COIL FORMER E13 Valox 420SE0 STICK IN STYRENE BOARD

TRANSFORMER COIL FORMER E20/10 12PIN; For Use With:E 20/10/6 Type B66311 Series Ferrite Cores; Product Range:B66206 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

INDUCTOR 100UH 1.8A +20% FULL REEL; Product Range:B82479A1 Series; Inductance:100 H; Inductance Tolerance: 20%; Inductor Construction:Wirewound; DC Resistance Max:0.19ohm; RMS Current (Irms):1.8A; Saturation Current (Isat):3A

VARISTOR 3225 4.2J 130VAC; Voltage Rating V AC:130V; Voltage Rating V DC:170V; Product Range:-; Clamping Voltage Vc Max:340V; Varistor Case Style:3225; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:400A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):4.2J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:100pF; Clamping Voltage:340V; Clamping Voltage @ 8/20µs Max:340V; MSL:MSL 2A - 4 weeks; Operating Temperature Range:-40°C to +85°C; Packaging:Cut Tape; Peak Pulse Current IPP @ 8/20µs:400A; Suppressor Type:Varistor; Surge Current:400A; Transient Energy:4.2J; Varistor Voltage:205V; Varistor Voltage @ 1mA:194.5V; Varistor Voltage @ 1mA Max:225.5V; Varistor Voltage Tolerance +:10%; Varistor Voltage Tolerance -:10%

FILM CAPACITOR PP 0.047UF 305VAC 20% RADIAL; Capacitance:0.047 F; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20%; dv/dt Rating:475V/ s ;RoHS Compliant: Yes

CAP FILM PP 680NF 305VAC RAD; Capacitance:0.68 F; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20%; Product Range:B32923C Series; dv/dt ;RoHS Compliant: Yes

INDUCTOR 3.3UH 900MA 10% FULL REEL; Product Range:B78108S BC Series; Inductance:3.3µH; DC Current Rating:900mA; DC Resistance Max:0.29ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:115MHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Current Rating:900mA; Inductor Case Style:Axial Leaded; No. of Pins:2Pins; Q Factor:60; Q Test Frequency:7.96MHz; Reel Quantity:5000

INDUCTOR AXIAL 68UH; Product Range:B78108S BC Series; Inductance:68µH; DC Current Rating:410mA; DC Resistance Max:1.35ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:6.5MHz; Packaging:Each; SVHC:No SVHC (15-Jun-2015); Body Diameter:4mm; Core Material:Ferrite; Current Rating:410mA; External Length / Height:9.2mm; Inductance Measurement Frequency:0.1MHz; Inductor Case Style:Axial Leaded; Inductor Type:High Frequency / RF; Lead Diameter:0.63mm; Lead Length:25mm; No. of Pins:2Pins; Q Factor:40; Q Test Frequency:2.52MHz; Tolerance +:5%; Tolerance -:5%

INDUCTOR 1MH 55MA 10% FULL REEL; Product Range:-; Inductance:1mH; DC Current Rating:55mA; High Frequency Inductor Case:1812 [4532 Metric]; Inductor Construction:Wirewound; DC Resistance Max:32ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:2.3MHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Core Material:Ferrite; Inductor Case Style:1812 [4532 Metric]; Q Factor:30; Q Test Frequency:796kHz; Reel Quantity:2500

INDUCTOR 220UH 250MA 5% FULL REEL; Product Range:B78108S BC Series; Inductance:220µH; DC Current Rating:250mA; DC Resistance Max:3.3ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:3.7MHz; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Current Rating:250mA; Inductor Case Style:Axial Leaded; No. of Pins:2Pins; Q Factor:70; Q Test Frequency:796kHz; Reel Quantity:5000

FILM CAP Y2 MKP 10 NF 20% 300Vac LS 10mm AMMO PACK

CAPACITOR POLYPROPYLENE PP FILM 5600PF 300VAC 20% RADIAL; Capacitance:5600pF; Suppression Class:Y2; Voltage Rating X:-; Voltage Rating Y:300V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20% ;RoHS Compliant: Yes

CAP FILM PET 0.1UF 400V RAD; Capacitance:0.1µF; Voltage Rating V DC:400V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 10%; Product Range:B32521 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:10mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating:400V

FILM CAP MKP DC LINK 1.0 5% 875Vdc LS 27.5mm BULK

CAP SUPPRESSION X1 0.1UF 10% RAD; Capacitance:0.1µF; Suppression Class:X1; Voltage Rating X:330V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32912 Series; dv/dt Rating:400V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating VAC:330V

FILM CAP MKP X1 0.33 20% 330Vac LS 15mm BULK

CAP FILM PP 330NF 330VAC RAD; Capacitance:0.33µF; Suppression Class:X1; Voltage Rating X:330V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:B32912 Series; dv/dt Rating:400V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitor Application:Safety / Suppression; External Depth:9mm; External Length / Height:17.5mm; External Width:18mm; Height:17.5mm; Lead Diameter:0.8mm; Lead Spacing:15mm; Voltage Rating VAC:330V

FILM CAP MKP X2 20µF 20% 305Vac LS 37.5mm

CAP SUPPRESSION Y2 0.68UF 20% RAD; Capacitance:0.68µF; Suppression Class:Y2; Voltage Rating X:-; Voltage Rating Y:300V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:B32024 Series; dv/dt Rating:400V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating VAC:300V

FILM CAP Y2 MKP 22NF 20% 300Vac LS 15mm BULK
