INDUCTOR 2.2UH 10% 1.45A 79MHZ 1812; Product Range:WE-GFH Series; Inductance:2.2µH; DC Current Rating:1.45A; High Frequency Inductor Case:1812 [4532 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.16ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:79MHz; Packaging:Each

INDUCTOR 3.3UH 20% 1.05A 79MHZ 1210; Product Range:WE-GFH Series; Inductance:3.3µH; DC Current Rating:1.05A; High Frequency Inductor Case:1210 [3225 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.325ohm; Inductance Tolerance:± 20%; Self Resonant Frequency Min:79MHz; Packaging:Each

INDUCTOR 12UH 10% 0.81A 31MHZ 1812; Product Range:WE-GFH Series; Inductance:12µH; DC Current Rating:810mA; High Frequency Inductor Case:1812 [4532 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.465ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:31MHz; Packaging:Each

INDUCTOR 27UH 10% 0.575A 20MHZ 1812; Product Range:WE-GFH Series; Inductance:27µH; DC Current Rating:575mA; High Frequency Inductor Case:1812 [4532 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.89ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:20MHz; Packaging:Each

INDUCTOR 100UH 10% 0.275A 10MHZ; Product Range:WE-GFH Series; Inductance:100µH; DC Current Rating:275mA; High Frequency Inductor Case:1812 [4532 Metric]; Inductor Construction:Wirewound; DC Resistance Max:3.72ohm; Inductance Tolerance:± 10%; Self Resonant Frequency Min:10MHz; Packaging:Each

POWER INDUCTOR PD 1280; Product Range:-; Inductance:3.5µH; RMS Current (Irms):8.9A; Saturation Current (Isat):9.6A; Inductor Construction:Shielded; DC Resistance Max:0.014ohm; Power Inductor Case:12mm x 12mm x 8mm; Inductance Tolerance:-20% to +40%; Packaging:Cut Tape; Resonant Frequency:37.5MHz

TPC INDUCTOR 4818 33UH SAT 0.5A; Product Range:WE-TPC Series; Inductance:33µH; RMS Current (Irms):730mA; Saturation Current (Isat):500mA; Inductor Construction:Shielded; DC Resistance Max:0.42ohm; Power Inductor Case:4.8mm x 4.8mm x 1.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:21MHz; Self Resonant Frequency Min:21MHz

LQ INDUCTOR 1210 2.2UH IN 0.79A; Product Range:WE-LQ Series; Inductance:2.2µH; RMS Current (Irms):790mA; Saturation Current (Isat):1.2A; Inductor Construction:Unshielded; DC Resistance Max:0.126ohm; Power Inductor Case:3.2mm x 2.5mm x 1.55mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Self Resonant Frequency Min:63MHz

TPC INDUCTOR 2811 0.056UH SAT=6A; Product Range:-; Inductance:56nH; RMS Current (Irms):4.5A; Saturation Current (Isat):6A; Inductor Construction:Shielded; DC Resistance Max:0.015ohm; Power Inductor Case:2.8mm x 2.8mm x 1.1mm; Inductance Tolerance:± 35%; Packaging:Cut Tape; Resonant Frequency:2GHz; Self Resonant Frequency Min:2GHz

TPC INDUCTOR 2811 15UH SAT=0.35A; Product Range:-; Inductance:15µH; RMS Current (Irms):450mA; Saturation Current (Isat):350mA; Inductor Construction:Shielded; DC Resistance Max:0.83ohm; Power Inductor Case:2.8mm x 2.8mm x 1.1mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:37MHz; Self Resonant Frequency Min:37MHz

TPC INDUCTOR 3816. 6.8UH SAT=0.75A; Product Range:WE-TPC Series; Inductance:6.8µH; RMS Current (Irms):850mA; Saturation Current (Isat):750mA; Inductor Construction:Shielded; DC Resistance Max:0.156ohm; Power Inductor Case:3.8mm x 3.8mm x 1.65mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:45MHz; Self Resonant Frequency Min:45MHz

TPC INDUCTOR 4818 8.2UH SAT=1.1A; Product Range:WE-TPC Series; Inductance:8.2µH; RMS Current (Irms):1.4A; Saturation Current (Isat):1.1A; Inductor Construction:Shielded; DC Resistance Max:0.135ohm; Power Inductor Case:4.8mm x 4.8mm x 1.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:40MHz; Self Resonant Frequency Min:40MHz

TPC INDUCTOR 4828 12UH SAT=0.95A; Product Range:WE-TPC Series; Inductance:12µH; RMS Current (Irms):1.12A; Saturation Current (Isat):950mA; Inductor Construction:Shielded; DC Resistance Max:0.125ohm; Power Inductor Case:4.8mm x 4.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:30MHz; Self Resonant Frequency Min:30MHz

TPC INDUCTOR 4828 33UH SAT=0.55A; Product Range:WE-TPC Series; Inductance:33µH; RMS Current (Irms):820mA; Saturation Current (Isat):550mA; Inductor Construction:Shielded; DC Resistance Max:0.23ohm; Power Inductor Case:4.8mm x 4.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:16MHz; Self Resonant Frequency Min:16MHz

TPC INDUCTOR 5828 5.3UH SAT=1.9A; Product Range:WE-TPC Series; Inductance:5.3µH; RMS Current (Irms):2.3A; Saturation Current (Isat):1.9A; Inductor Construction:Shielded; DC Resistance Max:0.04ohm; Power Inductor Case:5.8mm x 5.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:45MHz; Self Resonant Frequency Min:45MHz

TPC INDUCTOR 5828 15UH SAT=1.15A; Product Range:WE-TPC Series; Inductance:15µH; RMS Current (Irms):1.38A; Saturation Current (Isat):1.15A; Inductor Construction:Shielded; DC Resistance Max:0.1ohm; Power Inductor Case:5.8mm x 5.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:20MHz; Self Resonant Frequency Min:20MHz

TPC INDUCTOR 5828 33UH SAT=0.75A; Product Range:WE-TPC Series; Inductance:33µH; RMS Current (Irms):900mA; Saturation Current (Isat):750mA; Inductor Construction:Shielded; DC Resistance Max:0.19ohm; Power Inductor Case:5.8mm x 5.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:15MHz; Self Resonant Frequency Min:15MHz

TPC INDUCTOR 5828 68UH SAT=0.56A; Product Range:WE-TPC Series; Inductance:68µH; RMS Current (Irms):750mA; Saturation Current (Isat):560mA; Inductor Construction:Shielded; DC Resistance Max:0.35ohm; Power Inductor Case:5.8mm x 5.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:10MHz; Self Resonant Frequency Min:10MHz

TPC INDUCTOR 1028 15UH SAT=2.25A; Product Range:WE-TPC Series; Inductance:15µH; RMS Current (Irms):2.2A; Saturation Current (Isat):2.25A; Inductor Construction:Shielded; DC Resistance Max:0.09ohm; Power Inductor Case:10mm x 10mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:22MHz; Self Resonant Frequency Min:22MHz

TPC INDUCTOR 1038 330UH SAT=0.7A; Product Range:WE-TPC Series; Inductance:330µH; RMS Current (Irms):600mA; Saturation Current (Isat):700mA; Inductor Construction:Shielded; DC Resistance Max:1ohm; Power Inductor Case:10mm x 10mm x 3.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:6MHz; Self Resonant Frequency Min:6MHz
