MCU 16-Bit RL78/G13 RL78 CISC 32KB Flash 3.3V/5V 48-Pin LFQFP Tray

MCU 16-Bit RL78/G1x RL78 CISC 512KB Flash 1.8V/2.5V/3.3V/5V 80-Pin LFQFP Tray

MCU 16-Bit RL78/G12 RL78 CISC 4KB Flash 3.3V/5V 24-Pin HWQFN EP Tray

MCU 16-Bit RL78/G14 RL78 CISC 16KB Flash 3.3V/5V 32-Pin HWQFN EP Tray

MCU 16-Bit RL78/G14 RL78 CISC 32KB Flash 3.3V/5V 32-Pin LQFP Tray

MCU 16-Bit RL78/G1x RL78 CISC 192KB Flash 1.8V/2.5V/3.3V/5V 40-Pin HWQFN Tray

MCU 16-Bit RL78/G14 RL78 CISC 128KB Flash 3.3V/5V 48-Pin LFQFP Tray

MCU 16-Bit RL78/G14 RL78 CISC 256KB Flash 3.3V/5V 48-Pin HWQFN EP Tray

MCU 16-Bit RL78/G14 RL78 CISC 128KB Flash 1.8V/2.5V/3.3V/5V 64-Pin WFLGA Tray Low Power, High Function, General Purpose Microcontrollers for Motor Control, Industrial and Metering Applications RL78/G14 microcontrollers balance the industry's lowest level of consumption current (CPU: 66 μA/MHz, standby (STOP): 240 nA) and a high calculation performance of51.2 DMIPS (32 MHz). The built-in high-function timer supports three-phase motor control using three-phase complementary PWM output. They have an on-chip oscillator, data flash, A/D and D/A converters, comparator, and more. Built-in safety features (function that detects illegal operation of hardware) enable support for the household appliance safety standard (IEC/UL 60730). With a broad 30 to 100-pin lineup and up to 512 KB on-chip flash memory, these microcontrollers can be used in a wide variety of applications such as motor control and consumer and industrial equipment. Features: CPU: RL78 core, Max. 32MHz Voltage: 1.6V to 5.5V Package: 32 to 48-pin HWQFN, 48 to 100-pin LFQFP, 32 to 100-pin LQFP, 30-pin LSSOP, 36 to 64-pin WFLGA Memory: SRAM Max. 48KB, Program Flash Max. 512KB Timer: 16-bit Timer (ch) x 8, 8-bit Timer (ch) x 8, Watchdog Timer (ch) x 1, 12-bit Interval Timer x 1 ch PWM: PWM Output x 13, 3-phase PWM Output Function Analog function: 10-bit A/D Converter (ch) x 9, 8-bit D/A Converter (ch) x 2 On-chip Oscillator Freq. (MHz): High-Speed: 64, 48, 32, 24, 16, 12, 8, 6, 4, 3, 2, 1MHzLow-speed: 15kHz Others: RTC, Power-On Reset, Low Voltage Detection Applications: Industrial Sensing with IO-Link Interface HVAC Humidity Sensor HVAC Air Quality Sensor Air Quality Control for IoT Building Automation Refrigerator Compressor Digital Inverter Electric Vehicle (EV) Charger Biosensing with Wireless Charging and Bluetooth Refrigerator Odor Detector High-End Electric Fan with BLDC Control Battery Management System In-Home Air Quality Monitor System Modbus ASCII/RTU Slave Board USB-PD with Turbo Boost LoRaWAN-Based Gas Meter Sensor Signal Conditioner to Linearize Results Cordless Single-Phase BLDC Hand Blender Pure Sine Wave Home Inverter LoRa-based Solutions for RL78 Family

MCU 16-bit RL78/G14 RL78 CISC 192KB Flash 3/5V 64-Pin LQFP Tray

MCU 16-Bit RL78/I1A RL78 CISC 32KB Flash 3.3V/5V 20-Pin LSSOP Tray

MCU 16-Bit RL78/I1A RL78 CISC 32KB Flash 3.3V/5V 20-Pin LSSOP T/R

Microcontroller, 16-Bit, FLASH, RL78 CPU

MCU 16-Bit RL78/G1A RL78 CISC 64KB Flash 3.3V 25-Pin WFLGA Tray

MCU 32-Bit RX111 RX CISC 128KB Flash 3.3V 64-Pin LQFP Tray

MCU 32-Bit RX100 RX CISC 384KB Flash 3.3V 100-Pin LFQFP Tray

MCU 32-Bit RX210 RX RISC 256KB Flash 3.3V/5V 100-Pin LFQFP Tray

Microcontroller, 32-Bit, FLASH, RX CPU

MCU 32-Bit RX231 RXv2 CISC 512KB Flash 3.3V/5V 100-Pin LFQFP Tray

MCU 32-Bit RX231 RXv2 CISC 512KB Flash 3.3V/5V 48-Pin HWQFN EP Tray
