System on Module for PRIME Power Line Communication (CENELEC Frequency Band)
Description
This reference design has been replaced by the newer version TIDM-SOMPLC-F28PLC84.The SOMPLC-F28PLC83 is a single-board System on Module(SOM) for PLC in the CENELEC frequency band. This single hardware design supports Prime PLC industry standards. TI's certified PLC software is available along with the SOMPLC-F28PLC83. Engineers can take the SOM design and integrate it into their overall system board or keep the design as an add-on board to their application. The only additional hardware required is the AC mains line coupling circuitry. The included hardware schematics and Gerber files simplify the task for engineers to add PLC to their end system. OEMs will benefit from having the ability to rapidly evaluate and prototype Power Line Communications technology in their application.
Features
- Supports CENELEC A frequency band PRIME Compatible Comprehensive 2 chip solution includes TMS320F28PLC83 MCU and AFE031 integrated analog front end 34pin mini header provides flexibility for interfacing to custom board and other TI Designs like the PLC Data Concentrator and TMDSPLCKIT-V4. Small form factor: 1.5” X 1.9
Applications
- Power Line Communications
Product Categories
- C2000 Real-Time Control MCUs
| Download |
|---|
| Download the bill of materials for TIDM-SOMPLC-F28PLC83 | Download |
Schematic
Quickly understand overall system functionality.
Download the schematic for TIDM-SOMPLC-F28PLC83Design File
Download ready-to-use system files to speed your design process. Get Viewer.
Download the design file for TIDM-SOMPLC-F28PLC83| Title | Updated | Type | Size (KB) | |
|---|---|---|---|---|
| System on Module for Prime Power Line Communication Schematic (Rev. A) | 11 Sep 2015 | 49 | ||
| System on Module for Prime Power Line Communication Bill of Materials (BOM) | 23 Jan 2014 | ZIP | 23 |
