CAP FILM PP 680NF 1KV; Capacitance:0.68µF; Voltage Rating V DC:1kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32656S Series; Capacitor Case Style:-; Capacitor Terminals:-; Lead Spacing:37.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; Dissipation Factor:0.5%; Dissipation Factor Frequency:1kHz; Dissipation Factor Temperature:25°C; External Depth:16mm; External Length / Height:28.5mm; External Width:42mm; Flammability Rating:UL94V-0; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Operating life Time:200000h; Rate of Voltage Change dv / dt:90V/µs; Tolerance +:10%; Tolerance -:10%; Voltage Rating:1kV; Voltage Rating VAC:500V

CAP FILM PP 1UF 1.25KV SOLDER; Capacitance:1µF; Voltage Rating V DC:1.25kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 5%; Product Range:B32656S Series; Capacitor Case Style:-; Capacitor Terminals:Solder Lug; Lead Spacing:37.5mm; Operating Temperature Min:-55°C; Operating Temperature Max:100°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 5%; Capacitor Mounting:Through Hole; Climatic Category:55/100/56; Dissipation Factor:0.5%; Dissipation Factor Frequency:1kHz; Dissipation Factor Temperature:25°C; External Depth:28mm; External Length / Height:37mm; External Width:42mm; Flammability Rating:UL94V-0; Height:37mm; No. of Pins:2Pins; Operating Temperature Range:-55°C to +100°C; Operating life Time:200000h; Rate of Voltage Change dv / dt:140V/µs; Tolerance +:5%; Tolerance -:5%; Voltage Rating:1.25kV; Voltage Rating VAC:500V

FILM CAPACITOR PP 0.047UF 305VAC 20% RADIAL; Capacitance:0.047 F; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20%; dv/dt Rating:475V/ s ;RoHS Compliant: Yes

CAP FILM PP 680NF 305VAC RAD; Capacitance:0.68 F; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance: 20%; Product Range:B32923C Series; dv/dt ;RoHS Compliant: Yes

CAP FILM PP 68NF 305V RAD; Capacitance:0.068µF; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:B32922C Series; dv/dt Rating:340V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-40°C; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitor Application:Safety / Suppression; External Depth:5mm; External Length / Height:10.5mm; External Width:18mm; Lead Diameter:0.8mm; Lead Spacing:15mm; Voltage Rating VAC:305V

THERMISTOR NTC 15K RADIAL LEADED; Zero Power Resistance at 25 C:15kohm; Product Range:B57164K Series; Beta Value (K):4250K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating ;RoHS Compliant: Yes

THERMISTOR NTC 3.3K RADIAL LEADED; Zero Power Resistance at 25°C:3.3kohm; Product Range:B57164K Series; Beta Value (K):3950K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited

THERMISTOR NTC 22K RADIAL LEADED; Zero Power Resistance at 25 C:22kohm; Product Range:B57891M Series; Beta Value (K):4300K; Thermistor Mounting:Through Hole; Thermistor Case Style:-; Thermistor Terminals:Radial Leaded; Operating ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER P22 X 13; For Use With:P22 x 13 Type B65661 Series Ferrite Cores; Product Range:B65662 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

TRANSFORMER COIL FORMER RM6 6-PIN; For Use With:RM6 Type B65807 Series Ferrite Cores; Product Range:B65808 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

COIL FORMER E13 Valox 420SE0 STICK IN STYRENE BOARD

TRANSFORMER COIL FORMER E20/10 12PIN; For Use With:E 20/10/6 Type B66311 Series Ferrite Cores; Product Range:B66206 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

INDUCTOR 0805 5600NH 5%; Product Range:-; Inductance:5.6µH; DC Current Rating:85mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:4.3ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:180MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:0805 [2012 Metric]

VARISTOR 2220 11V; Voltage Rating VAC:11V; Voltage Rating V DC:14V; Product Range:-; Clamping Voltage Vc Max:33V; Varistor Case Style:2220 [5650 Metric]; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:1.2kA; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Peak Energy (10/1000uS):5.4J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance:0.012µF; Clamping Voltage:33V; Clamping Voltage @ 8/20µs Max:33V; Operating Temperature Range:-55°C to +125°C; Peak Pulse Current IPP @ 8/20µs:1200A; Suppressor Type:Varistor; Surge Current:1.2kA; Transient Energy:5.4J; Varistor Voltage @ 1mA Max:18V; Varistor Voltage Tolerance +:10%

THERMISTOR NTC 2K2 0805; Zero Power Resistance at 25°C:2.2kohm; Product Range:B57421V2 Series; Beta Value (K):4000K; Thermistor Mounting:SMD; Thermistor Case Style:0805 [2012 Metric]; Thermistor Terminals:-; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Beta Value Lower Limit Temperature:25°C; Operating Temperature Range:-55°C to +125°C; Power Dissipation Ptot Max:210mW; Resistance:2.2kohm; Resistance Tolerance:± 5%; Temperature Upper Limit Beta Value:100°C; Thermistor Tolerance:-5% to +5%; Thermistor Type:NTC

THERMISTOR NTC 4R7 3A; Product Range:B57153S0 Series; Disc Size:8.5mm; Zero Power Resistance at 25°C:4.7ohm; Approvals:UL; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:3A; SVHC:No SVHC (15-Jun-2015); Beta Value (K):2800K; Beta Value Lower Limit Temperature:25°C; Body Diameter:8.5mm; Current Max:3A; Lead Length:25mm; Lead Spacing:5mm; No. of Pins:2Pins; Operating Temperature Max:170°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +170°C; Operating Voltage:265V; Power Dissipation Ptot Max:1.4W; Resistance:4.7ohm; Resistance Tolerance:± 20%; Temperature Upper Limit Beta Value:100°C; Thermistor Case Style:Radial Leaded; Thermistor Tolerance:-20% to +20%; Thermistor Type:NTC

GDT AXIAL 5KA 470V; Product Range:-; DC Breakover Voltage:470V; GDT Case Style:Axial Leaded; Impulse Discharge Current:5kA; Impulse Sparkover Voltage:800V; SVHC:No SVHC (15-Jun-2015); Suppressor Type:Gas Discharge Tube (GDT)

?15 mm 7 Ohm 4.2 A ?20% Radial Inrush Current Limiting NTC Thermistor

B573xxV2 Series 0603 10 kO ?5% 3980K Surface Mount NTC Thermistor

CAPACITOR POLYESTER FILM 0.015UF 63V 5; CAPACITOR POLYESTER FILM 0.015UF 63V 5% RADIAL; Capacitance:0.015 F; Capacitor Dielectric Type:PET (Polyester); Voltage Rating:63V; Product Range:B32529 Series; Capacitance Tolerance: 5%; Capacitor Terminals:Radial Leaded
