CAP ALU ELEC 220UF 400V SNAP IN; Capacitance:220µF; Voltage Rating:400V; Product Range:-; Lifetime @ Temperature:4000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:30mm; ESR:0.4ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 100Hz:2.5A; Capacitance Tolerance ±:± 20%; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Ripple Current Temperature:85°C

CAP ALU ELEC 330UF 400V SNAP IN; Capacitance:330µF; Voltage Rating:400V; Product Range:-; Lifetime @ Temperature:10000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:30mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:45mm; ESR:0.2ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 100Hz:2A; Capacitance Tolerance ±:± 20%; No. of Pins:2Pins; Operating Temperature Range:-40°C to +85°C; Ripple Current Temperature:85°C

CAP ALU ELEC 33000UF 63V SCREW; Capacitance:33000µF; Voltage Rating:63V; Product Range:B41580 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:64.3mm; Lead Spacing:28.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.0055ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 100Hz:15A; Capacitance Tolerance ±:± 20%; External Diameter:64.3mm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Ripple Current Temperature:105°C

CAPACITOR STUD MOUNT 100V 4700UF; Capacitance:4700µF; Voltage Rating:100V; Product Range:-; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:35.7mm; Lead Spacing:12.7mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.018ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 100Hz:7.5A; Capacitance Tolerance ±:± 20%; External Diameter:35.7mm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Ripple Current Temperature:105°C

CAP ALU ELEC 22000UF 100V SCREW; Capacitance:22000µF; Voltage Rating:100V; Product Range:B41580 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:76.9mm; Lead Spacing:31.7mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.004ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 100Hz:17A; Capacitance Tolerance ±:± 20%; External Diameter:76.9mm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Ripple Current Temperature:105°C

CAP ALU ELEC 33000UF 63V SCREW; Capacitance:33000µF; Voltage Rating:63V; Product Range:-; Lifetime @ Temperature:15000 hours @ 85°C; Capacitance Tolerance:+30% -10%; Capacitor Terminals:Screw; Diameter:76.9mm; Lead Spacing:31.7mm; Operating Temperature Min:-55°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.004ohm; Automotive Qualification Standard:-; SVHC:1-Methyl-2-pyrrolidone (15-Jun-2015); AC Ripple Current @ 100Hz:21A; Capacitance Tolerance ±:+30% -10%; No. of Pins:2Pins; Operating Temperature Range:-55°C to +105°C; Ripple Current Temperature:105°C

CAP ALU ELEC 47000UF 40V SCREW; Capacitance:47000µF; Voltage Rating:40V; Product Range:-; Lifetime @ Temperature:15000 hours @ 85°C; Capacitance Tolerance:+30% -10%; Capacitor Terminals:Screw; Diameter:64.3mm; Lead Spacing:28.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:105°C; Height:105mm; ESR:0.005ohm; Automotive Qualification Standard:-; SVHC:1-Methyl-2-pyrrolidone (15-Jun-2015); AC Ripple Current @ 100Hz:17A; Capacitance Tolerance ±:+30% -10%; No. of Pins:2Pins; Operating Temperature Range:-55°C to +105°C; Ripple Current Temperature:105°C

INDUCTOR 680UH 61MA +10% 3MHz; Product Range:B82422H Series; Inductance:680 H; DC Current Rating:61mA; High Frequency Inductor Case:1210 [3225 Metric]; Inductor Construction:Wirewound; DC Resistance Max:31ohm; Packaging:Cut Tape ;RoHS Compliant: Yes

CAP FILM PP 10000PF 1KV RADIAL; Capacitance:10000pF; Voltage Rating:1kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32652 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (07-Jul-2017); Voltage Rating V DC:1kV

CAP FILM PP 0.1UF 400V RADIAL; Capacitance:0.1µF; Voltage Rating:400V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32652 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (07-Jul-2017); Voltage Rating V DC:400V

CAP ALU ELEC 100UF 50V RAD; Capacitance:100µF; Voltage Rating:50V; Product Range:B41851 Series; Capacitance Tolerance:± 20%; Capacitor Terminals:Radial Leaded; Diameter:8mm; Packaging:Each; Lead Spacing:3.5mm; Height:11.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Lifetime @ Temperature:2000 hours @ 105°C; ESR:2ohm; Automotive Qualification Standard:-; SVHC:No SVHC (07-Jul-2017)

CONTACTOR SPST-NO 24V PANEL; Load Current Inductive:-; Relay Mounting:Panel; Operating Voltage:900VDC; Contact Configuration:SPST-NO; No. of Poles:1 Pole; Switching Power AC3:-; Switching Current AC1:-; Coil Voltage VAC Nom:-; Coil Voltage VDC Nom:24V; Switching Power AC1:-; Load Current Resistive:-; Switching Current AC3:-; Product Range:HVC Series; SVHC:No SVHC (15-Jan-2018)

Pressure Sensors - Absolute Pressure Transducers

Pressure Sensors - Absolute Pressure Transducers

Pressure Sensors - Absolute Pressure Transducers

Film Capacitors Power Factor Correction - PhaseCap Premium Capacitors

CAPACITOR FILM 525V CAN; Output (kvar):20kvar @ 50Hz; 24kvar @ 60Hz; Voltage Rating VAC:525V; Capacitor Dielectric Type:PP (Polypropylene); Rated Capacitance:3 x 77µF; Current Rating:22A @ 50Hz; 26A @ 60Hz; Product Range:MKK525-D Series; Capacitor Case Style:Can; Terminal Connection:Threaded Stud; Stud Size - Metric:M12; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:77µF; Rated Capacitance:77µF

Film Capacitors Power Factor Correction Key components Capacitor contactors

Ferrites PQ Cores PQ 16/11.8

Transponder Coils - Size 11.4 3.5 2.4 mm
