Electric Vehicle (EV) Charger

Renesas Electronics Corporation

Published Date:

Description

Fueling with electricity offers some advantages that are not available in conventional internal combustion engine vehicles. Because electric motors react quickly, EVs are very responsive and have very good torque. EVs are often more digitally-connected than conventional vehicles, with many EV charging stations providing the option to control charging from a smartphone app. This design approach utilizes an active PFC and asymmetrical full-bridge ZVS converter, along with an RL78/G14 MCU for EV charger applications.

System Benefits:

  • Highly integrated MCU
  • The ISL6731B provides adaptive control that enables extremely low THD and high PF without DSP
  • The RL78/G14 MCU allows users to implement working logic, protections, and features for the driver
  • Battery health implementation features
