THERMISTOR NTC 22K RADIAL LEADED; Zero Power Resistance at 25 C:22kohm; Product Range:B57891M Series; Beta Value (K):4300K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER P22 X 13; For Use With:P22 x 13 Type B65661 Series Ferrite Cores; Product Range:B65662 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER RM6 6-PIN; For Use With:RM6 Type B65807 Series Ferrite Cores; Product Range:B65808 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

COIL FORMER E13 Valox 420SE0 STICK IN STYRENE BOARD

TRANSFORMER COIL FORMER E20/10 12PIN; For Use With:E 20/10/6 Type B66311 Series Ferrite Cores; Product Range:B66206 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

INDUCTOR 100UH 1.8A +20% FULL REEL; Product Range:B82479A1 Series; Inductance:100 H; Inductance Tolerance: 20%; Inductor Construction:Wirewound; DC Resistance Max:0.19ohm; RMS Current (Irms):1.8A; Saturation Current (Isat):3A

VARISTOR 3225 4.2J 130VAC; Voltage Rating V AC:130V; Voltage Rating V DC:170V; Product Range:-; Clamping Voltage Vc Max:340V; Varistor Case Style:3225; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:400A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):4.2J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:100pF; Clamping Voltage:340V; Clamping Voltage @ 8/20µs Max:340V; MSL:MSL 2A - 4 weeks; Operating Temperature Range:-40°C to +85°C; Packaging:Cut Tape; Peak Pulse Current IPP @ 8/20µs:400A; Suppressor Type:Varistor; Surge Current:400A; Transient Energy:4.2J; Varistor Voltage:205V; Varistor Voltage @ 1mA:194.5V; Varistor Voltage @ 1mA Max:225.5V; Varistor Voltage Tolerance +:10%; Varistor Voltage Tolerance -:10%

CAP ALU ELEC 150UF 400V SNAP IN; Capacitance:150µF; Voltage Rating:400V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:40mm; ESR:0.59ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 384-4; Capacitance Tolerance ±:± 20%; External Length / Height:40mm; Impedance:730mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:2000h; Ripple Current AC:0.82A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP ALU ELEC 330UF 400V SNAP IN; Capacitance:330µF; Voltage Rating:400V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:30mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:0.27ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 384-4; Capacitance Tolerance ±:± 20%; External Length / Height:45mm; Impedance:330mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:2000h; Ripple Current AC:1.5A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP ALU ELEC 47UF 400V SNAP IN; Capacitance:47µF; Voltage Rating:400V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:25mm; ESR:1.87ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 384-4; Capacitance Tolerance ±:± 20%; External Length / Height:25mm; Impedance:2310mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:2000h; Ripple Current AC:0.39A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP FILM PP 68NF 305V RAD; Capacitance:0.068µF; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:B32922C Series; dv/dt Rating:340V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-40°C; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitor Application:Safety / Suppression; External Depth:5mm; External Length / Height:10.5mm; External Width:18mm; Lead Diameter:0.8mm; Lead Spacing:15mm; Voltage Rating VAC:305V

CAP FILM PP 2.2UF 630V RAD; Capacitance:2.2µF; Voltage Rating V DC:630V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32674 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:27.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Voltage Rating:630V

INDUCTOR 100UH 370MA 5% FULL REEL; Product Range:-; Inductance:100µH; DC Current Rating:370mA; DC Resistance Max:1.7ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:5MHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Current Rating:370mA; Inductor Case Style:Axial Leaded; No. of Pins:2Pins; Q Factor:70; Q Test Frequency:796kHz; Reel Quantity:5000

VARISTOR 0.3J 11VAC FULL REEL; Voltage Rating VAC:11V; Voltage Rating V DC:14V; Product Range:StandarD Series; Clamping Voltage Vc Max:36V; Varistor Case Style:Disc 5mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:100A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):300mJ; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1500

VARISTOR 1.3J 20VAC FULL REEL; Voltage Rating VAC:20V; Voltage Rating V DC:26V; Product Range:StandarD Series; Clamping Voltage Vc Max:65V; Varistor Case Style:Disc 7mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:250A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):1.3J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1500

VARISTOR 1.6J 25VAC FULL REEL; Voltage Rating VAC:25V; Voltage Rating V DC:31V; Product Range:StandarD Series; Clamping Voltage Vc Max:77V; Varistor Case Style:Disc 7mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:250A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):1.6J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1500

VARISTOR 4.2J 50VAC FULL REEL; Voltage Rating VAC:50V; Voltage Rating V DC:65V; Product Range:StandarD Series; Clamping Voltage Vc Max:135V; Varistor Case Style:Disc 7mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:1.2kA; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):4.2J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1500

CAPACITOR POLYPROPYLENE PP FILM 0.15UF 300VAC 20% RADIAL; Capacitance:0.15 F; Suppression Class:Y2; Voltage Rating X:-; Voltage Rating Y:300V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20%; Packaging:Each

VARISTOR 17.0J 230VAC FULL REEL; Voltage Rating VAC:230V; Voltage Rating V DC:300V; Product Range:-; Clamping Voltage Vc Max:595V; Varistor Case Style:Disc 7mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:1.2kA; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):17J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1500

VARISTOR 21.0J 275VAC FULL REEL; Voltage Rating VAC:275V; Voltage Rating V DC:350V; Product Range:StandarD Series; Clamping Voltage Vc Max:710V; Varistor Case Style:Disc 7mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:1.2kA; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):21J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1000
