with headers is Arduino’s 3.3V AI enabled board in the smallest available form factor with a set of sensors that will allow you without any external hardware to start programming your next project, right away. With the Arduino Nano 33 BLE Sense Rev2, you can: Build wearable devices that using AI can recognize movements. Build a room temperature monitoring device that can suggest or modify changes in the thermostat. Build a gesture or voice recognition device using the microphone or the gesture sensor together with the AI capabilities of the board. The main feature of this board, besides the complete selection of sensors, is the possibility of running Edge Computing applications (AI) on it using TinyML. Learn how to use the Tensor Flow Lite library following this instructions or learn how to train your board using Edge Impulse. Tech Specs Microcontroller - nRF52840 Operating Voltage - 3.3V Input Voltage - 21V DC Current per I/O Pin - 15mA Clock Speed - 64MHz CPU Flash Memory - 1MB (nRF52840) SRAM - 256KB (nRF52840) EEPROM - none Digital Input / Output Pins - 14 PWM Pins - All digital pins UART - 1 SPI - 1 I2C - 1 Analog Input Pins - 8 (ADC 12 bit 200 k samples) Analog Output Pins - Only through PWM (no DAC) External Interrupts - All digital pins LED_BUILTIN - 13 USB - Native in the nRF52840 Processor IMU - BMI1270 and BMM150 Microphone - MP34DT06JTR Gesture, light, proximity, color - APDS9960 Barometric pressure - LPS22HB Temperature, humidity - HS3003

Schematic for Arduino Uno Rev3 Board

Stackable Female Headers for Arduino Shields - 1x8 and 1x6 Position (2 each)

PROTOTYPE SHIELD FOR ARDUINO BOARD; Silicon Manufacturer:-; Core Architecture:-; Core Sub-Architecture:-; Silicon Core Number:-; Silicon Family Name:-; For Use With:Arduino Boards with 1.0 Pin Out; Kit Contents:Prototyping Shield; Product Range:-; Accessory Type:Arduino Shield; Features:Arduino Pinout Reset Button ICSP Connector 14 pin SMD Footprint 20 pin Through Hole Footprint
