INDUCTOR 0805 680NH 190MA; Product Range:WE-KI Series; Inductance:680nH; DC Current Rating:190mA; High Frequency Inductor Case:0805 [2012 Metric]; Inductor Construction:Wirewound; DC Resistance Max:2.8ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:188MHz; Packaging:Cut Tape; Inductor Case Style:0805 [2012 Metric]

VARISTOR SMD HIGHSURGE 1812 30V; Voltage Rating VAC:30V; Voltage Rating V DC:38V; Product Range:-; Clamping Voltage Vc Max:85V; Varistor Case Style:1812 [4532 Metric]; Varistor Type:High Surge Current; Peak Surge Current @ 8/20µs:800A; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):4.2J; Automotive Qualification Standard:-; Breakdown Voltage Vbr:47V; Capacitance:2550pF; Clamping Voltage:85V; External Depth:3.2mm; External Length / Height:2mm; External Width:4.5mm; Operating Temperature Range:-40°C to +85°C; Packaging:Cut Tape; Suppressor Type:Varistor; Surge Current:800A

VARISTOR SMD HIGHSURGE 2220 30V; Voltage Rating VAC:30V; Voltage Rating V DC:38V; Product Range:-; Clamping Voltage Vc Max:85V; Varistor Case Style:2220 [5650 Metric]; Varistor Type:High Surge Current; Peak Surge Current @ 8/20µs:1.2kA; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Peak Energy (10/1000uS):12J; Automotive Qualification Standard:-; Breakdown Voltage Vbr:47V; Capacitance:5700pF; Clamping Voltage:85V; External Depth:5mm; External Length / Height:2.5mm; External Width:5.7mm; Operating Temperature Range:-40°C to +85°C; Packaging:Cut Tape; Suppressor Type:Varistor; Surge Current:1200A

INDUCTOR 1008 CASE 20% 2.2UH; Product Range:-; Inductance:2.2µH; DC Current Rating:850mA; High Frequency Inductor Case:1008 [2520 Metric]; Inductor Construction:Multilayer; DC Resistance Max:0.4ohm; Inductance Tolerance:± 20%; Self Resonant Frequency Min:70MHz; Packaging:Cut Tape; External Depth:2mm; External Length / Height:1mm; External Width:2.5mm; Inductor Case Style:1008 [2520 Metric]; Operating Temperature Max:125°C; Operating Temperature Min:-40°C

SWITCH DIP 2 WAY PIANO R/ANGLE; No. of Circuits:2Circuits; Contact Configuration:SPST; Switch Mounting:Through Hole; Product Range:-; Switch Type:DIP Unsealed; Contact Voltage DC Max:24VDC; Contact Current DC Max:25mA; Switch Actuator Style:Slide; Actuation Type:Flat; Colour:Red; Contact Plating:Gold Plated Contacts; Contact Resistance:50mohm; External Depth:7.99mm; External Length / Height:9.6mm; External Width:6.08mm; Insulation Resistance:100Mohm; Material:PPS / HTN / PA46; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Pitch Spacing:2.54mm; Terminal Plating:Tin

INDUCTOR DD 7332 3.3UH 20% 3.3A; Product Range:WE-DD Series; Inductance Parallel:3.3µH; RMS Current - Parallel:3.3A; Saturation Current - Parallel:4A; Coupled Inductor Case:7.3mm x 7.3mm x 4mm; DC Resistance Max - Parallel:0.064ohm; Packaging:Cut Tape

INDUCTOR DD 7345 2.4UH 20% 4.2A; Product Range:WE-DD Series; Inductance Parallel:2.4µH; RMS Current - Parallel:4.2A; Saturation Current - Parallel:5.6A; Coupled Inductor Case:7.3mm x 7.3mm x 4.8mm; DC Resistance Max - Parallel:0.042ohm; Packaging:Cut Tape

INDUCTOR DD 1280 220UH 20% 0.9A; Product Range:WE-DD Series; Inductance Parallel:220µH; RMS Current - Parallel:900mA; Saturation Current - Parallel:1.4A; Coupled Inductor Case:12.5mm x 12.5mm x 8.5mm; DC Resistance Max - Parallel:0.65ohm; Packaging:Cut Tape

