TIDA-00206 Reference Design

Texas Instruments

LED Display Driver with Serial Interface Reference Design

Description

This reference design drives 8 seven-segment digits with brightness control using a low-cost MSP430 and two DRV8860 octal low-side drivers. The display module gains benefits from DRV8860 on wide-supply range: high-current capability: PWM brightness control: serial daisy-chain connection and expandable outputs for hundreds of LEDs. AThis reference design and six demo display patterns are provided with the on-board MCU program along with the integrated protection from short-circuit: under voltage: and over-temperature.

Features
  • Serial interface minimizes the number of signalsDrives eight characters with only two DRV8860 devicesSmall PCB footprintExtendable output current capability for super bright LEDsInternal eight-level PWM duty for brightness control via serial interfaceSix demo display patterns provided with the on-board MCU
