VARISTOR 8.2J 250VAC FULL REEL; Voltage Rating VAC:250V; Voltage Rating V DC:320V; Product Range:StandarD Series; Clamping Voltage Vc Max:650V; Varistor Case Style:Disc 5mm; Varistor Type:Metal Oxide Varistor (MOV); Peak Surge Current @ 8/20µs:400A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):8.2J; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Operating Temperature Range:-40°C to +85°C; Packaging:Tape & Reel; Reel Quantity:1500

FILTER INLET IEC MEDICAL 6A 250V; Capacitance:0.1µF; Voltage Rating:250V; Current Rating:6A; Filter Type:IEC Mains; Filter Terminals:Quick Connect; Inductance Min:840µH; Leakage Current Max:-; Product Range:B84771 Series; SVHC:No SVHC (15-Jun-2015); Operating Temperature Max:50°C

AC Power Entry Modules Medical Filter 250volts 12A

FERRITE CORE RM 7 N48; Core Type:RM; Core Size:RM7; Core Material Grade:N48; For Use With:-; Effective Magnetic Path Length:-; Ae Effective Cross Section Area:-; Inductance Factor Al:250nH; Product Range:B65819 Series; SVHC:No SVHC (15-Jun-2015); Accessory Type:Ferrite Core; Material Grade:N48

INDUCTOR PWR 1UH 7.5A 20% 0.1MHZ; Product Range:B82476B1 Series; Inductance:1µH; RMS Current (Irms):7.5A; Saturation Current (Isat):12.5A; Inductor Construction:Unshielded; DC Resistance Max:8000µohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

INDUCTOR PWR 1.5UH 6.9A 20% 0.1MHZ; Product Range:B82476B1 Series; Inductance:1.5µH; RMS Current (Irms):6.9A; Saturation Current (Isat):10A; Inductor Construction:Unshielded; DC Resistance Max:9000µohm; Power Inductor Case:12.95mm x 9.4mm x 5.08mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015)

CAP ALU ELEC 1000UF 63V SNAP IN; Capacitance:1000µF; Voltage Rating:63V; Product Range:B41505 Series; Lifetime @ Temperature:5000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:25mm; ESR:0.149ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +105°C

CAP ALU ELEC 1000UF 400V SNAP IN; Capacitance:1000µF; Voltage Rating:400V; Product Range:B43305 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:50mm; ESR:0.14ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 820UF 450V SNAP IN; Capacitance:820µF; Voltage Rating:450V; Product Range:-; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:55mm; ESR:0.17ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 68UF 400V SNAP IN; Capacitance:68µF; Voltage Rating:400V; Product Range:B43305 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:22mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:25mm; ESR:1.99ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 390UF 450V SNAP IN; Capacitance:390µF; Voltage Rating:450V; Product Range:-; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:30mm; ESR:0.35ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 1000UF 250V SNAP IN; Capacitance:1000µF; Voltage Rating:250V; Product Range:B43305 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:25mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:50mm; ESR:0.13ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 2200UF 250V SNAP IN; Capacitance:2200µF; Voltage Rating:250V; Product Range:B43305 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:50mm; ESR:0.06ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 10000UF 450V SCREW; Capacitance:10000µF; Voltage Rating:450V; Product Range:B43457 Series; Lifetime @ Temperature:10000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:91mm; Lead Spacing:-; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:221mm; ESR:0.011ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 1000UF 250V SNAP IN; Capacitance:1000µF; Voltage Rating:250V; Product Range:B43504 Series; Lifetime @ Temperature:3000 hours @ 105°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:30mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Height:45mm; ESR:0.14ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +105°C

CAP ALU ELEC 68UF 450V SNAP IN; Capacitance:68µF; Voltage Rating:450V; Product Range:B43540 Series; Lifetime @ Temperature:10000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:25mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:25mm; ESR:1.42ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 100UF 400V SNAP IN; Capacitance:100µF; Voltage Rating:400V; Product Range:B43540 Series; Lifetime @ Temperature:10000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:25mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:25mm; ESR:0.64ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 560UF 250V SNAP IN; Capacitance:560µF; Voltage Rating:250V; Product Range:B43540 Series; Lifetime @ Temperature:10000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:40mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:30mm; ESR:0.12ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-40°C to +85°C

CAP ALU ELEC 3900UF 400V SCREW; Capacitance:3900µF; Voltage Rating:400V; Product Range:B43564 Series; Lifetime @ Temperature:15000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:76.9mm; Lead Spacing:-; Operating Temperature Min:-25°C; Operating Temperature Max:85°C; Height:105.7mm; ESR:0.029ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-25°C to +85°C

CAP ALU ELEC 2200UF 450V SCREW; Capacitance:2200µF; Voltage Rating:450V; Product Range:B43564 Series; Lifetime @ Temperature:15000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Screw; Diameter:64.3mm; Lead Spacing:-; Operating Temperature Min:-25°C; Operating Temperature Max:85°C; Height:105.7mm; ESR:0.043ohm; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 20%; Operating Temperature Range:-25°C to +85°C
