Pluggable Terminal Blocks WR-TBL Mod3631 3.5mm 6Pin Hztl Hook Wr Sd

POWER CHOKE 10UH 3.4A 24MHZ; Product Range:WE-TPC Series; Inductance:10µH; RMS Current (Irms):3.4A; Saturation Current (Isat):2.8A; Inductor Construction:Shielded; DC Resistance Max:0.035ohm; Power Inductor Case:8mm x 8mm x 4.3mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:24MHz; Self Resonant Frequency Min:24MHz

POWER CHOKE 33UH 1.9A 12MHZ; Product Range:WE-TPC Series; Inductance:33µH; RMS Current (Irms):1.9A; Saturation Current (Isat):1.5A; Inductor Construction:Shielded; DC Resistance Max:0.12ohm; Power Inductor Case:8mm x 8mm x 4.3mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:12MHz; Self Resonant Frequency Min:12MHz

POWER CHOKE 68UH 1.3A 8MHZ; Product Range:WE-TPC Series; Inductance:68µH; RMS Current (Irms):1.3A; Saturation Current (Isat):1.1A; Inductor Construction:Shielded; DC Resistance Max:0.23ohm; Power Inductor Case:8mm x 8mm x 4.3mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Resonant Frequency:8MHz; Self Resonant Frequency Min:8MHz

POWER INDUCTOR 0.68UH 3.4A 120MHZ; Product Range:-; Inductance:680nH; RMS Current (Irms):3.4A; Saturation Current (Isat):6.5A; Inductor Construction:Shielded; DC Resistance Max:0.0221ohm; Power Inductor Case:4.8mm x 4.8mm x 1.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Self Resonant Frequency Min:120MHz

POWER INDUCTOR 8.2UH 1.4A 26MHZ; Product Range:WE-SPC Series; Inductance:8.2µH; RMS Current (Irms):1.4A; Saturation Current (Isat):2.2A; Inductor Construction:Shielded; DC Resistance Max:0.134ohm; Power Inductor Case:4.8mm x 4.8mm x 2.8mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Self Resonant Frequency Min:26MHz

POWER INDUCTOR 47UH 0.66A 10MHZ; Product Range:WE-SPC Series; Inductance:47µH; RMS Current (Irms):660mA; Saturation Current (Isat):1A; Inductor Construction:Shielded; DC Resistance Max:0.608ohm; Power Inductor Case:4.8mm x 4.8mm x 2.8mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Self Resonant Frequency Min:10MHz

INDUCTOR 8.2NH 1A 5.5GHZ; Product Range:WE-KI Series; Inductance:8.2nH; DC Current Rating:1A; High Frequency Inductor Case:1008 [2520 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.06ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:5.5GHz; Packaging:Cut Tape; Inductor Case Style:1008 [2520 Metric]

INDUCTOR 12NH 1A 3.6GHZ; Product Range:WE-KI Series; Inductance:12nH; DC Current Rating:1A; High Frequency Inductor Case:1008 [2520 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.08ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:3.6GHz; Packaging:Cut Tape; Inductor Case Style:1008 [2520 Metric]

INDUCTOR 15NH 1A 2.7GHZ; Product Range:WE-KI Series; Inductance:15nH; DC Current Rating:1A; High Frequency Inductor Case:1008 [2520 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.08ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:2.7GHz; Packaging:Cut Tape; Inductor Case Style:1008 [2520 Metric]

INDUCTOR 18NH 1A 2.7GHZ; Product Range:WE-KI Series; Inductance:18nH; DC Current Rating:1A; High Frequency Inductor Case:1008 [2520 Metric]; Inductor Construction:Wirewound; DC Resistance Max:0.1ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:2.7GHz; Packaging:Cut Tape; Inductor Case Style:1008 [2520 Metric]

INDUCTOR 470NH 0.42A 0.48GHZ; Product Range:WE-KI Series; Inductance:470nH; DC Current Rating:420mA; High Frequency Inductor Case:1008 [2520 Metric]; Inductor Construction:Wirewound; DC Resistance Max:1.17ohm; Inductance Tolerance:± 5%; Self Resonant Frequency Min:480MHz; Packaging:Cut Tape; Inductor Case Style:1008 [2520 Metric]

GATE DRIVE TRANSFORMER 350UH 1500V ; Turns Ratio:2.5:1:1; Isolation Voltage:1.5kV; Product Range:-; Inductance:350µH; DC Resistance:0.7ohm; ET Constant:-

GATE DRIVE TRANSFORMER 260UH 1500V ; Turns Ratio:1:1:1; Isolation Voltage:1.5kV; Product Range:-; Inductance:260µH; DC Resistance:0.6ohm; ET Constant:-

GATE DRIVE TRANSFORMER 650UH 1500V ; Turns Ratio:1.5:1; Isolation Voltage:1.5kV; Product Range:-; Inductance:650µH; DC Resistance:1.2ohm; ET Constant:-

CHOKE 650UH 1.02 OHM 0.4A 75W; Power Rating:75W; Product Range:WE-PFC Series; DC Current Rating:400mA; Primary Inductance:650µH; DC Resistance 1 Max:1.02ohm; Turns Ratio:90:8; Packaging:Each

CHOKE 750UH 0.95 OHM 0.9A 75W; Power Rating:75W; Product Range:WE-PFC Series; DC Current Rating:900mA; Primary Inductance:750µH; DC Resistance 1 Max:0.95ohm; Turns Ratio:34:3; Packaging:Each

CHOKE 300UH 0.1973 OHM 3A 250W; Power Rating:250W; Product Range:WE-PFC Series; DC Current Rating:3A; Primary Inductance:300µH; DC Resistance 1 Max:0.1973ohm; Turns Ratio:8.75:1; Packaging:Each

CHOKE 200UH 0.3 OHM 1.4A 250W; Power Rating:250W; Product Range:WE-PFC Series; DC Current Rating:1.4A; Primary Inductance:200µH; DC Resistance 1 Max:0.3ohm; Turns Ratio:50:5; Packaging:Each

CHOKE 180UH 0.078 OHM 3A 250W; Power Rating:250W; Product Range:WE-PFC Series; DC Current Rating:3A; Primary Inductance:180µH; DC Resistance 1 Max:0.078ohm; Turns Ratio:9:1; Packaging:Each
