CAP FILM PP 680NF 305VAC RAD; Capacitance:0.68 F; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20%; Product Range:B32923C Series; dv/dt ;RoHS Compliant: Yes

CAP ALU ELEC 150UF 400V SNAP IN; Capacitance:150µF; Voltage Rating:400V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:40mm; ESR:0.59ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 384-4; Capacitance Tolerance ±:± 20%; External Length / Height:40mm; Impedance:730mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:2000h; Ripple Current AC:0.82A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP ALU ELEC 330UF 400V SNAP IN; Capacitance:330µF; Voltage Rating:400V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:30mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:0.27ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 384-4; Capacitance Tolerance ±:± 20%; External Length / Height:45mm; Impedance:330mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:2000h; Ripple Current AC:1.5A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP ALU ELEC 47UF 400V SNAP IN; Capacitance:47µF; Voltage Rating:400V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:25mm; ESR:1.87ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Approval Category:IEC 384-4; Capacitance Tolerance ±:± 20%; External Length / Height:25mm; Impedance:2310mohm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Operating life Time:2000h; Ripple Current AC:0.39A; Ripple Current Temperature:105°C; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP ALU ELEC 100UF 400V SNAP IN; Capacitance:100µF; Voltage Rating:400V; Product Range:-; Lifetime @ Temperature:10000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:25mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:25mm; ESR:0.67ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Climatic Category:40/085/56; External Length / Height:25mm; External Width:25mm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +85°C; Operating life Time:10000h; Ripple Current AC:0.8A; Tolerance +:20%; Tolerance -:20%; Voltage Rating V DC:400V

CAP FILM PET 1.5UF 100V RAD; Capacitance:1.5µF; Voltage Rating V DC:100V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 10%; Product Range:B32522 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; External Depth:10.5mm; External Length / Height:18mm; External Width:5mm; Flammability Rating:UL94V-0; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Tolerance +:5%; Tolerance -:10%; Voltage Rating:100V; Voltage Rating VAC:63V

CAP FILM PET 2.2UF 100V RAD; Capacitance:2.2µF; Voltage Rating V DC:100V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 10%; Product Range:B32522 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; External Depth:12.5mm; External Length / Height:18mm; External Width:7mm; Flammability Rating:UL94V-0; Height:18mm; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Tolerance +:5%; Tolerance -:10%; Voltage Rating:100V; Voltage Rating VAC:63V

Film Capacitor B32522 Series 0.33 F 10% PET (Polyester) 250 V ;RoHS Compliant: Yes

CAP FILM PET 10UF 63V RAD; Capacitance:10µF; Voltage Rating V DC:63V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 10%; Product Range:B32523 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:22.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; External Depth:20.5mm; External Length / Height:26.5mm; External Width:11mm; Flammability Rating:UL94V-0; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Tolerance +:5%; Tolerance -:10%; Voltage Rating:63V; Voltage Rating VAC:40V

CAP FILM PET 2.2UF 400V RAD; Capacitance:2.2µF; Voltage Rating V DC:400V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 10%; Product Range:-; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:27.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; External Depth:21.5mm; External Length / Height:31.5mm; External Width:12.5mm; Flammability Rating:UL94V-0; Height:31.5mm; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Tolerance +:5%; Tolerance -:10%; Voltage Rating:400V; Voltage Rating VAC:200V

CAP FILM PET 10NF 400V RAD; Capacitance:0.01µF; Voltage Rating V DC:400V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 10%; Product Range:B32561 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:10mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; External Depth:2.3mm; External Length / Height:5.1mm; External Width:11.5mm; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Tolerance +:10%; Tolerance -:10%; Voltage Rating:400V; Voltage Rating VAC:200V

Film Capacitor B32652 Series 6800 pF 5% PP (Polypropylene) 1.6 kV ;RoHS Compliant: Yes

CAPACITOR PP 22NF 1.25KV RADIAL; Capacitance:0.022 F; Voltage Rating VDC:1.25kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 5%; Product Range:B32652 Series; Capacitor Case Style:-; Lead Spacing:15mm ;RoHS Compliant: Yes

Film Capacitor B32653 Series 0.33 F 5% PP (Polypropylene) 400 V ;RoHS Compliant: Yes

Film Capacitor B32653 Series 0.22 F 5% PP (Polypropylene) 630 V ;RoHS Compliant: Yes

Film Capacitor B32653 Series 0.33 F 5% PP (Polypropylene) 630 V ;RoHS Compliant: Yes

CAP FILM PP 470NF 630V RAD; Capacitance:0.47µF; Voltage Rating V DC:630V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 5%; Product Range:B32653 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:22.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 5%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; External Depth:20.5mm; External Length / Height:26.5mm; External Width:11mm; Flammability Rating:UL94V-0; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Tolerance +:5%; Tolerance -:5%; Voltage Rating:630V; Voltage Rating VAC:250V

CAPACITOR PP 1500NF 630V RADIAL; Capacitance:1.5 F; Voltage Rating VDC:630V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 5%; Product Range:B32654 Series; Capacitor Case Style:-; Lead Spacing:27.5mm ;RoHS Compliant: Yes

Film Capacitor B32654 Series 0.33 F 5% PP (Polypropylene) 1.25 kV ;RoHS Compliant: Yes

CAP FILM PP 680NF 1KV; Capacitance:0.68µF; Voltage Rating V DC:1kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32656S Series; Capacitor Case Style:-; Capacitor Terminals:-; Lead Spacing:37.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; Dissipation Factor:0.5%; Dissipation Factor Frequency:1kHz; Dissipation Factor Temperature:25°C; External Depth:16mm; External Length / Height:28.5mm; External Width:42mm; Flammability Rating:UL94V-0; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Operating life Time:200000h; Rate of Voltage Change dv / dt:90V/µs; Tolerance +:10%; Tolerance -:10%; Voltage Rating:1kV; Voltage Rating VAC:500V