INDUCTOR DD 1280 47UH 20% 2.02A; Product Range:WE-DD Series; Inductance Parallel:47µH; RMS Current - Parallel:2.02A; Saturation Current - Parallel:3.1A; Coupled Inductor Case:12.5mm x 12.5mm x 8.5mm; DC Resistance Max - Parallel:0.125ohm; Packaging:Cut Tape

INDUCTOR TDC8018 10UH 20% 1A; Product Range:WE-TDC Series; Inductance Parallel:10µH; RMS Current - Parallel:1A; Saturation Current - Parallel:1.65A; Coupled Inductor Case:8mm x 8mm x 1.8mm; DC Resistance Max - Parallel:0.215ohm; Packaging:Cut Tape

INDUCTOR TDC8038 10UH 20% 1.35A; Product Range:WE-TDC Series; Inductance Parallel:10µH; RMS Current - Parallel:1.35A; Saturation Current - Parallel:2.6A; Coupled Inductor Case:8mm x 8mm x 3.8mm; DC Resistance Max - Parallel:0.128ohm; Packaging:Cut Tape

INDUCTOR TDC8038 12UH 20% 1.3A; Product Range:-; Inductance Parallel:12µH; RMS Current - Parallel:1.3A; Saturation Current - Parallel:2.3A; Coupled Inductor Case:8mm x 8mm x 3.8mm; DC Resistance Max - Parallel:0.132ohm; Packaging:Cut Tape

INDUCTOR TDC8038 18UH 20% 1.05A; Product Range:-; Inductance Parallel:18µH; RMS Current - Parallel:1.05A; Saturation Current - Parallel:1.9A; Coupled Inductor Case:8mm x 8mm x 3.8mm; DC Resistance Max - Parallel:0.201ohm; Packaging:Cut Tape

INDUCTOR TDC8038 22UH 20% 1A; Product Range:WE-TDC Series; Inductance Parallel:22µH; RMS Current - Parallel:1A; Saturation Current - Parallel:1.8A; Coupled Inductor Case:8mm x 8mm x 3.8mm; DC Resistance Max - Parallel:0.228ohm; Packaging:Cut Tape

INDUCTOR PMI 0806 4.7UH 1A 20%; Product Range:WE-PMI Series; Inductance:4.7µH; DC Current Rating:1A; High Frequency Inductor Case:0806 [2016 Metric]; Inductor Construction:Multilayer; DC Resistance Max:0.16ohm; Inductance Tolerance:± 20%; Self Resonant Frequency Min:45MHz; Packaging:Cut Tape; Inductor Case Style:0806 [2016 Metric]

INDUCTOR HCF 2013 3.1UH 15% 26A; Product Range:WE-HCF Series; Inductance:3.1µH; RMS Current (Irms):26A; Saturation Current (Isat):45A; Inductor Construction:Shielded; DC Resistance Max:2090µohm; Power Inductor Case:21.8mm x 21.5mm x 14.5mm; Inductance Tolerance:± 15%; Packaging:Cut Tape; No. of Pins:3Pins; Resonant Frequency:29MHz; Self Resonant Frequency Min:29MHz

INDUCTOR HCF 2013 7UH 15% 21A; Product Range:WE-HCF Series; Inductance:7µH; RMS Current (Irms):21A; Saturation Current (Isat):30A; Inductor Construction:Shielded; DC Resistance Max:5610µohm; Power Inductor Case:21.8mm x 21.5mm x 14.5mm; Inductance Tolerance:± 15%; Packaging:Cut Tape; No. of Pins:3Pins; Resonant Frequency:18MHz; Self Resonant Frequency Min:18MHz

INDUCTOR WE-TI HV 1MH 10% 0.5A; Product Range:WE-TI Series; Inductance:1mH; RMS Current (Irms):500mA; Saturation Current (Isat):550mA; DC Resistance Max:2.08ohm; Inductance Tolerance:± 10%; Packaging:Each; Core Material:Ferrite; DC Current Rating:500mA; No. of Pins:2Pins

INDUCTOR WE-TI HV 1.8MH 10% 0.35A; Product Range:WE-TI Series; Inductance:1.8mH; RMS Current (Irms):350mA; Saturation Current (Isat):380mA; DC Resistance Max:3.3ohm; Inductance Tolerance:± 10%; Packaging:Each; Core Material:Ferrite; DC Current Rating:350mA; No. of Pins:2Pins

DESIGN KIT FOR WE-HCC 8090 1090 1210; Kit Contents:139 Components of the SMD High Current Cube Inductor; Product Range:-
