Aluminum electrolytic Capacitors -Single-ended Capacitors

Ferrites and Accessories Double-aperture Cores

TRANSFORMER COIL FORMER E25/13 10PIN; For Use With:E 25/13/7 Type B66317 Series Ferrite Cores; Product Range:B66208 Series; SVHC:No SVHC (20-Jun-2016); MSL:MSL 1 - Unlimited ;RoHS Compliant: Yes

Ferrites and Accessories E 42/21/15 Core

INDUCTOR AXIAL 8UH 1.5A; Product Range:EPCOS - B82132 Series VHF Chokes; Inductance:8µH; Inductance Tolerance:± 20%; DC Resistance Max:0.16ohm; DC Current Rating:1.5A; Self Resonant Frequency Min:90MHz; Case Dimensions:5.5mm x ;RoHS Compliant: Yes

INDUCTOR 2220A 15UH 1.26A 10%; Product Range:-; Inductance:15µH; DC Current Rating:1.26A; High Frequency Inductor Case:2220 [5650 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.19ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:16MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:2220 [5650 Metric]

INDUCTOR 2220A 22UH 1.04A 10%; Product Range:B82442T Series; Inductance:22µH; DC Current Rating:1.04A; High Frequency Inductor Case:2220 [5650 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.238ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:13MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:2220 [5650 Metric]

INDUCTOR 2220A 330UH 0.28A 10%; Product Range:-; Inductance:330µH; DC Current Rating:280mA; High Frequency Inductor Case:-; Inductor Construction:Wirewound; DC Resistance Max:3.29ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:3.4MHz; Packaging:Cut Tape; SVHC:No SVHC (15-Jun-2015); Inductor Case Style:2220 [5650 Metric]

Inductors Transponder Coils Size 11.4 u3.5 u2.4 (mm)

INDUCTOR 33UH 1.8A 10% FULL REEL; Product Range:-; Inductance:33µH; RMS Current (Irms):1.8A; Saturation Current (Isat):2.2A; Inductor Construction:Unshielded; DC Resistance Max:0.1ohm; Power Inductor Case:10.4mm x 10.4mm x 4.8mm; Inductance Tolerance:± 10%; Packaging:Tape & Reel; SVHC:No SVHC (15-Jun-2015); Core Material:Ferrite; DC Current Rating:1.8A; Inductor Case Style:SMD; Reel Quantity:750

B722 Series 175 Vrms 225 VDC Radial Lead SIOV Metal Oxide Varistor

CAP FILM PP 3UF 1.1KV RAD; Capacitance:3µF; Voltage Rating V DC:1.1kV; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32774 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:27.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Voltage Rating:1.1kV

CAP FILM PP 330NF 330VAC RAD; Capacitance:0.33µF; Suppression Class:X1; Voltage Rating X:330V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:B32913 Series; dv/dt Rating:200V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitor Application:Safety / Suppression; External Depth:8.5mm; External Length / Height:16.5mm; External Width:26.5mm; Height:16.5mm; Lead Diameter:0.8mm; Lead Spacing:22.5mm; Voltage Rating VAC:330V

FERRITE CORE RM N87; Core Type:RM; Core Size:RM12; Core Material Grade:N87; For Use With:-; Effective Magnetic Path Length:57mm; Ae Effective Cross Section Area:146mm²; Inductance Factor Al:160nH; Product Range:B65815 Series; SVHC:No SVHC (15-Jun-2015); Accessory Type:Ferrite Core; Material Grade:N87

FERRITE CORE RM N87; Core Type:RM; Core Size:RM12; Core Material Grade:N87; For Use With:-; Effective Magnetic Path Length:57mm; Ae Effective Cross Section Area:146mm²; Inductance Factor Al:250nH; Product Range:B65815 Series; SVHC:No SVHC (15-Jun-2015); Accessory Type:Ferrite Core; Material Grade:N87

FERRITE CORE RM N87; Core Type:RM; Core Size:RM14; Core Material Grade:N87; For Use With:-; Effective Magnetic Path Length:70mm; Ae Effective Cross Section Area:200mm²; Inductance Factor Al:160nH; Product Range:B65887 Series; SVHC:No SVHC (15-Jun-2015); Accessory Type:Ferrite Core; Material Grade:N87

CAP FILM PP 6.8UF 305VAC RAD; Capacitance:6.8µF; Suppression Class:X2; Voltage Rating X:305V; Voltage Rating Y:-; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 20%; Product Range:-; dv/dt Rating:80V/µs; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Operating Temperature Min:-; Operating Temperature Max:110°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitor Application:Safety / Suppression; External Depth:18mm; External Length / Height:32.5mm; External Width:42mm; Height:32.5mm; Lead Diameter:1mm; Lead Spacing:37.5mm; Voltage Rating VAC:305V

CAP FILM PP 20UF 800V RAD; Capacitance:20µF; Voltage Rating V DC:800V; Capacitor Dielectric Type:PP (Polypropylene); Capacitance Tolerance:± 10%; Product Range:B32776 Series; Capacitor Case Style:-; Capacitor Terminals:Radial Leaded; Lead Spacing:37.5mm; Operating Temperature Min:-40°C; Operating Temperature Max:105°C; Packaging:Each; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); Capacitance Tolerance ±:± 10%; Capacitor Mounting:Through Hole; ESR:0.0065ohm; External Depth:28mm; External Length / Height:37mm; External Width:42mm; Height:37mm; Lead Diameter:1mm; No. of Pins:2Pins; Operating Temperature Range:-40°C to +105°C; Voltage Rating:800V

CAP ALU ELEC 68000UF 16V SNAP IN; Capacitance:68000µF; Voltage Rating:16V; Product Range:B41231 Series; Lifetime @ Temperature:2000 hours @ 85°C; Capacitance Tolerance:± 20%; Capacitor Terminals:Quick Connect Snap-In; Diameter:35mm; Lead Spacing:10mm; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Height:50mm; ESR:-; Automotive Qualification Standard:-; SVHC:No SVHC (15-Jun-2015); AC Ripple Current @ 120Hz:8.53A; Capacitance Tolerance ±:± 20%; No. of Pins:2Pins; Operating Temperature Range:-40°C to +85°C; Ripple Current Temperature:85°C

Electrolytic Capacitor Snap-in B41231 Series 6800 F 20% 63 V 30 mm ;RoHS Compliant: Yes
