FILM CAP Y2 MKP 3.3NF 20% 300Vac LS 10mm AMMO PACK

CAP FILM PP 1000PF 2KV RAD; Capacitance:1000pF; Voltage Rating V DC:2kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 5%; Product Range:B32672L Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating:2kV

CAP FILM PP 8200PF 2KV RAD; Capacitance:8200pF; Voltage Rating V DC:2kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 5%; Product Range:B32672L Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:15mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating:2kV

CAP FILM PP 5UF 1.1KV RAD; Capacitance:5µF; Voltage Rating V DC:1.1kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32774 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:27.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating:1.1kV

CAP FILM PET 330NF 100V RAD; Capacitance:0.33µF; Voltage Rating V DC:100V; Capacitor Dielectric Type:PET (Polyester); Capacitance Tolerance:± 5%; Product Range:B32521 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:10mm; Operating Temperature Min:-55°C; Operating Temperature Max:125°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 5%; Operating Temperature Range:-55°C to +125°C; Voltage Rating:100V

SMT-INDUCTOR 1210 120uH 10% TAPE & REEL

IN STOCK SHIP TODAY

INDUCTOR 0603 120NH 0.16A 5%; Product Range:B82496C Series; Inductance:120nH; DC Current Rating:160mA; High Frequency Inductor Case:0603 [1608 Metric]; Inductor Construction:Wirewound; DC Resistance Max:3ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:1.8GHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:0603 [1608 Metric]

INDUCTOR 0603 12NH 0.45A 5%; Product Range:-; Inductance:12nH; DC Current Rating:450mA; High Frequency Inductor Case:0603 [1608 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.35ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:5GHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:0603 [1608 Metric]

INDUCTOR SMD 82NH 220MA 5% 2GHZ; Product Range:B82496C Series; Inductance:82nH; DC Current Rating:220mA; High Frequency Inductor Case:0603 [1608 Metric]; Inductor Construction:Wirewound; DC Resistance Max:1.5ohm; Q Factor:35 ;RoHS Compliant: Yes

CHIP INDUCTOR 10NH 700MA 5% 5000MHZ FULL REEL; Product Range:B82498F Series; Inductance:10nH; DC Current Rating:700mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.09ohm ;RoHS Compliant: Yes

INDUCTOR 150NH 400MA +5% 1.15GHZ; Product Range:B82498F Series; Inductance:150nH; DC Current Rating:400mA; High Frequency Inductor Case:0805 ^2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.42ohm; Q Factor:45

INDUCTOR 27NH 700MA +5% 2.5GHZ; Product Range:B82498F Series; Inductance:27nH; DC Current Rating:700mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.09ohm; Q Factor:60 ;RoHS Compliant: Yes

INDUCTOR 0603 6.8NH 0.7A 5%; Product Range:B82496C Series; Inductance:6.8nH; DC Current Rating:700mA; High Frequency Inductor Case:0603 [1608 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.15ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:6GHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:0603 [1608 Metric]

CHIP INDUCTOR 47NH 600MA 5% 2000MHZ; Product Range:B82498F Series; Inductance:47nH; DC Current Rating:600mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.13ohm; Q Factor:65 ;RoHS Compliant: Yes

INDUCTOR 56NH 600MA +5% 1.7GHZ; Product Range:B82498F Series; Inductance:56nH; DC Current Rating:600mA; High Frequency Inductor Case:0805 ^2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.14ohm; Q Factor:60

CHIP INDUCTOR 68NH 500MA 5% 1600MHZ; Product Range:B82498F Series; Inductance:68nH; DC Current Rating:500mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.18ohm; Q Factor:60 ;RoHS Compliant: Yes

POWER LINE CHOKE 10MH 1.1A +50% -30%; Inductance:10mH; Rated Current:1.1A; Product Range:B82731M Series; Case Dimensions:21mm x 15mm x 20.5mm; Core Material:Ferrite; DC Current Max:1.1A; DC Current Rating:1.1A; No. of Pins:4Pins

NTC THERMISTOR 16R DISC 16MM; Product Range:B57238S0 Series; Disc Size:16mm; Zero Power Resistance at 25°C:16ohm; Approvals:CQC IEC UL VDE; Maximum Energy Rating at 25°C:-; Maximum Steady State Current at 25°C:-; SVHC:No SVHC (12-Jan-2017)

NTC THERMISTOR; Product Range:B57238S0 Series; Disc Size:16mm; Zero Power Resistance at 25 C:2.5ohm; Approvals:UL; Maximum Energy Rating at 25 C:-; Maximum Steady State Current at 25 C:8.4A; Beta Value (K):2800K; No. of Pins:2 ;RoHS Compliant: Yes
