VARISTOR 420VAC 1.12KV DIS REEL; Voltage Rating VAC:420V; Voltage Rating V DC:560V; Product Range:StandarD Series; Clamping Voltage Vc Max:1.12kV; Varistor Case Style:Disc 20mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:8kA; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):175J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:750

CAP FILM PP 40UF 450VAC SNAP IN; Capacitance:40µF; Product Range:B32332 Series; Voltage Rating VAC:450V; Capacitor Terminals:Quick Connect Snap-In; Capacitance Tolerance:± 5%; dv/dt Rating:10V/µs; Capacitor Dielectric Type:PP (Polypropylene); Capacitor Case Style:Can; Height:103mm; Diameter:40mm; Stud Size - Metric:M8; Operating Temperature Min:-25°C; Operating Temperature Max:85°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 5%; Operating Temperature Range:-25°C to +85°C; Voltage Rating:450VAC

CAP FILM PP 2.2UF 630V RAD; Capacitance:2.2µF; Voltage Rating V DC:630V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32674 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:27.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Voltage Rating:630V

INDUCTOR 4.7UH 150MA +10% 110MHz; Product Range:B82422A Series; Inductance:4.7 H; DC Current Rating:150mA; High Frequency Inductor Case:1210 [3225 Metric]; Inductor Construction:Wirewound; DC Resistance Max:2.2ohm; Q Factor:27 ;RoHS Compliant: Yes

INDUCTOR 100NH 440MA +10% 1GHZ; Product Range:B82422A Series; Inductance:100nH; DC Current Rating:440mA; High Frequency Inductor Case:1210 ^3225 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.26ohm; Q Factor:25

INDUCTOR PWR 15UH 3.4A 20% 0.1MHZ; Product Range:B82476B1 Series; Inductance:15µH; RMS Current (Irms):3.4A; Saturation Current (Isat):3.4A; Inductor Construction:Unshielded; DC Resistance Max:0.04ohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR PWR 150UH 1.1A 20% 0.1MHZ; Product Range:B82476B1 Series; Inductance:150µH; RMS Current (Irms):1.1A; Saturation Current (Isat):1.15A; Inductor Construction:Unshielded; DC Resistance Max:0.33ohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR PWR 330UH 0.65A 20% 0.1MHZ; Product Range:B82476B1 Series; Inductance:330µH; RMS Current (Irms):650mA; Saturation Current (Isat):670mA; Inductor Construction:Unshielded; DC Resistance Max:0.81ohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR PWR 4.7UH 5.3A 20% 0.1MHZ; Product Range:B82476B1 Series; Inductance:4.7µH; RMS Current (Irms):5.3A; Saturation Current (Isat):5.6A; Inductor Construction:Unshielded; DC Resistance Max:0.0165ohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 390UF 450V SNAP-IN; Capacitance:390µF; Voltage Rating:450V; Product Range:B43644 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:35mm; ESR:0.27ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)

THERMISTOR NTC 47KOHM 5% 0603; Zero Power Resistance at 25°C:47kohm; Product Range:B57352V5 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0603 [1608 Metric]; Thermistor Terminals:-; Operating Temperature Min:-40°C; Operating Temperature Max:150°C; Automotive Qualification Standard:AEC-Q200; SVHC:No SVHC (15-Jun-2015); No. of Pins:2Pins; Resistance:47kohm; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 100KOHM 5% 0603; Zero Power Resistance at 25°C:100kohm; Product Range:B57374V2 Series; Beta Value (K):4480K; Thermistor Mounting:SMD; Thermistor Case Style:0603 [1608 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); No. of Pins:2Pins; Resistance:100kohm; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 10KOHM 5% 0805; Zero Power Resistance at 25°C:10kohm; Product Range:-; Beta Value (K):4000K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-40°C; Operating Temperature Max:150°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); No. of Pins:2Pins; Resistance:10kohm; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 33KOHM 5% 0805; Zero Power Resistance at 25°C:33kohm; Product Range:B57451V5 Series; Beta Value (K):4000K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-40°C; Operating Temperature Max:150°C; Automotive Qualification Standard:AEC-Q200; SVHC:No SVHC (15-Jun-2015); No. of Pins:2Pins; Resistance:33kohm; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

CAP ALU ELEC 560UF 450V SNAP-IN; Capacitance:560µF; Voltage Rating:450V; Product Range:B43508 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:0.22ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 470UF 400V SNAP-IN; Capacitance:470µF; Voltage Rating:400V; Product Range:-; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:30mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:40mm; ESR:0.26ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 820UF 400V SNAP-IN; Capacitance:820µF; Voltage Rating:400V; Product Range:B43508 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:50mm; ESR:0.15ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 560UF 400V SNAP-IN; Capacitance:560µF; Voltage Rating:400V; Product Range:B43508 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:40mm; ESR:0.22ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 680UF 400V SNAP-IN; Capacitance:680µF; Voltage Rating:400V; Product Range:B43508 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:0.18ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 470UF 250V SNAP-IN; Capacitance:470µF; Voltage Rating:250V; Product Range:B43508 Series; Lifetime @ Temperature:2000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:40mm; ESR:0.25ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015)
