Wire-To-Board Connector Short Lever WR-BHD Series Through Hole Header 10 2.54 mm ;RoHS Compliant: Yes

FFC CABLE 26POS 152MM 60V WHITE; Connector Type A:-; Connector Type B:-; Cable Length - Imperial:6"; Cable Length - Metric:152mm; Contact Orientation:Opposite Sided Contacts; Jacket Colour:White; No. of Cores:26Core; Pitch ;RoHS Compliant: Yes

FFC CABLE 18POS 152MM 60V WHITE; Connector Type A:-; Connector Type B:-; Cable Length - Imperial:6"; Cable Length - Metric:152mm; Contact Orientation:Opposite Sided Contacts; Jacket Colour:White; No. of Cores:18Core; Pitch Spacing:0.5mm; Product Range:-

CABLE FFC REV 1MM 200MM 18WAY; Connector Type A:-; Connector Type B:-; Cable Length - Imperial:7.87"; Cable Length - Metric:200mm; Contact Orientation:Opposite Sided Contacts; Jacket Colour:White; No. of Cores:18Core; Pitch Spacing:1mm; Product Range:-; Cable Assembly Type:FFC FPC

CHOKE SMD 47UH 0.77A; Product Range:WE-TPC Series; Inductance:47µH; RMS Current (Irms):770mA; Saturation Current (Isat):700mA; Inductor Construction:Shielded; DC Resistance Max:0.55ohm; Power Inductor Case:5.8mm x 5.8mm x 1.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:18MHz; Self Resonant Frequency Min:18MHz

CHOKE SMD 470UH 0.14A; Product Range:WE-TPC Series; Inductance:470µH; RMS Current (Irms):140mA; Saturation Current (Isat):180mA; Inductor Construction:Shielded; DC Resistance Max:5.5ohm; Power Inductor Case:5.8mm x 5.8mm x 1.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:4MHz; Self Resonant Frequency Min:4MHz

CHOKE SMD 68UH 0.4A; Product Range:WE-TPC Series; Inductance:68µH; RMS Current (Irms):640mA; Saturation Current (Isat):500mA; Inductor Construction:Shielded; DC Resistance Max:0.85ohm; Power Inductor Case:5.8mm x 5.8mm x 1.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:14MHz; Self Resonant Frequency Min:14MHz

CHOKE SMD 4.7UH 2.4A; Product Range:WE-TPC Series; Inductance:4.7µH; RMS Current (Irms):2.4A; Saturation Current (Isat):1.95A; Inductor Construction:Shielded; DC Resistance Max:0.038ohm; Power Inductor Case:5.8mm x 5.8mm x 2.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:40MHz; Self Resonant Frequency Min:40MHz

CHOKE SMD 10UH 1.6A; Product Range:WE-TPC Series; Inductance:10µH; RMS Current (Irms):1.6A; Saturation Current (Isat):1.4A; Inductor Construction:Shielded; DC Resistance Max:0.07ohm; Power Inductor Case:6.8mm x 6.8mm x 2.3mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:35MHz; Self Resonant Frequency Min:35MHz

CHOKE SMD 1000UH 0.16A; Product Range:WE-TPC Series; Inductance:1mH; RMS Current (Irms):160mA; Saturation Current (Isat):130mA; Inductor Construction:Shielded; DC Resistance Max:5ohm; Power Inductor Case:6.8mm x 6.8mm x 2.3mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:2MHz; Self Resonant Frequency Min:2MHz

CHOKE SMD 47UH 0.73A; Product Range:WE-TPC Series; Inductance:47µH; RMS Current (Irms):730mA; Saturation Current (Isat):620mA; Inductor Construction:Shielded; DC Resistance Max:0.28ohm; Power Inductor Case:6.8mm x 6.8mm x 2.3mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:12MHz; Self Resonant Frequency Min:12MHz

CHOKE SMD 1.5UH; Product Range:WE-TPC Series; Inductance:1.5µH; RMS Current (Irms):7.2A; Saturation Current (Isat):10A; Inductor Construction:Shielded; DC Resistance Max:7500µohm; Power Inductor Case:10mm x 10mm x 3.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:65MHz; Self Resonant Frequency Min:65MHz

CHOKE SMD 5UH; Product Range:WE-TPC Series; Inductance:5µH; RMS Current (Irms):4.9A; Saturation Current (Isat):5.5A; Inductor Construction:Shielded; DC Resistance Max:0.022ohm; Power Inductor Case:10mm x 10mm x 3.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:30MHz; Self Resonant Frequency Min:30MHz

CHOKE SMD 22UH; Product Range:WE-TPC Series; Inductance:22µH; RMS Current (Irms):2.5A; Saturation Current (Isat):2.3A; Inductor Construction:Shielded; DC Resistance Max:0.075ohm; Power Inductor Case:10mm x 10mm x 3.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Current Rating:2.5A; Inductor Type:Power; No. of Pins:2Pins; Self Resonant Frequency Min:12MHz

CHOKE SMD 47UH; Product Range:WE-TPC Series; Inductance:47µH; RMS Current (Irms):1.75A; Saturation Current (Isat):1.85A; Inductor Construction:Shielded; DC Resistance Max:0.16ohm; Power Inductor Case:10mm x 10mm x 3.8mm; Inductance Tolerance:± 30%; Packaging:Cut Tape; Inductor Type:Power; No. of Pins:2Pins; Resonant Frequency:8MHz; Self Resonant Frequency Min:8MHz

INDUCTOR SMD HIGH CURRENT 71.5NH; Product Range:WE-HCM Series; Inductance:72nH; RMS Current (Irms):30A; Saturation Current (Isat):60A; Inductor Construction:Shielded; DC Resistance Max:235µohm; Power Inductor Case:7.15mm x 7mm x 5mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Inductor Type:High Current; No. of Pins:2Pins; Resonant Frequency:155MHz; Self Resonant Frequency Min:155MHz

INDUCTOR SMD HIGH CURRENT 150NH; Product Range:WE-HCM Series; Inductance:150nH; RMS Current (Irms):30A; Saturation Current (Isat):32A; Inductor Construction:Shielded; DC Resistance Max:235µohm; Power Inductor Case:7.15mm x 7mm x 4.7mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Inductor Type:High Current; No. of Pins:2Pins; Resonant Frequency:75MHz; Self Resonant Frequency Min:75MHz

IN STOCK SHIP TODAY

INDUCTOR SMD HIGH CURRENT 3.3UH; Product Range:WE-HCI Series; Inductance:3.3µH; RMS Current (Irms):6.5A; Saturation Current (Isat):11A; Inductor Construction:Shielded; DC Resistance Max:0.0172ohm; Power Inductor Case:7mm x 6.9mm x 3.8mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Inductor Type:High Current; No. of Pins:2Pins; Resonant Frequency:43MHz; Self Resonant Frequency Min:43MHz

INDUCTOR SMD HIGH CURRENT 2.4UH; Product Range:WE-HCI Series; Inductance:3.3µH; RMS Current (Irms):12A; Saturation Current (Isat):15A; Inductor Construction:Shielded; DC Resistance Max:5900µohm; Power Inductor Case:10.5mm x 10.2mm x 4.7mm; Inductance Tolerance:± 20%; Packaging:Cut Tape; Inductor Type:High Current; No. of Pins:2Pins; Self Resonant Frequency Min:54MHz
